jbc TM10 User manual

TM10
ESD Earthing Plug
for EU Sockets
INSTRUCTION MANUAL

Packing List
The following items are included:
Manual ................................................. 1 unit
Ref. 0031820
This manual corresponds to the following reference:
TM10
Application
To equip an EPA (Electrostatic Protected Area) workplace, it can be used, among other items, an ESD
earthing plug.
These components help to protect static-sensitive components from electrostatic discharge by
dissipating charge from objects placed on their surface. This prevents sensitive components from being
damaged by electrostatic discharges.
ESD Earthing Plug ................................... 1 unit
For EU sockets
Features
The plug comes in yellow color and is equipped with
two ø10mm snap fasteners (female) as well as an M5
screw connection.
The electrical resistance is 106Ω at each connector. ø10mm Snap Fastener
M5 Screw Connection
This ESD earthing plug can be used at ESD protection
zones.
When connected accordingly, it discharges static
electricity from people or objects to prevent damage
by electrostatic discharges to electronic devices and
components.
2

* not included, sold separately
TMS or
TMB
Table Mat ESD
TM21
Earthing Cable
TM20
ESD Spiral
Earthing Cable
TM50
ESD Earthing Wristband
ø10mm
Snap Fastener
Connection
ø3mm
Snap Fastener
Connection
Eyelet
Connection
ø10mm
Snap Fastener
Connection
Earth Connection or
Grounded Common
Point
TM10
ESD
Earting Plug
Alternative
Connection
*
*
*
*
*
For proper function, plug the ESD grounding plug into an EU socket and connect the connectors
-using an ESD grounding cable- to the ESD table mat of the workplace to be protected.
The following matching accessories are sold separately: an ESD table mat, an ESD spriral earthing
cable, an ESD earthing wristband, and an ESD earthing cable.
Workplace Connection Example
* not included, sold separately
Earthing Plug Connection Example
Screw Connector to
Bananna Connector
Connection with
Snap Fastener
Screw Connector
to Eyelet
TM21*
Earthing Cable
TM20*
Spiral Earting Cable
TM50*
Earthing Wristband
TM10
Earthing Plug
TMS* or TMB*
ESD Table Mat
3
40 mm
50 mm
60 mm
80 mm
100 mm
130 mm 130 mm
para manuales - color gris
200 mm
300 mm

This product should not be thrown in the garbage.
In accordance with the European directive 2012/19/EU, electronic equipment at the end of its life must
be collected and returned to an authorized recycling facility.
Warranty
JBC’s 2 year warranty covers this equipment against
all manufacturing defects, including the replacement
of defective parts and labour.
Warranty does not cover product wear or misuse.
In order for the warranty to be valid, equipment must
be returned, postage paid, to the dealer where it was
purchased.
40 mm
50 mm
60 mm
80 mm
100 mm
130 mm 130 mm
para manuales - color gris
200 mm
300 mm
0031820-270923
TM10
ESD Earthing Plug
Ref.: TM10
- Socket: For EU socket
- Connections: ø10mm snap fasteners (2x) and M5 screw connector (1x)
- Color: Yellow
- Electrical resistance: 106Ω for each connector
- Total Net Weight: 35 g / 0.08 lb
- Package Dimensions/Weight: 86 x 57 x 158mm / 64 g
(L x W x H) 3.39 x 2.24 x 6.22in / 0.14 lb
Complies with CE standards.
ESD Safe.
