Jennison Entertainment Technologies BLIZZARD BLAST User manual

BLIZZARD BLAST SERVICE MANUAL
VERSION 0.5
Jennison Entertainment Technologies Corporation
822 South Nova Road •Daytona Beach, Florida 32114 •U.S.A.
Toll Free Number: 1-855-JET-GAME
Service Email: [email protected]
Phone Number: 1-386-255-1599
Fax Number: 1-386-255-1589
Information Email: [email protected]
www.JENNISONGAMES.com
For Additional Information or for an Electronic Copy of This Manual Visit Our Website
MANUFACTURED BY:

WARNING
All warnings will be marked in ORANGE boxes. Failure to
follow these warnings could lead to damage to the unit and or
personal property.
DANGER
All danger messages are marked in RED boxes. Failure to
adhere to these messages could result in personal injury or
injury to others.
Through out the use of this manual, certain areas require special attention for the
safety of the service personal. Please take note of the following notifications and
be certain to read the information contained within. Failure to follow the given
information could lead to personal injury or property damage. Follow all
instructions contained within this manual and do not make any modifications to
the game without first contacting Jennison Entertainment Technologies.
ATTENTION
Attention boxes are in BLUE. These messages are provided in
cases where service personal must follow directions provided
by J.E.T.
NOTICE
Notices are given in GREEN boxes. These messages are
provided for the operator's convenience.
CAUTION
Caution messages are marked in YELLOW boxes. Failure to
follow these caution messages could result in damaging the
unit.
SAFETY NOTIFICATIONS
Jennison Entertainment Technologies Blizzard Blast Service Manual Page 3

If you or any of your relatives have a history of seizures or epilepsy,
consult a doctor before playing.
A very small percentage of people may experience a seizure when exposed
to certain visual images, including flashing lights or patterns that may
appear in video games. Even people who have no history of seizures or
epilepsy may have an undiagnosed condition that can cause these
"photosensitive epileptic seizures" while watching video games.
These seizures may have a variety of symptoms, including
lightheadedness, altered vision, eye or face twitching, jerking or shaking of
arms or legs, disorientation, confusion, or momentary loss of awareness.
Seizures may also cause loss of consciousness or convulsions that can lead
to injury from falling down or striking nearby objects.
Immediately stop playing and consult a doctor if you experience any of
these symptoms. Parents should watch for or ask their children about the
above symptoms - children and teenagers are more likely than adults to
experience these seizures.
The risk of photosensitive epileptic seizures may be reduced by taking the
following precautions:
Play in a well-lit room
Do not play when you are drowsy or fatigued
EPILEPSY DANGER
EPILEPSY WARNING
Jennison Entertainment Technologies Blizzard Blast Service Manual Page 4

WARNING
BLIZZARD BLAST, CAUTIONS, & NOTICES
CAUTION
Only qualified service personal should service POWER PONG.
Contact J.E.T. first with any questions before replacing any
part.
WARNING
If the power cord is damaged - replace it with a new one. DO
NOT attempt to use a damaged or repaired power cord.
WARNING
Always plug the game into a grounded circuit and verify the
total voltage draw on the circuit does not exceed its capacity.
CAUTION
Use appropriate care when servicing the game and ensure
that all removed components are away from facility guests
and children.
Make sure that the 115/230 VAC selector switch is properly
selected on all power supplies for the correct line voltage at
the installation site.
WARNING
This unit is suitable for INDOOR use only. The game should
not be placed in damp environments or in areas within close
proximity to the ocean.
Jennison Entertainment Technologies Blizzard Blast Service Manual Page 6

The Federal Communications Commission requires that all amusement
machine devices used in commercial applications comply with guidelines
for the amount of interference the internal components produce.
BLIZZARD BLAST complies with this requirement and the following
statement is posted on all units.
This equipment has been tested and found to comply with the limits for a
Class “A” digital device, pursuant to Part 15 of the FCC rules. These limits are
designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment.
Canadian Emissions Statement
(According to Industry Canada Notice ICES-003, Issue 4)
This Class “A” digital apparatus meets all requirements of the
Canadian Interference-Causing Equipment Regulations.
Cet appareil numérique da la classe “A” respecte toutes les
exigences du Réglement sur le matériel brouilleur du Canada.
FCC COMPLIANCE
Jennison Entertainment Technologies Blizzard Blast Service Manual Page 7

With our unique testing equipment, Jennison Entertainment Technologies can test components from ANY
SUPPLIER from ANY COUNTRY where we source our parts. The tools we utilize allow us to spot check
suppliers who have also self declared their components to be compliant ensuring you and your guests
safety.
The RoHS Directive stands for "the restriction of the use of certain hazardous substances in electrical and
electronic equipment". This Directive bans the placing on the European Union market, new electrical and
electronic equipment containing more than agreed levels of lead, cadmium, mercury, hexavalent chromium,
polybrominated biphenyl (PBB) and polybrominated diphenyl ether (PBDE) flame retardants.
Jennison Entertainment Technologies has taken steps to comply with this directive while sourcing the parts
for all machines. If available to the industry, these certified components were used in the construction on
BLIZZARD BLAST.
As of January 2016, Jennison Entertainment Technologies has tested all components used in the
manufacturing of BLIZZARD BLAST. All components have been found to be within the standards set forth for
RoHS compliance by the European Union. Test reports are available and will be provided upon request.
To verify that your machine has RoHS Compliant parts, look for the following logo on the information sticker
on the back of all our units.
RoHS COMPLIANCE
Jennison Entertainment Technologies Blizzard Blast Service Manual Page 8

The chart below should be used to record an changes in the software and the reasons for the change. This
will allow you to track which software version is installed or allow another technician to service the unit and
quickly identify what has been changed since delivery.
BLIZZARD BLAST has been designed to include a software program where all game settings are easily
managed through the use of a simple dip switch changes Although the software is very simple to navigate,
we highly recommend reading the following programming section to fully understand how to make changes
to the software and how each change will affect the machine. Should you have any questions about
changing the programming, or need to make a change outside the capability of the current software, please
contact Jennison Entertainment directly.
SOFTWARE UPDATE RECORD
REASON FOR CHANGE
SOFTWARE VERSION
DATE
GAME SETTINGS & PROGRAM
INITIAL PROGRAM INSTALLED AT FACTORY
20151120
INITIAL
Jennison Entertainment Technologies Blizzard Blast Service Manual Page 23

8) Device should possess meters for "Coin In" and "Token/Ticket Out"
9) Device must not award cash prizes - only tickets, vouchers or tokens which may be redeemed for prizes within the
facility.
10) Device must not be capable of awarding a prize in excess of $10,000.00.
11) Device must not incorporate a reflexive outcome determination or auto-percentaging
STATE OF NEW JERSEY APPROVED SOFTWARE
4) Device must lockout after maximum wager per game is inserted, unless a discount is offered. The coin mechanism
in Power Pong will not accept more than $2.00.
5) Device must not escrow inserted credits for more than one game's play unless a discount is offered.
6) Device must award tickets, tokens or prizes immediately upon completion of the game, or offer player an option
to collect or accumulate winnings.
7) Device must not possess a "Knock-Off" mechanism.
To view the installed software version, locate the main IC
chip on the I/O board and view the label printed onto the IC.
In order to operate the game in the State of New Jersey - you
must only use this version of software.
2 0 1 6 0 1 1 0
The installed software version can be viewed at any time by
viewing the label on the main IC.
State of New Jersey Approved Software
Verifying the installed software version
New Jersey Game Software Version
12) Device must retain tickets or tokens owed upon power interruption
Under the rules and regulations governed by the State of New Jersey Legalized Games of Chance Control Commission, there
are certain requirements for amusement and redemption games. A certain version of software has been designed to allow
Blizzard Blast to be operated within the State of New Jersey. This version of the software complies with the following
requirements:
The above requirements are published here for your information and obtained from Eclipse Compliance Testing in
conjunction with the New Jersey Legalized Games of Chance Control Commission. In order to operate Power Pong within
the State of New Jersey - you must operate a version of the software which complies with the above requirements. Call
your local distributor to order this software before operating the game. The version of software which complies with
these requirements can be found below.
1) Maximum allowable wager per player dose not exceed $10.00 per game. In Blizzard Blast (20160110) the game
will not accept more than 4 coins on $1.00 Play or 8 coins on $2.00 Play.
2) Maximum allowable accumulation of inserted credits does not exceed $10.00. In Blizzard Blast (20160110) the
game will not accept more than 4 coins on $1.00 Play or 8 coins on $2.00 Play.
3) Device must lockout after $10.00 is inserted. Blizzard Blast will not accept more than $2.00 maximum.
Jennison Entertainment Technologies Blizzard Blast Service Manual Page 26

SEG # 1
6
10
12
6
10
SEG # 4
30
40
50
30
40
SEG # 3
18
20
18
20
18
SEG # 2
12
14
16
12
14
SEG # 1
8
10
8
10
8
USD $2.00 GAME PLAY - (SCORE STATE D)
BONUS
100
250
500
100
1000
SEG # 4
10
50
10
40
10
SEG # 3
20
10
20
10
30
SEG # 2
10
16
10
16
10
SEG # 1
6
10
8
6
10
USD $1.50 GAME PLAY - (SCORE STATE C)
BONUS
100
50
500
10
500
SEG # 4
30
10
50
10
70
SEG # 3
10
20
10
30
10
SEG # 2
16
8
16
8
16
SEG # 1
4
8
10
4
8
USD $1.00 GAME PLAY - (SCORE STATE B)
BONUS
70
10
250
20
500
SEG # 4
8
20
8
40
8
SEG # 3
20
4
10
4
20
SEG # 2
8
10
8
10
8
SEG # 2
SEG # 1
USD $0.50 GAME PLAY - (SCORE STATE A)
BONUS
50
10
100
10
500
ADJUSTING THE PAYOUT PERCENTAGE
NOTICE
This ticket payout table is for reference only. These numbers have been determined after considerable
testing in field locations. This chart assumes a ticket cost of USD 0.01 (one Penney) and a desired payout
of 30-35%
USD $0.25 GAME PLAY (NOT CURRENTY USED)
BONUS
SEG # 4
SEG # 3
Jennison Entertainment Technologies Blizzard Blast Service Manual Page 27

Score Group
Game Time
Coins, Credits,Tokens Required
This setting is to adjust the
number of coins or credits
required to start the game.
Operator can choose between 1
and 7 coin(s) or token(s) per game
OFF
OFF
GAME SETTINGS - DIP SWITCH SETTINGS (SWITCH # 1)
A
ON
ON
B
OFF
ON
C
ON
OFF
D
90
ON
OFF
OFF
100
OFF
OFF
OFF
75
OFF
ON
OFF
ON
45
OFF
OFF
ON
60
ON
ON
OFF
ON
OFF
FREE PLAY
OFF
OFF
OFF
30
ON
ON
ON
35
OFF
ON
ON
40
1
2
3
4
ON
OFF
ON
OFF
ON
ON
OFF
5
ON
ON
OFF
6
OFF
ON
OFF
SW11
SW12
SW13
SW14
SW15
SW16
SW17
SW18
SWITCH # 1
CONTENT
ITEM DESCRIPTION
ON
ON
OFF
ON
OFF
ON
7
ON
OFF
All game settings in Blizzard Blast can be programmed using the three dip switch banks on the I/O board. The switches are
Switch # 1 (SW1), Switch # 2 (SW2), and Switch # 3 (SW3). Reference the chart below to make program changes including
the number of coins required to start the game, the length of game play, and the score group options for SWITCH # 1
(SW1). To operate the program, move each switch to the ON or OFF position. Switches moved towards the word ON are
ON. Switches moved away from the ON towards the numbers are OFF.
Jennison Entertainment Technologies Blizzard Blast Service Manual Page 28

GAME SETTINGS - DIP SWITCH SETTINGS (SWITCH # 1 CONTINUED)
SW13
SW14
SW15
SW16
SW17
SW18
$0.50 GAME PLAY
$1.00 GAME PLAY
$1.50 GAME PLAY
$2.00 GAME PLAY
NOT CURRENTLY USED
ITEM DESCRIPTION
SCORE
STATE
SWITCH # 1 (EXPANDED)
SW11
SW12
C
NOT CURRENTLY USED
A
ON
ON
B
OFF
ON
ON
OFF
D
OFF
OFF
G
E
F
NOT CURRENTLY USED
Jennison Entertainment Technologies Blizzard Blast Service Manual Page 29

Handle Speed Frequency
Shake Time
Ticket Per Score
(THIS VALUE IS
DIVIDED BY THE TOTAL
AMOUNT OF TICKETS
WON. (FOR 2 POINT
TICKETS, SELECT
"DIVIDE BY 2"- IF 100
TICKETS ARE WON, 50
TICKETS WILL BE
DISPENSED)
ON
OFF
0.25 SECOND
OFF
OFF
OFF
OFF
0.35 SECOND
ON
ON
0.30 SECOND
OFF
ON
0.27 SECOND
3 + 1
OFF
ON
4 + 1
ON
OFF
5 + 1
NO PAY
OFF
OFF
OFF
2 + 1
ON
ON
DIVIDE BY 50
ON
OFF
OFF
DIVIDE BY 5
ON
OFF
ON
DIVIDE BY 10
OFF
OFF
ON
DIVIDE BY 30
OFF
ON
OFF
1
ON
ON
ON
ON
DIVIDE BY 2
OFF
ON
DIVIDE BY 20
ON
ON
OFF
ITEM DESCRIPTION
CONTENT
SWITCH # 2
SW21
SW22
SW23
SW24
SW25
SW26
SW27
SW28
All game settings in Blizzard Blast can be programmed using the three dip switch banks on the I/O board. The switches are
Switch # 1 (SW1), Switch # 2 (SW2), and Switch # 3 (SW3). Reference the chart below to make program changes including
the number of tickets per score, shake time, and the handle speed frequency for SWITCH # 2 (SW2). To operate the
program, move each switch to the ON or OFF position. Switches moved towards the word ON are ON. Switches moved
away from the ON towards the numbers are OFF.
GAME SETTINGS - DIP SWITCH SETTINGS (SWITCH # 2)
Jennison Entertainment Technologies Blizzard Blast Service Manual Page 30

OFF
2
Double Score
Coin Meter
Hit Test
Display
Coin Lock
Crash
Alarm
OFF
YES
ON
NO
NORMAL
ON
OFF
OFF
TEST
OFF
ON
ON
OFF
2 TIMES
ON
3 TIMES
OFF
SINGLE
ON
DOUBLE
OFF
GAME SETTINGS - DIP SWITCH SETTINGS (SWITCH # 3)
ITEM DESCRIPTION
CONTENT
SWITCH # 3
SW31
SW32
SW33
SW34
SW35
SW36
SW37
SW38
All game settings in Blizzard Blast can be programmed using the three dip switch banks on the I/O board. The switches are
Switch # 1 (SW1), Switch # 2 (SW2), and Switch # 3 (SW3). Reference the chart below to make program changes including
double score play, duel meters, and various testing options for SWITCH # 3 (SW3). To operate the program, move each
switch to the ON or OFF position. Switches moved towards the word ON are ON. Switches moved away from the ON
towards the numbers are OFF.
Jennison Entertainment Technologies Blizzard Blast Service Manual Page 31

17
COIN UP SIGNAL
BILL ACCEPTOR
TICKET RESET
TICKET SIGNAL # 1
1
2
3
4
MAIN BOARD INPUTS
19
6
BLIZZARD BUTTON # 1
20
21
16
30
25
26
27
8
LEFT HANDLE SENSOR
RIGHT HANDLE SENSOR
BLIZZARD BLAST - MAIN BOARD INPUT IC (74HC245N) CHART
IC
CONTENT
INPUT #
18
13
14
15
10
11
12
7
32
U08
U09
U10
U11
22
23
24
28
29
MIDDLE SENSOR
9
31
BLIZZARD BUTTON # 2
5
TICKET SIGNAL # 2
Jennison Entertainment Technologies Blizzard Blast Service Manual Page 32

The Blizzard Blast input/output board utilizes 5 input IC's to control all inputs used within the game. In
Blizzard Blast, only TWO of the FIVE IC's are used. You may use the THREE spare input IC's in U09, U11, &
U12 on the board in order to replace the other input IC's should one become corrupt.
BLIZZARD BLAST - MAIN BOARD INPUT IC (74HC245N) CHART
IC
INPUT #
CONTENT
U12
33
38
39
40
36
MAIN BOARD INPUTS - CONTINUED
37
34
35
Jennison Entertainment Technologies Blizzard Blast Service Manual Page 33

CLUTCH DRIVE # 2
RED LED FAN LIGHTS
GREEN LED FAN LIGHTS
BLUE LED FAN LIGHTS
17
18
19
20
21
22
23
24
MAIN BOARD OUTPUTS
BLIZZARD BLAST - MAIN BOARD IC (ULN2803) OUTPUT CHART
IC
OUTPUT #
CONTENT
U23
1
2
3
U23 IS NOT UTLIZED IN BLIZZARD BLAST.
THIS SPARE IC CAN BE USED IN U27 OR U29
TO RECITFY POTENTIAL ISSUES WITH THOSE
IC'S. IF YOU SWAP IC'S, BE SURE TO PUT
THE DEFECTIVE IC BACK INTO U23 BEFORE
POWERING THE UNIT ON. IF THIS FIXES
YOUR PROBLEM, BE SURE TO RECORD THAT
THE IC IN U23 IS NOW DEFECTIVE AND
CANNOT BE USED AGAIN IN ANOTHER
SOCKET
U27
U29
25
26
27
28
29
30
31
32
FAN DRIVE LIGHTS 1
FAN DRIVE LIGHTS 2
FAN DRIVE LIGHTS 3
FAN DRIVE LIGHTS 4
BLUE BLIZZARD BUTTON LIGHT
7
8
U25 IS NOT UTLIZED IN BLIZZARD BLAST.
THIS SPARE IC CAN BE USED IN U27 OR U29
TO RECITFY POTENTIAL ISSUES WITH THOSE
IC'S. IF YOU SWAP IC'S, BE SURE TO PUT
THE DEFECTIVE IC BACK INTO U25 BEFORE
POWERING THE UNIT ON. IF THIS FIXES
YOUR PROBLEM, BE SURE TO RECORD THAT
THE IC IN U25 IS NOW DEFECTIVE AND
CANNOT BE USED AGAIN IN ANOTHER
SOCKET
AMPLIFIER
RED BLIZZARD BUTTON LIGHT
CLUTCH DRIVE # 1
U25
9
4
5
6
14
15
16
11
12
13
10
Jennison Entertainment Technologies Blizzard Blast Service Manual Page 34

Q9 - Q16
41
42
43
44
45
46
47
48
MAIN BOARD OUTPUTS - CONTINUED
BLIZZARD BLAST - MAIN BOARD IC (ULN2803) OUTPUT CHART
IC
OUTPUT #
CONTENT
Q1-Q8
33
34
35
36
37
38
39
40
COIN COUNTER
TICKET COUNTER
TICKET DRIVE # 1
TICKET DRIVE # 2
COIN LOCK
SINGLE PLAYER SENSOR
DOUBLE PLAYER SENSOR
Jennison Entertainment Technologies Blizzard Blast Service Manual Page 35
