Jennison entertainment technologies Intermission User manual

OPERATOR’S MANUAL

VERSION 050509

Intermission™ is a registered trademark of Jennison Entertainment Technologies

and is registered with the United States Patent and Trademark Office.

United States and International Patents Pending.

Table of Contents

Safety, Certificates, & Compliance

Warnings, Cautions, & Notices………………………………………………………………………….05

FCC Compliance……………………………………………………………………………………….. 06

RoHS Compliance……………………………………………………………………………………….07

Installation

Electrical Requirements……………………………………………………………………………….....08

Dimensions………………………………………………………………………………………………08

Inspection……………………………………………………………………………………………...... 09

Application of Playfield Character Ticket Value Stickers………………………………………………10

Coin Comparator Setup………………………………………………………………………………….11

Glass Removal (or) Servicing……………………………………………………………………………13

Configuration & Testing

Changing Menu Options & Setup………………………………………………………………………. 14

Changing Ticket Values of Jetty, Kernel, & Peggy in Software……………………………………….. 15

Normal Program Settings Chart………………………………………………………………………….21

Normal Program Settings Chart - Settings Definitions…………….…………………………………….22

Grand Jackpot Combo Bonus – Dip Switch Settings……………………………………………………24

Linking Units Together – Individual Unit Dip Switch Settings…………………………………………25

Returning to Factory Defaults……………………………………………………………………………26

Test Mode……………………………………………………………………………………………..…27

Input Values……………………………………………………………………………………...28

Output Values……………………………………………………………………………………29

Table of Contents (Continued)

Receipt Frame Score State Values……………………………………………………………………….30

Maintenance & Troubleshooting

Service or Parts Inquiry……………………………………………………………………………….... 31

Quick Troubleshooting Guide…………………………………………………………………………...32

Suggested Preventive Maintenance Schedule………………………………………………………….. 37

Wiring Schematics

Wiring Diagram………………………………………………………………………………………….38

Wiring Diagram (Header)……………………………………………………………………………….39

Technician Notes

Technical notes…………………………………………………………………………………………..40

Warranty Information

Warranty Information…………………………………………………………………………………... 41

Parts List

Parts List………………………………………………………………………………………………TBD

Warnings, Cautions, & Notices Explanations

Throughout this manual the following boxes will be utilized to stress importance in areas that require special

attention.

WARNING: All warnings will be marked in RED boxes indicating that potential injury could occur if

directions are not followed. The operator should STOP and READ all applicable instructions.

CAUTION: Caution messages will be indicated in YELLOW boxes. These messages are to indicate that

extreme caution should be exercised while following the appropriate action.

NOTICE: Notices are given in GREEN boxes. These messages are provided for the operator’s

convenience.

Warnings, Cautions, & Notices

WARNING: TRANSPORTING THE GAME.

This unit contains glass and fragile electronic components. Use appropriet care when transporting. Use

extreme caution when removing the top cabinet glass and ensure it is placed in an area away from

children while servicing this game.

WARNING: DISCONNECT POWER.

Always turn power OFF and unplug the power cable before servicing unless otherwise instructed.

Installing components with the power switched ON can damage the components and void warranty.

WARNING: CHECK BOTH POWER SELECTORS, FAN, AND LAMP.

Set the 115/230 VAC selector switch on both power supplies for the correct line voltage on the

installation site. Verify that the rear cabinet fan and the rear flourescent lamps are rated for the proper

line voltage.

WARNING: REMOVING UNIT FROM CRATE AND PALLET.

Please use extreme caution when removing this unit from its crate and pallet. A minimum of 2-4 people

should be utilized to lift the unit off the pallet.

WARNING: REMOVING GLASS FROM CABINET.

Failure to follow the proper instructions when removing the glass from the cabinet could result in

injury to persons and (or) damage to machine. Follow all instructions when removing the glass and

always have two people present to lift. NEVER lift the glass by yourself.

FCC Compliance

The Federal Communications Commission requires that all amusement machine devices used in commercial

applications comply with guidelines for the amount of interference the internal components produce.

Intermission complies with this requirement and the following statement is posted on all units.

Canadian Emissions Statement

(According to Industry Canada Notice ICES-003, Issue 4)

This equipment has been tested and found to comply with the limits for a

Class “A” digital device, pursuant to Part 15 of the FCC rules. These limits

are designed to provide reasonable protection against harmful interference

when the equipment is operated in a commercial environment.

This Class “A” digital apparatus meets all requirements of the

Canadian Interference-Causing Equipment Regulations.

Cet appareil numérique da la classe “A” respecte toutes les

exigences du Réglement sur le matériel brouilleur du Canada.

RoHS Compliance

The RoHS Directive stands for "the restriction of the use of certain hazardous substances in electrical and

electronic equipment". This Directive bans the placing on the European Union market, new electrical and

electronic equipment containing more than agreed levels of lead, cadmium, mercury, hexavalent chromium,

polybrominated biphenyl (PBB) and polybrominated diphenyl ether (PBDE) flame retardants.

Jennison Entertainment Technologies has taken steps to comply with this directive while sourcing the parts for

all machines. If available to the industry, these certified components were used in the construction on our

games.

As of January 2009, Jennison Entertainment Technologies has tested all components used in the manufacturing

of Intermission™. All components have been found to be within the standards set forth for RoHS compliance

by the European Union. Test reports are available and will be provided upon request.

To verify that your machine has RoHS Compliant parts, look for the following logo on the information sticker

on the back of all our units.

Electrical Requirements & Cabinet Dimensions

Electrical Requirements:

Electrical Requirements

Volts Hertz Amps

Domestic Power Requirement 120 VAC 60 Hz 2.5 Amps (Ma )

Foreign Power Requirement 240 VAC 50 Hz 1.3 Amps (Ma )

Dimensions:

Dimensions

Length Width Height Weight

Inches MM Inches MM Inches MM Pounds KG

Shipping Dimensions 49 1230 31 770 76 1920 450 190

Actual Cabinet Dimensions 48 1220 28 712 72 1829 400 180

WARNING: If you choose to convert your unit to a different Power Requirement than

what it was at time of delivery, you must change the Fluorescent Lighting and the Fan to

match the new voltage. You must also change the switch on both power supplies to the

other voltage. Please contact your distributor for the appropriate parts or for further

instructions.

Inspection & Installation

Please check the following after the game has been removed from its shipping crate and placed in a suitable

play or service area.

Make sure that the game cabinet is level. Adjust the casters as needed

1. Remove the cabinet keys from the coin comparator reject latch.

2. Open the front main cabinet door. Open the cash box and remove extra parts including the power cord

and spare parts.

3. Inspect the cabinet and any included parts for possible shipping damage.

a. Check the top cabinet glass for any signs of breakage

b. Check the cabinet backdoor

c. Check cabinet graphics

4. Open the rear cabinet door and verify that all connectors are secure and that the bottom of the cabinet is

free of loose objects, which may have possibly come loose during shipping. This includes the

fluorescent light assembly. Check to make sure that all bulbs are secure and did not come out of their

assembly.

WARNING: Use extreme care when moving or servicing the game cabinet. Do not plug the game into a

power outlet until you have read this entire operation manual.

WARNING: Use extreme caution when removing the machine from the pallet. Unit is very heavy. J.E.T

recommends that you have a least 3 personal available to remove the game from the cabinet and lower

it to the ground. DO NOT ATTEMPT TO PUSH THE UNIT OFF THE PALLET. CASTORS ARE

SECURED INTO A RECESSED AREA. WE SUGGEST LIFTING THE UNIT UP AND THEN

REMOVING THE PALLET FROM BELOW.

Installing (or) Applying the Bonus Playfield Character Ticket Values

Jennison Entertainment Technologies provides 1 set of stickers for the bonus playfield in all Intermission units.

These stickers are designed so that the operator can easily change or modify the ticket values on all pop-up

characters on the playfield. The program has been designed so that the operator can choose any value from 1 to

100 as the value for each character pop-up. We have included a set of commonly used numbers and have

provided a chart to guide you on payout.

1. Locate the unit keys and open the side access windows on the left and right side of the game. NOTE:

Although it is easy to access the character pop-ups through the side access windows – you can also

remove the top window to have more access to the pop-up displays.

2. Decide what values you would like to set each character frame to have. NOTE: You can only select

three different values as each character pair is the same. J.E.T. suggests that the lower number should

start with the Peggy assembly – but it doesn’t matter. All characters could have the same value if you

choose. Record your initial setting below here for easy reference in the future.

Peggy: _________________

Kernel: _________________

Jetty: ___________________

3. Locate the provided stickers and gently peel off the selected value and attach to the correct character.

NOTE: You may want to use a pair of scissors to cut the sticker to a smaller size. Firmly attach the

sticker to the character frame and ensure that all air bubbles are removed by pressing on all surface area

of the sticker. When properly attached – you should only barely recognize the sticker outline.

4. Repeat Step # 3 with each of the character frames until each one has your selected value.

5. You must now change the program to register the new ticket values. Please see “Changing the Bonus

Pop-Up Ticket Values” on the following page in order to set the program software to correctly payout

the chosen values.

Coin Comparator Setup

Jennison Entertainment Technologies (J.E.T.) has elected to install a coin comparator into Intermission in order

to facilitate ease of installation for different operators in different operations. Should you choose to use a

mechanical coin mechanism instead – please contact (J.E.T.) for the correct part number and mounting plate.

1. Insert key into the lock directly above the coin mechanism which is located on the napkin dispenser.

2. Slowly pull the coin mechanism towards you.(as shown in Figure # 1)

3. Pull the entire mechanism out of the napkin dispenser. Be careful of the electrical wires attached to the

mechanism. (Figure # 2)

4. Locate the slide mechanism and remove the plastic spacer from the spring loaded assembly. (Figure # 3)

5. Replace this spacer with the coin or token from your facility.

a. Make sure that the coin is set correctly or the unit may not accept coins

6. Insert the coin mechanism back into the napkin dispenser by installing the bottom first and then by

pushing the top back into place. (Figure # 4 & 5)

7. Lock the mechanism securely in place. The mechanism should not move when securely seated. (Figure

# 6)

8. With the unit POWERED ON, insert one of your coins into the coin comparator to test.

9. Coin(s) should easily be accepted and fall into the coin track.

Coin Comparator Setup (Continued)

Figure # 3:

Locate the comparator

mechanism. Replace the

plastic spacer token with the

coin of your choice.

Figure # 2:

Pull the mechanism out of

the napkin dispenser. Be

careful of the attached

electrical wires.

Figure # 1:

Insert key and pull the

entire coin mechanism

towards you at an angle as

shown.

Figure # 4:

Replace the mechanism

back into the napkin

dispenser by angling the

assembly so that the groove

fits into the unit as shown

Figure # 5:

Push the top portion of the

coin mechanism assembly

back into the napkin

dispenser.

Figure # 6:

Lock the assembly by

turning the key. Ensure that

the coin mechanism is

securely attached.

Cabinet Glass Removal

The Intermission cabinet was designed so that operators could access all internal components without much

difficulty. When servicing the inside playfield area, access should be gained primarily through the side access

panels. If it becomes necessary to remove the top cabinet glass, please do so with extreme caution!

Removal of the glass without following these directions COULD result in glass breakage and MAY result

in personal injury to you or your customers.

To remove the glass in order to access the inside playfield:

1. Remove the two acrylic tabs and screws located on the rear of the glass at the intersection of the

backboard. FAILURE TO REMOVE THESE TABS COULD RESULT IN THE GLASS

BREAKING. THESE TABS HOLD THE GLASS IN PLACE. IF YOU ATTEMPT TO REMOVE

THE GLASS WITHOUT REMOVING THESE TWO TABS, IT WILL PUT PRESSURE ON

THE WEAKEST PART OF THE GLASS AS IT IS BEING LIFTED UP.

2. Attach the glass vacuum hand-cup (provided) to the top of the glass. Make certain that the cam levers

are flipped into position and securely locked.

3. Two people are suggested when lifting the top glass off of the cabinet. Make certain that there are no

pieces of plexi-glass restricting the removal and ensure that the rear cabinet tabs have both been

removed. Each person should take a side and slowly lift the glass off the cabinet. One hand should be on

the glass hand-cup while the other should be on the glass. Lift the piece high enough so that it clears the

napkin dispenser and slowly place it onto a carpeted floor. Take care when placing the piece of glass on

the floor as it could slide if left unattended. Place the glass AWAY from any areas where children could

be present.

WARNING: TO PREVENT INJURY AND POSSIBLE GLASS BREAKAGE, PLEASE READ THIS

SECTION IN DETAIL AND FOLLOW ALL INSTRUCTIONS ON THE PROPER REMOVAL OF

GLASS.

WARNING: NOT FOLLOWING THE PROPER INSTRUCTIONS FOR GLASS REMOVAL

COULD RESULT IN DAMAGE TO THE GAME AND (OR) PHYSICAL INJURY.

CAUTION: TWO PEOPLE SHOULD BE PRSENT TO LIFT THE GLASS OFF OF THE CABINET

SETUP MODESETUP MODESETUP MODE

Changing Menu Options & Program Setup Information

Look for the Intermission™ Control

Panel located on the back of the door.

Intermission™ features a setup menu that allows operators the ability to quickly change program features.

Access to this menu allows the operator to quickly setup the machine to the locations requirements or to

modify various machine functions.

Press and hold the “SERVICE” button

for 3 seconds to enter the SETUP mode.

Open the front access door with the unit

powered ON.

SOFTWARE VERSIONSETUP MODESETUP MODE

Reading the Installed Software Version

1101 U._01

Example: 0010 is the context in the

picture to the right.

Example: F01 is the option number in the

picture to the right.

1. Press the “TEST” button to scroll

through the different menu items.

(NOTE: Pushing the button one time will

advance to the next menu option. The

option number can be viewed on the Cash

“TICKETS”. The numbers sta

The context values will be displayed on

the JACKPOT BONUS SEG display.

(NOTE: The default context value should

be displayed unless previously changed

by the operator. Any new context selected

by the operator will be retained unless

changed or unless the p

The Installed Software version will be

shown on the seg displays for a few

seconds.

9) Test Mode - t01 (Input)

TEST MODE TEST MODE SETUP MODE

While in the SETUP MODE, Push the

SERVICE button to enter into TEST

MODE.

NOTE: Youmust already be in the

SETUP mode to enter the TEST mode.

Pushing the "TEST" button while in the

SETUP mode only increases the menu

option.

Push the “INCREASE / DECREASE”

buttons located on the control panel to

change the context values.

A) Press the INCREASE button to

INCREASE the context.

B) Press the DECREASE button to

DECREASE the context.

Allows the operator to test all inputs.

Please refer to the Input chart.

10) Test Mode - t02 (Output)

11) Test Mode - t03 (Music)

12) Test Mode - t04 (Auto Test)

13) Exiting Setup - Return to Game Play

TEST MODE TEST MODE TEST MODEEXITING TEST MODE

Push the SERVICE button to EXIT the

TEST MODE and return to game play.

The software version will then be

displayed on the back board and the

machine will restart.

Allows the operator to test to make sure

all sounds are properly installed in the

software and are not corrupted.

Push the TEST button to enter the

AUTO TEST sequence. The software

will automatically run a test of all

functions. This will keep reating until you

Allows the operator to test all outputs.

Please refer to the Output chart.

JETTY

- Changing the Ticket Value of Jetty

C) Select the value of your choice.

Changing Ticket Values of Jetty, Kernel, & Peggy in the Software

Intermission™ features a setup menu that allows operators the ability to quickly change the ticket values for

Jetty, Kernel, and Peggy. After the operator has replaced the ticket value stickers on each character pop-up -

SETUP MODE

Push the TEST button to scroll through the different

mode options.

Continue scrolling to F08. Make sure that F08 is

displayed in the Tickets Owed SEG display. The

context that is currently programmed will be shown

on the Jackpot Bonus SEG display.

With the unit powered ON, push the SERVICE

button for 3 seconds to enter SETUP mode.

Open the front access door. Look for the

Intermission™ Control Panel located on the back of

the door.

Push the “INCREASE / DECREASE” buttons

located on the control panel to change the context

values.

A) Press the INCREASE button to INCREASE the

context.

JETTY VALUES

B) Press the DECREASE button to DECREASE

the context.

JETTY VALUES

KERNEL

- Changing the Ticket Value of Kernel

C) Select the value of your choice.

PEGGY

- Changing the Ticket Value of Peggy

KERNEL VALUES

PEGGY VALUES

Continue scrolling to F09. Make sure that F09 is

displayed in the Tickets Owed SEG display. The

context that is currently programmed will be shown

on the Jackpot Bonus SEG display.

KERNEL VALUES

Continue scrolling to F10. Make sure that F10 is

displayed in the Tickets Owed SEG display. The

context that is currently programmed will be shown

on the Jackpot Bonus SEG display.

Push the “INCREASE / DECREASE” buttons

located on the control panel to change the context

values.

A) Press the INCREASE button to INCREASE the

context.

B) Press the DECREASE button to DECREASE

the context.

C) Select the value of your choice.

10)

11)

12)

SERVICE MODE

Once you have selected all values and wish to make

no further changes to the software program. Push the

SERVICE button once for 3 Seconds to exit the

Push the SERVICE button one final time for 3

Seconds to EXIT TEST mode and return to normal

game operation.

SERVICE MODE TEST MODE

The machine will now be in TEST mode and the

displays will look like the picture to the right.

Push the “INCREASE / DECREASE” buttons

located on the control panel to change the context

values.

A) Press the INCREASE button to INCREASE the

context.

B) Press the DECREASE button to DECREASE

the context.

PEGGY VALUES

Table of contents

Other Jennison Entertainment Technologies Arcade Game Machine manuals
