Universal Space Pirate's Hook User manual

Operation Manual
www.universal-space.com

Pirate’s Hook 4p Manual
1
Non-technical personnel who do not have technical knowledge and
Expertise should refrain from performing such work that this manual
require or perform tasks which are not explained in this manual.
Failing to comply can cause severe accidents such as electric shock or
other serious injuries. All repairs must be performed to original
manufacturer specifications.
WARNING: To reduce the risk of fire, electric shock or personal injury,
unplug or disconnect the machine from the power supply before
servicing.
CONTENT
Important Safety Instructions………………………………………….………………………….……2
1. SPECIFICATIONS……………………………………………………………………….………………...4
2. PACKAGE CONTENTS……………………………………………………………………………….….5
3. PART NAMES…………………………………………………………………………......................…6
4. SET UP & INSTALLATION………………………………………………………………………….….7
5. HOW TO PLAY……………………………………………………………..……………………….……10
6. GAME OPTION………………………………………………………..…………………………………11
7. ERROR MESSAGE AND RECOVERY…………………………………………………….………16
8. MAINTENANCE, INSPECTION………………………………………………………………….….17
9. OVERALL CONSTRUCTION…………………………………………………………..……………..18

Pirate’s Hook 4p Manual
2
Thank you for purchasing Pirate’s Hook from Universal Space. We hope you
enjoy the product.
This manual contains valuable information about how to operate and maintain your game
machine properly and safely. It is intended for the owner and/or personnel in charge of
product operation. Carefully read and understand the instructions.
If you need any help during installation and setup please utilize this manual and
troubleshooting guide. If the product fails to function properly, non-technical personnel should
under no circumstance attempt to service the machine. Contact your distributor or
manufacturer for help.
Before use, please read IMPORTANT SAFETY INSTRUCTIONS.
IMPORTANT SAFETY INSTRUCTIONS
To ensure the safe usage of this product, carefully read and
understand these instructions before operating your game.
Save these instructions for future reference.
Use this product only as described in this manual. Other uses not recommended may cause
fire, electric shock or personal injury. Unplug the game from the outlet when not in use, when
moving from one location to another, and before cleaning/servicing.
Explanations which require special attention are indicated by signs of warning. Depending on
the potential hazardous degree, the terms: NOTE, NOTICE, and WARNING are used.
NOTE: A NOTE indicates useful hints or information about product usage.
NOTICE: A NOTICE indicates potential damage to product and how to avoid the problem.
WARNING: A WARNING indicates a potential for product damage or serious personal Injury.
It is important to understand the meaning of the following HAZARD SIGNS before continuing:
High Voltage and Shock Hazard:
High voltage can cause electric shock.
Turn off/unplug power before servicing.
High Temperature Hazard:
This part may cause scalding.
Do not touch. Surface may be hot.
No Touching Hazard:
This part may be hot or can cause electric shock.
Do not touch.

Pirate’s Hook 4p Manual
3
Use the following safety guidelines to help ensure your own personal safety and to help
protect your equipment and surrounding environment from potential damage.
This product is an indoor game machine. Do not install outdoors.
Avoid installing in the following places to prevent fire, electric shock, injury and/or
machine malfunctioning:
 Places subject to rain/moisture, or places subject to high humidity.
 Places subject to direct sunlight, or places subject to extremely hot or cold
temperatures to ensure that it is used within the specified operating range.
 Places where inflammable gas may be present or in the vicinity of highly
inflammable/volatile chemicals or items that can easily catch fire
 On unstable or sloped surfaces. The machine may topple or cause unforeseen
accidents.
 Vicinity of fire exits, fire extinguishers etc that may block/prevent safety measures
IMPORTANT NOTE:
ALL REPAIRS MUST BE DONE TO ORIGINAL MANUFACTURER SPECIFICATIONS.
FAILURE TO DO SO VOID ALL WARRANTIES AND OPERATOR ASSUMES ALL
RISKS.
Note: The contents of this manual may be updated without notice.

Pirate’s Hook 4p Manual
4
1. SPECIFICATIONS
Rated power supply: AC220-240V 50/60Hz
Min. Power consumption: 210W
Max. Power consumption：380W
Dimensions： W2707×D1074×H2043(mm)
Weight： Approximately 380kg
NOTICE: After turning off the game, please wait at least 1 minute before
restarting again.
Note: Game parameters are subject to change without notice.
NOTICE: After turning off the game, please wait at least 1 minute before
restarting again.

Pirate’s Hook 4p Manual
5
2. PACKAGE CONTENTS
Open the package and make sure all the items are included:
 1 x Body Assembly
 Following accessories
NO.
Part number Code Name SPEC. Qty
Illustration
1 P113-450-000
23301000001
Power
cord
10A/250V
1.8m 1
2 P113-740-000
41460837083
Manual Chinese 1
3 P113-451-000
25300171002
Key 171 2
4 P113-452-000
25300172002
key 171B 2
5 P113-453-000
41300000004
Memory
stick 4G 1
6 P113-446-000
21901000013
Fuse Φ5×20mm T10A
250VAC 1
If any items are found to be missing, please contact your sales representative
for help immediately.
NOTE: Part models are subject to change without notice.

Pirate’s Hook 4p Manual
6
3. PART NAME
Marquee
Monitor
Control panel
Fishing
mech
.
Cabinet
Stool assembly
Ticket payout Coin door

Pirate’s Hook 4p Manual
7
4. SET UP & INSTALLATION
This product is an indoor game machine. Do not install outdoors.
 Refer to IMPORTANT SAFETY INSTRUCTIONS (Pg. 2) for places to avoid
 Place the unit on a dry level surface
 Ventilation openings in the back of the unit must not be obstructed by objects or by wall.
4.1 Play Zone
This machine requires space for playing and for maintenance as shown below.
Leave space around the game upon installation:
Length: 3.7M
Width: 1.6M
Play Zone
250

Pirate’s Hook 4p Manual
8
4.2 Level Adjustment
Install this machine on a flat surface. Adjust levers to lift casters off the ground to level the
game. If the game is installed on an unsuitable floor, it could cause game malfunction.
To secure the game, adjust the Leveler down until it touches the floor, lifting the casters off
the ground by 5mm. Repeat the same for all levelers.
4.3 Transporting the Game
If you need to move the game, adjust the levelers back to an “up” position so the casters
touch the ground.
NOTICE
 Be careful not to damage the machine during transport.
 The machine should be handled with care when bringing it down from a higher level.
 Always unplug the game before moving.
 Keep the machine in upright position during transport.
 For longer distance transport, package the game properly to prevent damages
Leveler
Caster
About 5 mm
Move
Fix
Make sure the machine is level with the ground and all the
adjustable legs should stick to the floor closely.
NOTICE
Leveler Caster
Move
Fix

Pirate’s Hook 4p Manual
9
4.4 Connecting Power
WARNING: Check the voltage rating before you connect the equipment to
an electrical outlet to ensure that the required voltage and frequency match the
available power source. Please refer the label of the machine.
◎ Do not plug the equipment power cables into an electrical outlet if the power cable is
damaged.
◎ Avoid putting many loads on one electrical outlet as it could generate heat and fire
resulting from overload.
◎ Connect the grounding conductor to the earth terminal (GND):
WARNING
Ensure no heavy objects rest on the power cord. Check to make sure the game cabinet does
not sit on the power cord as this could damage the cord and become hazardous.
To disconnect the game, grip the plug and pull it from the wall outlet. Never pull by the cord.
To prevent electric shock, do not touch the power plug when hand is wet.
Ensure that nothing rests on the power cord and that it is not located where it can be stepped
on or tripped over.
Power socket
Power outlet
Power plug
Power cord
Power plug

Pirate’s Hook 4p Manual
10
5. HOW TO PLAY
5.1 Game Interface
5.2 How To Play
The machine provides for 4 players at the same time.
1. Insert coin(s).
2. aim for your target, press the button to lower the hook.
3. Rotate the handles to reel in the fish.
4. Catch as many fishes as possible within the time limit. Junk Items= No Tickets.
5. Catch the Lobster King to win the MEGA BONUS!
Play time
Current tickets
Current coins
Main play zone

Pirate’s Hook 4p Manual
11
6. GAME OPTIONS
6.1 Testing Button Distribution:
You can see the testing button after you open the coin
door below orange fishing mechanism. Press test
button and enter Menu adjustment options.
6.2 Main Menu Options:
Main Menu
Game Mode
Input Test
Output Test
Game Reset
Language
Date/Time Setting
Host configuration
Bookkeeping
Daily Record
Exit& Without Save
Exit& Save
6.2.1 Game mode
Name Option Description
Free Play ON/OFF Turn on/off the free play mode.
Ticket Out ON/OFF Turn on/off payout tickets.
Coins per Round 1-10 Coin needed to insert for one game.
Demo Music ON/OFF Turn on/off the demo music.
Save Coins ON/OFF Whether memorize inserted coins after
power off.
Volume 0-10 0 is mute, 10 is max.
Fixed Ticket 0-100 Fixed ticket setting. “0” is fixed ticket
off.
Lobster king
appears every 1-15(seconds) The frequency lobster appears
Ticket/Point Ticket/Point Award is given as ticket or points.
Average Ticket Out
8-100 Ticket payout setting. It is invalid when
fixed ticket ON or point mode ON.
Target Tickets Please refer to 6.2.1.1
Target Point
Setting Please refer to 6.2.1.2
T
est button

Pirate’s Hook 4p Manual
12
Name Option Description
Score Board Please refer to 6.2.1.3
Game Difficulty 1-4 1 is the easiest, 4 is the hardest.
Auto Play Game 5-20 seconds Time for player to play before auto play
Game Duration 10,20,30,40,50,60,70,80,90
seconds Play time setting
Resistance Setting
Please refer to 6.2.1.4
Fish Score Display
ON/OFF Whether to display score on each fish
Ticket Owed Mode
Continue to play/call
attendant
“call attendant”: game is stop until the
game is reset.
“Continue to play”: game is continue to
play when ticket is owed.
Angler Bonus 1000 Tickets awarded in Angler Bonus
Angler Bonus Need
Points 1100 Points needed to gain angler bonus
Comp bonus OFF Whether to combat with other players
Back Back to the main menu
6.2.1.1 Target Tickets:
Note: When Fixed Ticket is 0 and target is defined as Ticket, Lobster Mega Bonus can be
manual adjusted. The rest of the targets tickets are adjusted automatically base on the play
time, difficulty and average payout settings.
Target Image Ticket
SM fish 0-100 ticket
M fish 0-100 ticket
LG fish 0-200 ticket
Junk 0-10 ticket
Shark 0-500 ticket
Octopus 0-500 ticket
Lobster Mega Bonus 0-2000 ticket

Pirate’s Hook 4p Manual
13
6.2.1.2 Target Point Setting:
Note: When Fixed Ticket is 0 and target is defined as Ticket, Lobster Mega Bonus can be
manual adjusted.The rest of the targets tickets are adjusted automatically base on the play
time, difficulty and average payout settings.
6.2.1.3 Score Board:
Target Ticket Adjustment Range
SM fish 0-100 point
M fish 0-100 point
LG fish 0-200 point
Junk 0-10 point
Target Ticket Adjustment Range
Shark 0-500 point
Octopus 0-500 point
Lobster Mega Bonus
0-2000 point
Point Range Setting Range
0-4 PointGetTickets
1,2,3,4,5,6,7,
8,9,10,15,20,
25,30,40,50,6
0,70,80,90,10
0.
5-100 PointGetTickets
101-200 PointGetTickets
201-350 PointGetTickets
351-500 PointGetTickets
500-1000 PointGetTickets
1001-2000 PointGetTickets
Target Range
Small Fishes Resistance
0-7(default 0)
Middle Fishes Resistance
0-7(default 1)
Big Fishes Resistance 0-7(default 2)
Note: This item is available to adjust when
Target is defined as Points. When Fixed Ticket
is set to more than 0, this item is invalid.
6.2.1.4 Resistance Setting
:
Note: Targets in row 0,1,2,5 are
considered as Small Fishes. Targets in
row 3 and 4 are considered as Middle
Fishes. Targets in row 6 are considered
as Big fishes. Resistance is increased
from 0 to 7.

Pirate’s Hook 4p Manual
14
6.2.2 Input Test
Input test Output test
Player1 Resistance 0-7
Player2 Resistance 0-7
Player3 Resistance 0-7
Player4 Resistance 0-7
Player1 vibration ON/OFF
Player2 vibration ON/OFF
Player3 vibration ON/OFF
Player4 vibration ON/OFF
Player1 out of ticket light ON/OFF
Player2 out of ticket light ON/OFF
Player3 out of ticket light ON/OFF
Player4 out of ticket light ON/OFF
Player1 lower hook light ON/OFF
Player2 lower hook light ON/OFF
Player3 lower hook light ON/OFF
Player4 lower hook light ON/OFF
Player1 Ticket Out ON/OFF
Player2 Ticket Out ON/OFF
Player3 Ticket Out ON/OFF
Player4 Ticket Out ON/OFF
Player1 Multi Face light
ON/OFF
Player2 Multi Face light
ON/OFF
Player3 Multi Face light ON/OFF
Player4 Multi Face light ON/OFF
Lattice Display ON/OFF
Digital Display 0000-9999
CoinMech 1
CoinMech 2
CoinMech 3
CoinMech 4
CoinMech 5
CoinMech 6
CoinMech 7
CoinMech 8
Player1 Reel In
Player2 Reel In
Player3 Reel In
Player4 Reel In
Player1 Lower Hook
Player2 Lower Hook
Player3 Lower Hook
Player4 Lower Hook
Multi Face Off 1
Multi Face Off 2
Multi Face Off 3
Multi Face Off 4
Free Play 1, 2
Free Play 3, 4
Repair
BACK
ON/OFF
ON/OFF
ON/OFF
ON/OFF
ON/OFF
ON/OFF
ON/OFF
ON/OFF
ON/OFF
ON/OFF
ON/OFF
ON/OFF
ON/OFF
ON/OFF
ON/OFF
ON/OFF
ON/OFF
ON/OFF
ON/OFF
ON/OFF
ON/OFF
ON/OFF
ON/OFF
Mega bonus light
ON/OFF
BACK
6.2.7 Daily Record:
Game Reset
Reset Game Setting
Delete All Record
Clear Tickets
Back
aDte/Time Setting
Year 2012
Month 2
Date 13
Hour(24) 13
Minute 25
Back & apply
Back
Daily Record
Date
2012-02-04
Weekday
SAT
Run Time
00:01
Coins
3
Tickets
15
Payout
5.00
Reset
6.2.6 Bookkeeping
Bookkeeping
Player coin out tickets in payout
1 1 5 5.00
2 2 10 5.00
Reset
back
6.2.5 Date/Time setting
6.2.4 Game Reset

Pirate’s Hook 4p Manual
15
7. ERROR MESSAGE AND RECOVERY
7.1 Error Message
Symptom: Screen displays message “Communication ERROR” (there is communication
problem with the game)
Possible Causes & Fixes:
 Communication data wire is damaged  Replace the data wire.
 SCM is not working  Ask your technician to check and repair
 PC COM port has been used  Ask your technician to check and repair
Symptom: Screen displays ““PLEASE CALL ATTENDENT”, “TICKET ERROR” (there is problem in
the ticket payout function)
Possible Causes & Fixes:
No tickets in the game  Replenish tickets and then press the TICKET RESET button.
Ticket dispenser is damaged  Replace with a new ticket dispenser.
Faulty connection  Ask the technician to check and repair.
7.2 System Recovery Operation
1. Turn off the game. Insert the memory stick into the USB port at the back of the computer.
2. Restart PC to enter the system recovery screen as shown.
3. The game will automatically start recovery which will take last about 5 minutes. Please
wait until process is complete.
4. Once system recovery is finished (as shown below), remove the USB flash drive from the
computer and turn off the PC. Wait at least 30 seconds before restarting the PC.
WARNING: the USB flash drive should only be used to fix software errors. Using it for
other purposes may cause unexpected results and damages.

Pirate’s Hook 4p Manual
16
8. MAINTENANCE & INSPECTION
8.1 Safety Check
Check the points listed before operating the machine. These checks are necessary for safe
machine operation:
1. Try to run the game before operation each day.
2. Conduct monthly routine checks of game components ensure good working condition
3. Check the machine regularly for dust and clean when necessary.
Note: Parts and components require preventative maintenance to be kept running smoothly
8.2 Handling Precautions
When installing or inspecting the machine, be very careful of the following points and pay
attention to ensure that the player can enjoy the game safely.
Non-compliance with the following points or inappropriate handling running counter to
the cautionary matters herein stated can cause personal injury or damage to the machine
• Before servicing the machine, be sure to turn power off. Servicing without turning the
power off can cause electric shock or short circuit.
• To avoid electric shock or short circuit, do not plug then unplug the power quickly
• Do not expose power cords and earth wires, these are susceptible to damage.
• Damaged cords and wires can cause electric shock or short circuit and should be
replaced immediately.
• When or after installing the product, avoid pulling the power cord to prevent
unnecessary wear and tear. Use the power button to disconnect power.
• In case the power cord is damaged, ask for replacement through where the product was
purchased from or replace locally. Continued usage of damaged cord can cause fire,
electric shock or leakage.
• Perform grounding appropriately. Inappropriate grounding can cause electric shock.
• Use fuses that meet specified rating. Fuses exceeding can cause an electric shock.
• Should a problem occur, turn off the power immediately and stop operating the machine.
Unplug the power cord of the service outlet. Operating the machine without correcting the
problem may cause a fire or injuries.
• Insert the power plug securely into the outlet. Poor contact may cause overheating,
resulting in fire or burns.
• To ensure the warning labels attached on the machine are visible and legible, install the
machine in a well-lit location, and keep the labels clean at all times. Make sure the labels
are not hidden behind other game machines.
WARNING

Pirate’s Hook 4p Manual
17
9. OVERALL CONSTRUCTION
9.1 Wooden Part Assembly

Pirate’s Hook 4p Manual
18
No.
Part No. Draw No. Name Material Qty
1 P113-001-000
29941122S001A
Wooden frame Assembly 1
2 P113-103-000
20241122S021 Hinge plate Metal plateδ1.5 2
3 P113-104-000
20241122S020 Light bar mounted plate Metal plateδ0.8 2
4 P113-105-000
20241122S019 Button light mounted plate
Metal plateδ1.0 4
5 P113-106-000
20241122S001 Case lock assembly plate Q235 δ1.5 black 4
6 P113-107-000
20241122S002 Base metal strip Q235 δ1.2 blue 2
7 P113-108-000
20241122S003 Air spring mounted plate 1
Metal plateδ2.0 4
8 P113-109-000
20241122S004 Base reinforced strip Q235 δ1.2 blue 2
9 P113-111-000
20241122S006
Power connecter
fixed
plate
Metal plateδ1.0 1
10
P113-112-000
20241122S007 Side marquee plate Q235 δ1.5 blue 4
11
P113-113-000
20241122S008 Side marquee cover plate Q235 δ1.0 blue 4
12
P113-114-000
20241122S009 Limit SW base Metal plateδ1.5 2
13
P113-115-000
20241122S010 Dongle bracket Metal plateδ1.2 1
14
P113-601-000
20641122S001 Side marquee plastic
Transparent plastic
δ3.0 white
4
15
P113-602-000
29941122S015 L side plastic Transparent plastic
2
16
P113-603-000
29941122S016 R side plastic Transparent plastic
2
17
P113-408-000
25102000001 Stainless steel case lock C124
4
18
P113-101-000
26000012000 Anti-vibration screw A zinc
4
19
P113-903-000
20341122S001 Bottom board plywood
1
20
P113-904-000
20341122S002
Upper board MDF blue JQ11038 2
21
P113-905-000
20341122S003
L lower board MDF blue JQ11038 1
22
P113-906-000
20341122S004
R lower board MDF blue JQ11038 1
23
P113-907-000
20341122S005
Mid board MDF blue JQ11038 1
24
P113-908-000
20341122S006
Front board MDF yellow JQ11067 2
25
P113-909-000
20341122S007
Sided L marquee
supported board
MDF blue JQ11038 2
26
P113-910-000
20341122S008
Sided R marquee
supported board
MDF blue JQ11038 2
27
P113-911-000
20341122S009
Frame supported bracket MDF blue JQ11038 2
28
P113-912-000
20341122S010 door frame MDF blue JQ11038 6
29
P113-913-000
20341122S011 Sided door board MDF blue JQ11038 2
30
P113-914-000
20341122S012 Mid partition MDF blue JQ11038 1
31
P113-915-000
20341122S013
top board
MDF blue JQ11038 1
32
P113-916-000
20341122S014
Sided board L supported
board
MDF blue JQ11038 2
33
P113-917-000
20341122S015
Sided board R supported
board
MDF blue JQ11038 2
34
P113-918-000
20341122S016 computer partition MDF blue JQ11038 1

Pirate’s Hook 4p Manual
19
9.2 Marquee Assembly
No.
Part No. Draw No. Name Material Qty
1
P113-002-000
29941122S002A
Marquee frame Assembly 1
2
P113-120-000
20241122S018
Display board fixed plate1 Metal plateδ1.0 2
3
P113-121-000
20241122S013
Display board fixed plate2 Metal plateδ1.0 2
4
P113-122-000
20241122S014
Dot matrix fixed plate Metal plateδ1.0 8
5
P113-123-000
20241122S015
Dot matrix mounted plate Metal plateδ1.0 8
6
P113-124-000
20241122S016
Marquee metal strip Q235 δ1.0 blue 2
7
P113-125-000
20241122S017
Metal strip fixed plate Metal plateδ1.0 6
8
P113-126-000
20241122S022
Marquee 1 Q235 δ1.0 blue 1
9
P113-127-000
20241122S023
Marquee 2 Q235 δ1.0 blue 1
10
P113-128-000
20241122S024
Marquee edge strip Q235 δ1.0 blue 2
11
P113-129-000
20241122S025
Marquee mounted plate Metal plate δ1.5 4
12
P113-605-000
20641122S005
Marquee plastic Transparent plastic 1
13
P113-701-000
20541122S001
Marquee decal Plastic silk screen 1
14
P113-919-000
20341122S017 marquee bottom board MDF blue JQ11038 1
15
P113-920-000
20341122S018
marquee top board MDF blue JQ11038 1
16
P113-921-000
20341122S019
marquee mid plate MDF blue JQ11038 1
17
P113-922-000
20341122S020
marquee sided board MDF blue JQ11038 2
18
P113-923-000
20341122S021
speaker plate MDF blue JQ11038 4
19
P113-924-000
20341122S022
speaker front board MDF 4
20
P113-925-000
20341122S023
Wind tunnel partition 1 MDF blue JQ11038 4
21
P113-926-000
20341122S024
Wind tunnel partition 2 MDF blue JQ11038 4
