Jensen JE1569FDM User manual

15
Overhead 15" 16:9 Monitor
OPERATING MANUAL
JE1569FDM
Before operating the unit, please read these instructions carefully.
OT01005419- 06'10
Safety Precautions:
1. Ensure the plug is securely plugged into the main socket before operating
the unit.
2. Ensure the Voltage on the main socket is the same as specified on the unit.
3. Use parts only manufactured by the unit manufacturers.
4.
Ensure the battery is correctly installed before using the unit.
In case of the following emergencies, remove plug from the main socket
immediately:
1. Plug or cables are damaged.
2. Any form of foreign objects dropped inside the enclosure.
3. Unit is being exposed to rain and/or water.
4. Unit unable to operate under normal operation.
Notices:
1. Any changes or modifications made to this unit will void the users warranty.
2. To comply with the FCC RF exposure compliance requirments , no change
to the antenna or the device is permitted. Any change to the antenna or
the device could result in the device exceeding the RF exposure
requirements and void user's authority to operate the device.
This device complies with part 15 of the FCC RULES. Operations is subject to
the following two conditions:
(1) This device may not cause harmful interference and
(2) This device must accept any interference received, including interference that
may cause undisried operation.
The lighting flash with Arrowhead Symbol within an equilateral
triangle is intended to alert the user to the presence of "uninsulated
" dangeros voltage" within the product's enclosure that may be of
sufficient magnitude to consistute a risk of electric shock to persons.
The exclamation point within an equilater triangle is intended to alert
the user to the presence of important operating and maintenace
(servicing) instrucion in the literature accopmpanying the appliance.
CAUTION
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER - SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL
RISK OF ELECTRIC SHOCK
DO NOT OPEN

IMPORTANT NOTES:
* When the unit is used in conjunction with a Radio/TV tuner, please assure that the
receiver is manufactured to receive television broadcast signals that are transmitted via
terrestrial radio waves. Reception quality will change and vary according to geographic
location and climatic control.
* We strongly advise for the display screen to be installed at a location, where the
attentiveness of the driver will not be affected while driving.
* Only correct size of fasteners or installation cables should be used during installation.
Failure to do so may cause a mechanical failure and create a fire hazard.
* When in doubt, the authorized dealer should be contacted.
* To avoid electrical shock to yourself and others, do not disassemble the unit.,
NOTICE OF INTENDED USE
THIS VIDEO ENTERTAINMENT SYSTEM IS DESIGNED TO ENABLE VIEWING OF VIDEO
RECORDINGS ONLY FOR REAR-SEAT OCCUPANTS.
MOBILE VIDEO PRODUCTS ARE NOT INTENDED FOR VIEWNG BY THE DRIVER WHILE THE
VEHICLE IS IN MOTION. SUCH USE MAY DISTRACT THE DRIVER OR INTERFERE WITH THE
DRIVER’S SAFE OPERATION OF THE VEHICLE, AND THUS RESULT IN SERIOUS INJURY OR
DEATH. SUCH USE MAY ALSO VIOLATE STATE LAW.
THE MANUFACTURER DISCLAIMS ANY LIABILITY FOR ANY BODILY INJURY OR PROPERTY
DAMAGE THAT MAY RESULT FROM ANY IMPROPER OR UNINTENDED USE.
GENERAL INFORMATION
WELCOME
Thank you for your purchase of this Roof Mount Monitor. Prior to operating this unit, please
read this instruction manual and retain it for future references.
PRECAUTIONS
To avoid serious damage to the unit, to the car and/or to yourself, you should follow the
instructions in this manual.
* Should there be a need to replace the fuse ,
turn off the unit and disconnect all power
r
Use only the correct rating fuse to avoid electrical damage to the unit.
* During operation, if the unit should over-heat or malfunction, switch off the unit and see
your dealer. Do not disassemble the unit. There are no user-serviceable parts in this unit.
To avoid serious injury to yourself and prevent damage to the LCD panel, please observe
the following:
* Do not drop the LCD panel or subject it to direct impact. Impact will cause damage to the
LCD panel and/or to the back light element.
* Should the LCD panel brake or leak fluid, please avoid all contact with the unit. If you
should come into contact with the leaked fluid, please wash the affected area thoroughly
with water and seek immediate medical attention.
This unit is designed using high quality electronic components and manufactured under a
stringent quality control system. This unit will provide you with numerous hours of quality
performance if utilized as specified. If need be, please follow these maintenance
procedures:
* Do not use any chemical solvent, cleaning agent or corrosive detergent when wiping the
display. If chemicals are used, you will cause irreversible damage to the TFT screen. A
soft, damp, lens cleaning cloth should be used to wipe the screen of fingerprints and
debris.
* Do not drop the monitor or impact it with hard objects. This may cause permanent
irreversible damage to the LCD panel and/or the back light element.

INSTALLATION GUIDE:
1.1 Precautions:
1. This unit should be installed by a qualified service technician.
2. This product is designed to operate with a 12V DC, negative ground battery
system.
3. Disconnect the ground wire from the battery terminal prior to connecting the unit
to the electrical system.
4. The wiring from some other products or accessories might bear similar color code
as this product; however, they might be of other function. Please refer to the
electrical connection diagrams of this product prior to installing to avoid improper
connection.
5. Use proper installation and fastening materials to prevent electrical damage to the
unit.
6. Only supplied accessories should be used to avoid damage to the unit during
installation.
7. Ensure that the display monitor is suitably installed at a location, such that it will
not obstruct the rear view mirror and/or the air condition vents.
8.
Do not install screws over the plane surface, which may affect monitor eject or
retract function.
Color Code Function
Yellow (RCA) Video - In (V-IN 1)
SIGNAL CONNECTION:
VIDEO:
TYPICAL WIRING DIAGRAMS:
MAIN UNIT FUNCTION KEYS:
1. LCD Display
1. ACC-Red
2. GND-Black
Yellow (RCA)
1
1. EJECT/OPEN THE DISPLAY MONITOR
To eject/open the display monitor, push & pull the open button to the desired position.
2. KEEPING THE DISPLAY MONITOR CLOSED
To prevent the LCD display from opening, pull the monitor back into the tray and
engage the monitor lock with a click.
3. SIGNAL SOURCE ON
The unit will automatically power on when a video signal is applied.
OPERATING THE MONITOR:
ACC
GND

Accessories supplied:
Item
1
2
Item Description
Operating manual
2 pin power connector
Type
Display System
Aspect Ratio
Resolution
Overall Dimensions
Back Light
Mechanism
Display Angle
Source
Operating Voltage
Operating Current
Operating Temperature
Roof Mount Color Display Monitor
15 inch Active Matrix Color TFT LCD
16 : 9
854 (W) x 480 (H)
16.8"W x 11.35"H x 13.05"D
10,000 hours normal operation
Manual Open / Close
Adjustable
Horizontal: Up/Down < 100
Composite video input x 1
DC 12V
2.3A, Typical
0°C to 55°C
TECHNICAL SPECIFICATIONS:
All specifications are subjected to change without prior notification
