Jensen JRV4100 Installation instructions

JRV4100
Installation and Owner’s Manual

Content
01
A
ccessories………………………………………………………………………………………………………………………………………...02
Unit Installation………………………………………………………………………………………………………………………………..03
Wire Connection………………………………………………………………………………………………………………………………03
Parking Brake Connection ………………………………………………………………………………………………………04
Speaker connection……………………………………………………………………………………………………………………….05
Button Description………………………………………………………………………………………………………………………….06
Remote Control………………………………………………………………………………………………………………………………..07
Main Menu…………………………………………………………………………………………………………………………………………...09
Radio Operation……………………………………………………………………………………………………………………………….09
USB /SD Operation………………………………………………………………………………………………………………………..10
Settings Operation………………………………………………………………………………………………………………………..10
Bluetooth Operation……………………………………………………………………………………………………………………..12
A
ux-In Operation ……………………………………………………………………………………………………………………………13
T
roubleshooting……………………………………………………………………………………………………………………………..15
General Specification…………………………………………………………………………………………………………………..16

Power Cable Trim Ring User Manual
Accessories
Package contains the following accessories for installation and operation of the unit.
- Washer, Spring Washer,
M5 Nut 1 each
- Metal Mounting Strap 1
- Hex Bolt 1
- Screw
Max. 8mm (7/32 x max.
5/16 in) 4
- Metal
Mounting Sleeve 1
- Release Key 2
- Tapping Screw 1
- Rubber Cushion 1
02
Remote Control

Unit Installation
Wire Connection
The Description of the Input/Output Interface of the Rear Chassis.
03

Parking Brake Connection
In order to view videos, the parking brake wire must be connected, and the vehicle is parked
Connecting the reversing line to taillight on the car
04

Speaker Connection
Connect the speakers according to the following diagram, incorrect connections may damage the unit
or your speakers. Do not chassis ground the speakers. Always observe correct polarity.
Correct connection
Left front - Right front | Left rear - Right rear
Incorrect connections
05

1 78
5
6
2
Button Description
1. MIC
2. RETURN Button
Press return button to go back to previous menu.
3. HOME BUTTON
Press home button to return back to main menu.
4. SOURCE BUTTON
Press source button to change mode.
5. POWER / MUTE Button /VOL
Press it to turn on the unit. Press and hold for 2 seconds to turn the unit off .Press the button
briefly to mute .Please notes that the volume will be muted on all audio output connectors.
Rotate VOL knob to increase or reduce the volume.
6. USB/SD/AUX
USB for Multimedia playback files only. insert a USB into this slot and the unit will automatically start
reading and playback. (Supported Music File Format: MP3 and WMA files)
SD card slot, for Multimedia playback files only. Insert a SD CARD into this slot and the unit will
automatically start reading and playback. (Supported Music File Format: MP3 and WMA files)
Put the Aux plug into the Aux-In jack which is marked on front panel.
7. Display
Displays information when operating the unit.
8. Remote Sensor
Remote control signal receiving window. Max distance is 20 ft (6m), 45 deg.
06
3
4

Remote Control
1. POWER button
Power on or power off.
2. MODE button
Press it to select the mode: Radio, USB (if there is a USB device in the unit), SD (if there is a SD/MMC
card in the unit), Bluetooth, Aux-In.
3. LEFT button
Press it to move the cursor left.
4. / ACCEPT
In USB / SD mode, press to skip to the previous track.
In Radio mode, press to seek to previous station.
In Bluetooth mode, press to make a call after inputted a phone number or accept an incoming call.
5. VOLUME DOWN button
Press to decrease volume level.
6. Mute button/Bluetooth button
Short press to mute the volume output, press again to resume volume.
Long press this button to enter into Bluetooth mode (Handsfree).
7. UP button
Press it to move the cursor up.
8: ENTER
Press it to confirm your selection.
9. DOWN button
Press it to move the cursor down.
07
1: POWER
2: MODE
3: LEFT
4: PREVIOUS/Accept
5: VOLUMN DOWN
6: MUTE/BLUETOOTH
7: UP
8: OK
9: DOWN
10: MENU
11: SERARCH
12: RIGHT
13: NEXT/REJECT
14: VOLUMN UP

Remote Control
10. MENU
Press it to show main menu.
11. SEARCH button
Press to auto store AM/FM stations.
12. RIGHT button
Press it to move cursor right.
13. NEXT/REJECT button
In USB / SD mode,, press button to skip to the next track
In Radio mode, press to seek to next station.
In Bluetooth mode, press to end a call or decline an incoming call.
14. VOLUME UP button
Press to increase volume level.
Note:
The distance may vary according to the brightness of ambient light.
If the remote is not used for an extended period of time, remove the battery to prevent possible
damage from battery leakage or corrosion.
Do not place any objects between the remote control unit and the sensor on the unit.
Do not drop the remote control onto the floor; it may damage it beyond repair.
Do not use the remote control unit while simultaneously operating the remote control unit of any
other equipment; they may interfere resulting in improper operation.
The battery normally lasts for about one year depending how often the remote control is used. If
the remote control unit isn’t working even when it is operated near the unit, replace the battery
with a new battery of the same make and use only a lithium cell battery type: CR2025 (3V).
Dispose empty batteries in accordance with your local governmental regulations.
Do not short-circuit, disassemble, heat or dispose of flammable battery.
Keep the battery out of reach of children, should the battery be swallowed, immediately seek
medical attention.
08

Main Menu
The best way to discover the program is to explore each screen in detail, and to find out how to move
from one to another. Read this chapter for a guided tour.
Unit starts by displaying the main menu.
This is the root of the screen hierarchy, and you can simply access all features by tapping on the touch
screen buttons.
Tap the icons to enter a desired mode.
Pae 1
Radio Operation
To start radio, tap radio button on main menu screen.
Touch it to select station backward automatically, touch and hold this icon to select station
backward manually.
Touch it to select station forward automatically, touch and hold this icon to select station.
forward manually.
Touch it to select FM1—>FM2—>FM3.
Touch it to select AM1—>AM2.
Touch this button can turn on or turn off Local function.
Touch this button to select mono sound reception.
Touch this button can scan the stations from 1-18, Long Touch it to save the stations with
good reception automatically and scan each station for about 5 seconds.
09
