Remote Dust Collectors
Our latest addition to our complete line of dust collectors is
the convenience of a remote control and a built in timer. The
remote will operate these dust collectors from anywhere in
the shop. The timer will automatically shut the unit off at any
predetermined time from 1 to 99 minutes. This great feature
is available on all JET® dust collectors with bag lters and
canister lters.
STOCK NO. 900818
5M 07/05
©2005 WMH TOOL GROUP, Inc. All Rights Reserved.

jettools.com
REMOTE DUST COLLECTION
MODEL 1100 REMOTE DUST COLLECTORS
 Industrial-quality construction
effectively handles collection of wood chips and sawdust
 Single-stage design
for economical and quiet operation
 Industrial controls
designed for years of trouble-free use
 Quick-connect collection bags with elastic band
for fast, easy installation and removal
 High air velocity (CFM) design
stands up to any competitive specications
 Permanently lubricated, totally enclosed,
fan-cooled motors
are rated for continuous-duty
 Includes four casters
for maneuverability and total portability
 Remote Control is programmable from 1 to
99 minutes
to collect dust even while you are away from
your workshop
MODEL 1200 REMOTE DUST COLLECTORS
 Industrial-quality construction
effectively handles collection of wood chips
and sawdust
 Single-stage design
for economical and quiet operation
 Industrial controls
designed for years of trouble-free use
 Quick-connect collection bags with elastic band
for fast, easy installation and removal
 High air velocity (CFM) design
stands up to any competitive specications
 Permanently lubricated, totally enclosed,
fan-cooled motors
are rated for continuous-duty
 Includes four casters
for maneuverability and total portability
 Remote Control is programmable from 1 to
99 minutes
to collect dust even while you are away from
your workshop
MODEL 650 REMOTE DUST COLLECTORS
 Hook up one to three machines
for optimum dust cleaning
 Quick-install collection bag
makes emptying and re-attaching a snap
 Includes four casters
for maneuverability and total portability
 Remote Control is programmable
from 1 to 99 minutes
to collect dust even while you are away
from your workshop
STOCK NUMBER 708640RC 708641RC
Model Number DC-640RC DC-650RC
Remote Control yes yes
Blower wheel diameter (in.) 9-1/2 9-1/2
Sound Rating @ 3 ft. 60–dB 60–dB
1-Hose connection diameter (in.) 4 4
Bag diameter (in.) 14 14
Filter Bag/Canister length (in.) 31 24
Collection Bag length (in.) 23-5/8 24
Collection Bag capacity 2.67 cu. ft. 2.7 cu. ft.
Air Flow @ 4" (CFM) 650 650
Particle Size 30-micron 2-micron
Static Pressure (in. of water) 7.80 7.80
Velocity @ 4" (FPM) 7,445 7,445
Overall dimensions (L x W x H/in.) 27 x 14 x 66 27 x 14 x 61
Motor (TEFC)
1HP, 1Ph,
115/230V,
Prewired 115V
1HP, 1Ph,
115/230V,
Prewired 115V
Net weight (lbs.) 84 86
STOCK NUMBER 708639RC 708626RCK
Model DC-1100RC DC-1100RCK
Remote Control yes yes
Blower Wheel diameter (in.) 11 11
Sound Rating @ 3 ft. 70–80 dB 70–80 dB
1-Hose Connection dia. (in.) 6 6
2-Hose Connection dia. (in.) 4 4
Bag Diameter (in.) 20 20
Filter Bag/Canister length (in.) 46 26
Collection Bag length (in.) 30 30
Collection Bag Capacity 7. 36 cu. ft. 7. 36 cu. ft.
Air Flow @ 4" (CFM) 1,100 1,100
Particle Size 30-Micron 2-Micron
Static Pressure (in. of water) 11.5 11.5
Velocity @ 4" (FPM) 12,571 12,571
Overall dimensions (LxWxH/in.) 37x20x79 37x20x72
Motor (TEFC)
1-1/2HP, 1Ph,
115/230V, Prewired
115V
1-1/2HP, 1Ph, 115/
230V, Prewired
115V
Net Wt. (lbs.) 115 120
STOCK NUMBER 708634RC 708634CK 708635RCK
Model DC-1200RC DC-1200CK DC-1200RCK
Remote Control yes no yes
Blower Wheel dia. 12 12 12
Sound Rating @ 3 ft. 65–80 dB 65–80 dB 65–80 dB
1-Hose Connect. dia. 6 6 6
2-Hose Connect. dia. 4 4 4
Bag dia. 20 20 20
Filter Bag/ Canister length 46 26 26
Collection Bag length 34-1/2 34-1/2 34-1/2
Collection Bag Cap. 7.36 cu. ft. 7.36 cu. ft. 7.36 cu. ft.
Air Flow @ 4" (CFM) 1200 1200 1200
Particle Size 30-Mic. 2-Mic. 2-Mic.
Static Pressure (in. of water) 11.0 11.0 11.0
Velocity @ 4" (FPM) 13,745 13,745 13,745
Overall dim. (L x W x H/in.) 34x20.5x96 34x20x72 34x20x72
Motor (TEFC) 2HP, 1Ph,
230V
2HP, 1Ph,
230V
2HP, 1Ph,
230V
Net Wt. (lbs.) 143 150 150
