10" x 14" VARIABLE SPEED
INDEXING MINI LATHE
STOCK NO. 900492
10M 07/07
©2007 WMH TOOL GROUP, Inc. All Rights Reserved.
The JML-1014VSI is another new addition to our line of JET®Woodturning Lathes. This ½
HP lathe supports stock up to 10" in diameter and 14" in length. This lathe features solid
cast iron construction, the added convenience of a hollow tailstock, a 6" tool rest and
electronic variable speed. The spindle also has a versatile locking /indexing mechanism for
fluting and veining applications.
708375vs.indd 1 7/3/07 6:40:50 AM

jettools.com
10"x 14" VARIABLE SPEED
INDEXING MINI LATHE
•Continously variable speed operation from 500-3900 rpm
•Heavy-duty cast-iron lathe bed adds stability while limiting vibration during operation
•Indexing mechanism which allows for fluting and veining operations
•Self-ejecting tailstock for safe and easy removal of tooling
•Hollow tailstock and removable tip on live center allows for hole boring through stock
•Includes four non-skid rubber feet keep machine stable during use
•3" face plate included
10"x14" VARIABLE SPEED
INDEXING MINI LATHE
STOCK NUMBER 708375VS
Model Number JML-1014VSI
Net Weight (lbs.): 70
Swing Over Bed (in.): 10
Swing Over Tool Rest Base (in.): 7-1/2
Distance Between Centers (in.): 14
Speeds (RPM): Variable from 500-3900
Headstock Taper: MT-2
Spindle Nose (in. x TPI): 1 X 8
Tailstock Taper: MT-2
Hole Through Tailstock (in.): 3/8
Ram Travel (in.): 2
Motor HP: 1/2HP
Motor Phase: 1Ph
Motor Voltage: 115V
1/2HP Motor
Quick
Cam
Locks
2" Ram
Cast-Iron
Construction
6" Tool
Rest
Spindle
with
Indexing
Capability
Chrome
Plated
Handwheel
