SS SINGLE SPEED
HEAVY DUTY
ELECTRIC CHAIN
HOIST
STOCK NO. 900473
10M 07/05
©2005 WMH TOOL GROUP, Inc. All Rights Reserved.
Designed for commercial and industrial applications the JET
Single Speed Electric Hoists are easy to install, inspect, and
maintain. The SS Hoist is equipped with a heavy duty venti-
lated motor available in a range of HP from 7/8 to 2-1/7. Gear
trains feature lifetime lubrication eliminating the need for oil
changes. All models come standard with slip clutch overload
protection, chain containers and drop forged, heat treated
hooks that swivel 360 degrees for easy rigging. Single
phase units feature a solid state starting switch that
eliminates the mechanical centrifugal mechanism and
reversing switch. Quick connect wiring for power and
push button controls allow for quick set-up while the
DC electro-magnetic brake secures loads even if power
is interrupted.
For added convenience and versatility equip
the SS Series Electric Hoists with a JET ET
series Electric Trolley. Available in a variety
of capacities the ET Electric Trolley features
the same quick-connect cords as the
SS Electric Hoists allowing for fast set-up
and installation.

jettools.com
SS ELECTRIC HOIST
Front Mounted Table
Adjustment Dials
• Designed for commercial and industrial applications
• 1/2-ton to 5-ton capacities, single or three phase models
• 10', 15' and 20' lifts standard, custom length lifts available
• Easy to install, inspect and maintain
• Totally enclosed steel plate construction with a durable powder coat finish
• Gear train features lifetime lubrication, no oil changes required
• Heavy-duty ventilated motor with thermal overload protection or reverse phase protection
• Single phase models feature thermal overload protection
• Three phase models feature reverse phase protection
• Can be operated on 50Hz power with 16% reduction in lifting speed
• Equipped with heavy-duty chain container
• Reliable DC electromagnetic brake holds the load even if power is interrupted
• Quick-connect wiring for power and push button controls
• Upper and lower limit switches prevent over-travel
SS SERIES, SINGLE SPEED HEAVY-DUTY
ELECTRIC CHAIN HOISTS
STOCK
NUMBER
MODEL
NUMBER
STANDARD
LIFT
HEADROOM
(IN)
DUTY
CYCLE
DUTY CYCLE
RATING
LIFTING SPEED/
FT PER MINUTE
MOTOR
OUTPUT (HP)
RATED
AMPS
115V
RATED
AMPS
230V
LOAD CHAIN
DIAMETER
(MM)
NUMBER
OF FALLS
GROSS
WEIGHT
(LBS)
1/2 TON, 1 PHASE
121100 1/2SS-1C-10 10ft 20 3/16 25% H3 19.7 7/8 12.6 6 6.3x19 1 108
121150 1/2SS-1C-15 15ft 20 3/16 25% H3 19.7 7/8 12.6 6 6.3x19 1 112 1/2
121200 1/2SS-1C-20 20ft 20 3/16 25% H3 19.7 7/8 12.6 6 6.3x19 1 114 1/2
1 TON, 1 PHASE
111000 1SS-1C-10 10ft 24 7/16 25% H3 19.7 1-3/4 20.8 10 8x24 1 170
111500 1SS-1C-15 15ft 24 7/16 25% H3 19.7 1-3/4 20.8 10 8x24 1 174
112000 1SS-1C-20 20ft 24 7/16 25% H3 19.7 1-3/4 20.8 10 8x24 1 181
2 TON, 1 PHASE
211000 2SS-1C-10 10ft 28 1/8 25% H3 9.8 1-3/4 20.8 10 8x24 2 185
211500 2SS-1C-15 15ft 28 1/8 25% H3 9.8 1-3/4 20.8 10 8x24 2 196
212000 2SS-1C-20 20ft 28 1/8 25% H3 9.8 1-3/4 20.8 10 8x24 2 205
3 TON, 1 PHASE
311000 3SS-1C-10 10ft 31 1/2 25% H3 6.6 1-3/4 20.8 10 8x24 3 216
311500 3SS-1C-15 15ft 31 1/2 25% H3 6.6 1-3/4 20.8 10 8x24 3 231 1/2
312000 3SS-1C-20 20ft 31 1/2 25% H3 6.6 1-3/4 20.8 10 8x24 3 244 1/2
5T, 1 PHASE
511000 5SS-1C-10 10ft 30 11/16 25% H3 4.9 1-3/4 22 10.5 8x24 4 236
511500 5SS-1C-15 15ft 30 11/16 25% H3 4.9 1-3/4 22 10.5 8x24 4 255 1/2
1/2T, 3 PHASE
RATED
AMPS
230V
RATED
AMPS
460V
123100 1/2SS-3C-10 10ft 20-3/16 30% H3 31.5 1-1/5 3.5 1.8 8x24 1 99
123150 1/2SS-3C-15 15ft 20-3/17 30% H3 31.5 1-1/5 3.5 1.8 8x24 1 103 1/2
123200 1/2SS-3C-20 20ft 20-3/18 30% H3 31.5 1-1/5 3.5 1.8 8x24 1 106
1 TON, 3 PHASE
131000 1SS-3C-10 10ft 24 7/16 30% H3 24.8 2-1/7 5.9 3 8x24 1 158 1/2
131500 1SS-3C-15 15ft 24 7/16 30% H3 24.8 2-1/7 5.9 3 8x24 1 163
132000 1SS-3C-20 20ft 24 7/16 30% H3 24.8 2-1/7 5.9 3 8x24 1 170
2 TON, 3 PHASE
231000 2SS-3C-10 10ft 28 1/8 30% H3 12.4 2-1/7 5.9 3 8x24 2 174
231500 2SS-3C-15 15ft 28 1/8 30% H3 12.4 2-1/7 5.9 3 8x24 2 185
232000 2SS-3C-20 20ft 28 1/8 30% H3 12.4 2-1/7 5.9 3 8x24 2 194
3 TON, 3 PHASE
331000 3SS-3C-10 10ft 31 1/2 30% H3 8.3 2-1/7 5.9 3 8x24 3 205
331500 3SS-3C-15 15ft 31 1/2 30% H3 8.3 2-1/7 5.9 3 8x24 3 220 1/2
332000 3SS-3C-20 20ft 31 1/2 30% H3 8.3 2-1/7 5.9 3 8x24 3 233 1/2
5 TON, 3 PHASE
531000 5SS-3C-10 10ft 30 11/16 30% H3 6.2 2-1/7 5.9 3 8x24 4 225
531500 5SS-3C-15 15ft 30 11/16 30% H3 6.2 2-1/7 5.9 3 8x24 4 244 1/2
