Jetson JIMPULSE-WHT User manual

Impulse
Extreme-Terrain
Combo.
A guide for
your ride.
Model: JIMPULSE-WHT

Remember to be
safe and
most importantly,
have fun!

What’s in the Box
Specs & Features
1. Astro Hoverboard
2. Foot Rest
3. Front Wheel
4. Frame Tube
5. Handlebar
6. Seat
1
2
3
4
6
5
• Weight Limit: 220 lb
• Product Weight: 18 lb
• Product Dimensions: 24.5” × 8” × 7.5”
• Recommended Age: 12+
• Tire Size: 6.5”
• Max Speed: Up To 9 mph
• Max Range: Up To 12 miles
• Battery: 25.2V, 4.0 Ah Lithium-Ion
• Motor: 500W (250W*2), Dual Hub Motor
• Charger: UL Listed, 100-130V
• Charge Time: Up To 3 Hours
• Climbing Angle: Up To 15°
ASTRO
• Weight Limit: 220 lb
• Product Weight: 16 lb
• Recommended Age: 12+
• Product Dimensions: 39” × 30” × 17.5”
IMPULSE
A(×4) B(×6) C(×4)
1. Get Started
1.1 Charging the Battery
• Only use the included charger
• Plug the charger into the wall
before the Charging Port
• Don’t turn on the Astro while
it’s charging
• Charge the battery until it is
fully charged - up to 3 hours
• Replace the cover over the
Charging Port when done
- Charging
- Charge Complete
CHARGING INDICATOR ON THE CHARGER:
Charging Port

1.3 How to Recalibrate
1.2 Indicator Lights
Warning: The Astro will automatically slow down and lean up once the
battery power goes below 10% as a safety precaution.
Status Indicator Light - Lights up blue when you step onto the Astro.
If the Status Indicator Light turns red or if you are having issues with
the Astro, you may need to recalibrate it.
< 20% 20-49% 50% +Percentage
Battery
Indicator Light
Battery
Indicator Light
Status
Indicator Light
Follow these 3 simple steps...
1. Place the Astro on a flat, level surface.
2. Hold the Power Button (for about 5 seconds) until you are notified
of a successful recalibration.
3. Restart the Astro by turning it off and then on.
Hold for 5 seconds
*Adults must assist children in the initial assembly and adjustment procedures
to fold/unfold product and adjust handlebars.
1.5 Connecting to Bluetooth®
The Astro comes equipped with two Bluetooth® modules - one for the
Bluetooth® speaker and one for the Ride Jetson app.
To connect to your Bluetooth® speaker:
• Turn on the Astro, and it will become discoverable to your handheld device.
• Activate your Bluetooth® in your handheld device’s settings.
• Find the Astro in your handheld device’s list and select it.
• Now you can play your music.
Please Note: The default setting is advanced (fast) mode.
Please Note: When you turn off the Astro, it will return to the original factory
setting—advanced (fast) mode.
1.4 How to Change Speed
The Astro has three speed settings & each setting has
a different-colored indicator light:
Green for beginner (slow) mode
Yellow for intermediate (medium) mode
Red for advanced (fast) mode
Follow these 3 simple steps...
1. Place the Astro on a flat, level surface.
2. Power the Astro on—the indicator light will illuminate red for
advanced (fast) mode.
3. Quickly press and release the power button to cycle through the
speed modes. Stop once the indicator light changes to the respective
color of your desired speed.

2. Assembly
2.1 Assembling the Handles
Attach the handle to the
bracket using A(×2) and B(×2).
Then, attach to the frame using
B(×1) and C(×2). Remember to do
this on both sides of the Impulse.
Tighten the bolt
and lock nut before
each ride.
Adjust to preferred
length and tighten knob.
Place the Impulse on
top of the Astro.
Velcro Straps
2.2 Adjusting the Foot Rest
2.3 Attaching the Impulse
To connect to the Ride Jetson app:
• Open the Ride Jetson app on your handheld device.
• Tap the Bluetooth® symbol in the top left corner of the app.
• Select your Astro. Default password is 000000.
(To customize your password go to Settings in the App. If you forget
your new password, you can factory reset the Astro by recalibrating)
• You should now be connected to the Astro!
MODE SETTINGS
In the Ride Jetson app you can choose from three settings:
• Beginner Mode Max Speed: Up to 5 mph
• Intermediate Mode Max Speed: Up to 7 mph
• Advanced Mode Max Speed: Up to 9 mph
NOTE: Other features that can be adjusted include Steering
Sensitivity, Driving Force, and Auto Shutdown Time.

TURN LEFT
TURN RIGHT
NEUTRAL
Please Note: Images may not reflect exact appearance of actual product.
Pull the Velcro straps
tight and fold.
3.1 Riding the Astro
3. Make Moves
3.2 Riding the Impulse
FORWARD PUSH DOWN BRAKE / REVERSE PULL UP
TURN RIGHT TURN LEFT
Note: If the Astro is not leveled when you turn it on, the Impulse will
go forward or backward immediately. Tighten all screws and locking
nuts before each ride to ensure they are tight.
1. Place the Impulse on a flat surface with the Astro turned off.
2. Carefully take a seat and place your feet on the Foot Rest.
3. Make sure the Astro is leveled.
4. Now it’s time to turn on your Astro.

Care & Maintenance
CLEANING THE IMPULSE
To clean the Impulse, carefully wipe with a damp cloth, then dry with a
dry cloth. Do not use water to clean the Impulse, this may damage the
frame or seat.
STORAGE
• Store the Impulse indoors, in a dry place.
• To protect against dust, cover the Impulse.
FEW MUST-DO’S
• Keep away from fire and excessive heat.
• Avoid intense physical shock, severe vibration, or impact.
• Please ride the Impulse on a smooth, flat surface.
• Protect from water or moisture.
• Contact Jetson Customer Support if there are any issues with the
Impulse.
RIDING RANGE
The maximum range is 12 miles. However, many factors will affect how far
you can go per charge:
• Driving Surface: A smooth, flat surface will increase driving distance.
• Weight: More weight means less distance.
• Temperature: Ride, store, and charge the Astro above 50°F.
• Maintenance: Timely battery charging will increase driving distance.
• Riding Style: Frequent starting and stopping will reduce driving distance.
CLEANING THE ASTRO
To clean the Astro, carefully wipe with a damp cloth, then dry with
a dry cloth. Do not use water to clean the Astro, as the electrical
and electronic systems may get wet, resulting in personal injury or
malfunction of the Astro. If the electric parts or battery get wet, do
not power on the Astro. Please contact Jetson Customer Support for
assistance.
BATTERY
• Keep away from fire and excessive heat.
• Avoid intense physical shock, severe vibration, or impact.
• Protect from water or moisture.
• Do not disassemble the Astro or its battery.
• Contact Jetson Customer Support if there are any issues with the battery.
STORAGE
• Fully charge the battery before storing. The battery should be fully
charged once a month after this.
• Cover the Astro to protect against dust.
• Store the Astro indoors, in a dry place.
MODIFICATIONS
Do not attempt to disassemble, modify, repair, or replace the unit or any
components of the unit without instruction from Jetson Customer Support.
This will void any warranty, and can lead to malfunctions which may cause injury.
ADDITIONAL OPERATION CAUTIONS
Do not lift the product off the ground while it is on and the wheels are in motion.
This can result in freely spinning wheels, which may cause injury to yourself or others
nearby. Do not jump on or off the product, and do not jump while using it. Always
keep your feet firmly planted on the foot rest while in operation. Always check the
battery charge before using.
The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth
SIG, inc. And any use of such marks by Jetson Electric Bike LLC. is under license. Other
trademarks and trade names are those of their respective owners.
DISPOSAL OF USED BATTERY
Battery may contain hazardous substances which could endanger the
environment and human health. This symbol marked on the battery and/
or packaging indicates that used battery shall not be treated as municipal
waste. Batteries should be disposed of at an appropriate collection point for
recycling. By ensuring the used batteries are disposed of correctly, you will help
preventing potential negative consequences for the environment and human
health. The recycling of materials will help to conserve natural resources.
For more information about recycling of used batteries, please contact your
local municipality waste disposal service.

Safety Warnings
• Before use, please read the user manual and safety warnings carefully, and make sure
you understand and accept all the safety instructions. The user will be responsible for
any loss or damage caused by improper use.
• Before each cycle of operation, the operator shall perform the preoperation checks
specified by the manufacturer: That all guards and pads originally supplied by the
manufacturer are in proper place and in serviceable condition; That the braking system is
functioning properly; That any and all axle guards, chain guards, or other covers or guards
supplied by the manufacturer are in place and in serviceable condition; That tires are in
good condition, inflated properly, and have sufficient tread remaining; The area that the
product is to be operated should be safe and suitable for safe operation.
• Components shall be maintained and repaired in accordance with the manufacturer’s
specifications and using only the manufacturer’s authorized replacement parts with
installation performed by dealers or other skilled persons.
• Warning against recharging non-rechargeable batteries.
• Don’t allow hands, feet, hair, body parts, clothing, or similar articles to come in contact
with moving parts, wheels, or drive train, while the motor is running.
• This product should not be used by children or persons with reduced physical, sensory
or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction (IEC 60335-1/A2:2006).
• Unsupervised children should not play with the product (IEC 60335-1/A2:2006).
• Adult supervision is required.
• The rider should not exceed 220 lb.
• Units shall not be operated to perform racing, stunt riding, or other maneuvers, which may
cause loss of control, or may cause uncontrolled operator/passenger actions or reactions.
• Never use near motor vehicles.
• Avoid sharp bumps, drainage grates, and sudden surface changes. Scooter may
suddenly stop.
• Avoid streets and surfaces with water, sand, gravel, dirt, leaves, and other debris. Wet
weather impairs traction, braking, and visibility.
• Avoid riding around flammable gas, steam, liquid, or dust that could cause fire.
• Operators shall adhere to all of the manufacturer’s recommendations and
instructions, as well as comply with all laws and ordinances: Units without headlights
shall be operated only with adequate daylight conditions of visibility, and; Owners shall
be encouraged to highlight (for conspicuity) using lighting, reflectors, and for low-riding
units, signal flags on flexible poles.
• Persons with the following conditions shall be cautioned not to operate: Those with
heart conditions; Pregnant women; Persons with head, back, or neck ailments, or prior
surgeries to those areas of the body; and persons with any mental or physical conditions
that may make them susceptible to injury or impair their physical dexterity or mental
capabilities to recognize, understand, and perform all of the safety instructions and to
be able to assume the hazards inherent in unit use.
• Do not ride at night.
• Do not ride after drinking or taking prescription medication.
• Do not carry items when riding.
• Never operate the product barefooted.
• Always wear shoes and keep shoelaces tied.
• Make sure your feet are always placed securely on the deck.
• Operators always shall use appropriate protective clothing, including but not
limited to a helmet, with appropriate certification, and any other equipment
recommended by the manufacturer: Always wear protective equipment such as helmet,
knee pads, and elbow pads.
• Always give way to pedestrians.
• Be alert to things in front and far away from you.
• Do not allow distractions when riding, such as answering the phone or engaging in any
other activities.
• The product cannot be ridden by more than one person.
• When you ride the product along with other riders, always keep a safe distance to avoid
a collision.
• When turning, be sure to maintain your balance.
• Riding with improperly adjusted brakes is dangerous and can result in serious
injury or death.
• The brake may become hot while operating, do not touch the brake with your bare skin.
• Applying brakes too hard or too suddenly can lock up a wheel, which could
cause you to lose control and fall. Sudden or excessive application of the brake
may result in injury or death.
• If the brake loosens, please adjust with the hexagon wrench, or please contact Jetson
Customer Support.
• Replace worn or broken parts immediately.
• Check whether all safety labels are in place and understood before riding.
• The owner shall allow the use and operation of the unit after a demonstration
that such operators can understand and operate all components of the unit
before use.
• Do not ride without proper training. Do not ride at high speeds, on uneven
terrain, or on slopes. Do not perform stunts or turn abruptly.
• Recommended for indoor use.
• Prolonged exposure to UV rays, rain and the elements may damage the enclosure
materials, store indoors when not in use.
California Proposition 65
WARNING:
This product can expose you to a chemical such as Cadmium that is known to
the state of California to cause cancer or birth defects or other reproductive harm.
For more information go to www.p65warnings.ca.gov/product
NOTICE OF COMPLIANCE
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Warning: Changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/ TV technician for help.
Shielded cables must be used with this unit to ensure compliance with the Class B FCC limits.

Follow us @ridejetson
#MakeMoves
Enjoying the ride?
Questions? Let us know.
Leave a review on ridejetson.com/reviews or share your photos with us
online using the #RideJetson hashtag!
www.ridejetson.com
support.ridejetson.com
Hours of Operation: 7 Days a Week, 10am-6pm
US 1-[phone] | UK [phone]
Date Code: 08/2020
Made in China
Imported by Jetson Electric Bikes LLC.
86 34th Street 4th Floor, Brooklyn NY 11232
