Jetson E-KICK AIR User manual

1
E-KICK AIR
ELECTRIC SCOOTER
-MANUAL-

2
TABLE OF CONTENTS
A. Introduction 3
B. Included in the Box 4
C. Features and Specs 5
D. Assembly 6
E. Charging the Battery 8
F. Operating the E-Kick Air 9
G. Care and Maintenance 11
H. Safety Warnings 12
I. Warranty 14
J. Product Registration 15

3
Congratulations on your new Jetson E-Kick Air Electric Scooter! The
E-Kick Air is an innovative and fun electric scooter, ready to take on
everyday use. Before your rst ride, check whether the wheels are
damaged, or parts are loose. If there are any abnormalities, please
contact Jetson Customer Support at 1-888-976-9904 or email us at
[e-mail].
This product manual can help you understand, use, and maintain your
E-Kick Air. In order to avoid danger caused by collisions, falls, and
loss of control, please use caution and learn how to ride the E-Kick Air
safely. Jetson and authorized dealers cannot be held liable for injury or
damage caused from riding the E-Kick Air. Users ride at their own risk.
The rider is responsible for consequences caused by violating warnings
or improper operations.
If you want to return this product for any reason, be sure to rst call or
email us before taking it back to the store so we can assist you.
INTRODUCTION

4
INCLUDED IN THE BOX
1. Stem Base
2. Stem Clamp
3. Stem
4. Handlebar
5. Deck
6. Motor
7. Kickstand
8. Charging Port
3
1
5
6
7
8
4
2

5
FEATURES AND SPECS
MODEL: E-KICK AIR
WHEEL SIZE: 8”
MAX SPEED: 12 MPH
MAX RANGE: 8 MILES
BATTERY TYPE: LEAD ACID
BATTERY CAPACITY: 24V, 15AH
MOTOR TYPE: CHAIN
MOTOR: 200W
CHARGER: UL AC110-240V
CHARGE TIME: 6 HOURS
PRODUCT WEIGHT: 34.6 LBS
WEIGHT LIMIT: 220 LBS
RECOMMENDED AGE: 13+
PRODUCT DIMS: 37”x16.5”x41.5”
7. Twist Throttle
8. Handbrake
7 8

6
The E-Kick Air comes partially assembled, you will need to attach the
Stem and the Handlebar to fully assemble the E-Kick Air.
First, slide the Stem into the Stem Base. Then, using the provided Allen
Key, tighten the 3 bolts in the Stem Clamp until the Stem is tight and
secure.
ASSEMBLY
Tighten
Bolts

7
To assemble the Handlebar, rst place the Handlebar at the top of the
Stem. Align the markings on the Handlebar to those at the top of the
Stem so that the Handlebar is centered. Cover the Handlebar with the
Cover Plate.
Align the holes in the Cover Plate with the holes at the top of the Stem.
Run a bolt through the top of each hole and tighten using a lock nut.
Cover
Plate
4 lock nuts
underneath
Handlebar

8
Your E-Kick Air comes with a built-in rechargeable lead-acid battery.
Always use the provided charger only. The Charging Port is located on
the left side of the E-Kick Air. Please remember to cover the Charging
Port when you are done charging the E-Kick Air. Before your rst ride
you must fully charge the E-Kick Air - charge for 8 hours for the rst 3
times you use it. For every ride after, charge your E-Kick Air until it is
fully charged, and NOT LONGER. Do not leave any chargers plugged in
overnight, or leave it plugged in past the charge time.
CHARGING THE BATTERY
1. Plug one end of the power cord into a grounded AC outlet and the
other into the E-Kick Air’s Charging Port. The red charging light on the
charger unit will turn on.
2. The red light will turn green once fully charged. Recharge the E-Kick
Air after each use.
(Please note: Always plug the charger into the wall rst before the
device. If the wall outlet doesn’t have power and you plug the charger
into the device rst, it will light green, even if the battery is not full. So
always plug into the wall rst to make sure there is power.)
THE CHARGER OFFERS A CHARGING STATUS ON THE TOP OF THE
CHARGER:
CHARGING LIGHT RED: Battery is charging.
CHARGING LIGHT GREEN: Charging is complete.
Don’t use the E-Kick Air if the battery emits strange odors, overheats,
or begins leaking. If the battery does leak, do not touch any leaking
materials, as the battery contains dangerous substances. Do not open
the battery and do not insert anything into the battery.
Only use the provided charger for the E-Kick Air. Do not charge the
battery if it has over-discharged. It should be discarded for your safety.
Do not turn on the E-Kick Air while it is charging.

9
OPERATING THE E-KICK AIR
TURNING THE E-KICK AIR ON AND OFF
To turn the E-Kick Air on, ip the Power Switch located near the Stem
Base to “On.”
To turn the E-Kick Air off, rst make sure the E-Kick Air is not in motion.
Then, ip the Power Switch to “Off.”
SAFE RIDING
Helmet: Most serious injuries that occur while riding are head injuries.
This could be prevented by wearing a helmet.
Elbow and Knee Pads: For added protection, always wear elbow and
knee pads when riding your E-Kick Air, to prevent any serious injuries.
Get to know the E-Kick Air before riding it. Test your control over it.
Make your turns slowly and cautiously, and give yourself stopping
distance. It is recommended you practice your rst ride on the E-Kick Air
in an open space with no obstacles in your way.
Power Switch

10
USING THE TWIST THROTTLE
To activate the motor, use the Twist Throttle by turning it towards
yourself. Get accustomed to the acceleration of the throttle.
Twist
Throttle
FOOT POSITION
Before riding, put your foot as close as possible to the front of the Deck,
and your other foot on the ground. Make sure that your driving route is
clear. To start riding, boost yourself forward with your foot that is on the
ground. Keep one foot behind the other, (it’s more comfortable to place
one foot forward and the other one turned at 70-90°). It will help you
gain more stability. The turns on the E-Kick Air are commanded by the
direction you turn the Handlebar/Front Wheel in. Before turning, look
both ways to make sure your path is clear.
HOW TO APPLY THE BRAKE
To apply the brake, rst release the Twist Throttle. Then, squeeze the
Handbrake.
Handbrake

11
CARE AND MAINTENANCE
DRIVING RANGE
The average range of the E-Kick Air is 8 miles. However, a lot of factors
will affect how far you can go per charge:
• Driving surface: A smooth, at surface will increase driving
distance.
• Weight: More weight means less distance.
• Ambient temperature: Please ride and store the E-Kick Air
under recommended temperature, which will increase its
longevity and driving distance.
• Maintenance: Timely battery charging and maintenance will
increase driving distance.
• Speed and driving style: Maintaining a moderate speed will
increase distance. Frequent starting and stopping, acceleration,
and decelertion will reduce it.
SPEED LIMIT
The top speed of the E-Kick Air is 12 mph.
WEIGHT LIMIT
The maximum load is 220 lbs. Going above the maximum weight limit
can cause injury or damage the E-Kick Air.
CLEANING THE E-KICK AIR
To clean the E-Kick Air carefully wipe with a damp cloth, then dry with
a dry cloth. Do not use water to clean the E-Kick Air, as the electrical
and electronic systems may get wet, resulting in personal injury or
malfunction of the E-Kick Air.
BATTERY
• Keep the E-Kick Air away from re and excessive heat.
• To avoid damage to the battery, never subject the E-Kick Air to intense
physical shock, severe vibration, or impact.
• Protect the E-Kick Air from water or moisture.
• Never disassemble the E-Kick Air or its battery.
• If there are any issues with the battery, please contact Jetson
Customer Support at 1-888-976-9904 or email us at
[e-mail].

12
STORAGE
• If you plan on storing the E-Kick Air for a substantial period of time,
please make sure you fully charge the battery before storing. The
battery should be fully charged once a month after this.
• To protect against dust, cover the E-Kick Air.
• Store the E-Kick Air indoors, in a dry place and at a suitable
temperature.
• You should bring the E-Kick Air into a warm environment (above 50
degrees Fahrenheit) for charging.
• Do not leave the E-Kick Air plugged into the charger for long periods
of time.
SAFETY WARNINGS
Here are some useful tips to make sure you always have a safe ride:
• Do not ride after drinking or taking prescription medication.
• Do not carry items when riding.
• Prior to each ride, inspect each part of the E-Kick Air to ensure it has
been maintained correctly and is functioning properly.
• Always give way to pedestrians.
• Always comply with local trafc laws and regulations. Remember, the
E-Kick Air is a motor vehicle, and is treated as such by local law enforce-
ment. You can and will be arrested for drunk driving. Many cities have
restrictions on where you can drive motor vehicles, as well as additional
restrictions on driving non-automobiles on streets and highways.
• Be alert to things in front and far away from you.
• Make sure your feet are always placed securely on the deck.
•The E-Kick Air cannot be ridden by more than one person. Only one
person can ride at a time.
• When you ride the E-Kick Air along with other riders, always keep a
safe distance to avoid a collision.
• When turning, be sure to maintain your balance.
• Do not allow distractions when riding, such as answering the phone or
engaging in any other activities.
• Avoid riding in the rain or on smooth surfaces such as snow or ice.
• Do not ride on roads with obstacles (such as litter, small stones, etc.).
• Avoid riding in narrow spaces or on steep slopes.
• Avoid riding around ammable gas, steam, liquid, or dust that could
cause re.

13
• Never operate the product barefooted and keep shoelaces tied.
• Applying brakes too hard or too suddenly can lock up a wheel, which
could cause you to lose control and fall.
CALIFORNIA WARNING
This product contains chemicals, including lead, which are known to
the state of California to cause cancer, birth defects, and other medical
conditions.
MODIFICATIONS
Do not attempt to disassemble, modify, repair, or replace the E-Kick
Air or any components of the unit without instruction from Jetson
Customer Support. This will void any warranty, and can lead to
malfunctions which may cause injury.
ADDITIONAL OPERATION CAUTIONS
Do not lift the E-Kick Air off the ground while it is on and the wheels are
in motion. This can result in freely spinning wheels, which may cause
injury to yourself or others nearby. Do not jump on or off the E-Kick Air,
and do not jump while using it. Always keep your feet rmly planted on
the deck while in operation.

14
LIMITED 1 YEAR WARRANTY
TO QUALIFY FOR WARRANTY SERVICE:
1. You must present a copy of the sales receipt from an approved retail partner
within 90 days of purchase.
2. This product cannot be used for rental or commercial use.
3. This product cannot be used for competition.
LIMITATIONS OF LIABILITY
• This Limited 1 Year Warranty is non-transferable after the product’s initial sale.
• No unapproved modications can be made to the product, its performance
or otherwise, in order for this Limited 1 Year Warranty to remain in effect.
• No reimbursement is provided for towing, loss of time, loss of use, inconve-
nience, incidental or consequential damages.
• Warranty is void if weather related water damage is determined. Owner is
responsible for storage and protection from weather.
• Jetson® makes no warranty with respect to products or trade accessories
not made by Jetson®, including, but not limited to, motors, tires, wheels, and
batteries, such products or trade accessories, such items being subject to the
original manufacturer’s warranty, if any.
• This Limited 1 Year Warranty does not cover minor surface blemishes, rips,
tears, or other cosmetic damages due to normal use, or other intentional or
unintentional damage to the product.
• This Limited 1 Year Warranty will not cover any damage which results from the
application of improper cleaners, solvents or chemicals to the product, water
damage, smoke or soot, or from exposure to saltwater, sea breeze or salt.
• This Limited 1 Year Warranty will not cover any damage which results from
aging, such as fading of paint, deterioration of plated surfaces, deterioration of
rubber or plastics, or rusting.
• This Limited 1 Year Warranty does not cover improper repair or misdiagnoses
of problems.
• This Limited 1 Year Warranty only covers parts due to manufacturer defect.
• Damage due to misuse or neglect, use other than as specied in the Owner’s
Manual, or use under abnormal conditions are not covered by this Limited 1
Year Warranty.
OWNER’S WARRANTY RESPONSIBILITIES
As the device’s owner, you are responsible for the performance of the required
maintenance. You may be denied a warranty claim solely because of your
failure to ensure the performance of all scheduled maintenance. As the owner,
you should be aware that you may be denied your warranty coverage if your
device or a part has failed due to abuse, neglect, improper maintenance, or
unapproved modications. For any issue regarding your Jetson® product, call
toll free 1-888-976-9904, or email [e-mail].

15
Please complete and mail this card within 10 days of purchase or go to
https://www.ridejetson.com/product-registration.
Name: _____________________________________________________________________________
Address: ____________________________________________________________________________
City
, State,
Zip: ______________________________________________________________________
Email: ______________________________________________________________________________
Home Phone: ___________________________ Gender: _____________________________
Pu
rchase Date: _________________________ Purchased Fr
om: __________________________
Serial Number: ______________________________________________________________________
Is this your first
Jetson pr
oduct? ______________________________________________________
Other similar pr
oduct owned befor
e: _________________________________________________
How did you hear about the E-Kick Air? ______________________________________________
_____________________________________________________________________________________
Co
mplete this form and mail it to:
Attention: Product Registration
Jetson Electric Bikes
1 Rewe Street
Brooklyn, NY 11211
Why did you buy this pr
oduct?: For myself
For my child
For my grandchild
Gift for someone else (adult)
Gift for someone else (child)
PRODUCT REGISTRATION

16
E-KICK AIR
ELECTRIC SCOOTER
