Jetson JUNIOR User manual

JETSON JR.
OWNER'S MANUAL
THE FUTURE OF ECO-FRIENDLY ELECTRIC BIKES

JETSON JR. ELETRIC POWERED MINI BIKE
This operator's manual contains important safety information and
maintenance information. Read it carefully before using this vehicle. Failing
to follow the warnings contained in this operators manual could result in
INJURY or DEATH.
Keep this manual in a safe place. It is very important that this ownersmanual
be reviewed by any rider and it should remain with the vehicle when
transferred to a new owner.
All information, images and specifications contained in this manual are
based on the latest product information available at the time of publication.
Due to improvements or production changes, there could be discrepancies in
this manual. Jetson reserves the right to make product changes at any time,
without notice and without obligation to make the same or similar changes to
any vehicle previously built or sold.
DO NOT OPERATE THIS VEHICLE ON PUBLIC ROADWAYS or any
location where there is vehicular traffic. Doing so woud br very dangerous
and could also be in violation of local traffic laws and restrictions. Always
wear a helmet and protective eyewear and clothing.
No part of this owners manual may be reproduced or copied without express
written permission from Jetson.

TECHNICAL PARAMETERS
SPECIFICATION SHEET

TABLE OF CONTENTS
Intoduction
Limited Warranty
Safety
Initial Setup
Operating Controls
Before You Ride
Basic Operation
Slow Speed Safety Switch
Maintenance
Troubleshooting Guide
Register your Jetson jr.
1
3 - 5
1 - 2
6 - 7
8 - 9
10 - 11
12
13
Name Of All Structural Components 14
15 - 19
20 - 23
27 - 28
CONTENTS

INTRUDUCTION
Congratulations on choosing your Jetson jr. Electric Powered Mini Bike!
Your Jetson jr. was designed as a recreational vehicle for off-road use only and by a
single rider only. This mini bike is built for younger riders who are under 150 lbs. with
minimal experience.
Before riding, please take your time to get acquainted with your mini bike and how it
works. To protect your investment we urge you to keep it well maintained. In addition
to regular maintenance, it is important to observe and perform all pre-ride and periodic
checks outlined in this manual, where you will also find helpful safety information,
instructions and helpful tips. Keep this book handy to refer to later on as questions may
come up.
As you read through this manual you will find information that is noted with a NOTICE
symbol. This is to point out key bits of information that will help you avoid damage to
your mini bike and property around you. This manual covers basic maintenance
procedures as well. For problems with your mini bike that are not covered in this
manual, please refer to jetsonbike.com and contact customer support.
Read the warranty page careful so that you understand your rights and responsibilities.
Whenever you ride, tread lightly by staying on established trails and in approved areas.
Protect the environment and keep off-road riding areas open for future use.
Please be sure to register your Jetson product and notify us of any address changes so
we may contact you in the future with any important product information.
Enjoy your Jetson jr. Electric Mini Bike!
LIMITED WARRANTY
Jetson warrants to the first buyer of the product ("Buyer") that on the date of purchase
of the product, as shown on Buyer's sales receipt (“Purchase Date”) from an approved
retail partner, the Product shall be free from defects in material or workmanship subject
to and in accordance with the terms and conditions set forth herein. The duration of this
Limited Warranty is ninety (90) days from the Purchase Date (the “Warranty Period”).
Jetson will correct, at its option, by repair or by furnishing replacement parts, any parts
determined in Jetson’s sole discretion to have a defect in material or workmanship of
the Product reported to Jetson during the Warranty Period, subject to the terms,
conditions and limitations of this Limited Warranty. At its option, Jetson may require
the Buyer to return to Jetson, at its address set forth below, at Buyer’s expense, the part
claimed to be defective for Jetson’s inspection. Jetson’s sole obligation under this
Limited Warranty is to repair and/or replace parts on the Product. If Jetson determines
that any claimed defect or problem reported by Buyer is not covered by this Limited
Warranty, Buyer shall pay Jetson its then existing charge for any repair or replacement
made by Jetson.
www.jetsonbike.com 1

LIMITED WARRANTY
TO QUALIFY FOR WARRANTY SERVICE:
1. You must present a copy of the sales receipt from an approved retail partner within90
days of purchase.
2. This product can not be used for rental or commercial use.
3. This product can not be used for competition.
LIMITATIONS OF LIABILITY
• This Limited Warranty is non-transferable after the Product’s initialsale.
• No unapproved modifications can be made to the Product, its performance or
otherwise, in orderfor this Limited Warranty to remain in effect.
• No reimbursement is provided for towing, loss of time, loss of use, inconvenience,
incidental or consequential damages.
• Warranty is void if weather related water damage is determined. Owner is responsible
for storage and protection from weather.
• Jetson makes no warranty with respect to products or trade accessories not made by
Jetson, including, but not limited to, motors, tires, wheels and batteries, such products or
trade accessories, suchitems being subject to the original manufacturer’s warranty, if
any.
• This Limited Warranty does not cover minor surface blemishes, rips, tears, or other
cosmetic damages due to normal use, or other intentional or unintentional damage to the
Product.
• This Limited Warranty will not cover any damage which results from the application
of improper cleaners, solvents or chemicals to the Product, water damage, smoke or
soot, or from exposure to saltwater, seabreeze or salt.
• This Limited Warranty will not cover any damage which results from aging, such as
fading of paint, deterioration of plated surfaces, deterioration of rubber or plastics, or
rusting.
• This Limited Warranty does not cover improper repair or misdiagnosis of problem.
• This Limited Warranty covers only parts and labor due to manufacturer defect.
Damage due to misuse or neglect, use other than as specified in the Owner's Manual,
or use under abnormal conditions are not covered by this Limited Warranty.
OWNER’S WARRANTY RESPONSIBILITIES
As the vehicle owner, you are responsible for the performance of the required
maintenance. You should maintaina record ofall maintenance performed your vehicle
and retain all receipts covering maintenance on your vehicle. You may be denied a
warranty claim solely because of your failure to ensure the performance of all scheduled
maintenance or lack of maintenance records or receipts. As the vehicle owner, you
should be aware that you may be denied your warranty coverage if your vehicle or a
part has failed due to abuse, neglect, improper maintenance, or unapproved
modifications.For any issue regarding your Jetson product, call toll free 1-(888)
976-9904
www.jetsonbike.com 2

IMPORTANT SAFETY INFORMATION
Your personal safety and the safety of those around you is our primary concern.
Operating this mini bike safely is an important responsibility and should not be taken
lightly.
Jetson jr. has provided you with safe operating procedures,warning labels on your mini
bike and in this manual. This information will alert you to potential hazards that could
harm you or others.
It is understood that it is not practical or possible to warn you about all possible hazards
associated with off-road riding and maintaining your mini bike. You must always use
your own best judgement.
Any of the above labels can indicate a danger where you or someone around you can be
SERIOUSLY INJURED if the instructions that it accompanies are not followed
carefully.
This manual is filled with important safety information, please read it carefully and be
sure that you understand it.
www.jetsonbike.com 3
Safety information is presented in a variety of forms, including:
• Safety labels and tags on the mini bike
• Safety messages proceeded by a safety symbol and one of these three signal words:
DANGER, WARNING and CAUTION.

At Jetson, safety is our number one priority. There is an inherent
level of risk when using any motorized powersports product and an electric mini bike is
no different. Read the following warnings carefully to understand how you can avoid
injury to yourself, others and your Jetson jr..
RULE NUMBER 1
READ THIS BOOK COMPLETELY BEFORE RIDING THE FIRST TIME.
There is valuable and important information in this user guide that will keep you safe
and protect your minibike from becoming damaged from neglect. Read it carefully and
understand the contents. If you have any questions please call us at 888-488-6686.
RULE NUMBER 2
PARENTAL SUPERVISION REQUIRED.
An electric powersport product is not a toy. A child can not be left alone to play with
this product. Any rider under the age of 8 should not ride this mini bike and all children
must have parental supervision when riding. The age of 8 is only an estimate as it is
affected by weight, height and riding ability. A parents’ decision to allow their child to
ride this mini bike should be based on their child’s level of maturity and motor skills.
RULE NUMBER 3
RIDE AT YOUR OWN RISK AND USE COMMON SENSE.
Any mishap while using a powersports product can result in serious
injury or death. Avoid situations where you can’t see what is in front of you or behind
you, where other traffic is present and/or where your speed is too fast for the conditions.
Always ride within your own
limitations. Always obey local laws and regulations in your area.
Do not ride your minibike where such vehicles are prohibited.
RULE NUMBER 4
NEVER RIDE ON PUBLIC ROADWAYS
This minibike is designed for off-road use only. Never ride in roadways or near any
motor vehicles.
www.jetsonbike.com 4
IMPORTANT SAFETY INFORMATION

RULE NUMBER 5
RIDE SMART.
Never attempt to carry a passenger. Keep both hands on the handlebars at all times.
Never ride while wearing headphones, earbuds, or while using a cell phone. Keep
fingers and other body parts away from moving parts like the drive chain and sprocket
as injuries may result. Never
attempt to jump off of a ramp or near stairs. Never use near a pool or near spraying
water. Always wear proper riding attire including gloves, knee pads, sturdy shoes, a
properly fitting helmet and goggles. Keep loose clothing and shoelaces away from
moving parts like the drive chain and sprockets.
FAILURE TO ADHERE TO THE ABOVE RULES AND CAUTIONS COULD
RESULT IN SERIOUS PERSONAL INJURY OR DEATH. USE WITH CAUTION,
BE AWARE OF YOUR SURROUNDINGS AND PRACTICE SAFE RIDING
TECHNIQUES.
If you have determined that your child is ready to ride please remember the following
points:
• Never let your child ride without a helmet.
• Your child’s safety is your responsibility. Do not take it lightly.
• Never push you child to try things before they are ready.
• Always supervise your child when they are riding.
• Proper maintenance and upkeep of the mini bike is key to safe riding.
PLEASE NOTE:
Any modifications or improper accessories added to the mini bike
with parts that are not manufactured by Jetson can make it unsafe. Jetson strongly
recommends that you do not remove any of the
original equipment or make any modifications that alter the design
and/or operation of the mini bike.
www.jetsonbike.com 5
IMPORTANT SAFETY INFORMATION

1. Using the 6mm Allen wrench from your
tool kit, remove the four bolts and two
handlebar clamps from the top of the fork
and set aside.
2. Place the handlebars into position in the
lower clamps. Take care to get the
handlebars centered side to side, and set
in your desired upright position.
Be careful not to lean the handlebars too far forward or
3. Place the top clamps and bolts in position and tighten the four bolts
securely to 12 ft. lbs. DONOT OVERTIGHTEN.
STEP 1.
UNPACK YOUR Jetson jr.. The contents is as follows:
1. Jetson jr. Electric Minibike
2. Tool Pouch with tools
3. Battery Charger
4. Owners Manual
Once you have located all of these items, move on to step 2.
INITIAL SET-UP
STEP 2. ATTACH THE HANDLEBARS Your Jetson jr. arrives almost
completely assembled, making it easy to start riding. The only assembly that is required
for your Jetson jr. is to attach the adjustable handlebars. All cables and controls are
already hooked up to the bike, so attaching the handlebars is easy:
backward as this will affect the bike's handling and comfort of the ride.
STEP 3. CHARGE THE BATTERY First, be sure that the toggle switch on the
top of the "tank" in switched to the off position.
Locate the battery charger port which is under the seat on the right side
(shown at right) and flip up the small round black protective cap. Underthis cap you
will see a round connector with three small contact posts. Note that there is a small
spline at the bottom of the connector.
On the round end of the battery charger cord, you will see a plug that has three small
holes and a notch which fits into the conector on the minibike. Insert the plug into the
connector firmly. There is a round ring-nut that you can use to tighten the plug into the
connector, but this is optional.
www.jetsonbike.com 6
