JETWAY G03-NU93-F User manual

Technical Manual
Of
Intel Bay Trail Series CPU
Based SBC
NO.G03-NU93-F
Revision: 3.0
Release date: October 1, 2019
Trademark:
* Specifications and Information contained in this documentation are furnished for information use only, and are
subject to change at any time without notice, and should not be construed as a commitment by manufacturer.

ii
Environmental Protection Announcement
Do not dispose this electronic device into the trash while discarding. To minimize
pollution and ensure environment protection of mother earth, please recycle.

iii
ENVIRONMENTAL SAFETY INSTRUCTION...........................................................................iv
USER’S NOTICE .......................................................................................................................v
MANUAL REVISION INFORMATION.......................................................................................v
ITEM CHECKLIST.....................................................................................................................v
CHAPTER 1 INTRODUCTION OF THE MOTHERBOARD
1-1 FEATURE OF MOTHERBOARD................................................................................1
1-2 SPECIFICATION.........................................................................................................2
1-3 LAYOUT DIAGRAM....................................................................................................3
CHAPTER 2 HARDWARE INSTALLATION
2-1 JUMPER SETTING .....................................................................................................7
2-2 CONNECTORS AND HEADERS................................................................................9
2-2-1 CONNECTORS .............................................................................................9
2-2-2 HEADERS .....................................................................................................13
CHAPTER 3 INTRODUCING BIOS
3-1 ENTERING SETUP .....................................................................................................15
3-2 BIOS MENU SCREEN ................................................................................................16
3-3 FUNCTION KEYS .......................................................................................................17
3-4 GETTING HELP ..........................................................................................................17
3-5 MEMU BARS...............................................................................................................18
3-6 MAIN MENU................................................................................................................19
3-7 ADVANCED MENU.....................................................................................................20
3-8 CHIPSET MENU..........................................................................................................27
3-9 SECURITY MENU.......................................................................................................29
3-10 BOOT MENU...............................................................................................................30
3-11 SAVE & EXIT MENU...................................................................................................32
TABLE OF CONTENT

iv
Environmental Safety Instruction
Avoid the dusty, humidity and temperature extremes. Do not place the product in
any area where it may become wet.
0 to 60 centigrade is the suitable temperature. (The figure comes from the request
of the main chipset)
Generally speaking, dramatic changes in temperature may lead to contact
malfunction and crackles due to constant thermal expansion and contraction from
the welding spots’ that connect components and PCB. Computer should go
through an adaptive phase before it boots when it is moved from a cold
environment to a warmer one to avoid condensation phenomenon. These water
drops attached on PCB or the surface of the components can bring about
phenomena as minor as computer instability resulted from corrosion and oxidation
from components and PCB or as major as short circuit that can burn the
components. Suggest starting the computer until the temperature goes up.
The increasing temperature of the capacitor may decrease the life of computer.
Using the close case may decrease the life of other device because the higher
temperature in the inner of the case.
Attention to the heat sink when you over-clocking. The higher temperature may
decrease the life of the device and burned the capacitor.

v
USER’S NOTICE
COPYRIGHT OF THIS MANUAL BELONGS TO THE MANUFACTURER. NO PART OF THIS MANUAL,
INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT MAY BE REPRODUCED, TRANSMITTED
OR TRANSLATED INTO ANY LANGUAGE IN ANY FORM OR BY ANY MEANS WITHOUT WRITTEN
PERMISSION OF THE MANUFACTURER.
THIS MANUAL CONTAINS ALL INFORMATION REQUIRED TO USE THIS MOTHER-BOARD SERIES AND WE
DO ASSURE THIS MANUAL MEETS USER’S REQUIREMENT BUT WILL CHANGE, CORRECT ANY TIME
WITHOUT NOTICE. MANUFACTURER PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY
KIND, AND WILL NOT BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTIAL OR CONSEQUENTIAL
DAMAGES (INCLUDING DAMANGES FOR LOSS OF PROFIT, LOSS OF BUSINESS, LOSS OF USE OF DATA,
INTERRUPTION OF BUSINESS AND THE LIKE).
PRODUCTS AND CORPORATE NAMES APPEARING IN THIS MANUAL MAY OR MAY NOT BE
REGISTERED TRADEMARKS OR COPYRIGHTS OF THEIR RESPECTIVE COMPANIES, AND THEY ARE
USED ONLY FOR IDENTIFICATION OR EXPLANATION AND TO THE OWNER’S BENEFIT, WITHOUT
INTENT TO INFRINGE.
Manual Revision Information
Reversion Revision History Date
3.0 Third Edition October 1, 2019
Item Checklist
Motherboard
Cable(s)

1
Chapter 1
Introduction of the Motherboard
1-1 Feature of Motherboard
Onboard Intel®Bay Trail Series Processor, with low power consumption never
denies high performance
Onboard 1* mSATA slot
Onboard 1* half-size Mini-PCIE slot
Onboard 2 * RJ-45 gigabit Ethernet LAN port
Support dual HDMI outputs
Support USB 3.0 data transport demand
Support CPU Smart FAN
Compliance with ErP standard
Support Watchdog function

2
1-2 Specification
Spec
Description
Design
8-layer SBC; PCB size: 10.1 cm x 10.1 cm
Embedded CPU
Integrated with Intel®Bay Trail-D/M/I series CPU
Memory Slot
1 * DDR3L SODIMM Slot for un-buffered Single Channel
DDRIIIL 1066~1333* MHz SDRAM, expandable to 8GB
*DDR3L 1333 Mhz is optional for model with specific CPU. Pl
ease refer
to the actual product you purchase and consult your dealer for more
information.
Expansion Slot
1* Half-size Mini-PCIE slot
Storage
1* SATAII 3Gb/s port
1* MSATA slot
LAN Chip
Integrated with Intel 82583V PCI-E Gigabit LAN chip
Support Fast Ethernet LAN function of providing
10/100/1000Mbps Ethernet data transfer rate
Audio Chip
2-CH ALC887 HD audio chip
BIOS
AMI 64MB Flash ROM
Rear Panel I/O
2* RJ-45 LAN port
2* USB 2.0 port
2* HDMI port
1* Audio Line-Out / SPDIF-Out jack

1* DC 9V~24V power-in connector
Front Panel I/O
1* COM port
1* USB 2.0 port
1* USB 3.0 port
Internal I/O
1* Internal DC 9V~24V power-in connector
1* SATA Power connector
1* SPEAK_CON header

1* Front panel header

3
1* CPU FAN header
1-3 Layout Diagram
Rear IO Panel Diagram:
Front IO Panel Diagram:
USB 3.0 Port
COM Port
HDMI Port
HDMI Port
Line-OUT
/Optical SPDIF OUT
9V~24V DC
Power-in
Connector
RJ-45 LAN Ports
USB 2.0 Ports
USB 2.0 Port

4
Internal Diagram-Front Side:
DDR3L SODIMM Slot
MSATA Slot
Half-size
Mini-PCIE Slot
Serial Port (COM1)
JBAT
9V ~24V DC
Power-in Connector
RJ-45 LAN Port
Over USB 2.0 Port
HDMI Ports
USB 2.0 Port over
USB 3.0 Port
Line-Out
/Optical SPDIF Out
RJ-45 LAN Port
Over USB 2.0 Port
Speaker
Connector
USB 2.0 Port
Header
SATAII Port
SATA Hard Disk
Power-Out Connector
JPCOM1
JME
JP1
AT-MODE1

5
Internal Diagram-Back Side:
Intel CPU
CPUFAN1 Header
Front Panel Header

6
Jumper
Jumper
Name
Description
JBAT
CMOS RAM Clear Function Setting
2-Pin Block
JME
Clear ME RTC Function Setting
2-Pin Block
JP1
Security Measure Function Select
2-Pin Block
AT-MODE1
AT Mode Function Select
2-Pin Block
JPCOM1
COM1 Port Pin9 Function Select
4-Pin Block
Connectors
Connector
Name
UL1(Top)/ UL2(Top)
RJ-45 LAN Port Connector x2
UL1(Bottom)/ UL2(Bottom)
USB 2.0 Port Connector x2
HDMI1
HDMI Connector x2
HP_SPDIF1
Line Out Connector
/SPDIF Out Connector
USB1(Top)
USB 2.0 Port Connector
USB1(Bottom)
USB 3.0 Port Connector
COM1
Serial Port Connector
DCIN
DC 9V~24V Power–in Connector
ATX2P
Internal 9V~24V Power–in Connector
SATA1
SATA Port Connector
PWOUT1
SATA Power out Connector
Headers
Header
Name
Description
F_USB1
USB 2.0 Port Header
9-pin Block
SPEAK_CON
Speaker Header
4-pin Block
FP_CON1
Front Panel Header
4-pin Block
CPUFAN1
CPUFAN Header
3-pin Block

7
Chapter 2
Hardware Installation
2-1 Jumper Setting
JBAT (2-pin): Clear CMOS Setting
CMOS Clear Setting
1-2 Closed：Clear CMOS
JBAT
1-2 Open: Normal；
1
1
JME (2-pin): Clear ME_RTC Function Setting
1-2 Closed：Clear ME_RTC.
JME
1-2 Open: Normal；
1
1

8
JP1 (2-pin): Security Measure Function Select
1-2 Closed: Disable Security Measures
in the Flash Descriptor(Override).
JP1
1
1-2 Open:Enable Security Measures
in the Flash Descriptor(Default);
1
AT-MODE1 (2-pin): AT Mode Function Select
1-2 Closed：AT Mode Selected.
AT-MODE1
1-2 Open: ATX Mode Selected;
1
1
*Pin 1-2 closed: AT_MODE function is enabled. User needs to restart the system for
the settings to take effect. In this case your computer will automatically turns on when
power supply resumes.

9
JCOMP1 (4-pin): COM1 Port Pin9 Function Select
JCOMP1→COM1
4-6 Closed:
RI= 12V.
6
4
2
3-4 Closed:
RI= 5V;
2-4 Closed:
RI=RS232;
3
1
5
1
3
5
2
4
6
1
3
5
2
4
6
2-2 Connectors and Headers
2-2-1 Connectors
Rear IO Panel Diagram:
HDMI Port
HDMI Port
Line-OUT
/Optical SPDIF OUT
9V~24V DC
Power-in
Connector
RJ-45 LAN Ports
USB 2.0 Ports

10
Front IO Panel Diagram:
Icon Name Function
RJ-45 LAN Port This connector is standard RJ-45 LAN jack
for
Network connection.
HDMI Port T
o connect display device that support HDMI
specification.
USB 2.0 Port To connect USB keyboard, mou
se or other devices
compatible with USB specification.
Line-Out Connector
/Optical SPDIF-Out
Connector
For user to connect external speaker, earphones,
etc to transfer system audio output.
This connector can function as optical SPDIF-Out
jack with compatible cables & devices.
*COM1 Port
Mainly for user to connect external MODEM or
other devices that supports
Serial Communications Interface.
USB 3.0 Port To
connect USB keyboard, mouse or other devices
compatible with USB specification. USB 3.0 por
ts
supports up to 5Gbps data transfer rate.
USB 3.0 Port
COM Port
USB 2.0 Port

11
DC-in Power Connector
For user to connect compatible power adapter to
provide power supply for the system.
COM1 (9-pin Block): RS232/422/485 Port
COM1 port can function as RS232/422/485 port. In normal settings COM1 functions as RS232 port.
With compatible COM cable COM1 can function as RS422 or RS 485 port.
User also needs to go to BIOS to set ‘Transmission Mode Select’ for COM1 (refer to Page 21) at first,
before using specialized cable to connect different pins of this port.
ATX2P (2-pin Block): DC 9V~24V Power-in Connector

12
SATA1 (7-pin Block): SATAII Port connector
SATA1 port is a SATAII port that supports 3GB/s transfer rate.
Pin No.
Definition
1
GND
2
TXP
3
TXN
4
GND
5
RXN
6
RXP
7
GND
PWOUT1 (4-pin): SATA Power Connector
Pin No.
Definition
1
+5V
2
GND
3
GND
4
+12V

13
2-2-2 Header
F_USB1 (9-pin): USB 2.0 Port Header
Pin 1
VCC
-DATA
GND
+DATA
VCC
NC
-DATA
GND
+DATA
SPEAK_CON (4-pin): Speaker Connector
Pin No.
Definition
1
L-
2
L+
3
R+
4
R-

14
FP_CON1 (4-pin): Front Panel Connector
Pin1
Pin No.
Definition
1
Power_SW
2
GND
3
PWRLED -
4
PWRLED+
CPUFAN1 (4-pin): CPUFAN Connector
Pin1
Pin No.
Definition
1
VCC
2
GND
3
Fan Detect

15
Chapter 3
Introducing BIOS
Notice! The BIOS options in this manual are for reference only. Different
configurations may lead to difference in BIOS screen and BIOS
screens in manuals are usually the first BIOS version when the board is
released and may be different from your purchased motherboard.
Users are welcome to download the latest BIOS version form our
official website.
The BIOS is a program located on a Flash Memory on the motherboard. This program
is a bridge between motherboard and operating system. When you start the computer,
the BIOS program will gain control. The BIOS first operates an auto-diagnostic test
called POST (power on self test) for all the necessary hardware, it detects the entire
hardware device and configures the parameters of the hardware synchronization.
Only when these tasks are completed done it gives up control of the computer to
operating system (OS). Since the BIOS is the only channel for hardware and software
to communicate, it is the key factor for system stability, and in ensuring that your
system performance as its best.
3-1 Entering Setup
Power on the computer and by pressing <Del> immediately allows you to enter Setup.
If the message disappears before your respond and you still wish to enter Setup,
restart the system to try again by turning it OFF then ON or pressing the “RESET”
button on the system case. You may also restart by simultaneously pressing <Ctrl>,
<Alt> and <Delete> keys. If you do not press the keys at the correct time and the
system does not boot, an error message will be displayed and you will again be asked
to
Press <Del> to enter Setup
