JETWAY P4MVM User manual

P4MVM/P4MVMP
USER'S MANUAL
M/B For Socket 478 Pentium 4 Processor
NO. G03-P4MVMP
Rev:1.0
Release date: April 2004
Trademark:
* Specifications and Information contained in this documentation are furnished for information use only, and are
subject to change at any time without notice, and should not be construed as a commitment by manufacturer.

i
USER’S NOTICE.....................................................................................................................ii
MANUAL REVISION INFORMATION ..............................................................................ii
COOLING SOLUTIONS........................................................................................................ii
CHAPTER 1 INTRODUCTION OF P4MVM/P4MVMP
1-1 FEATURE OF MOTHERBOARD...................................................................................... 1
1-2 SPECIFICATION.................................................................................................................. 2
1-3 PERFORMANCE LIST........................................................................................................ 3
1-4 LAYOUT DIAGRAM & JUMPER SETTING................................................................... 4
CHAPTER 2 HARDWARE INSTALLATION
2-1 HARDWARE INSTALLATION STEPS ............................................................................ 6
2-2 CHECKING MOTHERBOARD'S JUMPER SETTING.................................................. 6
2-3 INSTALL CPU....................................................................................................................... 8
2-3-1 GLOSSARY................................................................................................................ 8
2-3-2 ABOUT INTEL PENTIUM 4 478-PIN CPU........................................................... 9
2-4 INSTALL MEMORY............................................................................................................ 9
2-5 EXPANSION CARD ............................................................................................................. 10
2-5-1 PROCEDURE FOR EXPANSION CARD INSTALLATION .............................. 10
2-5-2 ASSIGNING IRQ FOR EXPANSION CARD ........................................................ 10
2-5-3 INTERRUPT REQUEST TABLE FOR THIS MOTHERBOARD ...................... 11
2-5-4 AGP SLOT.................................................................................................................. 11
2-6 CONNECTORS, HEADERS................................................................................................ 12
2-6-1 CONNECTORS ......................................................................................................... 12
2-6-2 HEADERS .................................................................................................................. 14
2-7 STARTING UP YOUR COMPUTER................................................................................. 18
CHAPTER 3 INTRODUCING BIOS
3-1 ENTERING SETUP.............................................................................................................. 19
3-2 GETTING HELP................................................................................................................... 19
3-3 THE MAIN MENU................................................................................................................ 20
3-4 STANDARD CMOS FEATURES........................................................................................ 21
3-5 ADVANCED BIOS FEATURES.......................................................................................... 22
3-6 ADVANCED CHIPSET FEATURES.................................................................................. 24
3-6-1 DRAM TIMING SETTINGS.................................................................................... 25
3-6-2 AGP FUNCTION SETTINGS.................................................................................. 26
3-6-3 PCI TIMING SETTINGS......................................................................................... 26
3-7 INTEGRATED PERIPHERALS......................................................................................... 26
3-7-1 ONCHIP IDE FUNCTION....................................................................................... 27
3-7-2 ONCHIP DEVICE FUNCTION............................................................................... 28
3-7-3 ONCHIP SUPER IO FUNCTION ........................................................................... 29
3-8 POWER MANAGEMENT SETUP ..................................................................................... 30
3-8-1 PM WAKE UP EVENTS.......................................................................................... 31
3-8-1.1 IRQS ACTIVITIES ................................................................................................ 31
3-9 PNP/PCI CONFIGURATION SETUP................................................................................ 32
3-9-1 IRQ RESOURCES.................................................................................................... 33
3-10 PC HEALTH STATUS........................................................................................................ 33
3-11 MISCELLANEOUS CONTROL........................................................................................ 34
3-12 LOAD STANDARD/OPTIMIZED DEFAULTS............................................................... 35
3-13 SET SUPERVISOR/USER PASSWORD .......................................................................... 35
CHAPTER 4 DRIVER & FREE PROGRAM INSTALLATION
MAGIC INSTALL SUPPORTS WINDOWS 9X/ME/NT4.0/2000/XP....................................... 36
4-1 VIA 4 IN 1 INSTALL VIA SERVICE PACK 4 IN 1 DRIVER .............................. 37
4-2 VGA INSTALL PROSAVAGE DDR VGA DRIVER.................................... 38
4-3 SOUND INSTALL ALC/CMI AUDIO CODEC DRIVER................................. 39
4-4 LAN INSTALL VIA 10/100MB LAN CONTROLLER DRIVER................ 40
4-5 PC-HEALTH WINBOND HARDWARE DOCTOR MONITORING SOFTWARE 40
4-6 MAGIC BIOS INSTALL BIOS LIVE UPDATE UTILITY ......................................... 41
4-7 USB2.0 INSTALL VIA USB2.0 DEVICE DRIVER........................................... 43
4-8 PC-CILLIN INSTALL PC-CILLIN2004 ANTI-VIRUS PROGRAM ..................... 44
4-9 HOW TO DISABLE ON-BOARD SOUND........................................................................ 45
4-10 HOW TO UPDATE BIOS .................................................................................................... 45
TABLE OF CONTENT

ii
USER’S NOTICE
COPYRIGHT OF THIS MANUAL BELONGS TO THE MANUFACTURER. NO PART OF THIS
MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT MAY BE
REPRODUCED, TRANSMITTED OR TRANSLATED INTO ANY LANGUAGE IN ANY FORM OR
BY ANY MEANS WITHOUT WRITTEN PERMISSION OF THE MANUFACTURER.
THIS MANUAL CONTAINS ALL INFORMATION REQUIRED TO USE P4MVM/P4MVMP
MOTHER-BOARD AND WE DO ASSURE THIS MANUAL MEETS USER’S REQUIREMENT BUT
WILL CHANGE, CORRECT ANY TIME WITHOUT NOTICE. MANUFACTURER PROVIDES THIS
MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, AND WILL NOT BE LIABLE FOR ANY
INDIRECT, SPECIAL, INCIDENTIAL OR CONSEQUENTIAL DAMAGES (INCLUDING
DAMANGES FOR LOSS OF PROFIT, LOSS OF BUSINESS, LOSS OF USE OF DATA,
INTERRUPTION OF BUSINESS AND THE LIKE).
PRODUCTS AND CORPORATE NAMES APPEARING IN THIS MANUAL MAY OR MAY NOT BE
REGISTERED TRADEMARKS OR COPYRIGHTS OF THEIR RESPECTIVE COMPANIES, AND
THEY ARE USED ONLY FOR IDENTIFICATION OR EXPLANATION AND TO THE OWNER’S
BENEFIT, WITHOUT INTENT TO INFRINGE.
Manual Revision Information
Reversion Revision History Date
1.0 First Edition April 2004
Item Checklist
5P4MVM/P4MVMP motherboard
5Cable for IDE/Floppy
□Cable for COM2 Connector (Option)
5CD for motherboard utilities
□Cable for USB Port 3/4 (Option)
5P4MVM/P4MVMP User’s Manual
Intel Pentium 4 Processor Family
Cooling Solutions
As processor technology pushes to faster speeds and higher performance, thermal management
becomes increasingly crucial when building computer systems. Maintaining the proper thermal
environment is key to reliable, long-term system operation. The overall goal in providing the proper
thermal environment is keeping the processor below its specified maximum case temperature.
Heatsinks induce improved processor heat dissipation through increased surface area and concentrated
airflow from attached fans. In addition, interface materials allow effective transfers of heat from the
processor to the heatsink. For optimum heat transfer, Intel recommends the use of thermal grease and
mounting clips to attach the heatsink to the processor.
When selecting a thermal solution for your system, please refer to the website below for collection of
heatsinks evaluated and recommended by Intel for use with Intel processors. Note, those heatsinks are
recommended for maintaining the specified Maximum T case requirement. In addition, this collection
is not intended to be a comprehensive listing of all heatsinks that support Intel processors.
For vendor list of heatsink and fan, please visit :
http://developer.intel.com/design/Pentium4/components/index

1
Chapter 1
Introduction of P4MVM/P4MVMP Motherboard
1-1 Feature of motherboard
The P4MVM/P4MVMP motherboard is design for use Intel Pentium 4 Processor in 478 Pin
Package Processor with the VIA P4M266A(CE) Chipset delivers a high performance and
professional desktop platform solution. Which utilize the Socket 478 design and the memory
size expandable to 2.0GB.
These motherboards use the newest VIA P4M266A(CE) Chipset, supports 533MHz System
Bus in data transfer rate. Supports Hyper Threading/ Prescott CPU. These motherboard
provided 100MHz/133MHz Memory clock frequency, support DDR266/DDR200 DDR
Module. The motherboard embedded VIA VT8235 V-Link LPC South Bridge offer ULTRA
ATA 133 to provide speedier HDD throughout that boosts overall system performance. The
P4MVMP used the VIA VT6103 LAN PHY chip Support Fast Ethernet LAN function
provide 10/100 Mb/s data transfer rate.
These motherboards also has an integrated 6-channel AC’97 CODEC on board which is fully
compatible with Sound Blaster Pro®that gives you the best sound quality and compatibility.
These motherboards integrated High Performance & High Quality 3D Accelerator supports
Ultra-AGPII with 2GB/s bandwidth, built-in MPEG-2/1 Video Decoder and Video
Accelerator supports VCD DVD HDTV decoding and playback, supports graphic and video
overlay function. Built-in programmable 24-bit true-color RAMDAC up to 250MHz pixel
clock. Programmable frame buffer size from 8MB and up to 32MB. For those wanting even
greater graphic performance, an AGP 4X slot is included on the board, support AGP 2X/4X
capability and Fast write Transaction.
With USB control as well as capability of expanding to 6x USB2.0 function ports delivering
480Mb/s bandwidth and rich connectivity, these motherboards meet future USB demand also
has built-in hardware monitor function to monitor and protect your computer.
A useful software tool “Magic BIOS” examines the BIOS version automatically with the
correct version available on the web, links the site for users to download the latest version of
BIOS and updates the BIOS. Use “Magic BIOS”, users can download and update BIOS
automatically and completed under the OS easily.
These motherboards provide high performance & meets future specification demand. It is
really wise choice for your computer.

2
1-2 Specification
Spec Description
Design ∗Micro ATX form factor 4 layers PCB size: 24.4x22.4cm
Chipset ∗VIA P4M266A(CE) North Bridge Chipset
∗VIA VT8235 South Bridge Chipset
CPU Socket
(mPGA478B Socket) ∗Support Intel Pentium 4 478 Pin package utilizes Flip-Chip Pin
Grid Array (FC-PGA2) package processor
∗Support 1.5G∼3.2G 478 Pin Pentium 4 processor
∗Support Hyper Threading /Prescott CPU
∗Reserves support for future Intel Pentium 4 processors
Memory Socket ∗184-pin DDR Module socket x 2
∗Support 2 pcs DDR266/DDR200 DDR Modules Expandable to
2.0GB
Expansion Slot ∗AGP slot x1 support AGP 2.0 & 4X mode
∗32-bit PCI slot x3
Integrate IDE ∗Two PCI IDE controllers support PCI Bus Mastering, ATA
PIO/DMA and the ULTRA DMA 33/66/100/133 functions that
deliver the data transfer rate up to 133 MB/s
VGA
∗Integrated High Performance & High Quality 3D Accelerator
∗Support Ultra-AGPII with 2GB/s bandwidth
∗Built-in programmable 24-bit true-color RAMDAC up to
250MHz pixel clock
∗Programmable frame buffer size from 8MB and up to 32MB.
LAN
(Only for P4MVMP) ∗Support Fast Ethernet LAN function provide 10/100 Mb/s data
transfer rate
Audio ∗AC’97 Digital Audio controller integrated
∗6-channel AC’97 Audio CODEC on board
∗Audio driver and utility included
BIOS ∗Award 2MB Flash ROM
Multi I/O ∗PS/2 keyboard and PS/2 mouse connectors
∗Floppy disk drive connector x1
∗Parallel port x1 (connecting cable option)
∗Serial port x1
∗USB2.0 port x2 and headers x 4 (connecting cable option)
∗Audio connector (Line-in, Line-out, MIC & Game Port)

3
1-3 Performance List
The following performance data list is the testing result of some popular benchmark
testing programs. These data are just referred by users, and there is no responsibility
for different testing data values gotten by users (the different Hardware & Software
configuration will result in different benchmark testing results.)
Performance Test Report
CPU: Intel Pentium 4 1.9GHz mPGAB package
DRAM: 256MB DDR266 x1 (SAMSUNG K4H280838B-TCB0)
VGA Expansion Card: NVDIA Geforce2 MX-400 64MB (1024x768xHi-color)
Hard Disk Driver: IBM DTLA-305040 (ATA-100)
BIOS: Award Optimal default
OS: Win 98SE
DDR266
3D Mark 2000 5432
3D Mark 2001 2509
3D Winbench 2000 104
Final Reality 9.99
Content Creation Winstone 2000 43.2
Content Creation Winstone 2001 50.3
Content Creation Winstone 2002 20.1
Business Winstone2001 44.1
Winbench 99:
CPU Mark 99 111
FPU Winmark 99 6610
Business Disk Winmark99 7150
Hi-end Disk Winmark99 18800
Business Graphic Winmark 434
Hi-end Graphic Winmark 1260
SYS Mark 2000/2001 : SISMark 2000/2001 Rating (Internet Content
Creation / Office Productivity)
SISMark 2000 208 (226/195)
SISMark 2001 150 (175/129)
SISOFT Sandra 2001 :
Dhrystone ALU MIPS 3626
Whetstone FPU MFLOPS 1137/2371
Int ALU/RAM MB/S 1181
Float FPU/RAM MB/S 1183
Integer SSE2 IT/S 7547
Floating-Point SSE2 IT/S 9352
QUAKE3 DEMO1 FPS 169.1
DEMO2 FPS 169.7
WCPUID System/CPU Clock 101/1918.93

4
1-4 Layout Diagram & Jumper Setting
LINE-OUT
LINE-IN
MIC
GAME/MIDI PORT
COM1 VGA
PS/2 MOUSE
PS/2 Keyboard
USB
PRINT
(for P4MVMP)
LAN
Winbond 83697HF Chip
Front Panel Audio
PC99 Back Panel
CD Audio
PCI Slot
AGP Slot
KB Power ON Jumper
(JP2)
Floppy Connector
VIA Chip P4M266A
Front Panel Connector
ATA 133 IDE Conn.
Clear CMOS (JBAT)
ATX Power Conn.
USB Port (USB2)
(only for P4MVMP)
CPU FAN
2MBit Flash ROM BIOS
CPU Socket
DDR DIMM X2
Wake On LAN
SYSFAN
VIA VT8235 Chip
ATX 12V Power Connector
USB Port
/LAN Connector
(for P4MVMP)
PS2 KB/Mouse Port
SYSFAN1
(USB1) USB Port
USB Power ON Jumper
(JP4)
(JP3)
CPU F.S.B. Frequency Selector

5
Jumpers
Jumper Name Description Page
JBAT CMOS RAM Clear 3-pin Block P.6
JP2 Keyboard Power On Enable/Disabled 3-pin Block P.7
JP3 Front Side Bus Frequency Setting 2x2-pin Block P.7
JP4 USB Power On Enable/Disabled 3-pin Block P.7
Connectors
Connector Name Description Page
ATXPWR ATX Power Connector 20-pin Block P.12
ATX12V ATX 12V Power Connector 4-pin Block P.12
PS2KBM PS/2 Mouse & PS/2 Keyboard
Connector 6-pin Female P.12
USB USB Port Connector 4-pin Connector P.12
LAN LAN Port Connector RJ-45 Connector P.12
PARALL Parallel Port Connector 25-pin Female P.12
AUDIO_GAME Audio/Game Connector 3 phone jack + 15-pin Connector P.13
COM1 Serial Port COM1 Connector 9-pin Connector P.13
VGA VGA Connector 15-pin Female P.13
FDD Floppy Driver Connector 34-pin Block P.13
IDE1/IDE2 Primary/Secondary IDE Connector 40-pin Block P.13
for P4MVMP Only
HeadersHeader Name Description Page
AUDIO SPEAKER, MIC header 9-pin Block P.15
USB1 USB Port Headers 9-pin Block P.15
USB2 USB Port Headers 9-pin Block P.15
HD LED IDE activity LED 2-pin Block P.15
RESET Reset switch lead 2-pin Block P.15
SPEAK PC Speaker connector 4-pin Block P.15
PWR LED Power LED 2-pin Block P.15
PWR BTN Power switch 2-pin Block P.16
WOL Wake On-LAN Headers 3-pin Block P.16
SFAN1, SYSFAN, CPUFAN FAN Headers 3-pin Block P.17
CD_IN CD Audio-In Headers 4-pin Block P.17
Expansion Sockets
Socket/Slot Name Description Page
ZIF Socket 478 Pin CPU Socket 478-pin mPGA CPU Socket P.9
DDR1, DDR2 DDR Module Socket 184-pin DDR Module Socket P.9
PCI1 ∼PCI3 PCI Slot 32-bit PCI Local Bus Expansion slots P.10
AGP AGP 4X Mode Slot AGP Expansion Slot P.11

6
Chapter 2
Hardware installation
2-1 Hardware installation Steps
Before using your computer, you had better complete the following steps:
1. Check motherboard jumper setting
2. Install CPU and Fan
3. Install System Memory (DIMM)
4. Install Expansion cards
5. Connect IDE and Floppy cables, Front Panel /Back Panel cable
6. Connect ATX Power cable
7. Power-On and Load Standard Default
8. Reboot
9. Install Operating System
10. Install Driver and Utility
2-2 Checking Motherboard’s Jumper Setting
(1) CMOS RAM Clear (3-pin) : JBAT
A battery must be used to retain the motherboard configuration in CMOS RAM short 1-2
pins of JBAT to store the CMOS data.
To clear the CMOS, follow the procedure below:
1. Turn off the system and unplug the AC power
2. Remove ATX power cable from ATX power connector
3. Locate JBAT and short pins 2-3 for a few seconds
4. Return JBAT to its normal setting by shorting pins 1-2
5. Connect ATX power cable back to ATX power connector
Note: When should clear CMOS
1. Troubleshooting
2. Forget password
3. After over clocking system boot fail
CMOS RAM Clear Setting
JBAT 13
2-3 closed Clear CMOS
JBAT 13
1-2 closed Normal (Default)
(2) Keyboard/USB Power On function Enabled/Disabled: JP2, JP4

7
USB Power On Setting
2-3 closed USB Power ON Enabled
JP4 13
JP4
13
1-2 closed USB Power ON Disable
(Default)
Keyboard Power On Setting
2-3 closed
Keyboard Power ON Enabled
JP2
1
3
JP2 1
3
1-2 closed
Keyboard Power ON Disable
(Default)
(3) CPU Front Side Bus Frequency Setting Jumper : JP3
CPU Clock 1-2 3-4
AUTO ON OFF (Default)
100MHz OFF ON
133MHz OFF OFF
CPU Front Side Bus Frequency Setting
AUTO
(Default)
JP3
2
1 3
4
100MHz 133MHz
JP3
2
13
4
JP3
2
13
4
2-3 Install CPU

8
2-3-1 Glossary
Chipset (or core logic) - two or more integrated circuits which control the interfaces between
the system processor, RAM, I/O devises, and adapter cards.
Processor slot/socket - the slot or socket used to mount the system processor on the
motherboard.
Slot (AGP, PCI, ISA, RAM) - the slots used to mount adapter cards and system RAM.
AGP - Accelerated Graphics Port - a high speed interface for video cards; runs at 1X
(66MHz), 2X (133MHz), or 4X (266MHz).
PCI - Peripheral Component Interconnect - a high speed interface for video cards, sound
cards, network interface cards, and modems; runs at 33MHz.
ISA - Industry Standard Architecture - a relatively low speed interface primarily used for
sound cards and modems; runs at approx. 8MHz.
Serial Port - a low speed interface typically used for mouse and external modems.
Parallel Port - a low speed interface typically used for printers.
PS/2 - a low speed interface used for mouse and keyboards.
USB - Universal Serial Bus - a medium speed interface typically used for mouse, keyboards,
scanners, and some digital cameras.
Sound (interface) - the interface between the sound card or integrated sound connectors and
speakers, MIC, game controllers, and MIDI sound devices.
LAN (interface) - Local Area Network - the interface to your local area network.
BIOS (Basic Input/Output System) - the program logic used to boot up a computer and
establish the relationship between the various components.
Driver - software, which defines the characteristics of a device for use by another device or
other software.
Processor - the "central processing unit" (CPU); the principal integrated circuit used for
doing the "computing" in "personal computer"
Front Side Bus Frequency - the working frequency of the motherboard, which is generated
by the clock generator for CPU, DRAM and PCI BUS.
CPU L2 Cache - the flash memory inside the CPU, normal it depend on CPU type.
2-3-2 About Intel Pentium 4 478-pin CPU

9
This motherboard provides a 478-pin surface mount, Zero Insertion Force (ZIF) socket,
referred to as the mPGA478B socket supports Intel Pentium 4 processor in the 478 Pin
package utilizes Flip-Chip Pin Grid Array (FC-PGA2) package technology.
The CPU that comes with the motherboard should have a cooling FAN attached to prevent
overheating. If this is not the case, then purchase a correct cooling FAN before you turn on
your system.
WARNING! Be sure that there is sufficient air circulation across the processor’s
heatsink and CPU cooling FAN is working correctly, otherwise it may
cause the processor and motherboard overheat and damage, you may install
an auxiliary cooling FAN, if necessary.
To install a CPU, first turn off your system and remove its cover. Locate the ZIF socket and
open it by first pulling the level sideways away from the socket then upward to a 90-degree
angle. Insert the CPU with the correct orientation as shown below. The notched corner
should point toward the end of the level. Because the CPU has a corner pin for two of the
four corners, the CPU will only fit in the orientation as shown.
CPU ZIF mPGAB Socket
Colden Arrow
mPGA478B
When you put the CPU into the ZIF socket. No force require to insert of the CPU, then press
the level to Locate position slightly without any extra force.
2-4 Install Memory
This motherboard provides two 184-pin DDR DUAL INLINE MEMORY MODULES
(DIMM) sites for DDR memory expansion available from minimum memory size of 64MB to
maximum memory size of 2.0GB DDR SDRAM.
Valid Memory Configurations
Bank 184-pin DDR DIMM PCS Total Memory
Bank 0, 1 (DDR1) DDR266/DDR200 DDR DRAM Module X1 64MB∼1.0GB
Bank 2, 3 (DDR2) DDR266/DDR200 DDR DRAM Module X1 64MB∼1.0GB
Total System Memory (Max. 2.0GB) X2 64MB∼2.0GB
Generally, installing DDR SDRAM modules to your motherboard is very easy, you can refer
to figure 2-4 to see what a 184-pin DDR SDRAM module looks like.

10
DDR2 (BANK2+ BANK3) DDR1 (BANK0+ BANK1)
NOTE! When you install DIMM module fully into the DIMM socket the eject tab
should be locked into the DIMM module very firmly and fit into its
indention on both sides.
WARNING! For the DDR SDRAM CLOCK is set at 133MHz, use only DDR266- compliant
DDR Modules. When this motherboard operate at 133Mhz, most system will
not even boot if non-compliant modules are used because of the strict
timing issues, if your DDR Modules are not DDR266-compliant, set the
SDRAM clock to 100MHz to ensure system stability.
2-5 Expansion Cards
WARNING! Turn off your power when adding or removing expansion cards or other
system components. Failure to do so may cause severe damage to both
your motherboard and expansion cards.
2-5-1 Procedure For Expansion Card Installation
1. Read the documentation for your expansion card and make any necessary hardware or
software setting for your expansion card such as jumpers.
2. Remove your computer’s cover and the bracket plate on the slot you intend to use.
3. Align the card’s connectors and press firmly.
4. Secure the card on the slot with the screen you remove above.
5. Replace the computer system’s cover.
6. Set up the BIOS if necessary.
7. Install the necessary software driver for your expansion card.
2-5-2 Assigning IRQs For Expansion Card
Some expansion cards need an IRQ to operate. Generally, an IRQ must exclusively assign to
one use. In a standard design, there are 16 IRQs available but most of them are already in use.
Figure 2-4

11
Standard Interrupt Assignments
IRQ Priority Standard function
0 N/A System Timer
1 N/A Keyboard Controller
2 N/A Programmable Interrupt
3 * 8 Communications Port (COM2)
4 * 9 Communications Port (COM1)
5 * 6 Sound Card (sometimes LPT2)
6 * 11 Floppy Disk Controller
7 * 7 Printer Port (LPT1)
8 N/A System CMOS/Real Time Clock
9 * 10 ACPI Mode when enabled
10 * 3 IRQ Holder for PCI Steering
11 * 2 IRQ Holder for PCI Steering
12 * 4 PS/2 Compatible Mouse Port
13 N/A Numeric Data Processor
14 * 5 Primary IDE Channel
15 * 1 Secondary IDE Channel
* These IRQs are usually available for ISA or PCI devices.
2-5-3 Interrupt Request Table For This Motherboard
Interrupt request are shared as shown the table below:
INT A INT B INT C INT D INT E INT F INT G INT H
Slot 1 √
Slot 2 √
Slot 3
√
Onboard USB 1 √
Onboard USB 2 √
AC97/MC97
√
IMPORTANT! If using PCI cards on shared slots, make sure that the drivers support
“Shared IRQ” or that the cards don’t need IRQ assignments. Conflicts will
arise between the two PCI groups that will make the system unstable or
cards inoperable.
2-5-4 AGP Slot
This motherboard provides an AGP Slot, support the 2X/4X AGP VGA card.
AGP SLOT
2x notch 4x notch

12
2-6 Connectors, Headers
2-6-1 Connectors
(1) Power Connector (20-pin block) : ATXPWR
ATX Power Supply connector. This is a new defined 20-pins connector that usually
comes with ATX case. The ATX Power Supply allows to use soft power on momentary
switch that connect from the front panel switch to 2-pins Power On jumper pole on the
motherboard. When the power switch on the back of the ATX power supply turned on,
the full power will not come into the system board until the front panel switch is
momentarily pressed. Press this switch again will turn off the power to the system
board.
PIN ROW2 ROW1
1 3.3V 3.3V
2 -12V 3.3V
3 GND GND
4 Soft Power On 5V
5 GND GND
6 GND 5V
7 GND GND
8 -5V Power OK
9 +5V +5V (for Soft Logic)
10 +5V +12V
Pin 1
(2) ATX 12V Power Connector (4-pin block) : ATX12V
This is a new defined 4-pins connector that usually comes with ATX Power Supply. The
ATX Power Supply which fully support Pentium 4 processor must including this
connector for support extra 12V voltage to maintain system power consumption.
Without this connector might cause system unstable because the power supply can not
provide sufficient current for system.
Pin 1
(3) PS/2 Mouse & PS/2 Keyboard Connector: PS2KBM
The connectors for PS/2 keyboard and PS/2 Mouse.
(4) USB Port connector: USB
The connectors are 4-pin connector that connect USB devices to the system board.
(5) LAN Port connector: LAN (only for P4MVMP)
This connector is standard RJ45 connector for Network
(6) Parallel Port Connector (25-pin female): PARALL
Parallel Port connector is a 25-pin D-Subminiature Receptacle connector. The On-
board Parallel Port can be disabled through the BIOS SETUP. Please refer to Chapter 3
“INTEGRATED PERIPHERALS SETUP” section for more detail information.
(7) Audio and Game Connector : AUDIO_GAME

13
This Connector are 3 phone Jack for LINE-OUT, LINE-IN, MIC and a 15-pin
D-Subminiature Receptacle Connector for joystick/MIDI Device.
Line-out : Audio output to speaker
Line-in : Audio input to sound chip
MIC : Microphone Connector
Game/MIDI : For joystick or MIDI Device
(8) Serial Port COM1 : COM1
COM1 is the 9-pin D-Subminiature male connector. The On-board serial port can be
disabled through BIOS SETUP. Please refer to Chapter 3 “INTEGRATED PERIPHERALS
SETUP” section for more detail information.
(9) VGA Connector (15-pin D-Sub) Connector: VGA
VGA is the 15-pin D-Subminiature female connector for display monitor.
(10) Floppy drive Connector (34-pin block): FDD
This connector supports the provided floppy drive ribbon cable. After connecting the
single plug end to motherboard, connect the two plugs at other end to the floppy drives.
Floppy Drive Connector
Pin 1
FDD
(11) Primary IDE Connector (40-pin block): IDE1
This connector supports the provided IDE hard disk ribbon cable. After connecting the
single plug end to motherboard, connect the two plugs at other end to your hard disk(s).
If you install two hard disks, you must configure the second drive to Slave mode by
setting its jumpers accordingly. Please refer to the documentation of your hard disk for
the jumper settings.
PS/2
Keyboard COM1 VGA
PS/2
Mouse
USB LINE-OUT
LINE-IN
MIC
PRINT GAME/MIDI PORTLAN

14
Primary IDE Connector
Pin 1
IDE1
(12) Secondary IDE Connector (40-pin block): IDE2
This connector connects to the next set of Master and Slave hard disks. Follow the
same procedure described for the primary IDE connector. You may also configure two
hard disks to be both Masters using one ribbon cable on the primary IDE connector and
another ribbon cable on the secondary IDE connector.
Secondary IDE Connector
Pin 1
IDE2
•Two hard disks can be connected to each connector. The first HDD is referred to as the
“Master” and the second HDD is referred to as the “Slave”.
•For performance issues, we strongly suggest you don’t install a CD-ROM or DVD-ROM
drive on the same IDE channel as a hard disk. Otherwise, the system performance on this
channel may drop.

15
2-6-2 Headers
(1) Line-Out/MIC Header for Front Panel (9-pin): AUDIO
This header connect to Front Panel Line-out, MIC connector with cable.
Without install the cable, this header default setting is 5-6 short, 9-10 short. When you
install the cable you have take off these jumpers.
Line-Out, MIC Headers
A
UDIO Pin 1
AUD_MIC
AUD
_
FPOUT
_
L
AUD_MIC_BIAS
AUD_FPOUT_R
HP
_
ON
AUD
_
GND
AUD
_
RET
_
L
AUD
_
RET
_
R
AUD
_
VCC
2
910
(2) USB Port Headers (9-pin) : USB1, USB2
These headers are used for connecting the additional USB port plug. By attaching an
option USB cable, your can be provided with two additional USB plugs affixed to the
back panel.
USB Port Headers
Pin 1
USB1
VCC
-DAT
A
GND
+ DATA
VCC
OC
-DAT
A
GND
+ DATA
Pin 1
USB2
VCC
-DAT
A
GND
+ DATA
VCC
OC
-DAT
A
GND
+ DATA
(3) IDE Activity LED: HD LED
This connector connects to the hard disk activity indicator light on the case.
(4) Reset switch lead: RESET
This 2-pin connector connects to the case-mounted reset switch for rebooting your
computer without having to turn off your power switch. This is a preferred method of
rebooting in order to prolong the lift of the system’s power supply. See the figure
below.
(5) Speaker connector: SPEAK
This 4-pin connector connects to the case-mounted speaker. See the figure below.
(6) Power LED: PWR LED
The Power LED is light on while the system power is on. Connect the Power LED
from the system case to this pin.

16
(7) Power switch: PWR BTN
This 2-pin connector connects to the case-mounted power switch to power ON/OFF the
system.
System Case Connections
HDLED
RESET
VCC5
GND
VCC5 PWR LED
PWRBTN
PWRBTN
PWRLED
HDDLED
RSTSW
NC GND
JP_FP SPEAK
SPK
R
GND
NC
VCC5
Pin 1
Pin 1
(8) Wake On-LAN Headers (3-pin) : WOL
This connector connects to a LAN card with a WAKE ON-LAN output. This
connector power up the system when a wake up signal is received through the LAN
card.
NOTE: This feature requires that Wake On LAN or Ring In Wake up is enabled.
Wake-On-LAN Headers
WOL 13
5VS
B
GN
D
WO
L

17
(9) FAN Headers (3-pin) : SFAN1, SYSFAN, CPUFAN
These connectors support cooling fans of 350mA (4.2 Watts) or less, depending on the
fan manufacturer, the wire and plug may be different. The red wire should be positive,
while the black should be ground. Connect the fan’s plug to the board taking into
consideration the polarity of connector.
FAN Headers
SYSFAN
13
SFAN1
13
CPUFAN
1
3
(10) CD Audio-In Headers (4-pin) : CD_IN
CD_IN are the connectors for CD-Audio Input signal. Please connect it to CD-ROM
CD-Audio output connector.
CD Audio-In Headers
CD-IN 4
1
