John Lewis 87702708 Operating instructions

ELLISEXTENSIONDININGTABLE 160-200CM
StockNumber:87702708
Page: 1
Thankyouforpurchasing thisEllisExtensionDiningTable 160-200cm.Pleaseread theinstructionscarefully
beforeuseto ensuresafeand satisfactoryoperationofthisproduct.
John Lewis
Pleasecheckthepackcontentsbeforeattemptingto assemblethisproduct.Afullchecklistofcomponentsis
giveninthisleaflet.Ifanycomponentsaremissing,pleasecontacttheretailerfromwhomyouboughtthis
product.
Thisproducttakesapproximately 30 MINUTES to assemblewith 2PEOPLE.
Allassemblyshould beperformedonaflat,stable,cleanandsoftsurface.
Thisproductis HEAVY,itshould beassembledasnearaspossibleto the pointofuse. TAKE CARE
WHENLIFTING to avoid personalinjuryand (or)damagetotheproduct
Thefittingpackcontains SMALL ITEMS whichshould be KEPT AWAYFROMYOUNGCHILDREN.
IMPORTANT: Retaintheseinstructionsforfuturereference.
Pre-assemblypreparation
Pleaseensureinstructionsareread infullbeforeattemptingtoassemblethisproduct.
NecessaryTools
IW-17-4335-012-0

2
Page:2
Fittingsandpartschecklist
A
B
C
x4
Threadedbolt
Ø8x70
Cross dowel
M8Ø12x60 Flatwasher
x8
x8
D
E
Fx 1
Spanner
Lockwasher x8
x8
1
2
x4
x 1Tabletop
Legs
IW-17-4335-012-0

Page:3
Step1
Step2
Fitting
Fitting
Cx8
Dx8
Ax4
Bx8
Ex8
F x 1
:Insert crossdowels(A)intothe legs(1) byplacingeachfitting(A)intotheholeontopofeach
leg asshown.Ensurethehorizontalmarkingoneachfitting(A)isfacingoutasshown.
:Insert2x threadedbolts(B)into thetwo holesonthebevelofeachlegthentighten
theminto theholesoffitting(A)thatisconcealedineachleg (1) asshown.
Withthehelpofanassistant:
:Laythetabletop(2)onaflat,stable,cleanand softsurface.Attacheachleg (1) intoplaceby
insertingbolts(B)into thepredrilledholesofeachmetalcornerbracketasshown.
:Insertflatwasher(C),lockwasher(D)and hexnut(E)ontoallthreadedbolts(B)asshown
and intheorderasshown-(C)followedby(D)followedby(E).
Tighten hexnut(E)ontopthentighten the hexnut(E)onbottomusingthe spanner(F)
asshown.Continueto re-tighten allhexnutsuntiltheyaresecurelyfastened.
1
1
2
2
C
D
StepByStepAssemblyInstructions
1
1 Tightenfirst
IW-17-4335-012-0

Step 3
Page:4
Step 4 :Rotatetheextensionleafoutasshown.
: Caution: thisproductisheavy,withthehelpofanassistantstandthe tableupright.
:Pulltabletopapartasshown,untilbutterflyleafisclearlyvisibleunderneath.
IW-17-4335-012-0

Step 5
:-Closethetoptablebyslidingbothsidesofthemaintabletoptowardtheleafasshown.
Ensurethemetalpinsarealigned tothe holesonthemaintabletopand theleafbefore
closingthetable.
Page:5
Complete
Step 6
:Extendtheleafbyturningthetoplayeroftheleafallthe wayopenasshown.
-Turnthumbscrewsclockwisetolocktabletop inplace.
IW-17-4335-012-0

CareandMaintenance
WoodFurniture
Wood displays differentgrainpatternsdependingonwhichwaytheyarecut-forexample,the'medullary ray'
whichcanappearonoakfurnitureisamarkofgood qualitytimber-thesearejustcharacteristicsofthe natural
beauty ofthe wood.
Somefurnitureisalsodeliberatelyagedandrustic.
Woodveneersalso allowdistinctivepatternsto becreatedonsomesurfaces,suchastabletopsanddrawer
frontsbythewayslivers arearranged.
All timberand veneersurfaceswillchangecolourandmellowovertime.Newfurniturewillinitiallyvary inshade
fromitemsthathavebeenpreviouslypurchased.
Howtocare for yourwoodfurniture
Dustwithaclean,damp,lintfreecloth.Frequentdustingwillremoveabrasivebuildup,whichcandamagethe
finishovertime.
Donotuseaverywetclothorallowanyliquid tocontactwiththeveneersforalongperiod oftimeasthiscan
permanentlydamagethesurface.Wipeupspillsimmediately.
Donotuseanyabrasivecleanerorharshdetergentasthiscandamagethe surface ofthefurniture.
Spraypolishesarebestavoided astheycontainsiliconeswhichmayspoilthefurniture'ssurface bybuilding up
overtime.
Makesureallsurfacesareprotectedfromheatandliquidsbymatsandcoasters.
Ensurethatamatorpad isplaced underpaperwhenyouarewritingonthefurnituresurface.
Donotplacerubberorplasticmaterialsonthewoodfinishaschemicalswithinmayreactwiththe finishifleftin
contactforanextended periodoftime.
Ourfurniturewillenduremosttemperaturesinthehomebutitisbestto avoid placingfurniturenexttoheat
sourcessuchasradiatorsorfires.Beparticularlycarefulwithsolid woodasthelackofhumidity causedbyhome
heatingcancausedamagesuchaswarping,cracking orsplitting.
Excessiveexposureto sunlightcancausefadingofyourfurniture.
SafetyInstructions:
Neverdragfurniturewhenmoving it.Alwaysliftit.
Periodicallycheckallfixingsto ensurenonehavecomeloose.Re-tighten whennecessary.
Pleasetakecarewhenhandlingormovingthefurnitureascarelesshandlingmaycausedamageorinjury.
Furniturecanbedangerousifincorrectlyinstalled.Assemblyshouldbecarried outbyacompetentperson.
Noliabilitywillbeaccepted fordamageorinjurycaused byincorrectlyinstalledorassembledfurniture.
Heavyitemwarning:
Itisrecommendedtoseekassistance whenmovingaheavyobject.Takecarewhenliftingto avoid personal
injuryand(or)damageto theproduct.
Itisrecommended thatbeforemovingaheavyobjecttoanewlocationitiscompletelydis-assembledto
Extendabletablewarning:
Extendablediningtablesshould beleftextendedforthefirstfewmonthstoavoidanunevenappearance.
Likewise,lampsand ornamentsshouldalso bemovedregularly.
Page:6
PLEASEKEEP THESEINSTRUCTIONSFORFUTUREREFERENCE
John LewisPartnership 171 VictoriaStreet,London, SWIE5NN
www.johnlewis.com
avoid personalinjuryordamagetothefurniture.Pleasebecarefultoretainall fittingswhendoingthis.
