John Lewis Genoa 2 Drawer Storage 810/84001 User manual

Genoa 2 Drawer Storage Bed
PRE-ASSEMBLY PREPARATION
Please check the pack contents before attempting to assemble this product. A full checklist of components is
given in this leaflet. If any components are missing, please contact your the John Lewis Helpline.
This product is HEAVY, it should be assembled as near as possible to the point of use. TAKE CARE WHEN
LIFTING to avoid personal injury and (or) damage to the product.
This product takes approximately 90 MINUTES to assemble with 2 PEOPLE.
The fittings pack contains SMALL ITEMS which should be KEPT AWAY FROM YOUNG CHILDREN.
Read this leaflet in full before commencing assembly.
If you require any additional information or have any issues with this product please call the
John Lewis Helpline on 01244 689949 or email [email protected]
Stock Code: 810/84001
Stock Code: 810/84002
Double
King size
John Lewis
For product support or spare parts please call
the John Lewis Helpline;
T: 01244 689949
E: [email protected]
Please ensure instructions are read in full before attempting to assemble this product.
Necessary Tools
Thank you for purchasing this Genoa 2 drawer stoprage Bed. Please read the instructions carefully before use to
ensure safe and satisfactory operation of this product.

Fitting and parts checklist
A
B
C
F
G
D
EJ
H
I
M5 ALLEN KEY x 1
M4 ALLEN KEY x 1
Side Plastic Clip x 30
Spring Washer M8 x 8
Centre Plastic Cap x 15
M8 X 16mm Bolt x 8
M6 X 25mm Bolt x 2
M6 X 40mm Bolt x 8
Screw 3.5 x 30 x 40
Headboard x 1 Foot board x 1 Side Rail x 2
Slats x 30
Bottom Support x 2 Centre Support x 1 Drawer Side x 4
Drawer Back x 2 Drawer Front x 2 Drawer Bottom x 2
Centre Rail X1 Wooden Leg x 4
Drawer Panel x 2 Drawer Support x 6
Screw 3.5 x 40x 4
12 3
4 5 6
7 8 9
10 11 12
13 14

Step Two
Step by step assembly instructions
Step One
M5 (B)
Head/Foot
Board
Pre-inserted Nut
Wooden Leg
(6) x 4
2
1
3
1
2
M5
BRACKET
SIDE RAIL
3
1
BRACKET
SIDE RAIL
2
3
Hook the pre attached brackets on the side rails over the pre inserted bolts in the head and foot board. Tighten the bolts
using allen key M5 (B), as shown in the diagram below.
Remove the plastic cap from the wooden legs and attach them to the headboard (1) and foot board (2) by
screwing in to the pre inserted nut’s as shown in the diagram below.

Step Three
Attach washer (E) and bolt (F) into the metal xings on to both bottom supports (7).
Do not fully tighten.
x2
Step Four
Attach bottom supports (7) to centre support (8) and secure in to place using screws (I)
as shown in the diagram below.
7
x1
8
7
7
F
E
F
E
F
F
E
E
I x 4
F x 8
E x 8
M5
Cross head
screw driver
I
I

1
3
2
7
3
M5
Fig 2
Fig 1
Step Five
M5 (B)
Step Six
Insert centre rail (5) into the brackets on the Headboard (1) and foot board (2). Push
down fully and secure in place using bolt (G). Tighten using allen key M4 (A)
1
3
2
4
M4
M6 x 25mm
S
T
E
P
1
S
T
E
P
2
M5 (A) G x 2
Insert the inner frame from step four inside the bed frame as shown below. Secure in to place by hooking the
bolts on the inner frame on to the brackets on the side rails, as shown in g 1. Tighten using allen key (B) as
shown in g 2.

Step Seven
Side plastic cap (30 pcs)
Centre plastic clip (15 pcs)
Bent slat (30pcs)
4.
C.
D.
4
4
x15
C
5
4
4
C
D
D
D
4
x30
Insert 2 slats (4) into a centre clip (C) followed by a side plastic cap (D) on to the other end
of both slats. The centre clip is attached to the centre rail on the bed and the side plastic
clip is attached to the side rails as shown in the diagram below.
Step Eight
10
14
(x2) (x2)
J x 40
10
9
14
9
10
9
11
12
14
9
To construct the drawer, x drawer back (10) with drawer support panels (14) using screw (J) as
shown in g 1. Next, x the drawer side (9) using screw (J) as shown in g 2. Finally, insert
drawer bottom (12) and then x drawer front (11) using screw (J) as shown in g 3. Tighten
using a cross head screw driver.
Fig 1
Fig 2
Fig 3
(x2)
Cross head
screw driver

(x2) x2
H x 8
13
M4
13
11
Step Nine
Attach drawer panel (13) to drawer and tighten together using bolt (H) tighten with Allen
key M4 (A).
M4
Step Ten
Slide drawers in to both sides of the bed frame. The bed is now ready for use.

Care and Maintenance
Safety Instructions
This Genoa Storage Bed should be cleaned using a soft damp cloth and dried immediately.
Do not use a very wet cloth or allow any liquid contact for a long period of time as this can permanently
damage the surface.
Do not use detergents and do not rub as this can cause permanent damage.
Always protect your bed from direct sunlight as this may accelerate the natural on going discolouration
process.
Screws holding together the bed frame should be tightened regularly.
Please retain this information leaflet for future reference.
This product complies with BS 1725:98
If you require any additional information or have any issues with this product please call
the John Lewis Helpline on 01244 689949 or email [email protected]
John Lewis Partnership 171 Victoria Street, London , SWIE 5NN.
www.johnlewis.com
Never drag furniture when moving it, always lift it.
periodically check all fixings to ensure none have come loose and re-tighten where necessary.
Please take care when handling or moving the furniture as careless handling may cause damage or injury.
Furniture can be dangerous if incorrectly installed. Any assembly should be carried out by competent adult.
No liability will be accepted for damage or injury caused by incorrectly insalled or assembled furniture.
During assembly children should be kept away from the product due to possible risk of injury.
Do not use this item if any components are missing or damaged.
It is recommended that care is taken when moving heavy objects to a new location to avoid
personal injury or damage to the furniture. Please be careful to retain all fitting when doing this.
