John Thomas OF-64C User manual

ITEM NO.: OF-64C AND OF-64T
ISSUED DEC 17, 2015
Printed in Vietnam
THIS ITEM IS PACKED IN TWO CARTONS
- 1 -
Description
Item No.
: CANYON EXECUTIVE DESK BASE
: OF-64C AND OF-64T
ASSEMBLY INSTRUCTIONS

ITEM NO.: OF-64C AND OF-64T
ISSUED DEC 17, 2015
Printed in Vietnam
THIS ITEM IS PACKED IN TWO CARTONS
- 2 -
BEFORE ASSEMBLY
Thank you for purchasing this quality product. This product has been designed for easy assembly
and constructed for durability. All parts were checked prior to packaging to insure quality. Prior to
beginning assembly, however, make sure all parts and hardware are included and free of obvious
defect. If a part is missing or defective, please contact the store where purchased. If hardware is
missing, or you need help with assembly, please call toll free 888-944-8396.
IMPORTANT NOTE:
-Place all wooden parts on a clean and smooth surface such as a rug or carpet to avoid the
parts from being scratched.
-Remove all wrapping material, including staples & packing straps before you start to
assemble.
-DO NOT tighten all screws, bolts until completely assembled.
-Keep all hardware parts out of reach of children.
WARNING:
Long exposure to rubber or soft plastic may cause a chemical reaction and damage the
finish of your table. Protect the surface of the table with cloth if you are using any product
with rubber feet or base.
ASSEMBLY TOOLS REQUIRED
NOT INCLUDE

ITEM NO.: OF-64C AND OF-64T
ISSUED DEC 17, 2015
Printed in Vietnam
THIS ITEM IS PACKED IN TWO CARTONS
- 3 -
PART LIST OF-64T
When unpacking, please be careful not to discard any parts with the packaging. Before continuing,
please make sure you have the following parts:
NO
Description
Qty
Sketch
A
Top
1
PART LIST OF-64C
When unpacking, please be careful not to discard any parts with the packaging. Before continuing,
please make sure you have the following parts:
NO
Description
Qty
Sketch
NO
Description
Qty
Sketch
B
Cross bar
1
C
Base
2

ITEM NO.: OF-64C AND OF-64T
ISSUED DEC 17, 2015
Printed in Vietnam
THIS ITEM IS PACKED IN TWO CARTONS
- 4 -
HARDWARE LIST
When unpacking, please be careful not to discard any parts with the packaging. Before continuing,
please make sure you have all of the following hardware:
NO
Description
Qty
Sketch
NO
Description
Qty
Sketch
1
Short bolt
(M8 x 50mm)
8
2
Long bolt
(M8 x 70mm)
2
3
Lock Washer
(8.5 x13mm)
8
4
Flat Washer
(8.5 x19mm)
8
5
U-Washer
(M8)
2
6
Allen Key
(M4 x 107mm)
1
7
Wooden knob
4
8
Pan head screw
(M4 x 30mm)
4
METAL KNOB
(30x30mm)
ASSEMBLED INTO TOP
OF-64T (FINISHED) BY
PRODUCER
4
NOTE: HARDWARE IS PACKED IN CARTON OF-64C.
STEP 1
Attach cross bar (B) to the bases (C) with bolts (2) and U-washers (5), as shown below. Tighten with
Allen key (6).

ITEM NO.: OF-64C AND OF-64T
ISSUED DEC 17, 2015
Printed in Vietnam
THIS ITEM IS PACKED IN TWO CARTONS
- 5 -
STEP 2
Attach the bases (C) to the top (A) (from step 1) with bolts (1) and washers (3) and (4), as shown
below. Tighten with Allen key (6).
STEP 3
Attach knobs (7) to front of drawers with pan head screws (8), as shown below. Tighten with a
screwdriver.
