John Thomas T-4866XXTT User manual

ITEM NO.: T-4066XXTT OR T-4866XXTT OR T-42120XXT
AND T-51B OR T-52B OR T-53B
(PACKED IN SEPARATE BOX)
REVISED JULY 06, 2016
Printed in Vietnam
THE HARDWARE REQUIRED TO ATTACH THE LEGS IS PACKED WITH THE LEGS
- 1 -
ASSEMBLY INSTRUCTIONS
T-4066XXTT OR T-4866XXTT AND T-53B T-42120XXT AND T-53B
T-4066XXTT OR T-4866XXTT AND T-51B T-42120XXT AND T-51B
T-4066XXTT OR T-4866XXTT AND T-52B T-42120XXT AND T-52B
Description : TABLE
Item No. : T-4066XXTT OR T-4866XXTT OR T-42120XXT AND
T-51B OR T-52B OR T-53B
(PACKED IN SEPARATE BOX)

ITEM NO.: T-4066XXTT OR T-4866XXTT OR T-42120XXT
AND T-51B OR T-52B OR T-53B
(PACKED IN SEPARATE BOX)
REVISED JULY 06, 2016
Printed in Vietnam
THE HARDWARE REQUIRED TO ATTACH THE LEGS IS PACKED WITH THE LEGS
- 2 -
BEFORE ASSEMBLY
Thank you for purchasing this quality product. This product has been designed for easy assembly
and constructed for durability. All parts were checked prior to packaging to insure quality. Prior to
beginning assembly, however, make sure all parts and hardware are included and free of obvious
defect. If a part is missing or defective, please contact the store where purchased. If hardware is
missing, or you need help with assembly, please call toll free 888-944-8396.
IMPORTANT NOTE:
-Place all wooden parts on a clean and smooth surface such as a rug or carpet to avoid the
parts from being scratched.
-Remove all wrapping material, including staples & packing straps before you start to
assemble.
-DO NOT tighten all screws and bolts until completely assembled.
-Keep all hardware parts out of reach of children.
WARNING:
Long exposure to rubber or soft plastic may cause a chemical reaction and damage the
finish of your table. Protect the surface of the table with cloth if you are using any product
with rubber feet or base.
ASSEMBLY TOOLS REQUIRED
NOT INCLUDED

ITEM NO.: T-4066XXTT OR T-4866XXTT OR T-42120XXT
AND T-51B OR T-52B OR T-53B
(PACKED IN SEPARATE BOX)
REVISED JULY 06, 2016
Printed in Vietnam
THE HARDWARE REQUIRED TO ATTACH THE LEGS IS PACKED WITH THE LEGS
- 3 -
PARTS LIST T-4066XXTT OR T-4866XXTT
When unpacking, please be careful not to discard any parts with the packaging. Before continuing,
please make sure you have the following parts:
NO
Description
Q’ty
Sketch
NO
Description
Q’ty
Sketch
A
Top
1
B
TABLE LEAF
2
C
LEAF
APRONS
(L-R)
4
PARTS LIST T-42120XXT
When unpacking, please be careful not to discard any parts with the packaging. Before continuing,
please make sure you have the following parts:
NO
Description
Q’ty
Sketch
NO
Description
Q’ty
Sketch
A
Top
1
B
TABLE LEAF
3
When unpacking, please be careful not to discard any parts with the packaging. Before continuing,
please make sure you have the following parts:
NO
Description
Qty
Sketch
NO
Description
Qty
Sketch
D
LEG
(T-51B)
4
E
CENTER LEG
(T-51B)
1
D
LEG
(T-52B)
4
E
CENTER LEG
(T-52B)
1
D
LEG
(T-53B)
4
E
CENTER LEG
(T-53B)
1
PARTS LIST LEGS T-51B OR T-52B OR T-53B
PARTS LIST LEGS T-51B OR T-52B OR T-53B

ITEM NO.: T-4066XXTT OR T-4866XXTT OR T-42120XXT
AND T-51B OR T-52B OR T-53B
(PACKED IN SEPARATE BOX)
REVISED JULY 06, 2016
Printed in Vietnam
THE HARDWARE REQUIRED TO ATTACH THE LEGS IS PACKED WITH THE LEGS
- 4 -
HARDWARE LIST
When unpacking, please be careful not to discard any parts with the packaging. Before continuing,
please make sure you have all of the following hardware:
NO
Description
Q’ty
Sketch
NO
Description
Q’ty
Sketch
1
Flat washer
(2x8.5x22mm)
9
2
Hexagon nuts
(M8x13mm)
9
3
Lock washer
(8.5x13mm)
9
4
Wrench
(M8x13mm)
1
5
Wood screw
(M3.5x15mm)
8
NOTE: HARDWARE IS PACKED IN CARTON OF LEGS T-51B OR T-52B OR T-53B.
STEP 1
Attach aprons (C) to leaves (B) with screws (5) as shown below. Tighten with a screwdriver.
(THIS STEP IS NOT REQUIRED FOR T-42120XXT)

ITEM NO.: T-4066XXTT OR T-4866XXTT OR T-42120XXT
AND T-51B OR T-52B OR T-53B
(PACKED IN SEPARATE BOX)
REVISED JULY 06, 2016
Printed in Vietnam
THE HARDWARE REQUIRED TO ATTACH THE LEGS IS PACKED WITH THE LEGS
- 5 -
STEP 2
Attach legs (D) and (E) to the top (A) with washers (1) and (3), and nuts (2) as shown below.
Tighten with the wrench (4).
T-4066XXTT OR T-4866XXT
T-42120XXT

ITEM NO.: T-4066XXTT OR T-4866XXTT OR T-42120XXT
AND T-51B OR T-52B OR T-53B
(PACKED IN SEPARATE BOX)
REVISED JULY 06, 2016
Printed in Vietnam
THE HARDWARE REQUIRED TO ATTACH THE LEGS IS PACKED WITH THE LEGS
- 6 -
Unlock the table top from both sides underneath the top as shown below.
Pull the 2 parts of the table top apart.
T-4066XXTT OR T-4866XXT
T-42120XXT
STEP 3

ITEM NO.: T-4066XXTT OR T-4866XXTT OR T-42120XXT
AND T-51B OR T-52B OR T-53B
(PACKED IN SEPARATE BOX)
REVISED JULY 06, 2016
Printed in Vietnam
THE HARDWARE REQUIRED TO ATTACH THE LEGS IS PACKED WITH THE LEGS
- 7 -
Place the leaves (B) in the center of the top as shown below.
Push the table top closed. Lock the mechanism underneath two sides of the table top as shown
below.
T-4066XXTT OR T-4866XXT
STEP 4

ITEM NO.: T-4066XXTT OR T-4866XXTT OR T-42120XXT
AND T-51B OR T-52B OR T-53B
(PACKED IN SEPARATE BOX)
REVISED JULY 06, 2016
Printed in Vietnam
THE HARDWARE REQUIRED TO ATTACH THE LEGS IS PACKED WITH THE LEGS
- 8 -
T-42120XXT
