John Thomas TUSCAN OT-17E User manual

ITEM NO : OT
-
17E
RE
V
I
SED
OCT 16
, 2014
Printed in Vietnam
- 1 -
ASSEMBLY INSTRUCTIONS
Description
Item No.
:
TUSCAN END TABLE
: OT-17E

ITEM NO : OT
-
17E
RE
V
I
SED
OCT 16
, 2014
Printed in Vietnam
- 2 -
Thank you for purchasing this quality product. This product has been designed for easy assembly and
constructed for durability. All parts were checked prior to packaging to insure quality. Prior to beginning
assembly, however, make sure all parts and hardware are included and free of obvious defect. If a part is
missing or defective, please contact the store where purchased. If hardware is missing, or you need help with
assembly, please call toll free 888-944-8396.
IMPORTANT NOTE:
-Place all wooden parts on a clean and smooth surface such as a rug or carpet to avoid the parts from
being scratched.
-Remove all wrapping material, including staples & packing straps before you start to assemble.
-DO NOT tighten all screws and bolts until completely assembled.
-Keep all hardware parts out of reach of children.
WARNING:
Long exposure to rubber or soft plastic may cause a chemical reaction and damage the finish of your
table. Protect the surface of the table with cloth if you are using any product with rubber feet or base.
PART
LIST
When unpacking, please be careful not to discard any parts with the packaging. Before continuing,
please make sure you have the following parts.
NO Description Qty Sketch NO Description Qty Sketch
A Top 1 B Bottom
panel 1
C Leg 4
HARDWARE LIST
When unpacking, please be careful not to discard any parts with the packaging. Before continuing,
please make sure you have all of the following hardware:
NO Description Qty Sketch NO Description Qty Sketch
1 Bolt
( M6 x 60mm) 12
2 Lock Washer
(6.5 x11mm) 12
3 Flat Washer
(6.5 x19mm) 12
4 Allen key
(K4) 1
BEFORE ASSEMBLY

ITEM NO : OT
-
17E
RE
V
I
SED
OCT 16
, 2014
Printed in Vietnam
- 3 -
STEP 1
Attach legs (C) to the top (A) with bolts (1) and washers (2) and (3) as shown below. Tighten with Allen
key (4).
STEP 2
Attach bottom panel (B) to legs (C) with bolts (1) and washers (2) and (3) as shown below. Tighten
with Allen key (4).
.
