John Thomas OF-45D User manual

ITEM NO.: OF-45D
REVISED MAR 28, 2016
Printed in Vietnam
- 1 -
ASSEMBLY INSTRUCTIONS
Description
Item No.
: MISSION COMPUTER DESK
: OF-45D

ITEM NO.: OF-45D
REVISED MAR 28, 2016
Printed in Vietnam
- 2 -
Thank you for purchasing this quality product. This product has been designed for easy assembly
and constructed for durability. All parts were checked prior to packaging to insure quality. Prior to
beginning assembly, however, make sure all parts and hardware are included and free of obvious
defect. If a part is missing or defective, please contact the store where purchased. If hardware is
missing, or you need help with assembly, please call toll free 888-944-8396.
IMPORTANT NOTE:
-Place all wooden parts on a clean and smooth surface such as a rug or carpet to avoid the
parts from being scratched.
-Remove all wrapping material, including staples & packing straps before you start to
assemble.
-DO NOT tighten all screws and bolts until completely assembled.
-Keep all hardware parts out of reach of children.
WARNING:
Long exposure to rubber or soft plastic may cause a chemical reaction and damage the
finish of your table. Protect the surface of the table with cloth if you are using any product
with rubber feet or base.
BEFORE ASSEMBLY
ASSEMBLY TOOLS REQUIRED
NOT INCLUDED

ITEM NO.: OF-45D
REVISED MAR 28, 2016
Printed in Vietnam
- 3 -
PART LIST
When unpacking, please be careful not to discard any parts with the packaging. Before continuing,
please make sure you have the following parts:
NO
Description
Qty
Sketch
NO
Description
Qty
Sketch
A
Top
1
C
Crossbar
1
B
Side frame
(L-R)
2
D
Side decoration
4
HARDWARE LIST
When unpacking, please be careful not to discard any parts with the packaging. Before continuing,
please make sure you have all of the following hardware:
NO
Description
Qty
Sketch
NO
Description
Qty
Sketch
1
Bolt
(M6 x 65mm)
4
4
Pan head screw
*Metal knob: (M4 x 22mm)
*Wooden knob: (M4 x 25mm)
3
2
Barrel nut
(6 x 13mm)
4
5
Allen key
(M4 x 80mm)
1
3
Wooden knob
(SQR 32 x 20mm)
3
6
Screw
(M4 x 50mm)
2
METAL KNOB
(30 x 30mm)
GOES WITH
FINISHED ITEM
ONLY.
3

ITEM NO.: OF-45D
REVISED MAR 28, 2016
Printed in Vietnam
- 4 -
Attach side frames (B) to the top (A) with bolts (1) and nuts (2). Tighten with Allen key (5).
Attach side frames (B) to the crossbar (C) with screws (6). Tighten with a screwdriver.
STEP1

ITEM NO.: OF-45D
REVISED MAR 28, 2016
Printed in Vietnam
- 5 -
STEP 2
Attach knobs (3) to front of drawers with screws (4). Tighten with a screwdriver.
Attach side decorations (D) to side frames (B) as shown below.

ITEM NO.: OF-45D
REVISED MAR 28, 2016
Printed in Vietnam
- 6 -
STEP 3
NOTE: Put your hands in front of the drawer and open the flip down key board tray as shown below.
