John Thomas OT-16S User manual

ITEM NO.: OT-16S
ISSUED DEC 16, 2020
Printed in Vietnam
- 1 -
ASSEMBLY INSTRUCTIONS
Description
Item No.
: SURREY SOFA TABLE
: OT-16S

ITEM NO.: OT-16S
ISSUED DEC 16, 2020
Printed in Vietnam
- 2 -
BEFORE ASSEMBLY
Thank you for purchasing this quality product. This product has been designed for easy assembly and
constructed for durability. All parts were checked prior to packaging to insure quality. Prior to
beginning assembly, however, make sure all parts and hardware are included and free of obvious
defect. If a part is missing or defective, please contact the store where purchased. If hardware is
missing, or you need help with assembly, please call toll free 888-944-8396.
IMPORTANT NOTE:
-Place all wooden parts on a clean and smooth surface such as a rug or carpet to avoid the
parts from being scratched.
-Remove all wrapping material, including staples & packing straps before you start to assemble.
-DO NOT tighten all screws and bolts until completely assembled.
-Keep all hardware parts out of reach of children.
WARNING:
Long exposure to rubber or soft plastic may cause a chemical reaction and damage the finish
of your table. Protect the surface of the table with cloth if you are using any product with
rubber feet or base.
ASSEMBLY TOOLS REQUIRED
NOT INCLUDED

ITEM NO.: OT-16S
ISSUED DEC 16, 2020
Printed in Vietnam
- 3 -
PART LIST
When unpacking, please be careful not to discard any parts with the packaging. Before continuing,
please make sure you have the following parts:
NO
Description
Qty
Sketch
NO
Description
Qty
Sketch
A
Top
1
B
Leg
2
C
Bottom shelf
1
HARDWARE LIST
When unpacking, please be careful not to discard any parts with the packaging. Before continuing,
please make sure you have all of the following hardware:
NO
Description
Qty
Sketch
NO
Description
Qty
Sketch
1
Bolt
(M6 x 35mm)
4
2
Lock Washer
(6.5 x11mm)
4
3
Flat Washer
(6.5 x19mm)
4
4
Short Screw
(3.5 x 15mm)
8
5
Long Screw
(M4 x 50mm)
8
6
L-bracket
4
7
Allen key
(M4 x 30mm x 110mm)
1

ITEM NO.: OT-16S
ISSUED DEC 16, 2020
Printed in Vietnam
- 4 -
Attach leg (B) to top (A) with bolts (1), and washers (2) and (3) as shown below. Tighten with
Allen key (7).
STEP 2
Insert bottom shelf (C) into legs (B) as shown below. Attach top (A) to the other leg (B) with bolts (1),
and washers (2) and (3). Tighten with Allen key (7).
STEP 1

ITEM NO.: OT-16S
ISSUED DEC 16, 2020
Printed in Vietnam
- 5 -
STEP 3
Attach top (A) and bottom shelf (C) to legs (B) with screws (5) as shown below. Tighten with a
screwdriver.
Attach bottom shelf (C) to legs (B) with screws (4) and brackets (6) as shown below. Tighten with a
screwdriver.
STEP 3
