John Thomas T-42120 T Series User manual

ITEM NO.
:
T
-
42120XXT AND T
-
51B OR T
-
53B
REVISED OCT 25, 2014
Printed in Vietnam
THE HARDWARE REQUIRED TO ATTACH THE LEGS IS PACKED WITH THE LEGS
- 1 -
ASSEMBLY INSTRUCTIONS
T-42120XXT/T-53B
T-42120XXT/T-51B
Description
Item No.
:
42X68X84X102X120
TABLE
TOP
: T-42120XXT AND T-51B OR T-53B
(PACKED IN SEPARATE BOX)

ITEM NO.
:
T
-
42120XXT AND T
-
51B OR T
-
53B
REVISED OCT 25, 2014
Printed in Vietnam
THE HARDWARE REQUIRED TO ATTACH THE LEGS IS PACKED WITH THE LEGS
- 2 -
BEFORE ASSEM
B
LY
Thank you for purchasing this quality product. This product has been designed for easy assembly and
constructed for durability. All parts were checked prior to packaging to insure quality. Prior to beginning
assembly, however, make sure all parts and hardware are included and free of obvious defect. If a part is
missing or defective, please contact the store where purchased. If hardware is missing, or you need help with
assembly,
please call toll free 888-944-8396.
IMPORTANT NOTE:
-Place all wooden parts on a clean and smooth surface such as a rug or carpet to avoid the parts from
being scratched.
-Remove all wrapping material, including staples & packing straps before you start to assemble.
-DO NOT tighten all screws and bolts until completely assembled.
-Keep all hardware parts out of reach of children.
WARNING:
Long exposure to rubber or soft plastic may cause a chemical reaction and damage the finish of your
table. Protect the surface of the table with cloth if you are using any product with rubber feet or base.
PARTS LIST
TOP
When unpacking, please be careful not to discard any parts with the packaging. Before continuing,
please make sure you have the following parts:
NO
Description
Q’ty
Sketch
NO
Description
Q’ty
Sketch
A Top 1 B
Extension
Leaf 3
NO Description Qty Sketch NO Description Qty Sketch
D
LEGS
(T-51B)
4
E
CENTER
LEGS
(T-51B)
1
D LEGS
(T-53B) 4
E
CENTER
LEGS
(T-53B)
1
PARTS LIST LEGS T
-
51B OR T
-
52B OR T
-
53B

ITEM NO.
:
T
-
42120XXT AND T
-
51B OR T
-
53B
REVISED OCT 25, 2014
Printed in Vietnam
THE HARDWARE REQUIRED TO ATTACH THE LEGS IS PACKED WITH THE LEGS
- 3 -
HARDWARE LIST
When unpacking, please be careful not to discard any parts with the packaging. Before continuing,
please make sure you have all of the following hardware:
NO
Description
Q’ty
Sketch
NO
Description
Q’ty
Sketch
1
Hexagon nuts
(M8x13mm)
9 2 Lock washer
(8.5x13mm) 9
3 Flat washer
( 8.5x19mm) 9
4 WRENCH
(M8x13mm) 1
STEP
1
Attach legs (C) and center leg (D) to top (A) with lock washers (2), flat washers (3) and hexagon nuts
(1). Tighten with the wrench (4) as shown below.

ITEM NO.
:
T
-
42120XXT AND T
-
51B OR T
-
53B
REVISED OCT 25, 2014
Printed in Vietnam
THE HARDWARE REQUIRED TO ATTACH THE LEGS IS PACKED WITH THE LEGS
- 4 -
STEP 2
Unlock the table top from both sides underneath of the top as shown below.
Pull the 2 parts of the table top apart.

ITEM NO.
:
T
-
42120XXT AND T
-
51B OR T
-
53B
REVISED OCT 25, 2014
Printed in Vietnam
THE HARDWARE REQUIRED TO ATTACH THE LEGS IS PACKED WITH THE LEGS
- 5 -
STEP
3
Place the leaves (B) in the center of the top as shown below.
Push the table top closed. Lock the mechanism underneath 2 sides of the table top as shown below.
