Johnny's Selected Seeds Connecta Tool System Quick setup guide

Copyright © 2022 Johnny’s Selected Seeds. All rights reserved.
1
SEED BREEDERS, GROWERS, AND MERCHANTS SINCE 1973
955 Benton Ave., Winslow, ME 04901 •Phone: [phone] •Fax: [phone]
Email: [e-mail] •Web Site: Johnnyseeds.com
Materials Included
•(1) ConnectaTM Receiver
•(1) Oiled ashwood handle
•(1) #6 x ¾" Rounded-head stainless steel wood screw
Additional Tools Needed
•#1 Phillips screwdriver
•3/32" Allen wrench
ASSEMBLY INSTRUCTIONS
The ConnectaTM Receiver comes fully assembled and only requires the oiled ashwood handle to be attached
before use.
1. Insert the tapered handle into the metal receiver as far as it will go, until it is secure in place.
Note: Do not push the receiver down too far onto the handle as it could cause unnecessary strain on the
screws.
2. Secure the wooden handle into the metal receiver by inserting the #6 x ¾" wood screw provided into the
screw hole and tightening it with a #1 Phillips screwdriver.
OPERATION & USE
•To attach a tool head into the receiver, press the button and insert the tool head shank until it clicks
securely into place. You will need to gently push it in so the rubber gasket depresses to form a tight fit.
Note: Be sure the thumb grip on the tool head is in line with the receiver’s button.
•To remove a tool head, press the button and slide the tool head out of the ferrule.
•Extra tool heads for the ConnectaTM Tool System can be stored on the
belt loop clip, allowing you to swap tool heads quickly and easily in the
field.
•Important Note: The ConnectaTM Tool System is designed with tight
tolerances to keep the heads from shifting while in use. You may need
to insert new heads a few times before they fit snugly in the receiver.
ConnectaTM Tool System
Assembly, Use & Maintenance
Tool
shank
Thumb
grip
Button
Receiver
Belt loop clip
Tool shank

Copyright © 2022 Johnny’s Selected Seeds. All rights reserved.
2
SEED BREEDERS, GROWERS, AND MERCHANTS SINCE 1973
MAINTENANCE
•Always store your ConnectaTM Tool System components clean and dry.
•If dirt or debris gets inside the receiver, gently shake it upside-down to clean it out.
Note: DO NOT tap the receiver on a hard surface such as stone or concrete, as this could damage it.
•If the dirt or debris is particularly difficult to remove, you can spray water down into the receiver until it is
cleared. Allow the receiver to fully air-dry before use.
•A light coat of linseed oil can be applied to the wooden handle as needed.
Cleaning Inside the ConnectaTM Receiver
If necessary, the ConnectaTM Receiver can be disassembled for a more thorough cleaning.
•Remove the four #4-40 3/32" socket head screws from the bottom half of the receiver with a 3/32" Allen
wrench.
•Remove the button from the top half of the receiver and both ¼" compression springs housed below it.
•Clean out the receiver with water and allow all parts to completely dry before reassembling.
•You can lubricate the sides of the button and the springs with a couple drops of food-safe oil, if
necessary.
06.27.2022 | JG, ms
Wood screw
Socket head
screws
Compression springs
