M4-XPM Expansion Modules Installation Guide
Application
The M4-XPM series expansion I/O modules can serve
in one of two capacities depending on where they are
installed in the Metasys system. When installed on the
Sensor/Actuator (SA) Bus of an equipment controller, an
XPM expands the input and output interfaces that can be
used with that equipment controller. When installed on
the Field Controller (FC) Bus of a Metasys network engine,
an XPM can be used as I/O point multiplexors to support
monitoring and control from a Metasys network engine.
The point multiplexor can also be useful for sharing points
between other equipment controllers on the FC Bus using
peer-to-peer connectivity. XPMs operate on an RS-485
BACnet MS/TP Bus and are BACnet Testing Laboratory
(BTL) listed and certified to the BACnet Smart Actuator (B-
SA) profile.
Communications Protocols
The XPM expansion modules can communicate using
BACnet MS/TP or wireless using a ZFR/ZFR Pro Wireless
Field Bus Router (on the FC Bus only). By default, the XPM
expansion modules communicate using the BACnet MS/
TP protocol. The BACnet protocol is a standard for ANSI,
ASHRAE, and the International Standards Organization
(ISO) for building controls. To configure these expansion
modules in a wireless application installation, see
Configuring wireless communications.
Note: Using Controller Configuration Tool (CCT)
10.1 and later, Metasys Equipment Controllers
can be configured to communicate using either
the BACnet MS/TP or the N2 field bus networking
protocol. The operation of an XPM on the SA Bus
of an equipment controller is not affected by the
selection of the BACnet MS/TP or the N2 protocol in
the host controller.
North American Emissions Compliance
United States
This equipment has been tested and found to comply
with the limits for a Class A digital device pursuant to
Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful
interference when this equipment is operated in a
commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction
manual, may cause harmful interference to radio
communications. Operation of this equipment in a
residential area may cause harmful interference, in which
case the users will be required to correct the interference
at their own expense.
Canada
This Class (A) digital apparatus meets all the
requirements of the Canadian Interference-Causing
Equipment Regulations.
Cet appareil numérique de la Classe (A) respecte toutes
les exigences du Règlement sur le matériel brouilleur du
Canada.
Installation
Observe the following guidelines when installing an XPM
expansion module:
• To minimize vibration and shock damage transport the
expansion module in the original container.
• Verify that all parts shipped with the expansion module.
• Do not drop the expansion module or subject it to
physical shock.
Parts included
• One XPM expansion module with removable terminal
blocks (Input/Output, Power and SA bus terminal
blocks)
• One XPM Series Pack Sheet (A163816VBE)
Materials and special tools needed
• Three fasteners appropriate for the mounting surface
(M4 screws or #8 screws)
• One 20 cm (8 in.) or longer piece of 35 mm DIN rail and
appropriate hardware for DIN rail mount (only)
• Small straight-blade (1/8 in. or 3.2 mm) or Philips #2
screwdriver for securing wires in the terminal blocks
Physical features
The following figures display the physical features of XPM
expansion modules, and the accompanying table provides
a description of the physical features and a reference to
further information where required.
*241014302147B*
Part No. 24-10143-02147 Rev. B
Release 12.0
2022-05-20
(For factory use only)
M4-XPM04060, M4-XPM09090, M4-XPM18000

Figure 1: XPM09090 and XPM04060 Physical Features
(XPM09090 model shown)
Figure 2: XPM18000 Physical Features
Table 1: Physical features of expansion modules
Physical Feature: Description and References
1Binary Output (BO) Terminal Block: Black terminals. Only
present on XPM09090 and XPM04060 models. See Table 3.
2Configurable Output (CO) Terminal Block: Black terminals.
Only present on XPM09090 and XPM04060 models. See
Table 3.
3Analog Output (AO) Terminal Block: Black terminal. Only
present on XPM09090 model. See Table 3.
4Device Address Rotary Switch Block: Decimal Addressing
See Setting the device address.
5Supply Power Terminal Block: Gray terminals; 24 VAC,
Class 2. See Figure 9.
6Cover Lift Tab. See Removing the expansion module
cover.
7SA/FC Bus Terminal Block: Orange terminal. See SA/FC
Bus Terminal Block.
8End-of-Line (EOL) Switch. See Setting the End-of-Line
(EOL) switch.
Table 1: Physical features of expansion modules
Physical Feature: Description and References
9Binary Input (BI) Terminal Block: White terminals. See
Table 3.
10 Universal Input (UI) Terminal Block: Only present on
XPM09090 and XPM04060 models. See Table 3.
11 Sensor Actuator (SA) Bus/Field Controller (FC) Bus Port
(RJ-12 6-pin Modular Jack). See SA/FC bus port.
12 LED Status Indicators. See LED status and states.
Mounting
Observe the following guidelines when mounting an
expansion module:
• Ensure the mounting surface can support the
expansion module, DIN rail, and any user-supplied
enclosure.
• Mount the expansion module horizontally on 35 mm
DIN rail whenever possible.
• Mount the expansion module in the proper mounting
position.
• Mount the expansion module on a hard, even surface
whenever possible in wall-mount applications.
• Use shims or washers to mount the expansion module
securely and evenly on the mounting surface.
• Mount the expansion module in an area free of
corrosive vapors and observe the Ambient Conditions
requirements in Table 13.
• Provide for sufficient space around the expansion
module for cable and wire connections for easy cover
removal and good ventilation through the expansion
module (50 mm [2 in.] minimum on the top, bottom,
and front of the expansion module).
• Do not mount the expansion module on surfaces prone
to vibration, such as duct work.
• Do not mount the expansion module in areas where
electromagnetic emissions from other devices or wiring
can interfere with expansion module communication.
On panel or enclosure mount applications, observe the
following additional guidelines:
• Mount the expansion module so that the enclosure
walls do not obstruct cover removal or ventilation
through the expansion module.
• Mount the expansion module so that the power
transformer and other devices do not radiate excessive
heat to the expansion module.
• Do not install the expansion module in an airtight
enclosure.
M4-XPM Expansion Modules Installation Guide2

Figure 3: Expansion Module mounting position
Mounting features and dimensions
Figure 4: Back of XPM04060 and XPM18000 expansion
module
Figure 5: Back of XPM09090 expansion module
Note:
• Mounting dimensions are listed in millimeters in
the above figures.
• The DIN rail channel and the mounting clips are
shown in an extended position.
DIN rail mount applications
About this task:
To mount a XPM expansion module horizontally on a
35 mm DIN rail (recommended method), complete the
following steps:
1. Securely mount a 20 cm (8 in.) or longer section
of 35 mm DIN rail horizontal and centered in
the desired space so that the expansion module
mounts in the horizontal position.
2. Pull the two bottom mounting clips outward from
the expansion module to the extended position
(Figure 3).
3. Hang the expansion module on the DIN rail by
the hooks at the top of the (DIN rail) channel on
the back of the expansion module (Figure 4), and
position the expansion module snugly against the
DIN rail.
4. Push the bottom mounting clips inward (up) to
secure the expansion module on the DIN rail.
5. To remove the expansion module from the DIN rail,
pull the bottom mounting clips out to the extended
position and carefully lift the expansion module off
the DIN rail.
Wall mount applications
About this task:
To mount a XPM expansion module directly on a wall or
other flat vertical surface, complete the following steps:
1. Pull the two bottom mounting clips outward and
ensure they are locked in the extended position.
2. Determine the proper mounting position the
expansion module will be installed. Mark the
mounting hole locations on the wall using the
dimensions for the expansion module listed in
Mounting features and dimensions. Alternatively,
hold the expansion module up to the wall or
surface in a proper mount position and mark the
hole locations through the mounting clips.
3. Drill holes in the wall or surface at the marked
locations, and insert appropriate wall anchors in
the holes (if necessary).
4. Hold the expansion module in place, and insert
the screws through the mounting clips and into
the holes (or anchors). Carefully tighten all of the
screws.
Important: Do not over-tighten the mounting
screws. Over-tightening the screws may
damage the mounting clips.
Wiring
Observe the following guidelines when wiring an XPM
expansion module:
M4-XPM Expansion Modules Installation Guide 3

CAUTION
Risk of Electric Shock:
Disconnect the power supply before making electrical
connections to avoid electric shock.
ATTENTION
Mise En Garde: Risque de décharge électrique:
Débrancher l'alimentation avant de réaliser tout
raccordement électrique afin d'éviter tout risque de
décharge électrique.
CAUTION
Risk of Property Damage:
Do not apply power to the system before checking
all wiring connections. Short circuited or improperly
connected wires may result in permanent damage to
the equipment.
ATTENTION
Mise En Garde: Risque de dégâts matériels:
Ne pas mettre le système sous tension avant
d'avoir vérifié tous les raccords de câblage. Des
fils formant un court-circuit ou connectés de façon
incorrecte risquent d'endommager irrémédiablement
l'équipement.
Important: Do not exceed the expansion module
electrical ratings. Exceeding the electrical ratings
can result in permanent damage to the expansion
module and void any warranty.
Important: Use copper conductors only. Make
all wiring in accordance with local, national, and
regional regulations.
Important: Electrostatic discharge can damage
expansion module components. Use proper
electrostatic discharge precautions during
installation, setup, and servicing to avoid damaging
the expansion module.
For detailed information about configuring and wiring
an MS/TP Bus, FC bus, and SA bus, refer to the MS/TP
Communications Bus Technical Bulletin (LIT-12011034).
Terminal blocks and bus ports
See Physical features for terminal block and bus port
locations on the XPM expansion module. Observe the
following guidelines when wiring an XPM expansion
module.
Input and Output terminal blocks
XPM models have removable input and output terminal
blocks. On XPM09090 and XPM04060 models, all of the
input terminal blocks are located on the bottom of the
controller, and the output terminal blocks are located
on the top of the expansion module. The XPM18000 has
inputs only which are located on both the top and bottom
of the expansion module. For information about removing
a terminal block, see Removing a terminal block. For more
information about I/O terminal functions, requirements,
and ratings, see Terminal wiring guidelines, functions,
ratings, and requirements.
SA/FC Bus Terminal Block
An XPM can be connected to a Sensor/Actuator (SA)
bus or a Field Controller (FC) bus, but not to both buses
simultaneously. The SA/FC bus terminal block is a
removable, 4-pin terminal block that fits into a board-
mounted pin header.
When connecting the XPM to an FC bus, wire the bus
terminal blocks on the expansion module, and the other
FC Bus devices in a daisy-chain configuration using 3-
wire twisted, shielded cable as shown in the following
figure. See Communications bus and supply power wiring
guidelines for more information about communication
bus terminal block functions, ratings and requirements.
Figure 6: FC bus terminal block wiring
When connecting the XPM to an SA bus, wire the bus
terminal blocks on the expansion module and other
SA bus devices in a daisy-chain configuration using 4-
wire twisted, shielded cable as shown in the following
figure. See Communications bus and supply power wiring
guidelines for more information about communication
bus terminal block functions, ratings and requirements.
M4-XPM Expansion Modules Installation Guide4

Figure 7: SA bus terminal block wiring
Note:
The PWR/SHD terminal does not supply 15 VDC. The
PWR/SHD terminal is isolated and can be used to
connect (daisy chain) the 15 VDC power leads on the
SA bus or the cable shields on the FC bus.
The SA bus supervisor (CGE, CGM, CVE, CVM, FAC,
FEC, or VMA Controllers) supplies 15 VDC to the
devices on the SA bus that require power.
SA/FC bus port
The SA/FC bus port on the front of the expansion module
is an RJ-12, 6-position modular jack that provides a
connection for devices on the SA bus or a ZFR183x Pro
Wireless Router depending on which bus the expansion
module is operating on.
The SA/FC bus port is connected internally to the SA/
FC bus terminal block. See Communications bus and
supply power wiring guidelines for more information
about communication bus port functions, ratings and
requirements. The SA/FC bus port pin assignment is
shown in Physical features.
Figure 8: Pin number assignments for sensor, SA bus
and FC bus ports on expansion modules
Supply power terminal block
The 24 VAC supply power terminal block is a gray,
removable, 2-pin terminal block that fits into a board-
mounted pin header on the top right of the controller.
Wire the 24 VAC supply power wires from the transformer
to the HOT and COM terminals on the terminal plug as
shown in Figure 9. For more information about the Supply
Power Terminal Block, see Table 5.
Figure 9: 24 VAC supply power terminal block wiring
Table 2: Supply power terminal block wiring
Description
1 Supply power terminal block
2 Supply power terminal header
3 Wires from Johnson Controls 24 VAC, class 2 power
transformer
4 24 VAC (Orange wire)
5 COM (Brown wire)
Note: The supply power wire colors may be different
on transformers from other manufacturers. Refer to
the transformer manufacturer’s instructions and the
project installation drawings for wiring details.
Important: Connect 24 VAC supply power to the
expansion module and all other network devices
so that transformer phasing is uniform across the
network devices. Powering network devices with
uniform 24 VAC supply power phasing reduces
noise, interference, and ground loop problems. The
expansion module does not require an earth ground
connection.
Important: Power wires must be less than 30
meters between expansion module and transformer.
Inputs/outputs with cables less than 30 m (100 ft)
typically do not require an offset in the software
setup. Cable runs over 30 m (100 ft) may require an
offset in the input/output software setup.
Terminal wiring guidelines, functions,
ratings, and requirements
This section provides further guidelines on input and
output wiring, maximum cable length versus load current,
and SA Bus and supply power wiring.
For information about removing a terminal block from the
expansion module, see Removing a terminal block.
M4-XPM Expansion Modules Installation Guide 5

Input and Output wiring guidelines
I/O terminal block functions, ratings and requirements
provides information and guidelines about the functions,
ratings, and requirements for the controller input and
output terminals, and Table 4 also references guidelines
for determining proper wire sizes and cable lengths.
In addition to the wiring guidelines in I/O terminal block
functions, ratings and requirements, observe these
guidelines when wiring expansion modules inputs and
outputs:
• Run all low-voltage wiring and cables separate from
high-voltage wiring.
• All input and output cables, regardless of wire size or
number of wires, should consist of stranded, insulated,
and twisted copper wires.
• Shielded cable is not required for input or output
cables.
• Shielded cable is recommended for input and output
cables that are exposed to high electromagnetic or
radio frequency noise.
• Inputs/outputs with cables less than 30 m (100 ft)
typically do not require an offset in the software setup.
Cable runs over 30 m (100 ft) may require an offset in
the input/output software setup.
M4-XPM Expansion Modules Installation Guide6

I/O terminal block functions, ratings and requirements
Table 3: I/O terminal block functions, functions, ratings, requirements, and cable guidelines
Terminal Block label Terminal
label
Function, ratings, requirements Determine wire size and
maximum cable length
+15 V 15 VDC Power Source for active (3-wire) input devices
connected to the Universal UI-n terminals.
Provides 100 mA total current
Same as (Universal) UI-n
Note: Use 3-wire cable for
devices that source power
from the +15V terminal.
Analog Input - Voltage Mode (0–10 VDC)
10 VDC maximum input voltage
Internal 10k ohm Pull-down
See Guideline A in Table 4
Analog Input - Current Mode (4–20 mA)
Internal 100 ohm load impedance
Note: Current loop jumpers must be in the Enabled
position to maintain a closed 4-20 mA current loop. See
Setting the UI current loop jumpers.
See Guideline B in Table 4.
Analog Input - Resistive Mode (0–600k ohm)
Internal 12 V. 15k ohm pull up
Qualified Sensors: 0-2k ohm potentiometer, RTD (1k Nickel
[Johnson Controls® sensor], 1k Platinum, and A99B Silicon
Temperature Sensor) Negative Temperature Coefficient (NTC)
Sensor
See Guideline A in Table 4.
UI-n
Binary Input - Dry Contact Maintained Mode
1 second minimum pulse width
Internal 12 V. 15k ohm pull up
See Guideline A in Table 4.
UNIVERSAL
(Inputs)
UI-CnUniversal Input Common for all Universal Input terminals
Note: All Universal UI-Cn terminals share a common,
which is isolated from all other commons.
Same as (Universal) UI-n
Binary Input - Dry Contact Maintained Mode
0.01 second minimum pulse width
Internal 18 V. 3k ohm pull up
BI-n
Binary Input - Pulse Counter/Accumulator Mode
0.01 second minimum pulse width
(50 Hz at 50% duty cycle)
Internal 18 V. 3k ohm pull up
BINARY
(Inputs)
BI-CnBinary Input Common for all Binary Input terminals
Note: All Binary BI-Cn terminals share a common,
which is isolated from all other commons, except the
Configurable Output (CO) common (CO-Cn) when the
CO is defined as an Analog Output.
See Guideline A in Table 4.
Analog Output - Voltage Mode (0–10 VDC)
10 VDC maximum output voltage
10 mA maximum output current
Required an external load of 1,000 ohm or more.
See Guideline A in Table 4.CONFIGURABLE
(Outputs)
CO-n
Binary Output - 24 VAC Triac (External Power Source only)
Connects CO-n to CO-Cn when activated.
External Power Source Requirements:
24 VAC maximum output voltage
0.5 A maximum output current
40 mA minimum load current
See Guideline C in Table 4.
M4-XPM Expansion Modules Installation Guide 7

Table 3: I/O terminal block functions, functions, ratings, requirements, and cable guidelines
Terminal Block label Terminal
label
Function, ratings, requirements Determine wire size and
maximum cable length
CO-CnAnalog Output Signal Common All Configurable Outputs
(COs) defined as Analog Outputs (AOs) share a common,
which is isolated from all other commons except the Binary
Input common.
Binary Output Signal Common All Configurable Outputs
(COs) defined as Binary Outputs are isolated from all other
commons, including other CO commons.
Same as (Configurable) CO-n.
Analog Output - Voltage Mode (0–10 VDC)
10 VDC maximum output voltage
10 mA maximum output current
Required an external load of 1,000 ohm or more.
Note: The Analog Output (AO) operates in the Voltage
Mode when connected to devices with impedances
greater than 1,000 ohm. Devices that drop below 1,000
ohm may not operate as intended for Voltage Mode
applications.
AO-n
Analog Output - Current Mode (4–20 mA)
Requires and external load between 0 and 300 ohm.
Note: The Analog Output (AO) operates in the Current
Mode when connected to devices with impedances less
than 300 ohm. Devices with impedances greater than
300 may not operate as intended for Current Mode
applications.
ANALOG
(Outputs)
AO-CnAnalog Output Signal Common for all Analog Output
terminals.
Note: All Analog Output Common terminals (AO-
Cn) share a common, which is isolated from all other
commons.
See Guideline C in Table 4.
BO-nBinary Output - 24 VAC Triac (External Power Source)
Connects BO-n to BO-Cn when activated.
External Power Source Requirements:
24 VAC maximum output voltage
0.5 A maximum output current
40 mA minimum load current
BINARY
(Output)
BO-CnBinary Output Common for all Binary Output terminals.
Note: Each Binary Output Common terminal (BO-Cn) is
isolated from all other commons, including other Binary
Output Common terminals.
See Guideline C in Table 4.
M4-XPM Expansion Modules Installation Guide8

Cable and wire length guidelines
Table 4 defines cable length guidelines for the various wire sizes that may be used for wiring low-voltage (<30 V) input
and outputs. The required wire sizes and lengths for high-voltage (>30 V) Relay Outputs are determined by the load
connected to the relay, and local, national or regional electrical codes.
Table 4: Cable length guidelines
Guideline Wire size/Gauge and type Maximum cable length
and type
Assumptions
1.0 mm (18 AWG) stranded copper 457 m (1,500 ft) twisted
wire
0.8 mm (20 AWG) stranded copper 297 m (975
ft) twisted wire
297 m (975 ft) twisted
wire
0.6 mm (22 AWG) stranded copper 183 m (600
ft) twisted wire
183 m (600 ft) twisted
wire
A
0.5mm (24 AWG) stranded copper 107 m (350 ft)
twisted wire
107 m (350 ft) twisted
wire
100 mV maximum voltage drop
Depending on the cable length and the
connected input or output device, you may
have to define an offset in the setup software
for the input or output point.
1.0 mm (18 AWG) stranded copper 229 m (750 ft) twisted
wire
0.8 mm (20 AWG) stranded copper 297 m (975
ft) twisted wire
137 m (450 ft) twisted
wire
0.6 mm (22 AWG) stranded copper 183 m (600
ft) twisted wire
91 m (300 ft) twisted wire
B
0.5 mm (24 AWG) stranded copper 107 m (350
ft) twisted wire
61 m (200 ft) twisted wire
100 mV maximum voltage drop
Depending on the cable length and the
connected input or output device, you may
have to define an offset in the setup software
for the input or output point.
CSee Figure 10 to select wire size/gauge.
Use stranded copper wire.
See Figure 10 to
determine cable length.
Use twisted wire cable.
N/A
Maximum cable length versus load current
Use the following figure to estimate the maximum cable
length relative to the wire size and the load current (in
mA) when wiring inputs and outputs.
Note: Figure 10 applies to low-voltage (<30 V) inputs
and outputs only.
Figure 10: Maximum wire length for low-voltage (<30 V) Inputs and Outputs by current and wire size
M4-XPM Expansion Modules Installation Guide 9

Communications bus and supply power
wiring guidelines
Table 5 provides information about the functions, ratings,
and requirements for the communication bus and supply
power terminals. The table also provides guidelines for
wire sizes, cable types, and cable lengths for wiring the
expansion module's communication bus and supply
power.
In addition to the guidelines in Table 5, observe the
following guidelines when wiring an FC bus, SA bus, or the
24 VAC supply power:
• Run all low-voltage wiring and cables separate from
high-voltage wiring.
• All SA and FC bus cables, regardless of wire size, should
be twisted, insulated, stranded copper wire.
• Shielded cable is strongly recommended for all SA and
FC bus cables.
• Refer to the MS/TP Communications Bus Technical
Bulletin (LIT-12011034) for detailed information
regarding wire size and cable length requirements for
FC and SA buses.
Table 5: Communications bus and supply power terminal block functions, ratings, requirements, and cable
guidelines
Terminal block/
Port label
Terminal
labels
Function, electrical ratings/Requirements Recommended cable type
+
-
FC or SA Bus Communications
COM Signal Reference (Common) for FC or SA Bus
communications
FC BUS
or
SA BUS
SHD
or
PWR
SHD on FC Bus: Isolated terminal (optional shield drain
connection
PWR on SA Bus: 15 VDC power lead connection.
(Maximum total current draw for SA bus is 240 mA.)
Note: The PWR terminal on an XPM expansion
module does not supply 15 VDC. The SA bus
supervisor (CGE,CGM, CVE, CVM, FAC, FEC, VMA)
supplies 15 VDC to devices on the SA bus requiring
power.
FC Bus: 0.6 mm (22 AWG) stranded,
3-wire twisted, shielded cable
recommended.
SA Bus: 0.6 mm (22 AWG) stranded, 4-
wire (2 twisted-pairs), shielded cable
recommended.
Note: On the SA Bus, the + and
- wire are one twisted pair, and
the COM and PWR are the second
twisted pair of wires.
SA/FC BUS
(Port)
RJ-12 6-Position Modular Connector provides:
• FC or SA Bus Communications
• FC or SA Bus Signal Reference and 15 VDC
Common
24 AWG 3-pair CAT 3 Cable <30.5 m (100
ft)
HOT 24 VAC Power Supply - Hot
Supplies 20–30 VAC (Nominal 24 VAC)
24V~
COM 24 VAC Power Supply - Common
(Isolated from all other Common terminals on
controller.)
0.8 mm to 1.0 mm
(18 AWG) 2-wire
Note: See table labeled Cable length guidelines for
recommended wire sizes for low-voltage (<30 V) Inputs
and Outputs to determine wire size and cable lengths
for cables.
Note: The SA Bus and FC Bus wiring
recommendations in this table are for MS/TP
bus communications at 38,400 baud. For more
information, refer to the MS/TP Communications Bus
Technical Bulletin (LIT-12011034).
Termination diagrams
A set of Johnson Controls termination diagrams provides details for wiring inputs and outputs to the expansion modules.
See the figures in this section for the applicable termination diagrams.
Note: References to the analog output apply to the XPM09090 model only.
M4-XPM Expansion Modules Installation Guide10

Table 6: Termination details
Type of field
device
Type of Input/
Output
Termination diagrams
Temperature
Sensor
UI
Voltage Input -
External Source
UI
Voltage Input -
Internal Source
UI
Voltage Input
(Self-Powered)
UI
Current Input -
External Source
(Isolated)
UI
M4-XPM Expansion Modules Installation Guide 11

Table 6: Termination details
Type of field
device
Type of Input/
Output
Termination diagrams
Current Input -
Internal Source (2-
wire)
UI
Current Input -
Internal Source (3
wire)
UI
Current Input -
External Source (in
Loop)
UI
Feedback from
EPP-1000
UI
Dry Contact
(Binary Input)
UI or BI
M4-XPM Expansion Modules Installation Guide12

Table 6: Termination details
Type of field
device
Type of Input/
Output
Termination diagrams
0–10 VDC Output
to Actuator
(External Source)
AO
0–10 VDC Output
to Actuator
(Internal Source)
AO
Current Output AO
24 VAC Triac
Output (Switch
Low, External
Source)
AO
Analog Output
(Current)
AO
M4-XPM Expansion Modules Installation Guide 13

Table 6: Termination details
Type of field
device
Type of Input/
Output
Termination diagrams
4–20 mA Output to
Actuator
AO
4–20 mA Output to
Actuator
AO
Incremental
Control to
Actuator (Switch
Low, Externally
Sourced)
BO
24 VAC Binary
Output (Switch
Low, Externally
Sourced)
BO
24 VAC Binary
Output (Switch
High, Externally
Sourced)
BO
M4-XPM Expansion Modules Installation Guide14

Table 6: Termination details
Type of field
device
Type of Input/
Output
Termination diagrams
Incremental
Control to
Actuator (Switch
High, Externally
Sourced)
BO
Network Stat with
Phone Jack (Fixed
Address = 199)
SA Bus
Note: The bottom jack (J2) on the TE-700 and TE-6x00 Series Sensors is not usable as a zone
bus or an SAB connection.
Network Stat
with Terminals
Addressable
SA Bus
Network Stat with
Terminals (Fixed
Address = 199)
SA Bus
M4-XPM Expansion Modules Installation Guide 15

Setup and adjustments
Important: Electrostatic discharge can damage
controller components. Use proper electrostatic
discharge precautions during installation, setup, and
servicing to avoid damaging the controller.
Configuring wireless communications
About this task:
To configure an expansion module for use with the
ZFR183x Pro Series Wireless Field Bus system, complete
the following steps:
1. Disconnect the 24 VAC supply from the expansion
module.
2. Wire the input/output terminals and FC bus.
Note: In wireless network applications, do
not connect any wires to the FC bus terminal
block.
3. Important: Before the XPM expansion module
is powered on, connect the ZFR183x Pro Wireless
Field Bus Router to the FC bus port (RJ-12 modular
jack) on the front of the device.
4. Ensure that the expansion module's rotary
switches are set to the correct device address. For
details about setting a device address, see Setting
the device address.
5. Reconnect the 24 VAC supply to the expansion
module.
For more information about the ZFR Pro Wireless
Field Bus system, refer to the WRG1830/ZFR183x
Pro Series Wireless Field Bus System Technical Bulletin
(LIT-12013553).
Setting the device address
About this task:
Metasys expansion modules are manager devices on
MS/TP (FC or SA) buses. Before you operate expansion
modules on a bus, you must set a valid and unique
device address for each expansion module on the bus.
You set the XPM device address by setting the positions
of the Device Address rotary switches at the top of the
expansion module.
The following table describes the valid rotary switch
device addresses for communications bus applications.
Table 7: Switch device addresses
FC Bus communication
mode
Valid device address range
Wired MS/TP
communication
4-127
Note: Addresses 0-3 are
reserved and not for use on
expansion modules.
ZFR Pro wireless
communication
4-127
Note: Addresses 0-3 are
reserved and not for use on
expansion modules.
The device address is a decimal address that is set using
three rotary switches located at the top of the expansion
module. The numbers are ordered from left to right,
100s, 10s, and 1s when the expansion module is oriented
as shown in Physical features. In the following figure,
the switches are set to 1 2 3, designating this expansion
module's device address as 123.
Figure 11: Device address rotary switch block
The device address must match the device address
defined in the Controller Configuration Tool (CCT) under
Define Hardware > Network Settings.
To set the device addresses on XPM expansion modules,
complete the following steps:
1. Set a unique and sequential device address for
each of the devices connected on the FC or SA Bus,
starting with device address 4.
2. To ensure the best bus performance, set sequential
device addresses with no gaps in the device
address range (4, 5, 6, 7, 8, 9, and so on). The
devices do not need to be physically connected on
the bus in their numerical device address order.
3. Write each expansion module's device address on
the white label below the device address rotary
switch block on the expansion module's cover.
Refer to the MS/TP Communications Bus Technical
Bulletin (LIT-12011034) for more information about
device addresses and how to set them on MS/TP
buses.
Removing a terminal block
About this task:
To remove a terminal block from the circuit board,
complete the following steps:
Note: You need a flat blade screwdriver to remove
the terminal block.
1. To prevent any possibility of damage from an
accidental short, remove power from the
expansion module.
M4-XPM Expansion Modules Installation Guide16

2. Underneath the terminal block, in the small gap
between the bottom of the terminal block and
the circuit board, insert the flat blade of the
screwdriver.
Figure 12: Terminal block
3. To detach the left-hand side of the terminal block,
position the flat blade underneath the terminal
block to the left, and push down the screwdriver
handle. When you do this, you are using the
screwdriver as a lever to pry up the terminal block.
4. To detach the right-hand side of the terminal block,
position the flat blade underneath the terminal
block to the right, and push down the screwdriver
handle.
5. If necessary, repeat steps 3 and 4 until the terminal
block is removed.
Removing the expansion module cover
About this task:
Important: Electrostatic discharge can damage
expansion module components. Use proper
electrostatic discharge precautions during
installation, setup, and servicing to avoid damaging
the expansion module.
Important: Disconnect all power sources to
the expansion module before removing cover
and changing the position of any jumper or the
EOL switch on the expansion module. Failure to
disconnect power before changing a jumper or
EOL switch position can result in damage to the
expansion module and void any warranties.
The expansion module cover is held in place by four
plastic latches that extend from the base and snap into
slots on the inside of the housing cover.
To remove the expansion module cover, complete the
following steps:
1. Place your fingertips under the two cover lift tabs
(Physical features) on the sides of the housing
cover and gently pry the top of the cover away
from the base to release the cover from the two
upper latches.
2. Pivot the top of the cover further to release it from
the lower two latches.
3. Replace the cover by placing it squarely over the
base, and then gently and evenly push the cover
on to the latches until they snap into the latched
position.
Figure 13: XPM with cover removed showing EOL
switch and jumper positions (XPM09090 model shown)
Setting the End-of-Line (EOL) switch
About this task:
Each XPM expansion module has an EOL switch, which,
when set to ON (up), sets the expansion module as a
terminating device on the bus. See figure labeled XPM with
cover removed showing EOL switch and jumper positions for
the EOL switch location. The default EOL switch position is
OFF (down).
Figure 14: End-of-Line switch positions
To set the EOL switch on an expansion module, complete
the following steps:
1. Determine the physical location of the expansion
module on the SA or FC bus.
2. Determine if the expansion module must be set as
a terminating device on the bus.
Note: SA and FC buses have different EOL
termination rules. For detailed information
about EOL termination rules and EOL switch
settings, refer to the MS/TP Communications
Bus Technical Bulletin (LIT-12011034).
3. If the expansion module is a terminating device
on the FC bus, set the EOL switch to ON. If the
expansion module is not a terminating device on
the bus, set the EOL switch to Off.
When an expansion module is connected to power
with its EOL switch set to ON, the amber EOL LED
on the controller cover is illuminated.
M4-XPM Expansion Modules Installation Guide 17

Setting the UI current loop jumpers
CAUTION
Risk of Electric Shock:
Disconnect supply power to the expansion module
before attempting to adjust the UI current loop
jumpers. Failure to disconnect the supply power may
result in electric shock.
ATTENTION
Mise En Garde: Risque de décharge électrique:
Débrancher l'alimentation de l'controller avant tout
réglage du UI current loop jumpers. Le non-respect de
cette précaution risque de provoquer une décharge
électrique.
The UI current loop jumpers are on the circuit board
under the expansion module cover near the UI terminals
(Figure 13). When a UI is defined (in the system software)
as a 4-20 mA Analog Input, set the UI's current loop
jumper to the Enabled position (Figure 15).
Figure 15: UI Current loop jumper positions
Setting the current loop jumper to the Enabled position,
connects an internal 100 ohm resistor across the UI
terminals, which maintains the 4-20 mA current loop
circuit even when power to the expansion module is
interrupted or off.
Important: Current Loop jumpers must be in the
Disabled (default) position for all UIs that are not set
up to operate as 4-20 mA analog inputs.
Important: A current loop jumper must be in the
Enabled position to maintain a closed 4-20 mA
current loop.
The following tables identify the current loop switches
associated with each UI on the XPM09090 and XPM04060
models.
Table 8: XPM09090 UI Inputs and jumper labels
Universal Input
label
Jumper label on circuit board
UI-1 J13
UI-2 J14
UI-3 J15
UI-4 J16
UI-5 J17
UI-6 J18
UI-7 J19
Table 9: XPM04060 UI Inputs and jumper labels
Universal Input
label
Jumper label on circuit board
UI-1 J10
UI-2 J11
UI-3 J12
Commissioning
You commission expansion modules with the Controller
Configuration Tool (CCT) software using either Mobile
Access Portal (MAP) Gateway, a ZFR wireless dongle, or in
passthrough mode when connected to a Network Engine.
Refer to the Controller Tool Help (LIT-12011147) for detailed
information on commissioning expansion modules.
Troubleshooting expansion modules
Observe the Status LEDs on the front of the expansion module. Table 10 provides LED status indicator information for
troubleshooting the expansion module. To troubleshoot a local controller display, refer to the DIS1710 Local Controller
Display Technical Bulletin (LIT-12011270) or Local Controller Display User Guide (LIT-12013762).
M4-XPM Expansion Modules Installation Guide18

LED status and states
Table 10: Status LEDs and description of LED states
LED label LED color Normal LED state Description of LED states
POWER Green On Steady Off Steady = No Supply Power or the controller’s polyswitch/resettable fuse is
open. Check Output wiring for short circuits and cycle power to controller.
On Steady = Power Connected
FAULT Red Off Steady Off Steady = No Faults
On Steady = Device Fault; no application loaded
Blink - 2 Hz = Startup in progress, not ready for normal operation
Rapid blink = SA Bus communications issue
SA/FC BUS Green Blink - 2 Hz Blink - 2 Hz = Data Transmission (normal communication)
Off Steady = No Data Transmission
On Steady = Communication lost, waiting to join communication ring
EOL Amber Off (Except on
terminating
devices)
On Steady = EOL switch in ON position
Off Steady = EOL switch in Off position
Ordering information and accessories
The following tables provide the product code number and description for the XPM models and accessories.
Table 11: XPM Series ordering information
Product code number Description
M4-XPM04060-0 10-point Input/Output Expansion Module
Includes: MS/TP communication; 10 points (3 UI, 1 BI, 4 CO, 2 BO); 24VAC input
M4-XPM09090-0 18-point Input/Output Expansion Module
Includes: MS/TP communication; 18 points (7 UI, 2 BI, 4 CO, 2 AO, 3 BO); 24VAC input
M4-XPM18000-0 18-point Input Expansion Module
Includes: MS/TP communication; 18 points (18 BI); 24VAC input
Table 12: XPM series accessories (order separately)
Product Code Number Description
TL-CCT-0 Controller Configuration Tool (CCT) software
MS-FCP-0 Metasys Equipment Controller Firmware Package Files required for CCT
Mobile Access Portal (MAP) Gateway Refer to the Mobile Access Portal Gateway Catalog Page (LIT-1900869) to identify the
appropriate product for your region.
WRZ Series Wireless Room Sensors Refer to the WRZ Series Wireless Room Sensors Product Bulletin (LIT-12011653) for
specific sensor model descriptions.
WRZ-7860-0 Receiver for One-to-One Wireless Room Sensing Systems - functions with WRZ
Series Sensors
Refer to the WRZ-7860 Receiver for One-to-One Wireless Room Sensing Product
Bulletin (LIT-12011640) for a list of available products.
WRZ-SST-120 Wireless System Survey Tool. For use with the lower power 10mW WRZ and
WRZ-7860 systems.
Refer to the WRZ-SST-120 Wireless Sensing System Tool Installation Guide
(24-10563-55) for usage instructions.
ZFR-HPSST-0 Wireless System Survey Tool. For use with the higher power WRG1830/ZFR183x
System and lower power WRZ Sensors (10mW). Refer to the ZFR-HPSST-0 Wireless
Sensing System Tool Installation Guide (Part No. 24-11461-00012) for usage
instructions.
M4-XPM Expansion Modules Installation Guide 19

Table 12: XPM series accessories (order separately)
Product Code Number Description
Receiver for One-to-One Wireless Room Sensing
WRG1830/ZFR183x Pro Series Wireless Field Bus
System
For more information on products needed for wireless field bus installations and
for a list of available products, refer to the WRG1830/ZFR183x Pro Series Wireless
Field Bus System Catalog Page (LIT-1901153).
Y64T15-0 Transformer, 120/208/240 VAC Primary to 24 VAC Secondary, 92 VA, Foot Mount,
72.2 cm (30 in.), Primary Leads and 76.2 cm (30 in.) Secondary Leads, Class 2
Y65A13-0 Transformer, 120 VAC Primary to 24 VAC Secondary, 40 VA, Foot Mount (Y65AS),
20.32 cm (8 in.), Primary Leads and 76.2 cm (30 in.) Secondary Leads, Class 2
Y65T31-0 Transformer, 120/208/240 VAC Primary to 24 VAC Secondary, 40 VA, Foot Mount
(Y65AR+), 20.32 cm (8 in.), Primary Leads and Secondary Screw Terminals, Class 2
Y65T42-0 Transformer, 120/208/240 VAC Primary to 24 VAC Secondary, 40 VA, Hub Mount
(Y65SP+), 20.32 cm (8 in.), Primary Leads and Secondary Screw Terminals, Class 2
ACC-TBKINOUT-0 Input and Output terminal block replacement kit for SNC, CGE, CGM, CVE, CVM
and XPM products. Kit includes 5 of each 2, 3, and 4 position Input and Output
terminal blocks. 30 terminal blocks in total.
ACC-TBKPWFCSA-0 Power, FC Bus, and SA Bus terminal block replacement kit for SNC, CGE, CGM, CVE,
CVM, and XPM products. Kit includes 5 of each terminal block type. 15 terminal
blocks in total.
MS-FIT100-0 The Field Inspection Tool or (FIT) is a portable handheld device with a user
interface that is used to test and troubleshoot the BACnet protocol MS/TP RS-485
communications bus that connects supervisory controllers and equipment
controllers to field point interfaces.
The FIT can be used to check out the wiring of the MS/TP RS-485 bus as well
as verify proper communications of supervisory controllers and equipment
controllers connected to the bus. The FIT can be used on both the FC Bus and SA
Bus.
TL-BRTRP-0 Portable BACnet/IP to MS/TP Router
XPM Expansion Modules technical specifications
Table 13: Technical specifications
Power requirement 24 VAC (nominal, 20 VAC minimum/30 VAC maximum), 50/60 Hz, Power Supply Class 2
(North America), Safety Extra-Low Voltage (SELV) (Europe)
Power consumption 14 VA maximum
Note: The VA rating does not include any power supplied to the peripheral devices
connected to Binary Outputs (BOs) or Configurable Outputs (COs), which can
consume up to 12 VA for each BO or CO; for a possible total consumption of an
additional 84 VA (maximum).
Power source +15 VDC power source terminals provide 100 mA total current.
Note: Only present on XPM09090 and XPM04060 models.
•M4-XPM09090-0: Quantity 2-located in Universal Input terminals for active (3-wire)
input devices.
•M4-XPM04060-0: Quantity 1-located in Universal Input terminals for active (3-wire)
input devices.
Ambient conditions Operating: 0°C to 50°C (32°F to 122°F); 10% to 90% RH noncondensing
Storage: -40°C to 80°C (-40°F to 176°F); 5% to 95% RH noncondensing
Network engines All network engine model types
Communications protocol BACnet MS/TP; Zigbee Wireless also supported (at FC Bus and for Sensors) with additional
hardware.
XPM expansion modules support Zigbee wireless functionality for the FC bus and for
sensors with additional hardware.
Device addressing for BACnet MS/TP Decimal address set using the three rotary switches; valid controller device addresses
4-127
M4-XPM Expansion Modules Installation Guide20
