Johnson Controls Mercury 3 Series Manual

24-10707-198 Revision –
December 2017
P2000
Security Management System
CKM-MR52-S3
authentic Mercury™ terminal module
hardware
installation

Copyright 2017
Johnson Controls
All Rights Reserved
No part of this document may be reproduced without the prior permission of Johnson Controls.
If this document is translated from the original English version by Johnson Controls, all reasonable
endeavors will be used to ensure the accuracy of translation. Johnson Controls shall not be liable
for any translation errors contained herein or for incidental or consequential damages in connection
with the furnishing or use of this translated material.
Due to continuous development of our products, the information in this document is subject to
change without notice. Johnson Controls shall not be liable for errors contained herein or for
incidental or consequential damages in connection with furnishing or use of this material. Contents
of this publication may be preliminary and/or may be changed at any time without any obligation to
notify anyone of such revision or change, and shall not be regarded as a warranty.
Other Manufacturers’ Documentation
Johnson Controls does not duplicate documentation of other equipment manufacturers. When
necessary, Johnson Controls provides documentation that supplements that of other manufacturers.
When unpacking your equipment, keep all original manufacturer documentation for reference.
Technical Support
For factory technical support, Johnson Controls authorized field technicians or authorized dealer
representatives can contact Global Security Solutions Technical Support by phone at
[phone] or [phone], or by email at [email protected]. They
can also call the Field Support Center at [phone] or [phone] and use options 6, 1, 7.
End users and customers should contact their local Johnson Controls branch or authorized dealer
for any of their support needs (technical support, maintenance contracts, on-site field support,
P2000 Software Service Agreements, Service Partnerships, and so on). Visit
http://www.johnsoncontrols.com/location-finder to find your local Johnson Controls office.
For material returns contact the branch if the material was purchased through a Johnson Controls
branch or through the Product Sales Operations Team, if ordered through the Advanced Order
Management System (AOMS) and follow the RMA process; or contact the authorized dealer
representative where the material was purchased directly.
Single Point of Contact by Region
Acknowledgment
Metasys® and Johnson Controls® are trademarks of Johnson Controls. All other company and
product names are trademarks or registered trademarks of their respective owners.
European Single Point of Contact
JOHNSON CONTROLS
WESTENDHOF 3
45143 ESSEN
GERMANY
NA/SA Single Point of Contact
JOHNSON CONTROLS
507 E MICHIGAN ST
MILWAUKEE WI 53202
USA
APAC Single Point of Contact
JOHNSON CONTROLS
C/O CONTROLS PRODUCT
MANAGEMENT
NO. 22 BLOCK D NEW DISTRICT
WUXI JIANGSU PROVINCE 214142
CHINA

Declarations of Conformity
United States: This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference to
radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own expense.
Canada: CAN ICES-3 (A)/NMB-3(A)
European Union: This product complies with the requirements of the EMC Directive.
This equipment must not be modified for any reason and it must be installed as stated in the
Manufacturer’s instruction.
If this shipment (or any part thereof) is supplied as second-hand equipment, equipment for sale
outside the European Economic Area or as spare parts for either a single unit or system, it is not
covered by the Directives.

UNDERWRITERS LABORATORIES COMPLIANCE VERIFICATION SHEET
The following model number is listed under Underwriters Laboratories® (UL) 1076 for Proprietary
Burglar Alarm Units and Systems, UL 294 for Access Control Systems Units and Underwriters
Laboratories of Canada ULC/ORD-C1076-86.
CKM-MR52-S3
When installed at the site the following requirements must be met to comply with these standards.
1. The CKM-MR52-S3 shall be mounted in Listed Enclosures CKM-CE75-E2M, CKM-CE150-
E4M, and Listed Burglar Alarm and Access Control System Units SPF10000-1I00, SPF1I100-
1I00 or SPF1I300-1J00.
2. A CKM-MR52-S3 mounted in Listed Enclosures CKM-CE75-E2M, CKM-CE150-E4M, and
Listed Burglar Alarm and Access Control System Units SPF10000-1I00, SPF1I100-1I00 or
SPF1I300- 1J00 shall be powered through the CKM-F8P power distribution module.
3. Transient protection devices that are installed must not be removed or defeated.
4. Do not connect equipment to an AC power source that is controlled by a switch.
5. A 1.5Kohm/750ohm custom end-of-line resistance supervised circuit was investigated by
Underwriter Laboratories.
6. Power for devices connected through relay/control output wiring must be provided by a UL
Listed power limited power source.
7. RS485-type readers have not been investigated by Underwriters Laboratories.
8. Encrypted communication has not investigated by Underwriters Laboratories.
9. For a UL 294 Listed system the following Listed readers may be used.
Manufacturer Models
HID Global Corp. 30387, 31503, 31815, 31880, 32005, 32788, 32985
5355, 5365, 5395, 5405, 5455, 6005, 6100, 3110-6445,
R10T, R10N, R15N, R15T, RP15N, RP15T, R40N,
R40T, RK40N, RK40T, RP40N, RP40T, RPK40N,
RPK40T
All models may be followed by additional suffixes
OSDP Readers: R10Exxx, RP10Exxx, R15Exxx, RP15Exxx,
R30Exxx, RP30Exxx, R40Exxx, RP40Exxx, RK40Exxx,
RPK40Exxx.
All models may be followed by additional suffixes. The last “X” in
the model number maybe an “R” or “N”
Mercury Security Corp. MR-5, MR-20
10. The maximum Wiegand line impedance is 8 ohms, representing 22 AWG @ 500 feet.
11. The HID 3110-6445 shall be powered by a separate power source that is UL 294 or UL 603
power limited power source.
12. Suitable for use with the model P2K-nnn-UL-x Security Management System, where n can be
any number 0 through 9 and where x can be any three letters A through Z.
13. UL 294 Performance Levels
Destructive Attack Level I
Endurance Level IV
Line Security Level I
Standby Power Level I

CKM-MR52-S3 Hardware Installation Manual
24-10707-198 Rev. –
1
CKM-MR52-S3 READER TERMINAL MODULE
This document provides hardware installation and setup instructions for
CKM-MR52-S3, the authentic Mercury™ dual reader terminal module
Series 3. This document is divided into the following sections:
•General Information on page 1
•Mounting Information on page 2
•Wiring Information on page 2
•Jumper and DIP Switch Usage on page 7
•Status LEDs on page 9
•Specifications on page 11
•Maintenance on page 12
NOTE: Throughout this manual the CKM-MR52-S3 module is also referred to as
the CKM-MR52.
GENERAL INFORMATION
The CKM-MR52 reader interface provides a solution to the OEM system
integrator for interfacing to TTL, Wiegand, or RS-485 type readers and door
hardware. The CKM-MR52 can accept data from reader with clock/data,
Wiegand, or RS-485 signaling, and provide a tri-stated LED control and buzzer
control. Six form-C relay outputs may be used for strike control or alarm
signaling. Eight supervised inputs are provided for monitoring the door contact,
exit push button, and alarm contacts. Communication to the CKM-MR52 is
accomplished via a 2-wire RS-485 interface.
The CKM-MR52 requires 12 to 24 VDC for power. See the following figure
for component location.

CKM-MR52-S3 Hardware Installation Manual
24-10707-198 Rev. –
2
MOUNTING INFORMATION
Figure 1: CKM-MR52 Hardware
WIRING INFORMATION
This sections covers the following:
•Cable Routing
•Power Wiring
•Communications Wiring (SIO Communication Port)
•Reader Wiring
•Alarm Contact Wiring
•Control Output Wiring

CKM-MR52-S3 Hardware Installation Manual
24-10707-198 Rev. –
3
Cable Routing
The cables should run in grounded conduit or at least two feet from AC
power, fluorescent lights, or other high energy sources.
IMPORTANT: All data cables should be physically separated from power lines. If
conduit is used, do not run data cables in the same conduit as power cables or
certain door strike cables, e.g. strike voltage greater that 42V or Magnetic door
locks without EMI suppression.
All cables must conform with the following regulations:
• National Electrical Code
•NFPA 70
• Local electrical codes
• Canadian Electric Code C22.1 (installations in Canada)
• BSI Standard BS7671, latest edition (installations in Great Britain)
Cabling should be made using good wiring practices and should be long
enough to allow service loops at their terminations in the enclosure.
Power Wiring
The CKM-MR52 accepts 12 to 24 VDC for power on TB7. Locate the
power source as close to the CKM-MR52 as possible. Make power
connection with minimum of 18 AWG wires.
Figure 2: CKM-MR52 Supplying Power
IMPORTANT: Observe polarity on VIN.
NOTE: VOUT is not used.
12 TO 24Vdc
GND
VIN
+
-
TB7

CKM-MR52-S3 Hardware Installation Manual
24-10707-198 Rev. –
4
Communications Wiring (SIO Communication Port)
The CKM-MR52 communicates to an intelligent controller (for example,
CKM-EP2500) via a 2-wire RS-485 interface. The CKM-MR52 allows
for multidrop communication on a bus of up to 4,000 feet (1,200 m). Use
twisted pairs (minimum 24 AWG) with drain wire and shield for
communication. See Specifications for details.
Install RS-485 termination jumper, J4, on the interface boards at each end
of the communication line only.
Figure 3 shows the CKM-MR52 communications wiring.
Figure 3: CKM-MR52 Communications Wiring
Reader Wiring
Each reader port supports a reader with TTL (D1/D0, Clock/Data) or 2-wire
RS-485 signaling. Power to the reader is selectable: 12 VDC (VIN must be
greater than 20 VDC), or power is passed-through (PT) from the input voltage
of the MR52 (TB7-VIN), 300 mA maximum per reader port. Readers that
require different voltage or have high current requirements must be powered
separately. Refer to the reader manufacture specifications for cabling
requirements. In the 2-wire LED mode the buzzer output is used to drive the
second LED. Reader port configuration is set via the host software.

CKM-MR52-S3 Hardware Installation Manual
24-10707-198 Rev. –
5
To fully utilize each reader port:
• TTL signaling requires a 6-conductor cable (18 AWG)
• RS-485 signaling requires two 2-conductor cables. Use one cable for
power (18 AWG) and one cable for communication (24 AWG, with
drain wire and shield).
Figure 4: J1 - Reader Port Power Select
Figure 5: Typical D1/D0 - Clock/Data Reader
Figure 6: Typical 2-Wire RS-485 Device
NOTE: If the input voltage to the MR52 is 12 VDC, jumper J1 must be in the PT
position.

CKM-MR52-S3 Hardware Installation Manual
24-10707-198 Rev. –
6
Alarm Contact Wiring
There are 8 inputs that are typically used to monitor door position,
request to exit or alarm contacts. Input circuits can be configured as:
• Unsupervised alarm (2 states); reporting as open or closed contact.
• Supervised alarm (6 states); reporting as open or closed contact, open
circuit, shorted circuit, grounded circuit *, or foreign voltage*.
A supervised input circuit requires adding two resistors with value of 1k
Ohm, 1% to the circuit to facilitate proper reporting and should be located
as close to the sensor as possible. Custom end of line (EOL) resistances
may be configured via the host software.
* Grounded and foreign voltage states are not a requirement of UL 294
and therefore not verified by UL.
The input circuit wiring configurations shown are supported but may not
be typical.
Figure 7: CKM-MR52 Alarm Contact Wiring
There are two additional inputs for monitoring cabinet tamper (TMP) and
power failure (PFL). These two inputs do not use EOL resistors and are
for contacting monitoring only.
Control Output Wiring
Six form-C contact relays are provided for controlling door strikes or
other devices. Load switching can cause abnormal contact wear and
premature contact failure. Switching of inductive loads (strike) also
causes EMI (electromagnetic interference) which may interfere with
normal operation of other equipment.

CKM-MR52-S3 Hardware Installation Manual
24-10707-198 Rev. –
7
To minimize premature contact failure and to increase system reliability,
contact protection circuit must be used. The following two circuits are
recommended. Locate the protection circuit as close to the load as
possible, within 12 inches30cm), as the effectiveness of the circuit
decreases if it is located further away.
Use sufficiently large gauge of wires for the load current as to avoid
voltage loss.
Figure 8: CKM-MR52 Control Output Wiring
JUMPER AND DIP SWITCH USAGE
Switches 1 to 5 select the device address. Switch 6 and 7 select the
communication baud rate. Switch 8 enables encrypted communication. All
other configuration settings are set via host software.
Table 1: Switches
S8 S7 S6 S5 S4 S3 S2 S1 Selection
OFF OFF OFF OFF OFF Address 0
OFF OFF OFF OFF ON Address 1
OFF OFF OFF ON OFF Address 2
OFF OFF OFF ON ON Address 3
OFF OFF ON OFF OFF Address 4
OFF OFF ON OFF ON Address 5
OFF OFF ON ON OFF Address 6
OFF OFF ON ON ON Address 7
OFF ON OFF OFF OFF Address 8
OFF ON OFF OFF ON Address 9
OFF ON OFF ON OFF Address 10
OFF ON OFF ON ON Address 11

CKM-MR52-S3 Hardware Installation Manual
24-10707-198 Rev. –
8
OFF ON ON OFF OFF Address 12
OFF ON ON OFF ON Address 13
OFF ON ON ON OFF Address 14
OFF ON ON ON ON Address 15
ON OFF OFF OFF OFF Address 16
ON OFF OFF OFF ON Address 17
ON OFF OFF ON OFF Address 18
ON OFF OFF ON ON Address 19
ON OFF ON OFF OFF Address 20
ON OFF ON OFF ON Address 21
ON OFF ON ON OFF Address 22
ON OFF ON ON ON Address 23
ON ON OFF OFF OFF Address 24
ON ON OFF OFF ON Address 25
ON ON OFF ON OFF Address 26
ON ON OFF ON ON Address 27
ON ON ON OFF OFF Address 28
ON ON ON OFF ON Address 29
ON ON ON ON OFF Address 30
ON ON ON ON ON Address 31
OFF OFF 115,200 BPS1
OFF ON 9,600 BPS
ON OFF 19200 BPS
ON ON 38,400 BPS
OFF Encrypted communication not
required2
ON Encrypted communication
required2
1. Firmware revisions prior to 1.38.1, this setting is 2,400 BPS.
2. Firmware revisions prior to 1.38.1, SW8 is not defined. Set to the OFF position.
Table 1: Switches
S8 S7 S6 S5 S4 S3 S2 S1 Selection

CKM-MR52-S3 Hardware Installation Manual
24-10707-198 Rev. –
9
STATUS LEDS
Table 2: Jumpers
Jumper Description
J1 Reader Power Select
12V = 12 VDC at reader ports.1
1. The input power (VIN) must be 20 VDC minimum if the 12 VDC selection is to be used.
PT = VIN “Passed Through” to reader ports
J4 RS-485 Termination, install in first and last units only.
All other jumpers are for factory use only.
Table 3: LED Information
Process LED Information
Power-up All LEDs OFF
Initialization Once you apply power, initialization of the module begins.
When initialization is completed, LEDs A through R2 are briefly
sequenced ON then OFF.
Run Time1A LED Heartbeat and On-Line Status:
Offline
1-second rate, 20% ON
Online
Non-encrypted communication: 1-second rate, 80% ON
Encrypted communication:
0.1 second ON
0.1 second OFF
0.1 second ON
0.1 second OFF
0.1 second ON
0.1 second OFF
0.1 second ON
0.3 second OFF
A LED Error Indication:
Waiting for application firmware to be downloaded:
1 second ON
1 second OFF
B LED SIO Communication Port Status:
Indicates communication activity on the SIO communication port.

CKM-MR52-S3 Hardware Installation Manual
24-10707-198 Rev. –
10
Run Time1
(continued)
1 LED: Input Status: IN1
2 LED: Input Status: IN2
3 LED: Input Status: IN3
4 LED: Input Status: IN4
5 LED: Input Status: IN5
6 LED: Input Status: IN6
7 LED: Input Status: IN7
8 LED: Input Status: IN8
TMP: Cabinet Tamper
PFL: Power Fault
Input in the inactive state: OFF (briefly flashes ON every 3 seconds)
Input in the active state: ON (briefly flashes OFF every 3 seconds)
Input in a trouble state: Rapid Flash
R1 LED: reader port 1:
Clock/Data Mode: Flashes when data is received, either input
Data 0/Data 1 Mode: Flashes when data is received, either input
RS-485 Mode: Flashes when transmitting data
R2 LED: reader port 2:
Clock/Data Mode: Flashes when data is received, either input
Data 0/Data 1 Mode: Flashes when data is received, either input
RS-485 Mode: Flashes when transmitting data
K1 through K6 LEDs: Illuminates when output relay RLY 1 (K1) through
RLY 6 (K6) is energized.
1. Every 3 seconds, LEDs A through R2 are pulsed to their opposite state for 0.1 sec.
Table 3: LED Information
Process LED Information

CKM-MR52-S3 Hardware Installation Manual
24-10707-198 Rev. –
11
SPECIFICATIONS
Use this interface in low voltage, Class 2 circuits only.
Table 4: CKM-MR52 Specifications
Category Description
Primary Power 12 to 24 VDC ±10%, 550 mA maximum
Outputs Six Form-C relays:
Normally open contact (NO) contact: 5 A @ 30 VDC resistive
Normally closed contact (NC) contact: 3 A @ 30 VDC resistive
Inputs 8 unsupervised/supervised, standard EOL: 1k/1k ohm, 1% 1/4 watt
2 unsupervised, dedicated for cabinet tamper and UPS fault
monitoring
Reader Interface
Reader Power 12 VDC ±10% regulated, 300 mA maximum each reader
(jumper selectable and input voltage (VIN) must be 20 VDC
minimum), or
12 to 24 VDC ±10% (input voltage passed through) 300 mA
maximum each reader
Reader LED
Output
TTL compatible, high > 3 V, low < 0.5 V, 5 mA source/sink maximum
Buzzer Output Open collector, 12 VDC open circuit maximum, 40 mA sink maximum
Data Inputs TTL compatible inputs or 2-wire RS-485
Communication
Communication 2-wire RS-485: 9600, 19200, 38400 or 115200 bps
Cable Requirements
Power 1 twisted pair, 18 AWG.
RS-485 24 AWG, 120 ohm impedance, twisted pair with drain wire and shield,
4,000 ft
(1,219 m) maximum
Alarm Inputs 1 twisted pair per input, 30 ohms maximum
Outputs As required for the load.
Reader data (TTL) 18 AWG, 6 conductor, 500 ft (150 m) maximum
Reader data
(RS-485)
I/O Devices
24 AWG, 120 ohm impedance, twisted pair with drain wire and shield,
4,000 ft (1,219 m) maximum

CKM-MR52-S3 Hardware Installation Manual
24-10707-198 Rev. –
12
MAINTENANCE
Impaired Performance
The following is a list of the impaired performance conditions:
• Unit environment not as specified
• Unit power not as specified
• Cable type and length not as specified
Test Procedure
To check for proper operation of the device:
1. Verify LED status indicates device is online
2. Present a valid card to a reader connected to the device and the verify
that access is granted.
3. Present an invalid card to a reader connected to the device and the
verify that access is denied.
4. Change the state of any input and verify change of state.
5. Change the state of any output and verify change of state.
Environmental
Temperature 32 to 120°F (0 to 49°C) operating
-67 to 185°F (-55 to 85°C) storage
Humidity 10 to 93% RHNC
Mechanical
Dimensions
(W x L x H)
6 in. x 8 in. x 1 in. (15.2 cm x 20.3 cm x 2.5 cm)
Weight 11 oz. (312 g) nominal
Table 4: CKM-MR52 Specifications
Category Description

We welcome your comments at [email protected].
Security Solutions
[phone]
www.johnsoncontrols.com
