Model TFP PH5 — 5.6 K-factor
Institutional Horizontal Sidewall Sprinklers
Standard Response, Standard Coverage
Page 1 of 4 AUGUST 2018 TFP654
IMPORTANT
Refer to Technical Data Sheet
TFP2300 for warnings pertaining to
regulatory and health information.
Always refer to Technical Data
Sheet TFP700 for the “INSTALLER
WARNING” that provides cautions
with respect to handling and instal-
lation of sprinkler systems and com-
ponents. Improper handling and
installation can permanently damage
a sprinkler system or its compo-
nents and cause the sprinkler to fail
to operate in a fire situation or cause
it to operate prematurely.
Worldwide
Contacts
www.tyco-fire.com
General
Description
The TYCO Model TFP PH5, 5.6 K-fac-
tor, Institutional Horizontal Sidewall
Sprinklers are standard-response,
standard-coverage spray sprinklers
designed for use in areas such as cor-
rectional, detention, and mental health
care facilities.
The unique features of the Model
TFP PH5 provide a tamper-resistant
sprinkler design that helps eliminate
the opportunity for individuals to injure
themselves or others with components
of a fire sprinkler. At the same time,
the Model TFP PH5 optimizes an
aesthetically appealing flush design
that conceals most of the operating
parts.
NOTICE
The TYCO Model TFP PH5 Institu-
tional Horizontal Sidewall Sprinklers
described herein must be installed
and maintained in compliance with
this document, as well as with the
applicable standards recognized by
the Approval agency, in addition to
the standards of any authorities having
jurisdiction. Failure to do so may impair
the performance of these devices.
Johnson Controls specifically dis-
claims any liability for damages or
injury (including death) arising out of or
caused by manipulation, dismantling,
or misuse of TFP PH5 Sprinklers or the
use or attempted use of the TFP PH5
Sprinklers or any component thereof as
an instrument unrelated to its intended
function as a fire protection device.
The owner is responsible for main-
taining their fire protection system
and devices in proper operating con-
dition. Contact the installing contrac-
tor or product manufacturer with any
questions.
Sprinkler
Identification
Number (SIN)
TY3390
Technical
Data
Approvals
UL and C-UL Listed for light and ordinary
hazard occupancies (Refer to the Design
Criteria section.)
NYC under MEA 351-01-E
Maximum Working Pressure
175 psi (12,1 bar)
Inlet Thread Connection
1/2 in. NPT
Discharge Coefficient
K = 5.6 GPM/psi½(80,6 LPM/bar½)
Temperature Ratings
165° F ( 74°C )
Finishes
Sprinkler: Chrome Plated
Escutcheon: Chrome Plated
Physical Characteristics
Body . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Brass
Deflector . . . . . . . . . . . . . . . . . . . . . . . . . .Bronze
Deflector Hood . . . . . . . . . . . . . . . . . . . . .Bronze
Deflector Post . . . . . . . . . . . . . . . . . . . . . .Bronze
Deflector Post Pin . . . . . . . . . . . . . . . . . . .Bronze
Deflector Core. . . . . . . . . . . . . . . . . . . . . .Bronze
Compression Screw . . . . . . . . . . . . . . . . .Bronze
Lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Bronze
Release Spring . . . . . . . . . . . . . . . . . . . . .Bronze
Sealing Assembly ..Beryllium Nickel w/TEFLON
Dust Cover .............Chrome Plated Steel
Fusible Element . . . . . . . . . . . . .Solder, Copper,
Stainless Steel
Operation
In the standby condition, the design of
the TYCO Model TFP PH5 is such that
a dynamic load of 80 lb (36 kg) or more
applied to the linkage mechanism will
release the sprinkler. Also, when prop-
erly installed, the escutcheon is held
fast to the wall to deter its removal.
The shape of the escutcheon cannot
be grasped easily, which further deters
tampering.
A fusible solder operating element
secures the linkage mechanism of the
Model TFP PH5. When the rated tem-
perature is reached, the solder melts,
releasing the linkage mechanism that
holds the sprinkler closed. This release
allows the deflector to extend outward
and water to flow.

TFP654
Page 2 of 4
Design
Criteria
The TYCO Model TFP PH5, 5.6 K-fac-
tor (SIN TY3390) Institutional Horizon-
tal Sidewall Sprinklers are intended for
use in fire protection systems designed
in accordance with the standard instal-
lation rules recognized by the appli-
cable Listing or Approval agency (for
example, UL Listing is based on NFPA
13 requirements).
NOTICE
The Sprinkler Body must not extend
beyond the Institutional Escutcheon
(Ref. Figure 4). Otherwise, the tamper-
resistant design of the Model TFP PH5
will be compromised. Consequently,
Model 1752 Spacers, which are associ-
ated with other TFP institutional sprin-
klers, cannot to be utilized.
Integrity of the tamper-resistant design
of the Institutional Escutcheon is
dependent on the piping installation
design. When installed properly, the
Institutional Escutcheon is held fast to
the mounting surface by the tighten-
ing of the sprinkler assembly into the
sprinkler fitting. In order to accomplish
a proper installation, the sprinkler fitting
must be:
• properly located with respect to dis-
tance from the face of the sprinkler
fitting to the face of the mounting
surface (Ref. Figure 3);
• rigidly secured and held immobile;
and,
• installed with the center-line of the
sprinkler fitting perpendicular to the
mounting surface to assure that the
escutcheon sits squarely against
the mounting surface around the
entire perimeter of the Institutional
Escutcheon.
Figure 3 illustrates a typical installa-
tion that can be utilized to help adjust
the location of the sprinkler fitting; to
help assure immobility of the sprinkler
fitting; and, to help maintain perpen-
dicularity of the sprinkler fitting to the
mounting surface.
Installation
The TYCO Model TFP PH5 Sprinklers
must be installed in accordance with
this section.
NOTICE
Refer to the Design Criteria section for
important information regarding the
piping installation design and its effect
on maintaining the integrity of the tam-
per-resistant design of the Institutional
Escutcheons.
Obtain a leak-tight 1/2 in. NPT sprin-
kler joint by applying a minimum-to-
maximum torque of 7 to 14 lb-ft (9,5
to 19,0 N∙m). Higher levels of torque
can distort the sprinkler inlet with con-
sequent leakage or impairment of the
sprinkler.
Do not attempt to compensate for
improper location of the sprinkler fitting
by under- or over-tightening the sprin-
kler. Re-adjust the position of the sprin-
kler fitting to suit.
The Model TFP PH5 (SIN TY3390) must
be installed with a deflector-to-ceiling
distance of 4 in. to 6 in. (100 mm to
152,4 mm). To meet this requirement,
the center-line of the sprinkler water-
way must be located 4-1/2 in. to
6-1/2 in. (114,3 mm to 165,1 mm) below
the ceiling (Ref. Figure 3).
Only the Institutional Escutcheons
shown in Figure 2 can be utilized with
the Model TFP PH5.
NPT
1/2"
CENTERLINE
WATERWAY
OF SPRINKLER
1/2"
(12.7 mm)
ASSEMBLY
DEFLECTOR
IN OPERATED
POSITION
WRENCHING
NOTCH (2)
SPRINKLER
LINKAGE
MECHANISM
WITH DEFLECTOR
INSTALL
SPRINKLER
HOOD ORIENTED AT
TOP AS SHOWN
SPRINKLER
FITTING
FACE OF
NOMINAL MAKE-IN
7/16" (11.1 mm)
12
8
14 5
10
11
9
2
3 7 6
2.81"
(71.4 mm)
(80.8 mm)
3.18"
INSTALLED SIDE VIEW
OPERATED SIDE VIEW
FRONT VIEW
INSTALLED
CROSS-SECTION VIEW
Deflector Post
-
-
-
-
-
-
-
-
Deflector Post Pin
Release Spring
Dust Cover
Fusible Element
Lever
Compression Screw
(2 req'd)
(2 req'd)
Deflector Core
-
-
-
Deflector
Body
Deflector Hood
1
4
2
3
5
7
6
8
10
9
11
Components:
FIGURE 1
MODEL TFP PH5 INSTITUTIONAL
HORIZONTAL SIDEWALL SPRINKLER

TFP654
Page 3 of 4
After the installation is complete, make
certain that the Institutional Escutcheon
is held fast (that is, tight with no move-
ment or gap) to the mounting surface
and that the Escutcheon sits squarely
against the mounting surface around
the entire perimeter of the Escutcheon.
Step 1. Install the TFP PH5 Sprinklers
horizontally with the center-line of their
waterway perpendicular to the mount-
ing surface and parallel to the ceiling.
The Deflector must be located with the
top towards the ceiling (Ref. Figure 1).
Step 2. With the Institutional Escutch-
eon in place and with pipe-thread
sealant applied to the pipe threads,
hand-tighten the sprinkler into the
sprinkler fitting.
Step 3. Using only the Model 1509-3
Sprinkler Wrench (Ref. Figure 5),
wrench-tighten the Sprinkler while
applying the wrenching teeth of the
Sprinkler Wrench to the sprinkler
wrenching notch areas (Ref. Figure 1).
Step 4. After the installation is com-
plete, make certain that the Institutional
Escutcheon is held fast to the mounting
surface and that it sits squarely against
the mounting surface around its entire
perimeter.
NOTICE
The Sprinkler Body must not extend
beyond the Institutional Escutcheon
(Ref. Figure 4). Otherwise, the tamper-
resistant design of the Model TFP PH5
will be compromised.
Care and
Maintenance
The TYCO Model TFP PH5 Sprinklers
must be maintained and serviced in
accordance with this section.
Before closing a fire protection system
main control valve for maintenance
work on the fire protection system
that it controls, obtain permission to
shut down the affected fire protection
systems from the proper authorities
and notify all personnel who may be
affected by this action.
The owner must assure that the sprin-
klers are not used for hanging any
objects and that the sprinklers are only
cleaned by means of gently dusting
with a feather duster; otherwise, non-
operation in the event of a fire or inad-
vertent operation may result.
Sprinklers which are found to be
leaking or exhibiting visible signs of
corrosion must be replaced.
Automatic sprinklers must never be
painted, plated, coated, or other-
wise altered after leaving the factory.
Modified sprinklers must be replaced.
Sprinklers that have been exposed to
corrosive products of combustion, but
have not operated, should be replaced
if they cannot be completely cleaned
by wiping the sprinkler with a cloth or
by brushing it with a soft bristle brush.
Care must be exercised to avoid
damage to the sprinklers - before,
during, and after installation. Sprin-
klers damaged by dropping, striking,
wrench twist/slippage, or the like, must
be replaced. Also, replace any sprinkler
that has a cracked bulb or that has lost
liquid from its bulb. Refer to the Instal-
lation section for additional information.
The owner is responsible for the inspec-
tion, testing, and maintenance of their
fire protection system and devices in
compliance with this document, as well
as with the applicable standards of the
NATIONAL FIRE PROTECTION ASSO-
CIATION (that is, NFPA 25), in addi-
tion to the standards of any authorities
having jurisdiction. Contact the install-
ing contractor or product manufacturer
with any questions.
Automatic sprinkler systems should be
inspected, tested, and maintained by a
qualified Inspection Service in accor-
dance with local requirements and/or
national codes.
Note:
Model 1752 Spacers are not to be used to obtain horizontal adjustment for the Model TFP PH5 with Style B2 or C
Escutcheons.
CLEARANCE FOR
DETERMINED BY
DIAMETER
REDUCING
COUPLING
CLEARANCE FOR
DETERMINED BY
MOUNTING SURFACE
FITTING FLUSH WITH
FACE OF SPRINKLER
DIAMETER
REDUCING
COUPLING
(71.4 mm)
4-1/4" DIA.
(108.0 mm)
2.81"
(65.1 mm)
2-9/16"
1-3/16"
(30.2 mm)
5" DIA.
(127.0 mm)
(37.6 mm)(33.8 mm)
1.33" 1.48"
STYLE B2
STYLE C
FIGURE 2
INSTITUTIONAL ESCUTCHEON OPTIONS
FOR USE WITH THE MODEL TFP PH5

TFP654
Page 4 of 4
NATIONAL FIRE PROTECTION ASSOCIATION and NFPA are registered trademarks of National Fire Protection Association;
TEFLON is a registered trademark of DuPont
1400 Pennbrook Parkway, Lansdale, PA 19446 | Telephone [phone]
© 2018 Johnson Controls. All rights reserved. All specifications and other information shown were current as of document revision date and are subject to change without notice.
Limited
Warranty
For warranty terms and conditions, visit
www.tyco-fire.com.
Disclaimer
Johnson Controls specifically dis-
claims any liability for damages or
injury (including death) arising out of or
caused by manipulation, dismantling,
or misuse of TFP PH5 Sprinklers or
the use or attempted use of TFP PH5
Sprinklers or any component thereof as
an instrument unrelated to its intended
function as a fire protection device.
Ordering
Procedure
Contact your local distributor for avail-
ability. When placing an order, indicate
the full product name and Part Number
(P/N).
Sprinkler Assemblies
Specify: 5.6 K-factor, Chrome Plated,
165°F (74°C), Model TFP PH5 (TY3390)
Institutional Horizontal Sidewall Sprin-
kler, P/N 51-106-9-165
Separately Ordered Escutcheons
Specify: Style (B2 or C), Chrome
Plated, Institutional Escutcheons, P/N
(specify):
Style B2 .....................56-001-7-512
Style C ......................56-001-7-513
Separately Ordered Wrenches
Specify: Model 1509-3 Sprinkler
Wrench, P/N 56-001-5-093
Separately Ordered Parts For
Installation In Concrete Walls
Specify: Model 1781 Centering
Grommet for installation in concrete,
P/N 56-000-1-781
Specify: Model 1780 Retaining Flange
with Set Screws for installation in con-
crete, P/N 56-000-1-780
1” STEEL PIPE
(15,9 mm)
END
WITH GROOVED
(LENGTH TO SUIT
STEEL PIPE SLEEVE
WALL THICKNESS)
OR 2” (50 mm) I.D.
WITH SET SCREWS
RETAINING FLANGE
CORED HOLE
2” SCH. 40
WALL THICKNESS
CENTERING GROMMET
1” x 1/2" M.I. CLASS 150
REDUCING COUPLING
4” (101,6 mm) to 6” (152,4 mm)
WATERWAY
OF SPRINKLER
CENTERLINE
FINISHED
CEILING
RESULTS IN DEFLECTOR-
TO-CEILING DISTANCE OF
*
WITH ESCUTCHEON
MODEL TFP PH5
4-1/2” (114,3 mm) to
6-1/2" (165,1 mm) *
MODEL 1781
MODEL 1780
5/8”
ESCUTCHEON
BEYOND
MECHANISM
LINKAGE
NOT EXTEND
SPRINKLER
BODY MUST
ESCUTCHEON
SPRINKLER
BODY
1/2" DRIVE
ACCEPTS
TEETH
WRENCHING
FIGURE 3
TYPICAL INSTALLATION WHEN USING MODEL 1780 RETAINING
FLANGE AND MODEL 1781 CENTERING GROMMET
FIGURE 4
PROPER POSITIONING OF
ESCUTCHEON
FIGURE 5
MODEL 1509-3
SPRINKLER WRENCH
