JR Vibe 90 3D User manual

ASSEMBLY INSTRUCTIONS
VIBE 90 SPECIFICATIONS
Length: 54 in
Height: 17.5 in
Weight: 10.2-10.5 lb
Engine: .80–.91 Heli
Bearings: Full
Gear Ratio: 8:1:4.83
Main Blade: 700–720 mm
(Main rotor blades not included)
7749
7/2005
®
Designed for Today’s
Extreme 3D Flying

2
Making the Ultimate Machine
Start with the proven platform of the Worlds and 3D Championship-winning JR®
Vigor CS. Then re-think, redesign and restructure 80% of it’s critical components,
and you get a machine that shrugs off the most merciless, stick-bending
punishment today’s extreme 3D flying pilots can inflict.
And you top it off with a new name, the Vibe 90 3D.™
That’s exactly what (JR did, with critical input from) Curtis Youngblood—
with lots of valuable input from Marty Kuhns, Len Sabato and a host of other
JR Team members.
Judging by Curtis’ string of 3D and FAI wins with his Vibe, their combined
efforts have paid off big-time. What’s more, flying 10-12 flight per day with very
little maintenance, Curtis reports he has yet to find (the Vibe’s) its limit.
Great features and enhancements in the new JR Vibe 90 3D:
Just check this list of re-engineered and redesigned components and you’ll have a
handle on what makes the Vibe 90 3D the machine that’ll take your flying to new
levels.
Low Parts Count Means Quick Assembly
You will find that your Vibe 90 will assemble very quickly due to its well-
thought-out/straight-forward design, low parts count, and preassembled main
rotor head, washout unit, tail gear box, tail pitch slider assemblies, and 3-color
prepainted FRP canopy. The building time for the Vibe 90 usually takes only
10–12 hours from start to finish.
CCPM Control System
CCPM swashplate control is the key to the Vibe’s performance and low parts
count. The Vibe 90can be set up with the normal 120-degree CCPM system that is
supported in most of today's modern computer helicopter radio systems, or JR’s
original 140 CCPM. CCPM 140 places the ball links on the swashplate 140º back
from the forward ball, then the rear balls are extended, placing them the same
fore-to-aft distance from the center of the main shaft as the front ball. The main
advantage is that all three servos going to the swashplate now have the same
throw. With conventional 120 CCPM, the throws to the forward servos must be
reduced with radio programming by 50%. This causes the longer-throwing servos
to lag behind the shorter-throwing servo during quick cyclic inputs.
Frame Assembly
• New Carbon fiber upper servo mounts
• New Carbon fiber dual radio/gyro trays
• New Carbon tank mounts
• New 90-size motor mount
• New 3D Carbon fin design
Drivetrain
• New large diameter startshaft w/ HD one-way clutch bearing
• New machined aluminum upper pinion bearing block
• New hardened main shaft
• New supported aluminum bevel gear hub
• New HD autorotation assembly
• New 11-tooth pinion
• New 8:0 to 1 gear ratio
Rotor Head
• New no-bind high cyclic swash design
• New one-piece short span CNC 3D center hub
• New dual o-ring 3D dampeners
• New flight tuned composite blade holders, tuned
• New adjustable flybar/blade mixing ratio
• New ball bearing seesaw mixing arms
• New improved flybar control arms
Tail Rotor
• New Heavy Duty Tail Rotor Hub
• New Re-engineered Tail Gear Case
• New CNC Ball bearing Aluminum Tail Pitch Lever
• New Ball bearing Tail Control Lever w/HD Carbon Rod
• New Wide Spaced Dual Boom Braces
Canopy
• New, 3D Dynamic Canopy for drag reduction in all directions
• New Multi Color Pre-Painted Canopy
INTRODUCTION
WARNING
The radio controlled model helicopter contained in this kit is not a toy but a sophisticated
piece of equipment. This product is not recommended for use by children. Radio
controlled models such as this are capable of causing both property damage and/or bodily
harm to both the operator/assembler and/or spectator if not properly assembled and
operated. Horizon Hobby, Inc. assumes no liability for damage that could occur from the
assembly and/or use/misuse of this product. If you, as the buyer or owner, are not prepared
to accept the liability associated with the use of this product, you are advised to return this
kit immediately in new and unused condition to the place of purchase.
AMA INFORMATION
We strongly encourage all prospective and current R/C aircraft pilots to join the Academy
of Model Aeronautics. The AMA is a non-profit organization that provides services to
model aircraft pilots. As an AMA member, you will receive a monthly magazine entitled
Model Aviation, as well as a liability insurance plan to cover against possible accident or
injury. All AMA charter aircraft clubs require individuals to hold a current AMA sporting
license prior to operation of their models. For further information, you can contact
the AMA at:
Academy of Model Aeronautics
5151 East Memorial Drive
Muncie, IN 47302
[phone]
PREASSEMBLY INFORMATION
When first opening your Vibe 90 3D kit, you will notice that all of the parts are packaged
and numbered to coordinate with the assembly step numbers of this instruction manual.
All small hardware (nuts, bolts, washers, etc.) for each step are separated and packaged
separately within the main parts bags. When beginning a section, you will need to open
only the bag with the corresponding number to the section you are going to start. It is
suggested that you place all of the hardware in an open container (e.g., coffee can) during
assembly so as not to lose any of the small parts. It may also be helpful to familiarize
yourself with the various sizes of screws, bolts, nuts, etc., as illustrated in the appropriate
assembly section before you begin assembly. At the end of each assembly, in most cases,
there should be no parts remaining.
NOTE: Your kit also includes JR red and green threadlock. Unlike conventional U.S.-
made threadlock, JR red is actually the U.S. equivalent of blue. JR green is actually the
equivalent of U.S. red.
Great care has been taken in filling the bags with the correct quantity of parts and
hardware for each section. However, occasionally mistakes do happen. In the event that
you find a parts shortage or are in need of technical assistance, please contact your local JR
Heli Division parts dealer or contact the Horizon Service Center directly.
Horizon Service Center
4105 Fieldstone Road
Champaign, IL 61822
[phone] (9 a.m. to 5 p.m. CST)

3
INDEX
Section Description Page Section Description Page
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Radio System Requirements (not included) . . . . . . . . . . . . . . . . . . . . 4
Engine Requirements (not included) . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Building Supplies (not included) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Tools Needed to Assemble the JR Vibe 90 3D (not included) . . . . . . . 6
Field Equipment Required (not included) . . . . . . . . . . . . . . . . . . . . . . 6
Hardware Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1-1 Clutch Bell/Start Shaft Assembly . . . . . . . . . . . . . . . . . . . 8
1-2 Elevator Arm Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1-3 T-Arm Lever Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . 10
1-4 Fuel Tank Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2-1A Main Frame Assembly:Bearing Block/Clutch Installation . . 11
2-1B Elevator Arm Installation . . . . . . . . . . . . . . . . . . . . . . . . . 12
2-2 Main Frame Assembly: Cross Member Installation . . . . 13
2-3A T-Lever Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2-3B Elevator Control Arm Installation . . . . . . . . . . . . . . . . . . 15
2-4 Main Frame Assembly: Engine Mount/Cross Member
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2-5 Main Frame Assembly: Bottom Plate Installation . . . . . . 17
2-6 Fuel Tank Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
2-7 Front Radio Bed Installation . . . . . . . . . . . . . . . . . . . . . . 19
3-1A Main Drive Gear/Autorotation Assembly . . . . . . . . . . . . .19
3-1B Bevel Gear Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
3-2 Main Shaft/Main Drive Gear Installation . . . . . . . . . . . . 20
3-3 Landing Gear Assembly Installation . . . . . . . . . . . . . . . . 21
3-4 Cooling Fan/Hub Installation . . . . . . . . . . . . . . . . . . . . . 21
3-5 Clutch Assembly Attachment . . . . . . . . . . . . . . . . . . . . . 22
3-6 Engine Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
3-7 Cooling Fan Shroud Bracket Attachment . . . . . . . . . . . . 23
3-8 Bolt Tightening Order/Gear Mesh Adjustment . . . . . . . . 23
3-9 Cooling Fan Shroud Installation . . . . . . . . . . . . . . . . . . . 24
3-10 Installation of the Muffler/Fuel Line Connections . . . . . 24
4-1 Swashplate Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
4-2 Swashplate/Washout Assembly Installation . . . . . . . . . . 26
4-3 Rotor Head Installation . . . . . . . . . . . . . . . . . . . . . . . . . . 27
4-4 Flybar Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
4-5 Flybar Paddle Attachment . . . . . . . . . . . . . . . . . . . . . . . 28
4-6 Swashplate/T-Arm Control Rod Installation . . . . . . . . . . 29
5-1 Tail Drive Shaft Preparation . . . . . . . . . . . . . . . . . . . . . . 30
5-2 Tail Drive Shaft Assembly . . . . . . . . . . . . . . . . . . . . . 30-31
5-3 Bevel Pinion Gear Assembly . . . . . . . . . . . . . . . . . . . . . .31
5-4 Boom/Bevel Pinion Gear Installation/Adjustment . . . . . .32
5-5 Tail Support Clamp Installation . . . . . . . . . . . . . . . . . . . .33
5-6 Tail Boom Brace Assembly . . . . . . . . . . . . . . . . . . . . . . .33
5-7 Tail Brace Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
5-8 Horizontal/Vertical Fin Installation . . . . . . . . . . . . . . . . . 34
5-9 Tail Center Hub Assembly . . . . . . . . . . . . . . . . . . . . . . . . 35
5-10 Tail Blade Holder Assembly . . . . . . . . . . . . . . . . . . . . . . 35
5-11 Steel Joint Ball Installation . . . . . . . . . . . . . . . . . . . . . . . 36
5-12 Tail Drive Shaft/Tail Gear Box Installation . . . . . . . . . . . 36
6-1 Tail Belcrank Attachment . . . . . . . . . . . . . . . . . . . . . . . . 37
6-2 Upper Servo/Gyro Tray Attachment . . . . . . . . . . . . . . . . 38
6-3 Servo/Switch Harness Installation . . . . . . . . . . . . . . . . . . 39
6-4A Intermediate Tail Control Rod Attachment . . . . . . . . . . . 40
6-4B Tail Control Rod Assembly . . . . . . . . . . . . . . . . . . . . . . . 40
6-4C Tail Control Rod/Tail Guide Attachment . . . . . . . . . . . . . 40
6-5 Gyro/Receiver/Battery Installation . . . . . . . . . . . . . . . . . 41
Radio System Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Understanding CCPM Control Systems . . . . . . . . . . . . . . . . . . . . 43-44
Important CCPM Programming Do’s & Dont’s . . . . . . . . . . . . . . 45-46
CCPM Software Activation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47-50
7-1 Preparation and Installation of Servo Horns . . . . . . . . . . 51
7-2 CCPM Servo Centering with the Sub-Trim Function . . . 52
7-3 Control Rod Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
7-4 CCPM Control Rod Attachment . . . . . . . . . . . . . . . . . . . 54
7-5 Tail Control Rod Connection . . . . . . . . . . . . . . . . . . . . . . 55
7-6 Throttle Linkage Connection . . . . . . . . . . . . . . . . . . . . . . 56
7-6.1 Throttle Arm/Servo Horn Positions . . . . . . . . . . . . . . . . . 57
7-7 Checking the Swashplate for Level . . . . . . . . . . . . . . . . . 58
7-8 Pitch-to-Aileron Mixing Adjustment with Travel Adjust 59
7-9 Pitch-to-Elevator Mixing Adjustment with Travel Adjust 60
Final Servo Adjustment and Radio Setup . . . . . . . . . . . . . . . . . . . 61-62
8-1 Grommet Attachment . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
8-2 Body Attachment & Final Fitting . . . . . . . . . . . . . . . . . . 64
Decal Placement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
8-3 Main Rotor Blade Attachment (Blades not included) . . . 66
Preflight Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
General Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
P-1 Assembly Process – Main Rotor Head 1 . . . . . . . . . . . . . 69
P-2 Assembly Process – Main Rotor Head 2 . . . . . . . . . . . . . 69
P-3 Assembly Process – Main Rotor Head 3 . . . . . . . . . . . . . 70
P-4 Assembly Process – Main Rotor Head 4 . . . . . . . . . . . . . 70
P-5 Assembly Process – Washout Unit . . . . . . . . . . . . . . . . . 71
P-6 Assembly Process – Tail Slide Ring . . . . . . . . . . . . . . . . 71
P-7 Assembly Process – Flybar Control Arm . . . . . . . . . . . . 72
Data Sheets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .73-79
Start Shaft/Clutch/Engine Assembly Parts List . . . . . . . . . . . . . . 80-81
Main Frame/Landing Gear/Autorotation Assembly Parts List . . . 82-83
Swashplate/CCPM Control System Parts List . . . . . . . . . . . . . . . 84-85
Main Rotor Head/Washout Assembly Parts List . . . . . . . . . . . . . 86-87
Tail Drive System/Shaft Drive Parts List . . . . . . . . . . . . . . . . . . . 88-89
Tail Rotor Blade Holder/Tail Brace . . . . . . . . . . . . . . . . . . . . . . . 90-91
Body Set/Fuel Tank Assembly Parts List . . . . . . . . . . . . . . . . . . . 92-93
Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .94

4
ITEMS REQUIRED TO COMPLETE THE JR VIBE 90 3D
JR XP9303 JR PCM10X
JRPS8311 Ultra Torque Digital
Aileron, Elevator, Collective Servo Throttle, Tail Rotor Servo
8700G High Speed Super
CCPM-Ready JR Radio Systems
Most current JR heli radio systems (XP662,
XP8103 w/digital trims, XP9303, 10X, as
well as older 10 series systems) are
equipped with 120° CCPM electronics for
use with JR CCPM machines. Radios you
may be flying now, like the X347, X388S,
XP783, and XP8103*, have 120° CCPM
capability built in but require activation by
the Horizon Service Department. For details,
please call [phone].
*Please note that many XP8103 systems have the CCPM
function already activated. Please check with the Horizon
Service Center for details.
Current Radio Systems
JRP1656**PCM 10X, 120° & 140° CCPM
JRP8622**XP8103FM, 120° CCPM
JRP8653**XP8103PCM, 120° CCPM
JRP9252** XP9303 PCM 120/140 CCPM
JRP6822**XP662 FM,120° CCPM
JR G500T Gyro or equivalent
JR G500T Gyro
1. RADIO SYSTEM REQUIREMENTS (NOT INCLUDED):
• 6-channel or greater R/C helicopter system with 120° or 140° CCPM with 5 servos
• 1800mAh or larger receiver battery
• Gyro
JRPB4440
1800mAh Battery Pack
JR G7000T Gyro

5
Double-Sided Servo
Mounting Tape
Nylon Wire Ties
(to secure radio wires)
Pacer Poly Zap 1/2 oz
(PAAPT22) JB Weld Epoxy Adhesive
(JBW8265S)
Pacer Zip Kicker
(PAAPT15) Optional
Heavy-Duty Servo Wheels
(3 pcs) w/Screws
JRPA216 or equivalent
Light Oil Rubbing Alcohol
Fuel Filter Glow Plugs
( HAN3020 )
2. ENGINE REQUIREMENTS (not included):
3. BUILDING SUPPLIES (not included):
The following items are needed to complete the assembly of the JR Vibe 90 3D:
A .90 – .91 R/C helicopter engine is required. A special helicopter type muffler is also required.
YS 91 ST4 Heli Engine
or
OS 91 C-Spec Heli Engine
RVO1180 (YS)
RVO1190 (OS)
High-Speed
Grease
Medium
Silicone Fuel
Tubing (3 ft)

6
Needle-Nose Pliers
Drill and Drill Bits
Allen Wrenches: 1.5, 2.0, 2.5,
3.0 mm
Sandpaper (80–120 Grit) Adjustable Pliers
Small Hammer Hobby Knife Metric Ruler
Scissors
12-Volt Electric Starter 12-Volt Starting Battery
Helicopter Fuel 15% –30%
Pitch Gauge
(JRP960326)
Fuel Pump
Ball Link Pliers
(RVO1005)
Glow Plugs
(HAN3020) Hex Starting Shaft
(JRP960090)
Phillips Screwdriver Nut Drivers: 5 mm, 7 mm
4. TOOLS NEEDED TO ASSEMBLE THE JR VIBE 90 3D (not included):
5. FIELD EQUIPMENT REQUIRED (not included):
JR Ball Link Sizing Tool
JRP60219
( Optional )
1.5-Volt Glow Plug Battery OR
Must have long shaft to reach glow plug.
Remote Glow Plug Adaptor

7
Socket Head Bolt Self Tapping Screw Flat Washer
.05mm
Flat Head Screw Lock Nut
There are a variety of sizes and shapes of hardware included in this kit.
Prior to assembly, please be careful to identify each screw by matching it
to the full size screw outlines included in each step.
All of the hardware, screws, nuts, etc., contained in the Vibe 90 3D kit are
described in the following A, B, C manner:
CC
C
A
A
B
A
A
B
B
BC
AB
3 x 8 mm Socket Head Bolt
Set Screw
C
A
B
C
C
A
A
A
A
B
2 x 8 mm Flat Head Screw
2.6 x 10 mm Self Tapping Screw
AB
B
3 mm Flat Washer
AB
B
3 mm Lock Nut
Star Washer
AB
B
3 mm Star Washer
A
B
Flat Head Cap Screw
AC
B
C
3 x 8 mm Flat Head Cap Screw
A
Hex Nut
AB
B
2 mm Hex Nut
C
AB
4 x 4 mm Set Screw
HARDWARE IDENTIFICATION

8
1-1 CLUTCH BELL/START SHAFT ASSEMBLY
Socket Head Bolt, 3 x 14 mm
...2 pcs
...................1 pc
...................1 pc
....................2 pcs
Starter Hex
Adaptor
Set Screw,
4 x 4 mm
Start Shaft
Bearing Block
Pinion Gear
Long Bearing Block “A”
Long Bearing Block “B”
Flat Washer, 3 mm (2 pcs)
Socket Head Bolt,
3 x 14 mm (2 pcs)
Clutch Bell Assembly
Start Shaft
Set Screw, 4 x 4 mm
Flat Washer, 3 mm
Thin Washer, 6 x 8 mm
Complete Assembly
Thin Washer
6 x 8 mm
Be sure the bearing
with the 6 mm ID
faces upward.
Use Red & Green
Threadlock
TEAM TIP: Clean areas with rubbing alcohol to
remove any oil residue before applying threadlock.
Use Green Threadlock
Note:
Position so that
bearing is at
the top of the
bearing block.
Green
Green
Red
Apply Red Threadlock
& Tighten at Step 3-8
Red
Lightly Oil
Assembly Order:
1. Attach pinion to clutch bell
2. Attach clutch bell to
bearing block “A”
3. Attach start shaft bearing
block to pinion
4. Assemble start shaft
assembly
5. Attach bearing block “B”
Do not fully tighten at this time.
Note:
Note:

1-2 ELEVATOR A-ARM ASSEMBLY
..........................2 pcs
.............................2 pcs
...............................1 pc
.....1 pc
Socket Head Bolt, 3 x 8 mm
Socket Head Bolt, 2.3 x 15 mm
Set Screw, 4 x 4 mm
A-Arm Bearing Collar
A-Arm Link Base Spindle
Red
Red
Red
Red
18.5 mm
Socket Head Bolt, 3 x 8 mm (2 pcs)
A-Arm
Set Screw, 4 x 4 mm
A-Arm Base
Use Red
Threadlock A-Arm
Bearing Collar (2 pcs)
Socket Head Bolt,
2.3 x 15 mm
11 mm
Elevator A-Arm
Remove 1 mm from the bottom
of this link using a hobby knife
Push link into A-Arm, then insert
2.3 x 15 mm Socket Head Bolt
Universal Link
2 pcs
Red
Remove JR®Propo
from outside of link
using a hobby knife.
Note:
Oil outside of link
to ease assembly.
Note:
*Connect the A-arm to the A-arm base
in the standard range position as shown.
Wide Range
Standard Range*
Note:
Apply a very thin coating of Threadlock
so that it will not seep into the bearing.
9

Use two wrenches if necessary
to secure tank nipple.
1-4 FUEL TANK ASSEMBLY
1. Cut the small silicone fuel
tubing(included) to a length of 77 mm.
Next, connect the fuel tank clunk,
nipple, and medium silicone fuel
tubing (not included) as shown above.
Fuel
Tank
Clunk
Medium Silicone Fuel
Tubing (not included) —
Connect to engine carburetor.
Nipple
Silicone Tube (small)
Use tubing included in
separate package in kit.
4. Pull the medium fuel tubing out of the
fuel tank until the threads of the fuel tank
nipple are exposed.
Nut, 7 mm
...........1 pc
Washer, 7 x 12 x 1 mm
...........1 pc
Complete Assembly
5. Remove the medium silicone fuel
tubing from the nipple and secure
the nipple to the fuel tank using
the 7 x 12 x 1 mm washer and
7 mm nut supplied. Be sure to
secure this assembly firmly to
avoid leakage.
Nut, 7 mm
Washer, 7 x 12 x 1 mm
2. Insert the assembly into the fuel tank
opening so that the nipple is inside the
tank. Next, slide the fuel tank grommet
over the medium fuel tubing .
Fuel Tank Grommet
1-3 T-ARM LEVER ASSEMBLY
3. Inset the fuel tank grommet into the
fuel tank opening, making sure that it
is fully seated.
Use Red Threadlock
on all screws
.......................... 8 pc
.......................... 8 pcs
Flat Head Screw, 2 x 8 mm
Steel Joint Ball
Flat Head Screw, 2 x 8 mm (4 pcs)
Flat Head Screw, 2 x 8 mm (2 pcs)
Steel Joint Ball
Steel Joint Ball (6 pcs)
T-Arm Assembly
Flat Head Screw,
2 x 8 mm (2 pcs
)
Elevator Control Arm
Steel Joint Ball (2 pcs)
Wide Range
Standard Range *
*Connect the control ball to the
T-Arms in the standard range
position as shown.
Note:
10
10 20 30 40 50 60 70 77mm

11
2-1A MAIN FRAME ASSEMBLY: BEARING BLOCK/CLUTCH INSTALLATION
Socket Head Bolt, 3 x 8 mm
Socket Head
Bolt, 3 x 8 mm (4 pcs)
Socket Head Bolt, 3 x 40 mm
Nylon Lock Nut, 3 mm
Nylon Lock Nut, 3 mm (4 pcs)
Top Bearing Case
Flat Washer, 3 mm Flat Washer, 3 mm (8 pcs)
.....................................4 pcs
...4 pcs
..................4 pcs
..................8 pcs
Threaded Rod, 3 x 50 mm
...4 pcs
*
*
Positon so that bearing faces upward.
Note:
Top Bearing Case Direction
Up
Prior to assembling the main
frames, sand all edges of the
frame using 120 grit sandpaper.
This will prevent wire chaffing
during continuous operation.
Note:
Cross Member, 32 mm
.....2 pc
Use Red
Threadlock
TEAM TIP: Don’t tighten bolts completely at this
time. These bolts will be tightened in Step 3-8 to
achieve proper alignment.
Socket Head Bolt, 3 x 40 mm (4 pcs)
Flat Washer, 3 mm (8 pcs)
Threaded Rod,
3 x 50 mm
*
*
**
*
*
Cross Member,
32 mm (2 pcs)
Red
Main Frame (2 pcs)

12
2-1B ELEVATOR ARM INSTALLATION
Direction of Installation
Standard Range
Long
Front
Rear
Short
Socket Head Bolt, 3 x 8 mm
Nylon Lock Nut, 3 mm
...............4 pcs
.......................4 pcs
........................ 1 pc
Spacer, 4 x 5 x 1 mm
Socket Head Bolt, 4 x 10 mm
........1 pc
Use Red
Threadlock
Socket Head
Bolt 4 x 10 mm
Nylon Lock Nut, 3 mm (4 pcs)
Spacer, 4 x 5 x 1 mm
Socket Head Bolt, 3 x 8 mm (4 pcs)
Elevator Arm Bearing Case (2 pcs)
Red

13
2-2 MAIN FRAME ASSEMBLY: CROSS MEMBER INSTALLATION
Use Red
Threadlock
*TEAM TIP: Don’t tighten bolts completely at this time.
These bolts will be tightened in Step 3-8.
Set Screw,
3 x 18 mm (2 pcs)
Cross Member, 24 mm
10 mm
Red
*TEAM TIP: Do not apply
threadlock to bolts unless
you will proceed through
Step 3-8 during this
building session.
Nylon Lock Nut, 3 mm
...................3 pcs
Socket Head Bolt, 3 x 40 mm....3 pcs
Cross Member, 24 mm
............2 pcs
Set Screw, 3 x 18 mm
.....................2 pcs
Cross Member, 32 mm
.....1 pc
When installing the cross member A,
be careful not to overtighten.
Note:
Socket Head Bolt, 3 x 40 mm (3 pcs)
Cross Member A
(note correct direction)
Cross Member,
24 mm (2 pcs)
Set Screw, 3 x 18 mm (2 pcs)
Red
Red
Nylon Lock
Nut, 3 mm (3 pcs)
Cross Member, 32 mm

T-LEVER INSTALLATION
2-3A
Socket Head Bolt, 3 x 28 mm
Nylon Lock Nut, 3 mm
....2 pcs
......................................2 pcs
Mixing Lever Spacer
...............................2 pcs
..................................... 2 pcs
Spacer, 3 x 5 x 1 mm
If a collar in T-arm is too one-
sided, please correct the collar to
center before inserting the bolts. 140 CCPM/Standard Range
120 CCPM/Standard Range
T-Lever Position on Main Frame Slots
Note:
TEAM TIP: If you have difficulty reaching the
3 mm T-lever nuts, remove the two top bolts
from the plastic cross member and slide the
cross member forward.
T-Lever Positions
Socket Head Bolt, 3 x 28 mm (2 pcs)
Nylon Lock Nut, 3 mm (2 pcs)
Mixing Lever Spacer (2 pcs)
Spacer, 3 x 5 x 1 mm (2 pcs)
140 CCPM
120 CCPM
14

15
Elevator Control Arm
*Standard Range Direction
Nylon Lock Nut, 4 mm
Flat Washer, 4 mm
Set Screw, 4 x 4 mm
2-3B ELEVATOR CONTROL ARM INSTALLATION
90
Nylon Lock Nut, 4 mm
..................................1 pc
Flat Washer, 4 mm
...................................1 pc
Set Screw, 4 x 4 mm
....................................2 pcs
Use Red
Threadlock
Elevator
Control Arm
A-Arm Base
Make sure that the elevator control
arm is installed so that it is 90° to the
A-arm base. Use the locating hole in
the main frame to help achieve the
90-degree position.
Note:
Red
Red

16
2-4
MAIN FRAME ASSEMBLY: ENGINE MOUNT/CROSS MEMBER INSTALLATION
Remove a 1/2" x 1/2" portion of the clear coating from the inside of each
main frame as shown.
.....3 pcs
....6 pcs
.....................................9 pcs
Socket Head Bolt, 3 x 40 mm
Socket Head Bolt, 3 x 50 mm Nylon Lock Nut, 3 mm
Up
O.S. Engines and YS Engines
Engine Mount Direction
*TEAM TIP: Do not tighten bolts completely at this
time. These bolts will be tightened in Step 3-8.
Socket Head Bolt, 3 x 50 mm (3 pcs)
Cross Member B
(note correct direction)
Rear Grounding Bracket
Socket Head
Bolt, 3 x 40 mm
(6 pcs)
Socket Head
Bolt, 3 x 50 mm (1 pc)
(Do not use threadlock.)
*
*
*
**
*
*
Remove a 1/2" x 1/2" portion of the clear
coating from the inside of each frame plate
as shown.
*
*
Nylon Lock
Nut, 3 mm
(8 pcs)
1/2"
1/2"
Cross Member B
(note direction)
Landing Struts
Adaptor (4 pcs)

17
2-5 MAIN FRAME ASSEMBLY: BOTTOM PLATE INSTALLATION
* Socket Head Bolt, 3 x 10 mm (2 pcs)
Button Head Bolt,
3 x 10 mm (2 pcs)
Flat Washer, 3 mm (8 pcs)
Carbon Fiber
Bottom Plate
*
*
*
*
*Tighten bolts at this time.
Remove a 3/4" x 11/4" portion of the clear coating from the top of the bottom carbon fiber plate as shown.
Remove a 3/4" x
11/4" portion of the
clear coating from
plate as shown.
3/4"
1-1/4"
When properly installed, the RF grounding bracket will make contact with both the two main frames and the bottom
carbon plate in the areas where the clear coating has been removed. This will properly complete the ground between
the main frame and the bottom carbon plate.
................4 pcs
..........................8 pcs
Socket Head Bolt, 3 x 6 mm
Flat Washer, 3 mm
............2 pcs
Button Head Bolt, 3 x 10 mm
............2 pcs
Socket Head Bolt, 3 x 10 mm
Use Red
Threadlock

18
2-6 FUEL TANK INSTALLATION
Socket Head Bolt, 3 x 20 mm
Socket Head
Bolt, 3 x 20 mm (4 pcs)
* Tank Mounting Rubber
Tank Frame
Hex Spacer, 3 x 6 x 6 mm
Spacer, 3 x 6 x 6 mm (2 pcs)
Spacer, 3 x 6 x 2 mm
Spacer, 3 x 6 x 2 mm (2 pcs)
Cross Member, 32 mm
Cross Member,
32 mm (3 pcs)
2 pcs
....4 pcs
...................2 pcs
.......................2 pcs
*
Fuel Tank
Use Red
Threadlock
Attach fuel
line to tank
prior to
installation.
*TEAM TIP: Insert 32 mm cross members
before installing the fuel tank.
Red
Red
Red
If a YS engine is to be
used, replace the
existing tank mounting
rubber with Aerotrend
large fuel tubing or
equivalent.
* Note:
* Cut the tank mounting rubber to
a length as shown from the two
pieces included with the kit.
120 mm
210 mm
Red

19
2-7 FRONT RADIO BED INSTALLATION
3-1A
MAIN DRIVE GEAR/AUTOROTATION ASSEMBLY
Socket Head Bolt 3 x 8mm
Socket Head Bolt, 3 x 6 mm
Main Drive Gear
88T
Autorotation Assembly
Autorotation Assembly
Direction
(Note correct direction
during assembly.)
Socket Head Bolt, 3 x 6 mm (4 pcs)
(Tighten equally to prevent warping of main drive gear)
Socket Head Bolt, 3 x 8 mm (4 pcs)
Socket Head Bolt 3 x 10 mm
Body Mounting Standoff 24 mm
Cross Member 48 mm
Cross Member,
48 mm
Special Cross
Member, 48 mm (2 pcs)
Flat Head Bolt,
3 x 6 mm (4 pcs)
Carbon Radio Bed
................................................4 pcs
..............................................4 pcs
...................2 pcs
...................4 pcs
.......1 pc
Up
*Apply a light
coating of grease to
torrington bearing.
Use Red
Threadlock
Use Red
Threadlock
*TEAM TIP: Apply a light coating of high speed
grease to the inside of the torrington bearing.
Red
4pcs
Flat Head Bolt, 3 x 6 mm
...................... 4 pcs
Red
Body Mounting
Standoff, 24 mm (2 pcs)
Red
Red
Red
Red
Socket Head Bolt, 3 x 10 mm (4 pcs)
Body mounting
standoffs attach
to the forward-
most holes in the
tank mounts
as shown.
Note:

20
3-2 MAIN SHAFT/MAIN DRIVE GEAR INSTALLATION
3-1B BEVEL GEAR ASSEMBLY
Use Red
Threadlock
........................4 pcs
......1 pc
...............1 pc
...........1 pc
Set Screw, 4 x 4 mm
Hex Head Bolt, 6 x 10 mm
Steel Washer, 10 x 16 x 2.5 mm
Main Shaft Washer
Bevel Gear
Bevel Gear Hub
Flat Head Bolt, 3 x 6 mm
Flat Head Bolt, 3 x 6 mm (4 pcs)
...................... 4 pcs
Use Red Threadlock
Red
Attach the bevel gear hub as shown.
Be sure not to overtighten the four 3 mm bolts
as this could distort the bevel gear.
Socket Head Bolt, 3 x 12 mm
..... 1 pc
Socket Head Bolt, 3 x 20 mm
... 1 pc
Assembly Steps
1. Secure the bottom 6 x 10 mm
bolt to the shaft.
2. Pull up on the shaft and secure
the main shaft collar using the
4-4 mm set screws.
3. Secure the bevel gear assembly.
Main Shaft Collar
Set Screw
4 x 4 mm (4 pcs)
4 pcs
Red
Hex Head Bolt, 6 x 10 mm
Socket Head
Bolt, 3 x 20 mm
Bevel Gear
Assembly
Main Drive
Gear Assembly
Washer, 10 x 16 x 2.5 mm
(fits between bottom bearing
and auto-rotation unit)
Socket Head Bolt, 3 x 12 mm
Main Shaft Washer
Red
Special Washer, 10 x 6 x 0.5 mm
Red
Red
Both washers fit below
bottom bearing block.
Main Shaft Washer Direction
Bevel Cutting
Up
Note:
