Initial Operation
6 2.13.2018
1. Initial Operation
1.1. Connecting to power supply
Caution:
•This device may be attached to protected earth (PE) mains
power outlets only!
•The mains plug serves as a reliable way to disconnect the
unit from its power supply for safety reasons and must be
readily accessible at all times.
•Do not attempt to use the unit if the power cable is damaged!
•Regularly inspect the power cable for damage.
•No liability for improper power connection!
Compare the available mains voltage and mains frequency with the
specifications on the type label.
•Connect the mains plug to a protected earth (PE) power
supply socket!
1.2. Switching the unit on / selecting language
Refer to >Settings menu< on
page 18 for language selection.
To switch the unit on:
Use the mains switch to bring the unit into operation.
The integrated lamp indicates that the power is on.
As initialization proceeds, the unit will assume the start positions
and emit mechanical sounds.
The unit's name and voltage type are displayed briefly.
The unit will enter the same operating mode that it was in before
shutdown, i.e.
manual model (operation with the unit's controls or
remote control (operation via PC).

USER INTERFACE
2.13.2018 7
2. Normal display
Normal display:
The normal display contains
important values and functions.
Adjust the high temperature
cut-off by slowly turning the
dial with a screwdriver. The
exact value will appear on the
display.
Note:
The order and availability of values
9 to 12 will depend on the settings
in the > Customize Home display <
menu. Page 20
The factory state is shown here.
1 Date / time
2 Status: on/Standby / Warning
3 Fill level indicator
4 External temperature sensor value
5 Current power (X% heating, -X% cooling)
6 Selected temperature control (internal/external)
7 Actual liquid temperature
8 Selected max. pressure and actual pressure
9 Selected high temperature cut-off ( page 46)
10 Selected low temperature cut-off
11 High temperature cut-off (TANK)
12 High temperature cut-off (RESERVOIR)
Cooling icon Blinking or continuous
Heating icon Blinking or continuous
< Setpoint button
Adjust normal display
Call up main menu
Start/Stop button
State information
Examples:
Remote control mode through interface
( page 94)
A storage medium is inside the unit.
( page 42)
The unit is connected to a PC via ethernet.
( page 55)
Access to unit is blocked ( page 13)
Remote control mode via "Wireless Temp"

Normal display
8 2.13.2018
Warning
•The > TANK < high temperature cut-off should be set to
15 °C above the working temperature setpoint.
•The > RESERVOIR < high temperature cut-off must be set
to at least 25 °C below the heattransfer liquid's flashpoint.
Adjust the normal display
You can adjust the normal
display to your requirements
by pressing the >Display< key.
You may select the colors
used in the normal display's
chart.
>Settings menu< page 18.
Chart shows the progression of the setpoint and actual
temperature.
Displays during errors
ALARM red >
WARNING yellow >
Help is always accessible through
the icons or .
Touch the icon and a list of errors
will be displayed.
The unit provides straightforward and intuitive operation on the
color TFT display even during errors.
Error messages are divided into two categories:
>ALARM< and >WARNING<
Date and time when the error appeared are stored and displayed.
If possible, this data will also be stored during removal of the error.
Example code

USER INTERFACE
2.13.2018 9
ALARM display
Error messages are displayed in a
red box.
Resolution for example E14:
Touch the red box to
mute the alarm.
Press < > button for help text.
The module and the configuration
are displayed.
Follow the instructions in the help
text.
Press < > button.
Press < > button again for help
text.
Press < > button.
.
Another error message (E108)
appears and describes a pathway
for overcoming the alarm.
Press < > button for help text.
Follow the instructions in the help
text.
The unit is now ready to continue
operation.
The unit switches to „Standby“. Heater, refrigeration unit and
circulation pump are switched off.

Error message (E 14) remains although the safety temperature
has been raised.
A <Reset> is not permitted in this case because, according to
NAMUR, this condition must be resolved via hardware.
Errors not subject to this regulation are resolved via
<Reset>.
Not all alarms may be removed on-site.
List of all error messages see page 108

Normal display
10 2.13.2018
WARNING display:
A warning does not result in shutdown of the heater, refrigeration
unit, and circulation pump.
The unit provides the option of defining some warning limits
independently, such as limits for pump pressure, limits for over-
temperature and under-temperature.
If one of these limits is exceeded, a warning (ticker and signal) will
continue for as long as the cause is active.
The yellow attention symbol will remain. It will draw attention
to events that occurred during absence of the operating personnel.
The events are stored in a list of errors.
Warnings are displayed as a ticker
in the status line.
Example: Warning 40
Touch the icon to mute the signal.
Touch or
and a list of errors will be
displayed.
Buttons in the list -
Press the < > button for help
text.
Press < > to delete an error
message from the list.
The 10 most recent events are
shown.
The complete list may be viewed in
the password-protected service
menu.
page 45
Use the keys to view the list.
Use the key to exit the list. The yellow Attention icon " "
is reset to " ".

USER INTERFACE
2.13.2018 11
2.1. Set temperature
Select setpoint
Setpoint button
Input panel (example: 25.00 °C)
The green keys display the most recently selected
values.
Input keys
Keys 0 to 9 (digits keypad)
Decimal point button
Minus/plus button
Backspace key
Exit window without changes
Input/confirm entry
2.2. Start / Stop
Press Start/Stop button The start-up phase can last up to 30 seconds.
The unit switches to „On“ and runs
through a start-up phase, during
which various parameters are
checked and/or adjusted.
When the ticker is no longer
displayed, the unit operates
normally.

Main menu view
12 2.13.2018
3. Main menu view
Select menu
3.1. Available keys in the main menu
Block access to unit / password-protected actions.
Go back one menu level.
Home (return to normal display).
Retrieve help menu
Press < > and then press the desired entry in the menu.
Indicates available submenu.
Digits keypad
Keys 0 to 9 (digits keypad)
Exit window without changes
Move cursor: left / right
Example: Date input boxes
Backspace key
Input/confirm entry
Example: Input box with temperature value -10 °C
Decimal point button
Minus/plus button

USER INTERFACE
2.13.2018 13
3.2. Unit Access/Safety Settings
have full rights.
Administrator assignment of
password and access rights.
Without an entry in the menu, the unit can be operated by any
authorized person. You can change the unit's safety settings in this
menu. The authorized users and user rights can be restricted.
An >Administrator< is authorized to manage access to the unit. He
can approve differing rights for two groups of users.
Access is always password-protected.
A six-digit password was set at the factory so the administrator can
gain initial access.
Six zeros: 000000
Refer to page 16 to change the administrator password.
3.2.1. Administrator - Managing Access to the Unit
Press the key
in > Main menu <.
The >Unit account< menu is
displayed.
Press the key
Enter the administrator password.
>Lock unit< >Idle timer<
Description page 17

Light gray buttons are blocked.
Press >Logout< to re-enable access to the unit.

Main menu view
14 2.13.2018
Press the key
Enter administrator password
The administrator uses the password-protected >Settings< menu
to grant access rights and passwords.
Default settings
Press the key
>Access rights<
are granted in the >Default
values< menu.
Press the key
= released, = blocked
Confirm setting with
If none of the user groups are logged in, the released functions
and menus will be accessible by all users.
Buttons
in the Normal view and in the main menu
User groups
Press the key
or
This is where the administrator assigns a password and access
rights to specific user groups.
If a user group is logged in, settings can be changed only after
entering the corresponding password.

USER INTERFACE
2.13.2018 15
Press the key
The user is asked to enter a new
password and reenter the
password for confirmation.
Confirm setting with
Example:
Basic users
Example:
4-digit password for > Basic users <
Press the key
Use the check box to grant
or deny
access rights to user groups.
Confirm setting with
Basic users Advanced users
Factory settings 
Reset
Press the key
.
Press this button to reset all access rights to factory settings.

Main menu view
16 2.13.2018
Administrator
Change Password:
Press the key
The user is asked to enter a new
password and reenter the
password for confirmation.
ATTENTION:
Record the new password in a secure place.
It will not be possible to access the unit without this password. The
factory password will be overwritten.
Forget your password?
This can be resolved only through the >Service menu< Page 45.
The authorized service person can delete the stored password and
reset it back to the factory setting.
3.2.2. User Groups - Managing Access to the Unit
Users can sign on with the password that has been assigned to
them.
After login, all settings approved for the relevant user group will be
accessible by everyone without reentering the password. Press
"Lock unit" to prevent misuse.
Press the key
in > Main menu <.
The >Unit account< menu is
displayed.
Light gray buttons are blocked.
Press this button to login
Enter the password
Access to the unit is enabled for
the respective user group.
Permitted adjustments can now be
performed.

USER INTERFACE
2.13.2018 17
Block unit access immediately
Press the key
Block with time delay.
Press the key
Set time.
Press the key
"Deactivate" time or
"Edit" time.
Enter the desired time here, after which the unit will be blocked if
no additional entries are made.
Example: 5 minutes.
The current setting is shown on the button and will remain until
changed.
The unit will automatically switch to
the normal display.
Press to enter password
If someone attempts to use a locked unit, a window will open to
notify the user that the unit is locked.
Example:
Access to the unit can be restored by entering the password of the
user group that locked the unit or the administrator password.
If an incorrect user group password is entered three times in a row,
the administrator password will be required to enable the unit.
Enable access to the unit.
Press Logout to confirm.
After pressing >Logout<, access to the unit is re-enabled.

"Settings" menu
18 2.13.2018
4. "Settings" menu
Select in the main menu
Select menu here
The buttons will display the current
settings
or
indicate availability of a submenu:
.
Example:
Call up the >Units< Help menu.
Press the < > button and then press the >Units< button in the
menu.
4.1. "Language" menu
Select language.

USER INTERFACE
2.13.2018 19
4.2. "Autostart" menu
Switch Autostart on/off
Allows the direct start of the temperature control systems via the
mains power switch.
>Autostart<
Note:
The temperature system has been configured and supplied by
JULABO according to N.A.M.U.R. recommendations. This means
for the start mode, that the unit must enter a safe operating state
after a power failure (non-automatic start mode). This safe
operating state is indicated by "OFF", on the TFT-Display. A
complete shutdown of the main functional elements such as heater
and circulation pump is effected simultaneously.
Using the AUTOSTART function is only possible when a set-point
is set via >TFT Display< and >EPROG-input<.
Should such a safety standard not be required, the AUTOSTART
function (automatic start mode) may be activated, thus allowing the
start of the instrument directly by pressing the mains power switch
or using a timer.
4.3. "Units" menu
The buttons will display the current
settings.
Select the temperature units
°C or °F
Select pressure units
bar or psi
Select flow rate units
l/m or gpm

"Settings" menu
20 2.13.2018
4.4. Menu Customize Home display
Two paths to the submenu
> Customize Home display <.
1. Via
2. Touch the field.
The current setting is displayed on
the keypad.
Choose value X.
Example: value 1
Choice of displayable values.
Push for further values.
Choose value and
automatic return to
> Customize Home display <.
Or push and leave the display
without changes.
Active key light green.
or
The sequence and choice of the values in the orange field can be
changed.
The partial area in the lower right is a keypad which turns
orange when touched.
Example: Value 1 / Flow rate 
Message in case of incorrect choice.
Setting via
Whether >Pressure< or >Flow rate< are settable, depends on the
setting of >JULABO Sensor Pres./Flow<.
