Jung NRS 0834 Series User manual

Emergency system set and emergency system set with UPS
01.10.20201 / 110024015123
Emergency system set
Ref.-no.: NRS .. 0834 ..
Emergency system set with UPS
Ref.-no.: NRS .. 0834-2 ..
Operating instructions
1 Safety instructions
Electrical devices may only be mounted and connected by electrically skilled persons.
Serious injuries, re or property damage possible. Please read and follow manual fully.
Danger of electric shock. Always disconnect before carrying out work on the devise or load.
When installing the emergency system the general safety regulations for telecommunication systems must
be observed according to DIN VDE 0800.
These instructions are an integral part of the product, and must remain with the end customer.
2 Battery safety instructions
WARNING! Improper handling of batteries can result in explosion, re or chemical burn due to leakage.
Do not heat or throw batteries into re.
Do not reverse polarity, short-circuit or recharge batteries.
Do not deform or disassemble batteries.
Replace batteries only with an identical or equivalent type.
Remove empty batteries immediately and dispose of in an environmentally friendly manner.
3 System overview
The emergency system set consists of the single devices pull cord button, emergency signal, reset button, power
supply and UPS module.The emergency system set can be extended with the service unit and with call buttons.
12
3
Fig. 1: Emergency signal
1. Insert emergency signal
2. Frame
3. Cover emergency signal
GB

Emergency system set and emergency system set with UPS
01.10.20202 / 110024015123
42
5
6
7
Fig. 2: Pull cord push-button
4. Insert pull cord push-button
5. Cover pull cord push-button
6. Pull cord
7. Status light
82
9
10
Fig. 3: Reset button
8. Insert reset button
9. Cover reset button
10. Reset button
11 12 2
13
Fig. 4: Power supply
11. Power supply
12. Supporting frame
13. Cover

Emergency system set and emergency system set with UPS
01.10.20203 / 110024015123
14 2
13
Fig. 5: UPS module (only included in the emergency system set with UPS)
14. UPS module
15 2
16
18 17
Fig. 6: Service unit (not included in the set)
15. Insert service unit
16. Cover service unit
17. Reset visual call
18. Reset acoustical call
19 2
20
21
Fig. 7: Call button (not included in the set)
19. Insert call button
20. Cover call button
21. Status light

Emergency system set and emergency system set with UPS
01.10.20204 / 110024015123
4 Function
Intended use
- In accordance with DIN VDE 0834, the emergency system set is meant to be used in bathrooms for people with
disabilities.
- Installation into ush box according to DIN 49073
- UPS module: Installation into deep ush box (recommendation min. 48 mm)
Product characteristics
- Pull cord push-button with status light
- Reset of calls with the reset button
- Service unit with visual and acoustical indication
- Only included in the emergency system set with UPS: UPS module for bridging power failures
- Call triggered via oating contact
5 Operation
Send emergency call
• Activate call with pull cord push-button.
• Deactivate call with reset button.
6 Information for electrically skilled persons
Installation and electrical connection
Mounting height according to DIN VDE 0834 (call systems in hospitals, nursing homes and similar facilities).
Pull cord push-button:
Min. installation height: 20 cm higher than the shower head
The pull cord has to reach 10 cm above the oor and be accessible for a person lying on the oor.
Operating devices:
0.7 – 1.5 m above the oor
Operating devices with text:
1.5 – 1.7 m above the oor
Devices with installation units:
1.6 – 1.8 m above the oor
Signal lights and text displays:
1.5 – 2.2 m above the oor
iInstallation and connection of calling systems is only permitted for trained electricians.
DANGER
Electric shock from touching live parts in the installation environment.
An electric shock can be fatal.
Before working on the device, disconnect the power and cover live parts in the area.

Emergency system set and emergency system set with UPS
01.10.20205 / 110024015123
Jumper at the emergency signal (22)
Jumper 1 (JP1)
closed: Activated buzzer of the emergency signal
open: Deactivated buzzer (factory settings)
Jumper 2 (JP2)
closed: Signal light and buzzer (also service unit) with permanent sound (factory settings)
open: Signal light and buzzer intermittent (also service unit)
TOP
JP1 JP2
22
Fig. 8: Emergency signal (front side)
Connecting and wiring emergency system
Installation: see g. 1, 2, 3, 4, 5, 6, 7
Connection: see g. 9, 10
Wiring: see g.11
Connecting UPS module:
• Only connect accumulator with UPS module after connecting main power supply to avoid discharging of
accumulator.
iThe accumulator will be completely charged after several hours of operation.
Replacing accumulator at UPS module:
According to DIN VDE 0834 wearing components, i.e. batteries and accumulators, must be replaced once a year.
• Disconnect the accumulator from the UPS before replacing the accumulator or decommissioning the emergency
system. This avoids discharging of the accumulator and short circuits during the dismounting of the accumulator.

Emergency system set and emergency system set with UPS
01.10.20206 / 110024015123
JY(St) Y 2x2x0.6
(max. 500 m)
GND
+24V
GND
M
GND
M
Floating contact
Emergency
signal
UPS module Power supply
24 V/200 mA
Service unit
KW
KA
KR
RT
RL(WC)
+24V AT/
AT AT
Pull cord push-button or call button
Reset button
RT(WC)
BL
+24V+24VE
only included in the
emergency system set
with UPS
GNDE
+24V IN
+24V OUT
Fig. 9: Wiring plan
+24V
M
GND
+24V
M
GND
KW KR
KA +24VE
GNDE
RT
BL
AT
RLWC
RTWC
RTWC\
+24V
AT AT\
15
48
1
Service unit
Reset button
AT AT\
further
reset button
Pull cord
push-button
Emergency
signal
RL RT RT\
Call button
AC 230 V~
+24V
GND
11
Power supply
14
M
GND GND
UPS module
+24V
only in
emergency system
set with UPS
+24V IN +24V OUT
Fig. 10: Wiring call button

Emergency system set and emergency system set with UPS
01.10.20207 / 110024015123
Service unit
Corridor
UPS module
only included in the emergency system set with UPS
Toilet for people
with disabilities
Fig. 11: Installation situation
+24V
M
GND
+24V
M
GND
KW KR
KA +24VE
GNDE
RT
BL
AT
RLWC
RTWC
RTWC\
+24V
AT AT\
15
48
1
Service unit
Reset button
AT AT\
further
reset button
Pull cord
push-button
Emergency
signal
RLWC
RTWC
RTWC\
+24V
further
pull cord
push-button
AC 230 V~
+24V
GND
11
Power supply
14
M GND GND
UPS module
only in
emergency system
set with UPS
+24V IN +24V OUT
Fig. 12: Wiring pull cord push-button

Emergency system set and emergency system set with UPS
01.10.20208 / 110024015123
7 Connection terminals
Emergency signal
Ref-No.: NRS .. 0834 RM ..
Visual and acoustical call identication, oating contact.
+24V
M
GND
KW KR
KA +24VE
GNDE
RT
BL
AT
Fig. 13: Emergency signal (rear side)
+24VE +24V external
GNDE GND external
RT Call button
BL Status light
AT Reset button
KA Make contact
KR Break contact
KW Contact input
M Service unit terminal
GND Power supply –
+24V Power supply +
The external connections are intended for downstreamed components (pull cord push-buttons, reset buttons, ...).
Pull cord push-button
Ref-No.: NRS .. 0834 ZT..
Pull cord push-button with status light
RLWC
RTWC
RTWC\
+24V
Fig. 14: Pull cord push-button
RLWC Light
RTWC Pull cord push-button (IN)
RTWC\ Pull cord push-button (OUT)
+24V Power supply +

Emergency system set and emergency system set with UPS
01.10.20209 / 110024015123
Reset button
Ref-No.: NRS .. 0834 AT..
Reset button to reset the call.
AT AT\
Fig. 15: Reset button (rear side)
AT Reset button (IN)
AT\ Reset button (OUT)
UPS module (only included in the emergency system set with UPS)
Ref.-no.: NRS .. 0834 USV ..
For bridging power failures
With replaceable accumulator (ref.-no.: NRS AKKU 130)
Reports accumulator error or power failure to the emergency signal
+24V IN
M
GND GND
+24V OUT
Fig. 16: UPS module (rear side)
+24V OUT +24V external (OUT)
GND GND external (OUT)
M Emergency signal terminal
GND Power supply + (IN)
+24V IN Power supply – (IN)
Acoustic signals at emergency signal:
Accumulator use: one short signal in an interval of 12 seconds
Accumulator error: two short signals in an interval of 12 seconds

Emergency system set and emergency system set with UPS
01.10.202010 / 110024015123
Service unit (not included in the set)
Ref-No.: NRS .. 0834 DZE ..
Optional operation and control unit with acoustical and visual call, call suppression and call interruption for 20 s.
+24V
M
GND
Fig. 17: Service unit (rear side)
+24V Power supply +
GND Power supply –
M Emergency signal terminal
Call button (not included in the set)
Ref-No.: NRS .. 0834 RT ..
Call button with status light.
+24V
RT/ RL
RT
Fig. 18: Call button (rear side)
+24V Power supply +
RT Button (IN)
RT\ Button (OUT)
RL Light
