JVC KS-JA0502-4 User manual

LVT2125-001A
[A/U]
9-INCH WIDESCREEN MONITOR WITH DVD PLAYER
INSTRUCTIONS
MENU
KS-JA0502-4
KS-JA0502-3
Cover_KSJA0502-4[U].indd 2Cover_KSJA0502-4[U].indd 2 09.11.11 11:50:00 AM09.11.11 11:50:00 AM

2
This product incorporates copyright protection technology that is protected by U.S. patents and
other intellectual property rights. Use of this copyright protection technology must be authorized
by Macrovision, and is intended for home and other limited viewing uses only unless otherwise
authorized by Macrovision. Reverse engineering or disassembly is prohibited.
Thank you for purchasing a JVC product.
Please read all instructions carefully before operation, to ensure your complete understanding and to
obtain the best possible performance from the unit.
IMPORTANT FOR LASER PRODUCTS
1. CLASS 1 LASER PRODUCT
2. CAUTION: Do not open the top cover. There are no user serviceable parts inside the unit; leave
all servicing to qualified service personnel.
3. CAUTION: Visible and/or invisible class 1M laser radiation when open. Do not view directly
with optical instruments.
4. REPRODUCTION OF LABEL: CAUTION LABEL, PLACED OUTSIDE THE UNIT.
[European Union only]
Inst_KS-JA0502-4[U].indb 2Inst_KS-JA0502-4[U].indb 2 09.11.10 3:30:19 PM09.11.10 3:30:19 PM

3
WARNINGS
• DO NOT INSTALL THE MONITOR IN
A LOCATION WHICH OBSTRUCTS
DRIVING, VISIBILITY, SAFETY
DEVICE FUNCTION SUCH AS AIR
BAGS OR WHICH IS PROHIBITED
BY APPLICABLE LAWS AND
REGULATIONS.
• There may be legal regulations defining
the permissible installation locations for
the monitor which differ by country or by
state. Be sure to install the monitor in a
correct location according to such laws.
• The driver must not operate the monitor
while driving.
* Stop your vehicle in a safe location before
operating the monitor.
• The driver must not watch the television or
playback pictures while driving.
If the driver does it while driving, it may
lead to carelessness and cause an accident.
• Keep the monitor at an appropriate sound
level while driving.
Driving with the sound at a level that
prevents you from hearing sounds outside
of and around the vehicle may cause an
accident.
• Be sure not to let the monitor fall or be
strongly impacted since this may cause a
malfunction or fire.
• Do not use the monitor with the engine off.
Doing so will consume battery power and
may prevent the engine from starting.
• When not in use, close the liquid crystal
panel and store it into the compartment.
• Do not touch the surface of the liquid
crystal panel directly.
• Do not hang any
object on the
monitor or hang
down, as this
may damage the
monitor.
CAUTION:
This monitor should be used on DC 12 V
only. To prevent electric shocks and fire
hazards, DO NOT use any other power
source.
CAUTION on volume setting:
Discs produce very little noise compared
with other sources. Lower the volume
before playing a disc to avoid damaging
the speakers by the sudden increase of the
output level.
CAUTIONS on the supplied headphones
—KS-HP2:
• DO NOT leave the headphones in a place
exposed to direct sunlight for a long
time, such as a dashboard, as they may be
damaged.
• Keep the headphones away from a cellular
phone to avoid interference.
• DO NOT turn off the power with the
volume set at high level, as the sudden
blast of sound can damage your hearing
and/or headphones next time you use the
headphones.
• If you experience a ringing in your
ears, reduce volume or stop using the
headphones.
CAUTION:
DTS sound cannot be reproduced.
Inst_KS-JA0502-4[U].indb 3Inst_KS-JA0502-4[U].indb 3 09.11.10 3:30:20 PM09.11.10 3:30:20 PM

4
How to read this manual
The following methods are used to make the
explanations simple and easy-to-understand.
• Some related tips and notes are explained in
“More about this monitor” (see pages
33 – 36).
• Button operations are mainly explained with
the illustrations as follows:
Press briefly.
Press repeatedly.
Press either one.
Press and hold until
your desired response
begins.
Press and hold both
buttons at the same
time.
How to forcibly eject a disc
If a disc cannot be recognized by the monitor
or cannot be ejected...
The disc comes
out.
• Be careful not to drop the disc when it
ejects.
Monitor only
(for about 5 seconds
while power is on)
Inst_KS-JA0502-4[U].indb 4Inst_KS-JA0502-4[U].indb 4 09.11.10 3:30:20 PM09.11.10 3:30:20 PM

5
Unique disc functions...................... 22
Selecting audio languages ..................... 22
Selecting subtitles .................................. 22
Selecting multi-angle views................... 22
Disc menu operations ............................ 23
Zoom in.................................................. 23
On-Screen disc operations............... 24
Operations using the on-screen bar ....... 24
Basic on-screen bar operations .............. 25
Basic control screen operations ............. 26
List screen operations ............................ 27
DVD setup menu ............................ 28
Basic setting procedure.......................... 28
Maintenance .................................. 31
Language codes.............................. 32
More about this monitor................. 33
Troubleshooting ............................. 37
Specifications................................. 39
Contents
How to forcibly eject a disc................... 4
How to read this manual........................ 4
Precautions.................................... 6
Widescreen monitor ....................... 7
Parts identification................................. 7
Remote controller — RM-RK231 ....... 8
Main elements and features ................... 8
Headphones — KS-HP2 .................... 10
Main elements and features ................... 10
Basic operations ............................. 11
Adjustments .................................. 13
Using the monitor menu ........................ 13
Changing the aspect ratio ...................... 15
Playable discs................................ 17
Disc operations .............................. 18
Playing a disc ................................. 18
Starting playback ................................... 18
Basic operations..................................... 19
Temperature inside the car....
If you have parked the car for a long time in
hot or cold weather, wait until the temperature
in the car becomes normal before operating the
unit.
For safety....
• Do not raise the volume level too much, as
this will block outside sounds, making driving
dangerous.
• The driver must not operate the monitor while
driving.
* Stop your vehicle in a safe location before
operating the monitor.
Inst_KS-JA0502-4[U].indb 5Inst_KS-JA0502-4[U].indb 5 09.11.10 3:30:20 PM09.11.10 3:30:20 PM

6
Precautions
The red spots, blue spots and green spots on
the panel surface are a normal characteristic of
liquid crystal panels, and not a problem.
Note:
The liquid crystal panel is built with very
high precision technology and has at least
99.99% effective image pixels. Be aware that
on 0.01% of the panel there may be missing or
constantly lit pixels.
When the temperature is very cold or very
hot, the image may not appear clearly or may
move slowly.
The image may not be synchronized with
the sound or the image quality may decline
in such environments. Note that this is not a
malfunction or problem.
• Usage temperature range: –20°C to +60°C
–20°C or colder
60°C or hotter
When the liquid crystal panel reaches high
temperatures or low temperatures, chemical
changes occur inside the panel, which may
cause it to malfunction.
Do not expose the liquid crystal panel to direct
sunlight.
• Storage temperature range: –40°C to +85°C
Do not drop the liquid crystal panel or strike
it sharply.
Spots
Cautions for handling the liquid crystal panel
During the summer,
temperatures can
reach as high as
100°C.
+85°C
–40°C
–40°C to +85°C
Inst_KS-JA0502-4[U].indb 6Inst_KS-JA0502-4[U].indb 6 09.11.10 3:30:21 PM09.11.10 3:30:21 PM

7
Widescreen monitor
1IR transmitters
2Disc loading slot
3Dome light
4Screen compartment
5Screen (Liquid crystal panel)
60(eject) button
7(play/pause) button
84(reverse skip) button
9¢(forward skip) button
pMODE button
Parts identification
q(standby) button
• Turns on the power if pressed.
• Turns off the power if pressed and held.
wRemote sensor
eOpen button
rDome light switch
• See “To activate the door sensor” on page
12.
tAV1 INPUT terminals
When you watch the screen at an angle, the picture might not be clear. This is not a malfunction.
The finest picture can be seen when you watch the screen straight-on.
Inst_KS-JA0502-4[U].indb 7Inst_KS-JA0502-4[U].indb 7 09.11.10 3:30:21 PM09.11.10 3:30:21 PM

8
Remote controller — RM-RK231
Remote sensor
Main elements and features
MONITOR
1MODE button
• Selects the playback source.
2ASPECT button
• Changes the aspect ratio of the screen.
3MENU button
• Calls up the menu, then selects the
adjustable menu items.
4/ buttons
• Adjust the level of the selected item or
select an appropriate setting for selected
item.
MENU
Installing the lithium coin battery
(CR2025)
Before using the remote controller:
• Aim the remote controller directly at the
remote sensor on the monitor. Make sure
there is no obstacle in between.
• Do not expose the remote sensor to strong
light (direct sunlight or artificial lighting).
Warnings:
• Store the batteries in a place which
children cannot reach.
If a child accidentally swallows the
batteries, immediately consult a doctor.
• Do not recharge, short, disassemble or heat
the batteries or dispose of in a fire.
Doing any of these things may cause the
batteries to give off heat, crack or start a
fire.
• Do not leave the batteries with other
metallic materials.
Doing this may cause the batteries to give
off heat, crack or start a fire.
• When throwing away or saving batteries,
wrap in tape and insulate; otherwise, it
may cause the batteries to give off heat,
crack or start a fire.
• Do not poke the batteries with tweezers or
similar tools.
Inst_KS-JA0502-4[U].indb 8Inst_KS-JA0502-4[U].indb 8 09.11.10 3:30:21 PM09.11.10 3:30:21 PM

9
DVD
5Disc basic operation buttons
7(stop), 3(play), 8(pause)
• 3(play) button functions as ZOOM
button when pressed with SHIFT button.
6Advanced disc operation buttons
•
/TITLE 5/ ∞
– Select the titles (for DVD) or folders
(for MP3/WMA/WAV/JPEG/MPEG-1/
MPEG-2/DivX)*1.
• 4/ ¢(reverse skip/forward skip)*2
• 1/ ¡(reverse search/forward
search)*3
7TOP M (menu) button*4
• Displays the DVD and DivX disc menu.
• Resumes PBC playback for VCD.
8SETUP button*4
9SHIFT button
pOSD button
• Displays the on-screen bar.
• Also functions as the /TITLE button
when pressed with SHIFT button.
– You can directly select folders (for
MP3/WMA/WAV/JPEG/MPEG-1/
MPEG-2/DivX) or titles (for DVD)
using the number buttons (see right
column).
qMENU button*4
• Displays the DVD and DivX disc menu.
• Resumes PBC playback for VCD.
wMenu operation buttons*4
• Cursor (%, fi, @, #) and ENTER
eRETURN button*4
rSpecial function buttons
• DVD/VCD/DivX: (audio)
• DVD/DivX: (subtitle)*4
• DVD: (angle)
*1These buttons function as the +10/–10
buttons when pressed with SHIFT button.
*2These buttons function as the +100/–100
buttons when pressed with SHIFT button.
*3Not used for JPEG operations.
*4These buttons function as the number
buttons when pressed with SHIFT button.
How to select a number
• To select a number from 0 – 9:
• To select a number greater than 9:
• +100/–100 buttons are used for searching a
track number greater than 99 (not available
for CD/DVD/VCD).
Inst_KS-JA0502-4[U].indb 9Inst_KS-JA0502-4[U].indb 9 09.11.10 3:30:21 PM09.11.10 3:30:21 PM

10
You can listen to the playback sounds with
cordless headphones—KS-HP2.
Installing the batteries
CAUTIONS:
• The supplied batteries are not rechargeable.
DO NOT recharge them; otherwise, battery
leakage or explosion may result.
• Insert the batteries with the correct polarity
“+” and “–” to prevent the battery leakage
or explosion.
Before using the cordless headphones:
The headphones give the best results when used
within about 1.8 m from the IR transmitters.
These headphones need to receive infrared
(IR) signals sent from IR transmitters on the
monitor. Therefore, if you use the headphones
where the signals cannot be received in a
straight line of sight, noises may be generated.
Main elements and features
1IR sensors
• DO NOT cover the IR sensors, as
reception will become poor.
2ON/OFF button
• Turns the power on and off.
• The power automatically shuts off in the
following cases:
– The headphones are used for about 4
hours.
– No signal is received for about 4
minutes.
3POWER lamp
4VOL (volume) control
Playback sounds are transmitted through IR
transmitters to the cordless headphones.
When using the headphones, select
“HEADPHONE” (or “HEADPHONE/AUX”)
for the monitor menu item “AUDIO.” (See page
14.)
WARNING:
DO NOT use the headphones while driving.
Shutting out all outside sounds while driving
is dangerous and may result in a traffic
accident.
Headphones — KS-HP2
Left side Right side
IR transmitters
POWER VOL
Batteries (R03/AAA)
—supplied only
for initial setup
purpose
Inst_KS-JA0502-4[U].indb 10Inst_KS-JA0502-4[U].indb 10 09.11.10 3:30:22 PM09.11.10 3:30:22 PM

11
1 Open the liquid crystal panel.
Press the open button until the liquid crystal panel is unlocked, then open the liquid crystal
panel by both hands.
CAUTIONS:
• When not in use, close the liquid crystal panel and store it into the compartment;
otherwise, it may obstruct the visibility through the rearview mirror.
• Do not touch the surface of the liquid crystal panel directly.
When closing the liquid crystal panel, store it in the screen compartment until it is locked.
2 Turn on the power.
Monitor only
3 Adjust the monitor angle.
Basic operations
Continued on the next page...
Inst_KS-JA0502-4[U].indb 11Inst_KS-JA0502-4[U].indb 11 09.11.10 3:30:22 PM09.11.10 3:30:22 PM

12
4Select the playback source.
Each time you press the button, the playback source changes as follows:
• DISC: Selects the built-in DVD player.
• AV 1: Selects the external component connected to the AV1 INPUT terminals of the
monitor.
• AV 2: Selects the car AV unit.
5Operate the playback source you selected.
To operate the built-in DVD player, see “Disc operations” on page 18.
To operate the external components, refer to the manuals for the connected components.
6Adjust the volume on the car AV unit.
• When using the headphones, adjust its volume level (see page 10).
To turn off the power
• When using the headphones, turn off the power after turning off the
headphones.
• When shipped from the factory, “POWER OFF MODE” of the
monitor menu is set to “20 min.” (see page 14). With this setting,
you can keep the monitor turned on for 20 minutes after switching
off the ignition of the car.
To activate the door sensor
• OFF: Turns off the dome lights.
• DOOR: Activates the door sensor which turns on the dome lights when a door is open.
• ON: Turns on the dome lights.
MODE
AV 1 AV 2DISC
Monitor Remote controller
Monitor only
Inst_KS-JA0502-4[U].indb 12Inst_KS-JA0502-4[U].indb 12 09.11.10 3:30:23 PM09.11.10 3:30:23 PM

13
Using the monitor menu
You can make your own display or sound adjustments using the monitor menu.
• For the adjustable items, see the next page.
• When shipped from the factory, the monitor menu language is set to English. To change the
language, change the “LANGUAGE” setting.
The Remote controller—RM-RK231 has two MENU buttons.
In this section, use MENU button on the MONITOR section.
• The monitor menu operation can be done by the remote
controller only.
Basic procedure
1Call up the menu.
The menu goes off if other operations are done or no operation is done for about 10 seconds.
2Select an item you want to adjust.
3Adjust the level of the selected item (or select an appropriate setting for the
selected item).
4Exit from the menu.
Press the button repeatedly until the menu is erased.
Adjustments
MENU
MENU
AUDIO HEADPHONE/AUX
LANGUAGE ENGLISH
BRIGHTNESS MODE AUTO
DAY BRIGHTNESS
NIGHT BRIGHTNESS
CONTRAST
TINT
COLOR
BLUE BACK AV1/AV2:OFF
POWER OFF MODE 20 min.
Current menu item
When “ENGLISH” is selected
for “LANGUAGE”
AUDIO HEADPHONE/AUX
LANGUAGE ENGLISH
BRIGHTNESS MODE AUTO
DAY BRIGHTNESS
NIGHT BRIGHTNESS
CONTRAST
TINT
COLOR
BLUE BACK AV1/AV2:OFF
POWER OFF MODE 20 min.
Inst_KS-JA0502-4[U].indb 13Inst_KS-JA0502-4[U].indb 13 09.11.10 3:30:23 PM09.11.10 3:30:23 PM

14
Adjustable items on the monitor menu Initial: Underlined
AUDIO*1:Select whether you listen to the sounds using the headphones and/or
speakers.
• Selectable settings: HEADPHONE/AUX, HEADPHONE, AUX
LANGUAGE*2:Select the language used for the monitor menu.
• Selectable settings: ENGLISH, ITALIANO, DEUTSCH,
FRANÇAISE
BRIGHTNESS
MODE:
Select the screen brightness and illumination control.
• Selectable settings:
AUTO: The screen brightness is changed to the level adjusted in
“NIGHT BRIGHTNESS” when you turn on the headlights.
DAY: The screen brightness is set to the maximum level.
NIGHT: The screen brightness is set to the level adjusted in “NIGHT
BRIGHTNESS.”
DAY
BRIGHTNESS:
Adjust this if the picture is too bright or too dark.
• Adjustable range: –10 to +11, Initial: 0(center)
NIGHT
BRIGHTNESS:
Adjust the screen brightness.
• Adjustable range: –5 to +5, Initial: 0(center)
CONTRAST: Control the degree of difference between the lightest and darkest parts of
the picture.
• Adjustable range: –10 to +11, Initial: 0(center)
TINT*3:Adjust this if the human skin color is unnatural.
• Adjustable range: –10 to +11, Initial: 0(center)
COLOR: Adjust the color of the picture—lighter or darker.
• Adjustable range: –10 to +11, Initial: 0(center)
BLUE BACK: Activate or deactivate the blue back screen displayed while no video signal
is coming in for AV1 or AV2.
• Selectable settings: AV1/AV2:OFF, AV1/AV2:ON,
AV1:OFF AV2:ON, AV1:ON AV2:OFF
POWER OFF
MODE:
Select “20 min.” to turn off the monitor 20 minutes after switching off the
ignition of the car, or “AUTO” to turn off the monitor when switching off
the ignition of the car.
• Selectable settings: 20 min., AUTO
*1Turn off the headphones before changing the “AUDIO” setting.
*2When you select English, Italian, French, or German for “ON SCREEN LANGUAGE,” the
monitor menu language is also changed (see page 29).
*3“TINT” cannot be adjusted when PAL signal is coming in for AV1 or AV2 (“FIXED” appears).
Inst_KS-JA0502-4[U].indb 14Inst_KS-JA0502-4[U].indb 14 09.11.10 3:30:23 PM09.11.10 3:30:23 PM

15
Changing the aspect ratio
You can select an appropriate aspect ratio for the playback video signals.
Basic procedure
Remote controller only
Each time you press the button, aspect ratio changes.
Selectable aspect ratio
When incoming 16:9 video signal:
FULL: Pictures are fully shown on the screen.
• In some cases, the black bars may be shown at the top and
bottom sides of the screen.
NORMAL: Pictures are reduced horizontally.
• The black bars will be shown at the left and right sides of
the screen.
• In some cases, the black bars may be shown also at the top
and bottom sides of the screen.
JUST: The middle of pictures are compressed horizontally, and the
left and right side of the picture enlarged horizontally.
• In some cases, the black bars may be shown at the top and
bottom sides of the screen.
ZOOM: Pictures are enlarged on the screen so that no black bars will
be shown on the screen. (The entire picture cannot be shown
on the screen.)
ASPECT
Continued on the next page...
Inst_KS-JA0502-4[U].indb 15Inst_KS-JA0502-4[U].indb 15 09.11.10 3:30:24 PM09.11.10 3:30:24 PM

16
When incoming 4:3 video signal:
FULL: Pictures are enlarged horizontally and are fully shown on the
screen.
NORMAL: Pictures are shown at the center of the screen.
• The black bars will be shown at the left and right sides of
the screen.
JUST: Pictures are enlarged horizontally. The extension ratio
increases toward the both sides of the screen.
ZOOM: Pictures are enlarged on the screen so that no black bars will
be shown on the screen. (The entire picture cannot be shown
on the screen.)
Inst_KS-JA0502-4[U].indb 16Inst_KS-JA0502-4[U].indb 16 09.11.10 3:30:24 PM09.11.10 3:30:24 PM

17
Playable discs
Caution for DualDisc playback
• The Non-DVD side of a “DualDisc” does
not comply with the “Compact Disc Digital
Audio” standard. Therefore, the use of Non-
DVD side of a DualDisc on this product may
not be recommended.
*1Manufactured under license from Dolby
Laboratories. “Dolby” and the double-
D symbol are trademarks of Dolby
Laboratories.
*2A hybrid file system used to provide
compatibility with ISO 9660 for accessing
any type of files on the disc. (UDF stands for
Universal Disk Format.)
• “DVD Logo” is a trademark of DVD Format/
Logo Licensing Corporation registered in the
US, Japan and other countries.
• DivX, DivX Ultra Certified, and associated
logos are trademarks of DivX, Inc. and are
used under license.
• Official DivX®Ultra Certified product
• Plays all versions of DivX®video (including
DivX®6) with enhanced playback of DivX®
media files and the DivX®Media Format
• Microsoft and Windows Media are either
registered trademarks or trademarks of
Microsoft Corporation in the United States
and/or other countries.
Discs you can play
You can play back the following discs on the
built-in DVD player:
• DVD Video: Linear PCM, Dolby Digital*1,
and MPEG Audio disc of the Region Code
“2” (see below). (DTS sound cannot be
reproduced.)
– PAL video signals on a disc are converted
to NTSC video signals.
– DVD-R/DVD-RW/+R/+RW recorded in the
DVD Video format can also be played (see
page 33).
• Video CD (VCD)/Audio CD
• MP3/WMA/WAV/JPEG/MPEG-1/
MPEG-2/DivX: Recorded on CD-R/CD-RW
or DVD-R/DVD-RW/+R/+RW/DVD-ROM.
– CD-R/CD-RW: Compliant with ISO 9660
Level 1, ISO 9660 Level 2, Romeo, and
Joliet.
– DVD-R/DVD-RW/+R/+RW/DVD-ROM:
Compliant with UDF-Bridge Format*2.
On some discs, the actual operations may be
different from what is explained in this manual.
Discs cannot be played back
DVD-Audio, DVD-ROM (data), DVD-RAM,
DVD-R/DVD-RW recorded in the DVD-VR
format, CD-ROM, CD-I (CD-I Ready), Photo
CD, etc.
• Playing back these discs will generate noise
and damage the speakers.
Note on Region Code:
DVD players and DVD Video discs have their
own Region Code numbers.
• South East Asia, Hong Kong region: 3
• Australia: 4
• India: 5
If you insert a DVD Video disc of an incorrect Region Code
“REGION CODE ERROR” appears on the screen. The disc will eject automatically.
Examples:
Inst_KS-JA0502-4[U].indb 17Inst_KS-JA0502-4[U].indb 17 09.11.10 3:30:24 PM09.11.10 3:30:24 PM

18
The disc type is automatically detected, and
playback starts automatically (for DVD:
automatic start depends on its internal program).
• This unit can play back either audio (MP3/
WMA/WAV), picture (JPEG), or movie
(MPEG-1/MPEG-2/DivX) files if a disc
includes any of the files. Set the playback
file type on DVD setup menu (see page 28)
before playing back a disc containing files of
different kinds.
If the current disc is not a DVD and VCD with
PBC, all tracks will be played repeatedly until
you change the source or eject the disc.
• If a title list or disc menu appears after
inserting a disc, see “Disc menu operations”
on page 23.
The following marks are used to indicate
the playable discs.
DVD Video Video CD with PBC
Video CD with/
without PBC
Audio CD/
CD Text
MP3/WMA/WAV
disc
JPEG disc
DivX disc MPEG-1/MPEG-2
disc
All discs listed here
• Disc operations are explained mainly
using the buttons on the remote controller;
however, the buttons on the unit can work in
the same way if they have the same names or
marks.
Starting playback
1Open the liquid crystal panel.
• You can play a disc even if the monitor is
closed.
2Turn on the power.
• Do not insert a disc while
the power is turned off.
Monitor only
3Insert a disc into the loading slot.
• For some discs, playback does not start
automatically.
If playback does not start...
Disc operations
Playing a disc
If “ ” appears on the monitor when
pressing a button, the disc cannot accept an
operation you have tried to do.
• In some cases, without showing “ ,”
operations will not be accepted.
Playback (shining) side
facing down
Remote controllerMonitor
Inst_KS-JA0502-4[U].indb 18Inst_KS-JA0502-4[U].indb 18 09.11.10 3:30:25 PM09.11.10 3:30:25 PM

19
Operations Next operation
To stop playback
temporarily
Monitor
Remote controller
Playback pauses.
A still picture appears.
AFrame by frame playback
Remote controller only
BSlow motion playback
Remote controller only
To resume normal play:
To replay the previous
scenes—One Touch Replay
Remote controller only
The playback position moves back about 10 seconds before
the current position.
• This function works only within the same title.
• For some DVDs, this function does not work.
To stop playback
Remote controller only
When you start playback again, playback starts from
where it has been stopped (Resume play).
• During playback, on-screen guide icons appear on the monitor for a while (see page 36).
To eject the disc
Basic operations
Continued on the next page...
Remote controllerMonitor
Monitor only
Inst_KS-JA0502-4[U].indb 19Inst_KS-JA0502-4[U].indb 19 09.11.10 3:30:25 PM09.11.10 3:30:25 PM

20
To forward or
reverse search the
chapter/track
* The search speed of MPEG-1/MPEG-2/DivX
is 3 steps — ¡(1) 1/2/3.
• To resume normal speed
Monitor Remote controller
To locate a particular title/
chapter/track directly
• For DVD:
During playback or pause—select a chapter.
During stop—select a title.
• For VCD:
While PBC (see page 23) is not in use.
• For MP3/WMA/WAV/JPEG/MPEG-1/
MPEG-2:
Select a track within the same folder.
Select the number corresponding to the item
you want (see page 9).
To go to the next or previous
chapters/tracks
• For DVD: During playback or pause
To the following
chapters/tracks.
To go back to the beginning of the current
chapter/track, then the previous chapters/
tracks.
To fast-forward or
reverse the chapter/
track
Fast-forwards.
Reverses.
* The search speed changes to x2 ]x10 (¡
(1) 1/2 for MPEG-1/MPEG-2/DivX), but
the information is shown on the monitor only
when playing back DVD/VCD/MPEG-1/
MPEG-2/DivX.
Inst_KS-JA0502-4[U].indb 20Inst_KS-JA0502-4[U].indb 20 09.11.10 3:30:26 PM09.11.10 3:30:26 PM
