SERVICE MANUAL
COPYRIGHT © 2006 Victor Company of Japan, Limited No.YD090
2006/1
HDD & DVD VIDEO RECORDER
YD09020061
DR-MH300SAA
TABLE OF CONTENTS
1 PRECAUTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
2 SPECIFIC SERVICE INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
3 DISASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
4 ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
5 TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
Since the whole mechanism assembly unit is replaced, the DVD recorder mechanism of this unit
need not be adjusted.
DR-MH300SAA [D5HR10]
Area Suffix
AA ----------------- Australia
STANDBY/ON
PR
HDD DVD
RAM/RW
ENTER NAVIGATION PROG
PR
PUSH-OPEN
This service manual is a service manual of a model in which destination added to the issued service
manual DR-MH300BE/EK, DR-MH300SE/EF/EK/ER, DR-ED400SE (issue number: YD089 2005/12).
This service manual consists of only "Parts List", "Schematic diagrams" and "Instruction Book".
Regarding service information other than these sections, refer to the service manual DR-MH300BE/EK,
DR-MH300SE/EF/EK/ER, DR-ED400SE (issue number: YD089 2005/12).

1-2 (No.YD090)
SPECIFICATION
E.& O.E. Design and specifications subject to change without notice.
• Manufactured under license from Dolby Laboratories. “Dolby” and the double-D symbol are trademarks of Dolby Laboratories.
• “DTS” and “DTS DIGITAL OUT” are trademarks of Digital Theater Systems, Inc.
• This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property rights. Use of this copyright
protection technology must be authorized by Macrovision. Reverse engineering or disassembly is prohibited.
• G-CODE is a registered trademark of Gemstar Development Corporation. The G-CODE system is manufactured under license from Gemstar De-
velopment Corporation.
• i-LINK is a trademark of Sony Corp .
DR-MH300SAA
GENERAL
Power requirement AC 110 V - 240 V~, 50 Hz/60 Hz
Power consumption Power on : 36 W
Power off : 6.4 W
Temperature Operating : 5°C to 35°C
Storage : -20°C to 60°C
Operating position Horizontal only
Dimensions (W ×H ×D) 435 mm ×70 mm ×300 mm
Weight 4.5 kg
VIDEO/AUDIO (DVD Deck)
Recordable disc DVD-RAM 12 cm (4.7 GB/9.4 GB*1),DVD-RAM 8 cm (1.4 GB/2.8 GB*2),DVD-R 12 cm (4.7 GB),DVD-R 8 cm
(1.4 GB),DVD-RW 12 cm (4.7 GB),DVD-RW 8 cm (1.4 GB)
*1 9.4 GB double-sided discs
*2 2.8 GB double-sided discs
Recording format DVD-RAM : DVD Video Recording format
DVD-R : DVD Video format, DVD Video Recording format
DVD-RW : DVD Video format, DVD Video Recording format
Recording time Maximum 8 hours (with 4.7 GB disc)
(XP) : Approx. 1 hour, (SP) : Approx. 2 hours, (LP) : Approx. 4 hours, (EP) : Approx. 6 hours, (FR) : Approx.
1 hour - 8 hours
Audio recording system Dolby Digital (2 ch)
Linear PCM (XP mode only)
Video recording compression system MPEG2 (CBR/VBR)
VIDEO/AUDIO (HDD Deck)
Capacity 160 GB
Recording time (DV) : Approx. 11 hours,(XP) : Approx. 34 hours,(SP) : Approx. 69 hours,(LP) : Approx. 138 hours,
(EP) : Approx. 209 hours,(FR480) : Approx. 300 hours
Audio recording system Dolby Digital (2 ch)
Linear PCM (XP mode only)
Video recording compression system MPEG2 (VBR)
Input/Output
21-pin SCART connectors IN/OUT X 1, IN/DECODER X 1
S-video input Y:1.0 Vp-p,75 ohms
C : 0.3Vp-p, 75 ohms
Video input 1.0 Vp-p, 75 ohms (pin jack)
Audio input 2 Vrms (pin jack)
i.Link 4-pin for DV Input/Output
Component video output Y : 1.0 Vp-p, 75 ohms
PB/PR: 0.7 Vp-p, 75 ohms
Corresponding to copy protection
Digital audio output Coaxial
Corresponding to Dolby Digital and DTS Digital Surround,
Bit stream
Selectable in digital audio output setting menu
TUNER/TIMER
Tuning system Frequency synthesised tuner
Signal system PAL/SECAM colour signal, 625 lines/50 fields
TV channel storage capacity 99 positions (+AUX position)
Channel coverage VHF : 44 MHz - 89 MHz/
104 MHz - 300 MHz/
302 MHz - 470 MHz
UHF : 470MHz - 862MHz
Memory backup time Approx. 10 minutes.

(No.YD090)1-3
SECTION 1
PRECAUTION
1.1 Safety Precautions
(1) This design of this product contains special hardware and
many circuits and components specially for safety purpos-
es. For continued protection, no changes should be made
to the original design unless authorized in writing by the
manufacturer. Replacement parts must be identical to
those used in the original circuits. Services should be per-
formed by qualified personnel only.
(2) Alterations of the design or circuitry of the product should
not be made. Any design alterations of the product should
not be made. Any design alterations or additions will void
the manufacturers warranty and will further relieve the
manufacture of responsibility for personal injury or property
damage resulting therefrom.
(3) Many electrical and mechanical parts in the products have
special safety-related characteristics. These characteris-
tics are often not evident from visual inspection nor can the
protection afforded by them necessarily be obtained by us-
ing replacement components rated for higher voltage, watt-
age, etc. Replacement parts which have these special
safety characteristics are identified in the Parts List of Ser-
vice Manual. Electrical components having such features
are identified by shading on the schematics and by ( ) on
the Parts List in the Service Manual. The use of a substitute
replacement which does not have the same safety charac-
teristics as the recommended replacement parts shown in
the Parts List of Service Manual may create shock, fire, or
other hazards.
(4) The leads in the products are routed and dressed with ties,
clamps, tubings, barriers and the like to be separated from
live parts, high temperature parts, moving parts and/or
sharp edges for the prevention of electric shock and fire
hazard. When service is required, the original lead routing
and dress should be observed, and it should be confirmed
that they have been returned to normal, after reassem-
bling.
(5) Leakage shock hazard testing
After reassembling the product, always perform an isola-
tion check on the exposed metal parts of the product (an-
tenna terminals, knobs, metal cabinet, screw heads,
headphone jack, control shafts, etc.) to be sure the product
is safe to operate without danger of electrical shock.Do not
use a line isolation transformer during this check.
• Plug the AC line cord directly into the AC outlet. Using a
"Leakage Current Tester", measure the leakage current
from each exposed metal parts of the cabinet, particular-
ly any exposed metal part having a return path to the
chassis, to a known good earth ground. Any leakage cur-
rent must not exceed 0.5mA AC (r.m.s.).
• Alternate check method
Plug the AC line cord directly into the AC outlet. Use an
AC voltmeter having, 1,000Ωper volt or more sensitivity
in the following manner. Connect a 1,500Ω10W resistor
paralleled by a 0.15µF AC-type capacitor between an ex-
posed metal part and a known good earth ground.
Measure the AC voltage across the resistor with the AC
voltmeter.
Move the resistor connection to each exposed metal
part, particularly any exposed metal part having a return
path to the chassis, and measure the AC voltage across
the resistor. Now, reverse the plug in the AC outlet and
repeat each measurement. Voltage measured any must
not exceed 0.75 V AC (r.m.s.). This corresponds to 0.5
mA AC (r.m.s.).
1.2 Warning
(1) This equipment has been designed and manufactured to
meet international safety standards.
(2) It is the legal responsibility of the repairer to ensure that
these safety standards are maintained.
(3) Repairs must be made in accordance with the relevant
safety standards.
(4) It is essential that safety critical components are replaced
by approved parts.
(5) If mains voltage selector is provided, check setting for local
voltage.
1.3 Caution
Burrs formed during molding may be left over on some parts
of the chassis.
Therefore, pay attention to such burrs in the case of pre-
forming repair of this system.
1.4 Critical parts for safety
In regard with component parts appearing on the silk-screen
printed side (parts side) of the PWB diagrams, the parts that are
printed over with black such as the resistor ( ), diode ( )
and ICP ( ) or identified by the " " mark nearby are critical
for safety. When replacing them, be sure to use the parts of the
same type and rating as specified by the manufacturer.
(This regulation dose not Except the J and C version)
Good earth ground
Place this
probe on
each exposed
metal part.
AC VOLTMETER
(Having 1000
ohms/volts,
or more sensitivity)
1500 10W
0.15 F AC TYPE

1-4 (No.YD090)
1.5 Important for laser products
1.CLASS 1 LASER PRODUCT
2.DANGER : Invisible laser radiation when open and inter
lock failed or defeated. Avoid direct exposure to beam.
3.CAUTION : There are no serviceable parts inside the
Laser Unit. Do not disassemble the Laser Unit. Replace
the complete Laser Unit if it malfunctions.
4.CAUTION : The CD,MD and DVD player uses invisible
laser radiation and is equipped with safety switches which
prevent emission of radiation when the drawer is open and
the safety interlocks have failed or are defeated. It is
dangerous to defeat the safety switches.
5.CAUTION : If safety switches malfunction, the laser is able
to function.
6.CAUTION : Use of controls, adjustments or performance of
procedures other than those specified here in may result in
hazardous radiation exposure.
!
Please use enough caution not to
see the beam directly or touch it
in case of an adjustment or operation
check.
REPRODUCTION AND POSITION OF LABEL
On mechaism assembly
The photograph might be
different from the actual thing.
OR

(No.YD090)1-5
1.6 Hard Disk Drive (HDD) Handling Precautions
The HDD is a precision device for use in reading and writing a large amount of data on or from a disk rotating at a high speed. If it is
not handled carefully, either abnormal operation may result or it may not be possible to read data. The HDD is sensitive to the following
items and special care is required in safeguarding against them when handling an HDD. Also take care in handling a set incorporating
an HDD.
(1) Vibrations and impacts
(2) Static electricity
(3) Rough handling
1.6.1 Handling in transport, etc.
• Be sure to place the HDD in the manufacturer's specified pack-
age carton before transport.
• When receiving a package containing an HDD, check that the
package carton is not damaged (such as having holes in the
carton, crushed corners, etc.).
• Do not impact the packaging carton when loading or unloading
it.
• It is not permitted to use the inner package carton only for
transporting an HDD.
• Do not stack package cartons one upon another.
1.6.2 Handling an HDD in the stand-alone status
• When handling an HDD on a hard workbench, place an anti-
static mat (rubber sheet) or similar object on the hard surface
(to prevent any impacts occurring between the HDD and
bench).
• Do not stack the HDDs one upon another.
• Do not knock an HDD with a hard object (such as a screwdriv-
er).
• Do not place an HDD on its side panel without using a support
(do not place an HDD in an unstable position).
1.6.3 Handling the installation of an HDD
• Place antistatic mats or similar sheets on all of the surfaces on which work is conducted or when the HDD is transported.
• Do not permit the HDD to knock against the set's brackets.
• When screwing the brackets, be careful not to knock the HDD. When using a power screwdriver, use a low-shock model and arrange
the tightening torque properly.
• When mounting an HDD in a main body, take care not to apply excessive force to the brackets.
HDD
Do not throw or
drop packages.
Be sure to package and
transport the HDDs correctly.

1-6 (No.YD090)
SECTION 2
SPECIFIC SERVICE INSTRUCTIONS
This service manual does not describe SPECIFIC SERVICE INSTRUCTIONS.
SECTION 3
DISASSEMBLY
Please refer to "DR-MH300BE, DR-MH300BEK, DR-MH300SE, DR-MH300SEF,
DR-MH300SEK,DR-MH300SER, DR-ED400SE (issue number : YD089 2005/12)"
about this section.
SECTION 4
ADJUSTMENT
Please refer to "DR-MH300BE, DR-MH300BEK, DR-MH300SE, DR-MH300SEF,
DR-MH300SEK,DR-MH300SER, DR-ED400SE (issue number : YD089 2005/12)"
about this section.
SECTION 5
TROUBLESHOOTING
Please refer to "DR-MH300BE, DR-MH300BEK, DR-MH300SE, DR-MH300SEF,
DR-MH300SEK,DR-MH300SER, DR-ED400SE (issue number : YD089 2005/12)"
about this section.

(No.YD090)1-7

(No.YD090)
DIGITAL VIDEO STORAGE CATEGORY 12, 3-chome, Moriya-cho, kanagawa-ku, Yokohama, kanagawa-prefecture, 221-8528, Japan
Victor Company of Japan, Limited
VPT
Printed in Japan

SCHEMATIC DIAGRAMS
HDD & DVD VIDEO RECORDER
No.YD090SCH
2006/1
COPYRIGHT 2006 Victor Company of Japan, Limited
DR-MH300SAA
CD-ROM No.SML200601
Since the whole mechanism assembly unit is replaced, the DVD recorder mechanism of this unit
need not be adjusted.
DR-MH300SAA [D5HR10]
Area Suffix
AA ----------------- Australia
STANDBY/ON
PR
HDD DVD
RAM/RW
ENTER NAVIGATION PROG
PR
PUSH-OPEN
This service manual is a service manual of a model in which destination added to the issued service
manual DR-MH300BE/EK, DR-MH300SE/EF/EK/ER, DR-ED400SE (issue number: YD089 2005/12).
This service manual consists of only "Parts List", "Schematic diagrams" and "Instruction Book".
Regarding service information other than these sections, refer to the service manual DR-MH300BE/EK,
DR-MH300SE/EF/EK/ER, DR-ED400SE (issue number: YD089 2005/12).

!
CHARTS AND DIAGRAMS
NOTES OF SCHEMATIC DIAGRAM
Safety precautions
The Components indentified by the symbol are
critical for safety. For continued safety, replace safety
critical components only with manufacturer's recom-
mended parts.
1. Units of components on the schematic diagram
Unless otherwise specified.
1) All resistance values are in ohm. 1/6 W, 1/8 W (refer to
parts list).
Chip resistors are 1/16 W.
K: KΩ(1000Ω), M: MΩ(1000KΩ)
2) All capacitance values are in µF, (P: PF).
3) All inductance values are in µH, (m: mH).
4) All diodes are 1SS133, MA165 or 1N4148M (refer to parts
list).
2. Indications of control voltage
AUX : Active at high.
AUX or AUX(L) : Active at low.
3. Interpreting Connector indications
Note: If the voltages are not indicated on the schematic
diagram, refer to the voltage charts.
12 3
2.5
(5.0) 1.8
PB and REC modes
(Voltage of PB and REC modes
are the same)
PB mode
REC mode
4. Voltage measurement
1) Regulator (DC/DC CONV) circuits
REC : Colour bar signal.
PB : Alignment tape (Colour bar).
— : Unmeasurable or unnecessary to measure.
2) Indication on schematic diagram
Voltage indications for REC and PB mode on the sche-
matic diagram are as shown below.
6. Indication of the parts for adjustments
The parts for the adjustments are surrounded with the circle
as shown below.
7. Indication of the parts not mounted on the circuit board
“OPEN” is indicated by the parts not mounted on the circuit
board.
R216
OPEN
1
2
3
1
2
3
1
2
3
1
4
2
3
Removable connector
Wire soldered directly on board
Non-removable Board connector
Board to Board
Connected pattern on board
The arrows indicate signal path
Note: The Parts Number, value and rated voltage etc. in
the Schematic Diagram are for references only.
When replacing the parts, refer to the Parts List.
CIRCUIT BOARD NOTES
1. Foil and Component sides
1) Foil side (B side) :
Parts on the foil side seen from foil face (pattern face)
are indicated.
2) Component side (A side) :
Parts on the component side seen from component face
(parts face) indicated.
2. Parts location guides
Parts location are indicated by guide scale on the circuit board.
Parts location are indicated by guide scale on the circuit board.
LOCATION
REF No.
IC101 B C 6 A
IC Category : IC
Horizontal “A” zone
Vertical “6” zone
B : Foil side
(A : Component side)
C : Chip component
D : Discrete component)
2-1 2-2

A
1
2
3
4
5
BCDEFG
CN1202
CN2401
CN1402
CN5303 CN5001
Wiring diagram
p10727001a_rev1
2-3 2-4

A
1
2
3
4
5
BCD EFG
Audio signal control section (SHEET 3)
OP.AMP.
IC8202
24bit
A/D converter
IC8001
ACD_RST[L]
I2C_CLK2
I2C_DATA2
A_MUTE1[H]
TU_AUDIO[L/R]
AOUTL AOUTR
AI_D[0] AI_SCLK AI_MCLK0 AI_FSYNC
A_MUTE2[H]
AUDIO_OUT1[L/R]
LINE_OUT[L/R]
AUDIO_IN2[L/R]
DEC_OUT[L/R]
AUDIO_IN1[L/R]
AV2_HAV1_L
DAC_SDA DAC_SCL A_DAC_CS DAC_RST[L]
AO_D[0] AO_SCLK AO_FSYNC AO_MCLKO
TO
SHEET 7
TO SHEET 8
TO SHEET 8
TO SHEET 8
TO SHEET 5
TO SHEET 8
TO SHEET 5
AO_IEC958
J8501
TO CN4402
SHEET 17
TO CN7102
SHEET 10
Video controller
IC4001
SYNC_DET
I2C_DATA2 I2C_CLK2 PD[L]
REAR2_RC_IN
REAR2_Y_IN
REAR1_C_IN
REAR1_V_IN
REAR1_Y_IN
YTODIGI CTODIGI
CN3001
TO CN7001
SHEET 10
I2C_DATA2 I2C_CLK2 SYNC_DET PD[L] RGB_IN[H]
STB RC_IN S_CLK
S_DATA_TOSYS LED_OUT
S_DATA_FRSYS
ADC_RST[L] A_MUTE1[H] I2C_CLK2 I2C_DATA2 AV1_L AV2_H
HDD_P_CTL[H] DVD_P_CTL[H] FAN_CTL P.CTL[H] P.SAVE[L]
G_TX IRTX G_RX K_BUS_OUT K_BUS_IN K_BUS_CLK
K_BUS_REQ SYS_RESET P.CTL[H]
System controller
IC3001
SCR_ID 4_3[L] TV[L] RGB_TH[H] AV1_YC_IN[H] BIAS/RGB_CTL AV1_L AV2_H
P_MUTE[H] RAPID_SW V_MUTE[L] P50_I/O YC_MIX[L] RAPID_IN
TU_V_MUTE[H] TU_DATA TU_CLK AFC SW_1 SW_2 RF_AGC
System controller section (SHEET 6)
Muting
Q6030
TO SHEET 3
TO CN6701
SHEET 9
Tuner section (SHEET 7)
Tuner
TU6001 DEMOD[L/R]
TU_VIDEO
TU_VIDEO
FRONT_VIDEO FRONT_Y_IN FRONT_C_IN
F_AUDIO[L/R]
VIDEO_OUT
COMP SIF
TU_V_MUTE[H]
AFC
RF_AGC
SW_1 SW_2
TU_DATA TU_CLK
MAIN 0 3
Muting
Q8203,Q8205
IC8501 COAXIAL OUT
Audio/Video signal input control section (SHEET 4)
CN4001CN4401
2chDA converter
IC8201
TO
SHEET 1
TO
SHEET 8
Block diagrams
AV Switch
IC8301
OP.AMP.
IC8303
Video switch
IC4202
VPS/PDC Slicer
IC4201
AV Switch
IC8302
REAR2_Y_IN
REAR2_RC_IN
REAR2_B_IN
REAR2_G_IN
FSC2
H_OUT
V_OUT
SYNC
SYNIN
RGB_IN[H]
C_FROM_RGB
Y_FROM_RGB
Input/output terminal section
(SHEET 5)
J7301
J7302
J7304
AUDIO OUT
4_3[L] P50_I/O AV_YC_IN[H] TV[L]
PB/B_OUT PR/R_OUT
PY/G_OUT V/Y_OUT
Q7310 to
Q7312
Video driver
IC7301
SWITCH
IC7303 IC7304
TO
SHEET 3
REAR2_RC_IN REAR2_G_IN
REAR2_B_IN REAR2_Y_IN
AV2_H RGB_TH[H]
VMUTE[L] YC_MIX[L]
SCOUT SYOUT
SCR_ID
AV1_L
REAR1_V_IN
R
G
B
V_OUT
DEC_OUT[L/R] AUDIO_IN2[L/R]
LINE_OUT[L/R]
AUDIO_IN1[L/R]
R
G
B
V_OUT
AUDIO_OUT1[L/R]
L-1 SCART Terminal
L-2 SCART Terminal
RAPID_SW BIAS/RGB_CTL
REAR1_C_IN REAR1_Y_IN
COMPONENT
VIDEO OUT
J7309
SWITCH
IC7302
CN6701
2-5 2-6

A
1
2
3
4
5
BCDEFG
DDR_DQ0 to 15
DDR SDRAM
IC1602 IC1604
DDR-SDRAM Section (SHEET 12)
IEEE1394 Section (SHEET 11)
IEEE1394
terminal
IEEE1394
controller
IC1801
TPA+ TPA- TPB+ TPB-
PHY_RESET[L]
PHY_LREQ PHY_CLK
PHY_CNA PHY_CTL[0],[1]
PHY_DATA[0-7] PHY_LPS
PHY_LINK_ON
DDR SDRAM
IC1601 IC1603
RA1613 to
RA1616
RA1609 to
RA1612
RA1625 to
RA1628
R1613 to
R1616
R1653 to R1660
RA1633
DDR_DQ16 to 31SDRAM_DQ16 to 31
SDRAM_A_17
SDRAM_DQ0 to 15
SDRAM_A0 to 16
SDRAM_CKE
SDRAM_RAS_L
SDRAM_CAS_L
SDRAM_WE_L
SDRAM_DQM0 to 3
SDRAM_DQS0 to 3
SDRAM_CLK0,1
SDRAM_CLK_L0,1
DDR_CLK0,1
DDR_CLK_L0,1
DDR_DQM0 to 3
DDR_DQS0 to 3
DDR_CKE
DDR_RAS_L
DDR_CAS_L
DDR_WE_L
DDR_BA0,1
DDR_A0 to 12
CN4204
J4212
CN1801
Media processor section (SHEET 13)
Media
processor
IC1401
ATA_DMAACK[L] ATA_INTRQ ATA_ADD0 to 4 ATA_DIOR[L]
ATA_DIOW[L] ATA_IORDY ATA_DAT0 to 15 ATA_RESET
ATA_DMARQ ATA2_DMAACK[L] ATA2_INTRQ ATA2_ADD0 to 4
ATA2_DIOR[L] ATA2_DIOW[L] ATA2_IORDY ATA2_DAT0 to 15
ATA2_RESET ATA2_DMARQ
RD/WR[L] ALE OE[L]/LDS[L] MADD1 to 22 CS0 to 3 SYS_RESET[L]
UWE[L]/UDS[L] EPG_INT[L]
VI_D2 to D9 VIDEO_27M AI_SCLK AI_FSYNC AI_MCLK AI_D[0]
VIDEO_MUTE[H] EPG_V_SEL E5_CVBS_OUT E5_SY_OUT
E5_SC_OUT E5_Y_OUT E5_PB_OUT E5_PR_OUT VIDEO_RST[L]
DAC_RST[L] SPI_CLK K_BUS_CLK K_BUS_REQ SYS_RESET[L]
K_BUS_OUT K_BUS_IN A_MUTE2[H] A_DAC_CS VIDEO_CS
VIDEO_RXD SPI_MOSI
TO DRIVE UNIT
TO HDD
ATAPI Interface section (SHEET 15)
CN2201 CN2101
DIGITAL 5 0
SYS_RESET[L] P_CTL[H] A_MUTE[H]
K_BUS_CLK K_BUS_REQ K_BUS_IN K_BUS_OUT
AI_MCLK AI_FSYNC AI_D[0] DAC_SDA DAC_SCL A_DAC_CS DAC_RST[L]
AO_FSYNC AO_D[0] AO_SCLK AO_MCLK AO_IEC958
P_MUTE[H] Y_OUT C_OUT C/R_OUT Pr/G_OUT
Y/V_OUT Pb/B_OUT C_IN/R_IN YV_IN
TO CN4101
SHEET 8
TO CN4102
SHEET 8
TO CN4103
SHEET 8
Video interface section (SHEET 14)
Video
decoder
IC1001 16M SDRAM
IC1002
CN1101CN1102CN1103
ALE MADD6 to 21
64Mbit Flash
IC1201
EPG
IC1301
MADD1 to 22
IC1202
IC1203
FLASH-ROM/EPG Section (SHEET 16)
RD/WR[L] SYS_RESET[L] OE[L]/LDS[L] CS[0]
CS_3 SYS_RESET[L] EPG_INT[L]
UWE[L]/UDS[L] OE[L]/LDS[L]
LH_AR6 to 21
MADD1 to 4
MADD6 to 13
2-7 2-8

A
1
2
3
4
5
BCD EFG
FL Display section (SHEET 10)
Power switch section (SHEET 10)
Operation switch section (SHEET 10)
CN7001
FL Display driver
IC7001
Remote controller
IC7101
TO CN3001
SHEET 6
Operation switch
S7101 to S7104
DVD/HDD LED
D7103 D7104
LIGHTING
D7106
RC-IN
KEY1,KEY2
KEY1 KEY2 S1 S2
LED1 LED2
STB S_DATA_FRSYS
S_DATA_TOSYS S_CLK
FL Display
DI7001
G1 to G10
S1 to S18
BLUE_LED
LIGHTING
D7111
BLUE_LED
Operation switch
S7111 to S7115
S7131 to S7135
KEY1,KEY2
FRONT_C/Y_IN
Front S-video IN
Front A/V IN
J7002
J7001
FRONT_VIDEO_IN
FRONT_A[L/R]_IN
CN7101 CN7102
TO CN4001
SHEET 4
DISPLAY 2 8
OPERATION 2 6
SW/JACK 2 7
CN7002
CN7003
CN7103
Junction section (SHEET 8)
YTODIGI CTODIGI SYNC_DET1
PB/B_OUT PY/G_OUT PR/R_OUT V/Y_OUT SC_OUT SY_OUT
A_MUTE2[H]
P.CTL[H] SYS_RESET[L] HDD_P.CTL[H] P_MUTE[H] G_RX
IRTX G_TX
AO_IEC958 AO_MCLKO AO_SCLK AO_D[0] AO_FSYNC
DAC_RST[L] A_DAC_CS DAC_SCL DAC_SDA AI_D[0] AI_SCLK
AI_FSYNC AI_MCLKO
K_BUS_OUT K_BUS_IN K_BUS_REQ K_BUS_CLK
MAIN 0 3
TO CN1103
SHEET 14
TO SHEET 4
TO SHEET 5
TO SHEET 3
TO SHEET 6
TO CN1102
SHEET 14
TO CN1101
SHEET 14
CN4103CN4102 CN4101
Demodulator section (SHEET 9)
Demodulator
IC6701
I2C_DATA I2C_CLK DEMOD[L/R]
COMP SIF
DEMOD 1 4
TO CN6701
SHEET 7
CN6701
RGB-Y/C Converter section (SHEET 17)
IC4403
2IN-1OUT Switch
IC4402
Video AMP.
IC4404
H_OUT
V_OUT
YOUT
R_IN
G_IN
B_IN
Y_FROM_RGB
REAR2_Y_IN
C_FROM_RGB
SYNC
FSC2
REAR2_RC_IN
REAR2_G_IN
REAR2_B_IN
TO CN4401
SHEET 4
RGB_YC 6 8
RGB-Y/C Converter
IC4401
CN4402
2-9 2-10

A
1
2
3
4
5
BCDEFG
Power
transformer
T5001
Power supply section (SHEET 1)
AC IN
CN5303 CN5301 CN5304
TO Fan assembly
TO SHEET 10
TO each sheet
TO SHEET 6
TO DRIVE UNIT
TO HDD
TO each sheet
5V REG.
IC5303
DV5V REG.
IC5308
AC-DC
D5001
Switching
regurator
IC5101
-29V DC3.9V[+/-]
SW-12V SW12V SW5V AL5.8V D1.8V D2.5V
FAN_CTL P.CTL[H]
D5V
DV5V
DV12V
HD12V
6V D2.5V D1.8V
P.SAVE[L]
DVD_P.CTL[H]
MAIN 0 3
HD5V REG.
IC5302
DC/DC Converter section (SHEET 2)
CN5702CN5701
DC/DC CONV 0 2
Switching
Q5720 2ch FET Driver
IC5701
Switching
IC5710
STB
OUT1
OUT2
CN5305
2-11 2-12

A
1
2
3
4
5
BCD EFG
T5001
R5307
D5203
C5002
D5210
D5104
R5305
D5001
D5201 Q5301
CN5305
D5318
C5209
C5306
R5301
R5303
L5203
R5306
C5104
R5109
C5302
C5301
C5311
C5309
C5001
IC5301
L5204
R5304
R5337
R5332
Q5306
R5324
R5311
D5202
Q5305
R5103
D5101
D5208
C5208
R5107
R5336
D5320
C5202
D5301
Q5310
C5102
PC5101
Q5303
LF5001
C5003
R5108
C5105
R5106
C5103
R5105
D5103
R5101
B5502
Q5302
C5317
B5501
CP5301
IC5304IC5306
R5302
C5101
Q5309
C5331
IC5311
C5333 C5349C5335
R5320
R5310
D5209
Q5307
D5214
L5206
R5334
C5201
R5319
C5004
Q5308
D5302
R5333
D5303
Q5316
C5350
F5001
CN5001
C5324
D5205
C5348
D5309
CN5303
IC5303
D5207
C5310
D5206
R5308
C5312
C5205
C5207
R5313
L5205
Q5304
R5312
R5343
C5346
C5323
C5345
IC5310
C5308
L5202
Q5313
R5335R5309
C5334
P.CTL[H]
D5316
C5330
C5305
R5329
C5106
IC5101
L5201
C5328 C5329
C5343
IC5302
C5307
D5204
C5204
C5347
C5303
R5318
C5203
D5315
B5301
DC3.9V[+]
D5211
C5325
Q5314
SW3.3V
IC5308
R5344
C5316
CP5302
D5319
R5321
R5323
R5322
SW2.5V
C5313
C5314
C5304
C5321
C5315
C5320
CN5304
C5322
C5318
C5319
C5342
R5328
C5327
B5503
D5314
D5213
C5336
CN5301
C5210
Q5311
D5215
Q5312
DC3.9V[-]
-29V
D5323
D5310
R5341
D5322
C5206
SW-12V
D5321
SW12V
C5351
D5212
D5V
SW5V
AL5.8V
GND
D5105
D5106 R5102
R5104C5107
3.3V
B5504
B5506
BT2
45V
D1.8V
D2.5V
FAN_CTL
P.SAVE[L]
HDD_P.CTL[H]
DVD_P.CTL[H]
Q5315
C5326
IC5307
C5005
B5505
C5339
C5341
C5332
C5340
D5307
C5344
D5308
D5311
D5312
D5313
CN5302
IC5309
D5304
D5305 D5306
R5315
R5314

Standard schematic diagrams
Power supply section
DANGEROUS VOLTAGE
p20494001a_rev0
SHEET 1
TO SHEET 10
To each sheet
TO FAN UNIT
TO DRIVE UNIT
TO HDD
Not use
TO CN5701,CN5702
SHEET 2
To each sheet
Parts are safety assurance parts.
When replacing those parts make
sure to use the specified one.
2-13 2-14

A
1
2
3
4
5
BCDEFG
Q5720
R5730
C5731
R5731
R5732
C5730
C5710 R5710
D5710
R5711
R5713 C5716
C5712
IC5710
C5714 C5715
L5710 K5710
C5720R5720D5720
R5721
CN5701
L5720K5720
C5724C5725
C5726 R5723
C5722
IC5701
CN5702
C5732 C5711
R5712
D5721
C5713
C5721
R5722 C5723
DC/DC Converter section
p30133001a_rev0
SHEET 2
TO CN5305 SHEET 1
2-15 2-16

A
1
2
3
4
5
BCD EFG
Q8201
C8029
R8036
Q8202
3.3V
R8037
D8001
R8302
AI_IEC958
R8301
C8316
C8308
C8302
C8301
R8315
C8307
J8501
R8206
C8306
C8305
C8304
C8303
C8312
C8311
SW5V
B8003
B8011
B8002
B8001
B8012
R8316
R8038
R8205
R8507
R8041
R8040
IC8303
AV1_L
AV2_H
Q8301
Q8302
R8303
R8306
C8022
R8304
IC8202
C8203
R8215
C8206
R8221
R8216
R8307
R8305
R8211
R8212
R8308
R8213
C8215
R8214
R8241
C8204 R8242
IC8201
IC8001
C8024
C8023
C8028
C8027
C8026
C8025
R8031
C8210
C8010
R8032
C8021
C8011
C8012
C8014
R8310
R8019
TU_AUDIO[R]
TU_AUDIO[L]
C8005
R8002R8001
R8233
R8313
IC8301 LINE_OUT[L]
LINE_OUT[R]
R8026
DEC_OUT[L]
C8007
C8008
C8009 R8021
DEC_OUT[R]
I2C_CLK2
I2C_DATA2
ADC_RST[L]
R8323
F_AUDIO[R]
R8325
F_AUDIO[L]
R8013 R8014
AUDIO_IN1[R]
AUDIO_IN1[L]
R8015 R8016
R8321
AUDIO_IN2[R]
R8017
AUDIO_IN2[L]
R8322
IC8302
R8035
D5V
3.3V
GND
R8034
R8201
R8202 R8203 R8204
R8324 A_MUTE2[H]
AO_IEC958
AO_D[0]
AO_SCLK
AO_MCLKO
DAC_SDA
DAC_SCL
A_DAC_CS
DAC_RST[L]
AO_FSYNC
C8202 C8201
R8326
R8222
C8322
R8217
R8218
R8219
R8220
C8207
C8208
C8205
Q8203
R8244
AUDIO_OUT1[R]
C8324 C8323
C8321
C8217
R8249
R8250
Q8205
R8252
AUDIO_OUT1[L]
IC8501
C8501
R8224
R8223
C8211 C8212
C8209
SW-12V
SW12V
R8501
R8234
A_MUTE1[H]
R8007 R8008
C8502
R8022
R8502
R8033
AI_D[0]
R8503
C8503
R8023
R8024
R8020
R8504
C8504
R8505
L8501
R8506
K8501
C8506
C8505
C8315 C8314
C8313
C8318
C8317
R8045 R8044
R8042R8043
AI_SCLK
AI_FSYNC
AI_MCLK0
Audio signal control section
p20496001a_rev0
SHEET 3
TO SHEET 6
TO SHEET 7
TO SHEET 4
TO SHEET 5
TO SHEET 1
TO SHEET 8
TO
SHEET 8
TO
SHEET 6
TO
SHEET 5
2-17 2-18

A
1
2
3
4
5
BCDEFG
REAR1_Y_IN
C4005
YTODIGI
C4030
GND
CN4401
CTODIGI
DTV_Y_OUT
SW5V
DTV_C_OUT
R4015C4045
I2C_DATA2
L4007
C4011
R4311
I2C_CLK2
C4310
IC4301
C4301
C4309
R4309
R4319
R4310
C4319
PD[L]
C4307
R4318
C4306
Q4201
L4005
CN4001
R4216
C4308
F_AUDIO[R]
R4317
D4002
IC4201
D4301
GND
L4301
R4018
C4318
C4304
R4007
C4002
R4304
R4001
C4007 R4006
R4305
Q4302
C4012
F_AUDIO[L]
Q4303
TU_VIDEO
R4306
C4047
C4008
C4006
R4307
R4308
C4305
C4031
C4302
IC4304
R4019
R4021
R4313
WR2
R4314
R4036
R4040
REAR2_RC_IN
R4041
C4204
L4202
L4201
R4204
Q4001
C4036
C4035
REAR2_Y_IN
R4011
C4065
C4034
C4001
X4201
GND
SYNC_DET
I2C_CLK2
I2C_DATA2
R4005
REAR1_C_IN
REAR1_V_IN
SECAM_DET[H]
IC4001
C4033
C4032
REAR2_G_IN
REAR2_B_IN
C4009
R4212
SEPA_IN[H]
SYNC_DET1
R4017
C4003
C4004
R4002
L4003
C4048
IC4202
C4216
C4028
C4029
C4026
C4027
R4003
C4010
D4001
R4004
RGB_IN[H]
C4217 C4218
C4023
R4016C4046
C4019
R4014 R4013
R4215
C4203
R4201
R4202
R4206
R4010
C4020
C4017
R4217
C4210
R4211
C4205
R4009
C4018
C4206
C4201 C4202
R4203
C4209
R4210
C4208 C4207 R4209
C4013
C4024
C4016 C4042
C4021
R4008C4014
C4015
C4050
C4022
C4025
C4044
L4001 L4002
Audio/Video signal input control section
p10763001a_rev0
SHEET 4
TO SHEET 1
TO SHEET 8
TO SHEET 7
TO SHEET 3
TO CN7102
SHEET 10
TO SHEET 6
TO SHEET 6
TO SHEET 8
TO SHEET 6
TO CN4402
SHEET 17
TO SHEET 5
2-19 2-20
