JVC Sirius KT-SR3000 User manual

LVT1466-001A
[J]
INSTRUCTIONS
KT-SR3000
SIRIUS Radio
For Customer Use:
Enter below the Model No. and Serial No.
which are located either on the rear, bot-
tom or side of the cabinet. Retain this
information for future reference.
Model No.
Serial No.
KT_SR3000_Cover_revision.p65 05.8.22, 2:06 PM3

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
2
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
INFORMATION
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
–Reorient or relocate the receiving antenna.
–Increase the separation between the equipment and receiver.
–Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
–Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the Manufacturer for compliance could void the
user’s authority to operate the equipment.
KT_SR3000_02_14.p65 05.8.22, 2:07 PM2

3
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
CONGRATULATIONS!
Your new JVC SIRIUS Radio KT-SR3000, called “JVC Plug & Play (PnP),” lets you enjoy SIRIUS Satellite
Radio’s digital entertainment channels anywhere you’ve installed either KS-K6012 Car Docking Kit or
KS-K6013 Home Docking Kit (sold separately). Use this manual to familiarize yourself with all of JVC PnP’s
features and capabilities.
For the latest information about this and other JVC PnP products, visit the JVC Web site at <http://www.jvc.com>.
Table of Contents
Menu Options Settings ............................................. 26
Basic Setting Procedure ..................................... 26
1Sirius ID ........................................................ 26
2FM Transmitter ............................................. 27
3Game Alert .................................................... 27
4Jump Settings ................................................ 28
5Display Settings ............................................ 28
6Confirm Tone Options .................................. 29
7Add or Skip ................................................... 29
8Lock Options ................................................ 29
9Audio Level Options ..................................... 30
0Antenna Aiming ............................................ 31
-Memory Options ........................................... 31
=Time Based Features ..................................... 32
~Factory Default ............................................. 34
Specifications ........................................................... 35
Troubleshooting ........................................................ 35
Safety Precautions ...................................................... 4
Box Contents .............................................................. 5
Installation: Preparation.............................................. 6
Installation in Your Car with KS-K6012 .................... 7
Installation in a Home with KS-K6013 .................... 11
JVC PnP’s Controls and Features ............................. 12
Activating Your SIRIUS Subscription ...................... 14
Basic Operation ........................................................ 15
Selecting a Program ........................................... 16
Direct Tuning ..................................................... 17
Presetting the Desired Channels ........................ 18
Presetting a Frequently Accessed Channel
—Jump Preset ................................................. 19
Enlarging the Indications—Display Button ...... 20
Instant Replay .................................................... 20
Searching for Your Favorite Programs
—S-Seek Alert ................................................ 23
KT_SR3000_02_14.p65 05.8.22, 2:07 PM3

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
4
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Safety Precautions
WARNINGS:
Take the following precautions to prevent traffic
accidents and avoid personal injury:
•Installation must be performed according to this
instruction manual. JVC is not responsible for
issues arising from incorrect installations.
• Do not install the unit where it may obstruct your
view through the windshield or of your vehicle’s
indicator displays.
• Do not install the unit where it may hinder the
function of safety devices such as an airbag.
Doing so may prevent the airbag from functioning
properly in the event of an accident.
•The installation and use suggestions contained in
this manual are subject to any restrictions or
limitations that may be imposed by applicable
law—the purchaser should check applicable law for
any restrictions or limitations before installing and/
or operating the unit.
•Failure to follow these safety instructions and
warnings may result in a serious accident.
WARNINGS:
Take the following precautions to prevent fire and
avoid personal injury:
•To avoid short circuits, never put or leave any
metallic objects (coins, tools, etc.) inside the unit.
•If the unit emits smoke or strange smells, turn the
power off immediately and consult your dealer.
•Do not drop the unit or subject it to strong shocks.
•If the LCD display becomes damaged or broken, do
not touch the liquid crystal fluid. The fluid may be
dangerous to your health or even fatal. If the liquid
crystal fluid contacts your body or clothing,
immediately wash it off with soap and water.
WARNING:
Do not operate the unit in a way that might divert your
attention from driving safely. As a driver, you alone
are responsible for safely operating your vehicle in
accordance with traffic safety laws at all times.
WARNINGS:
•Store the battery in a place where children cannot
reach. If a child accidentally swallows the battery,
consult a doctor immediately.
KT_SR3000_02_14.p65 05.8.22, 2:07 PM4

5
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Box Contents
After you unpack your JVC PnP, make sure
everything listed below is included:
If anything is missing or damaged, or if your JVC PnP
fails to operate, notify your dealer immediately. It is
recommended that you keep the original packaging in
case you need to ship your JVC PnP in the future.
SIRIUS Radio
Remote Controller
•Do not recharge, short, disassemble, heat the battery
or dispose of it in a fire. Doing any of these
behaviors may cause the battery to give off heat,
crack, or start a fire.
•Do not leave the battery with other metallic
materials. Doing this may cause the battery to give
off heat, crack, or start a fire.
•When throwing away or saving the battery, wrap it
in tape and insulate; otherwise, the battery may start
to give off heat, crack, or start a fire.
CAUTIONS:
Take the following precautions to keep the unit in
proper working order:
•Be sure the unit is connected to a 12 V DC power
supply with a negative ground connection.
•Do not install the unit where it will be exposed to
high levels of humidity, moisture, or dust.
•When replacing a fuse, use only a new one with the
proper rating. Using a fuse with the wrong rating
may cause the unit to malfunction.
•When drilling holes to mount the unit, make sure
not to damage any wiring or other systems.
Battery
(CR2032)
(The battery has been
installed when shipped
from the factory.)
KT_SR3000_02_14.p65 05.8.22, 2:07 PM5

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
6
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Installation: Preparation
To use your JVC PnP in your car or at home, it is
required to separately purchase either KS-K6012 Car
Docking Kit or KS-K6013 Home Docking Kit.
KS-K6012 includes...
•Installations
•Car Docking Cradle
•Suction Cup Mount
•Cigarette Lighter Adapter
•Magnetic Roof-mount SIRIUS Antenna
Note: KS-K6012 does not include any connecting
cord; however, you can also use an optional audio
cord or a cassette adapter to send the signals to your
car stereo.
KS-K6013 includes...
•Installations
•Home Docking Cradle
•SIRIUS Antenna
•Power Supply
•Audio Cord
CAUTION:
Do not put JVC PnP in the cradle until you have
completed the installation unless it is required for
testing.
How to Remove Your JVC PnP from the
Docking Cradle
Slide the locking knob on the back of
the cradle into the unlock position and
gently slide JVC PnP out of the cradle.
KT_SR3000_02_14.p65 05.8.22, 2:07 PM6

7
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Installation in Your Car with KS-K6012
CAUTION:
Do not plug the cigarette lighter adapter into the cigarette lighter until you have completed the
installation.
Installing in Your Car
For more illustrated explanations, refer to the
Installations supplied with your Car Docking Kit.
1 Determine where you want to mount JVC PnP.
•Do not install JVC PnP where it may obstruct
your view through the windshield or your view
of your car’s indicator displays.
•Do not install JVC PnP where it will hinder your
access to the car’s controls.
•Do not install JVC PnP where it may hinder the
function of safety devices such as an airbag.
Doing so may prevent the airbag from
functioning properly in the event of an accident.
•Find a location that provides good visibility of
and access to JVC PnP’s front panel.
2 Attach the supplied suction cup mount to the
car docking cradle using the supplied screws.
•When using other screws, use screws less than 8
mm (3/8 inch) long with a diameter of 4 mm
(3/16 inch).
3 Plug the cigarette lighter adapter into the back
of the cradle—DC 12 V.
KT_SR3000_02_14.p65 05.8.22, 2:07 PM7

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
8
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Finding the Best Antenna Mounting
Location
1 Temporarily plug the antenna into the back of
the cradle—ANT. until it is firmly secured.
2 Find an antenna location on a metal surface of
your car—at least 30 cm ×30 cm (12 inches ×
12 inches), and at least 15 cm (6 inches) from a
window.
•The antenna’s powerful magnet will secure it to
the metal surface.
•
Best reception is achieved with the antenna
mounted on the roof or the trunk for convertibles.
•If your car has a roof rack or skid ribs, it may be
necessary to mount the antenna off-center.
3 Temporarily plug the cigarette lighter adapter
into the cigarette lighter.
4 Slide JVC PnP all the way into the cradle so
that the connector at the bottom of the unit
makes proper contact in the cradle.
Installation in Your Car with KS-K6012 (continued)
5 Slide the locking knob
on the back of the cradle
into the lock position.
6 Press the (POWER) button to turn on your
JVC PnP.
7 Activate the FM signal transmitter and preset the
frequency
(see “2FM Transmitter” on page
27).
•It is recommended to preset the same frequency
into your car stereo as you have selected so you
can easily tune in to the frequency.
KT_SR3000_02_14.p65 05.8.22, 2:07 PM8

9
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Running the Antenna Cable
Before routing the antenna cable, confirm that the
antenna is mounted in a good location.
1 Press the (POWER) button to turn off your
JVC PnP.
2 Slide the locking knob
into the unlock position.
3 Remove your JVC PnP from the cradle.
4 Unplug the cigarette lighter adapter from the
cigarette lighter and the antenna from the
cradle. Continued on the next page...
•If your JVC PnP has been properly connected
and the antenna is receiving the SIRIUS signal,
you will hear audio.
•If your JVC PnP has not been properly
connected, “Antenna Error” will appear on the
display of your JVC PnP.
Check the connections and the antenna location.
–Make sure your car is not in a garage, or
somewhere the satellite signal could be
blocked.
Note: You can also connect a cassette adapter or
an audio cord (both not supplied) to the AUDIO
jack to send the signals to your car stereo.
An optional hard-wired FM transmitter—FM
Switching Box Assembly (Parts No. 112C3159) is
available. By connecting this Assembly between
the FM OUT terminal of the cradle and the
antenna input terminal of your car stereo, you can
obtain stable and reliable transmission/reception.
KT_SR3000_02_14.p65 05.8.22, 2:07 PM9

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
10
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
5 Route the cable from the antenna into the
trunk by tucking it underneath the rubber
molding around the rear window.
•Route the cable from the lowest point of the rear
window. Take advantage of any existing cable
channels or wiring conduits.
•For SUVs, minivans & 5-door vehicles, bring
the cable into the car under the rubber molding
for the tailgate, and continue under the interior
trim.
6 From the trunk, route the cable around the
passenger compartment and to the back of the
cradle.
CAUTION:
•Do not pull the cable across sharp edges that
could damage it.
•Do not route the cable nearby areas where it
could become tangled in the driver’s or
passenger’s feet.
Installation in Your Car with KS-K6012 (continued)
7 Plug the antenna into the back of the cradle—
ANT. until it is firmly secured.
8 Plug the cigarette lighter adapter into the
cigarette lighter.
9 Attach the SIRIUS antenna to the metal
surface of the car, such as the roof of your car.
Note: It is strongly recommended to unplug the
cigarette lighter adapter after you turn off the car
ignition.
KT_SR3000_02_14.p65 05.8.22, 2:07 PM10
