JVC NX-F55 User manual

NX-F55
Consists of CA-NXF55,
SP-THFT3F and SP-NXF30W
NX-F40
Consists of CA-NXF40,
SP-NXF40F and SP-NXF30W
NX-F30
Consists of CA-NXF30,
SP-NXF30F and SP-NXF30W
COMPACT COMPONENT SYSTEM
GVT0267-001C
[B]
INSTRUCTIONS
NX-F55[B]-frontcover.fm Page 1 Thursday, January 21, 2010 9:56 AM

G-1
CAUTION
To reduce the risk of electrical shocks, fire, etc.:
1. Do not remove screws, covers or cabinet.
2. Do not expose this appliance to rain or moisture.
CAUTION
The Fbutton in any position does not disconnect the mains line.
Disconnect the mains plug to shut the power off completely (the STANDBY lamp goes off).
The MAINS plug or an appliance coupler is used as the disconnect device, the disconnect device shall
remain readily operable.
• When the system is on standby, the STANDBY lamp lights red.
• When the system is turned on, the STANDBY lamp goes off.
The power can be remote controlled.
CAUTION
• Do not block the ventilation openings or holes.
(If the ventilation openings or holes are blocked by a newspaper or cloth, etc., the heat may not be able
to get out.)
• Do not place any naked flame sources, such as lighted candles, on the apparatus.
• When discarding batteries, environmental problems must be considered and local rules or laws
governing the disposal of these batteries must be followed strictly.
• Do not expose this apparatus to rain, moisture, dripping or splashing and that no objects filled with
liquids, such as vases, shall be placed on the apparatus.
CAUTION
• Excessive sound pressure from earphones or headphones can cause hearing loss.
IMPORTANT FOR LASER PRODUCTS
1. CLASS 1 LASER PRODUCT
2. CAUTION: Do not open the top cover or cabinet. There are no user serviceable parts inside the unit;
leave all servicing to qualified service personnel.
3. CAUTION: Visible and/or invisible class 1M laser radiation when open. Do not view directly with
optical instruments.
4. REPRODUCTION OF LABEL: CAUTION LABEL, PLACED INSIDE THE UNIT.
Warnings, cautions and others
NX-F40_NX-F30[B].book Page 1 Wednesday, December 24, 2008 10:04 AM

G-2
CAUTION — Proper Ventilation
To avoid risk of electric shock and fire and to protect from damage, locate the apparatus as follows:
Top/Front/Back/Sides: No obstructions should be placed in the areas shown by the dimensions below.
Bottom: Place on the level surface. Maintain adequate air path for ventilation by placing on
a stand with a height of 10 cm or more.
In addition, maintain the best possible air circulation.
Front view of the main unit and speakers (CA-NXF40/CA-NXF30 and SP-NXF40F/SP-NXF30F)
Speaker SpeakerMain unit
Speaker Main unit
Front view of the main unit and speakers (CA-NXF55 and SP-THFT3F)
Speaker
Main unit
Side view of the main unit (CA-NXF55/CA-NXF40/CA-NXF30)
CAUTION
• Battery shall not be exposed to excessive heat such as sunshine, fire or the like.
NX-F40_NX-F30[B].book Page 2 Thursday, December 24, 2009 2:00 PM

G-3
Information for Users on Disposal of Old Equipment and Batteries
[European Union]
These symbols indicate that the electrical and electronic equipment and the
battery with this symbol should not be disposed of as general household waste
at its end-of-life. Instead, the products should be handed over to the applicable
collection points for the recycling of electrical and electronic equipment as well
as batteries for proper treatment, recovery and recycling in accordance with
your national legislation and the Directive 2002/96/EC and 2006/66/EC.
By disposing of these products correctly, you will help to conserve natural
resources and will help to prevent potential negative effects on the environment
and human health which could otherwise be caused by inappropriate waste
handling of these products.
For more information about collection points and recycling of these products,
please contact your local municipal office, your household waste disposal
service or the shop where you purchased the product.
Penalties may be applicable for incorrect disposal of this waste, in accordance
with national legislation.
(Business users)
If you wish to dispose of this product, please visit our web page
http://www.jvc.eu/ to obtain information about the take-back of the product.
[Other Countries outside the European Union]
These symbols are only valid in the European Union.
If you wish to dispose of these items, please do so in accordance with
applicable national legislation or other rules in your country for the treatment of
old electrical and electronic equipment and batteries.
Notice:
The sign Pb below
the symbol for
batteries indicates
that this battery
contains lead.
Products
Battery
Dear Customer,
This apparatus is in conformance with the valid European directives and standards regarding
electromagnetic compatibility and electrical safety.
European representative of Victor Company of Japan, Limited is:
JVC Technical Services Europe GmbH
Postfach 10 05 04
61145 Friedberg
Germany
Warnings, cautions and others (continued)
NX-F40_NX-F30[B].book Page 3 Thursday, December 24, 2009 2:00 PM

G-4
IMPORTANT for the U.K.
DO NOT cut off the mains plug from this equipment. If the plug fitted is not suitable for the power points in
your home or the cable is too short to reach a power point, then obtain an appropriate safety approved
extension lead or consult your dealer.
BE SURE to replace the fuse only with an identical approved type, as originally fitted.
If nonetheless the mains plug is cut off ensure to remove the fuse and dispose of the plug immediately, to
avoid a possible shock hazard by inadvertent connection to the mains supply.
If this product is not supplied fitted with a mains plug then follow the instructions given below:
IMPORTANT:
DO NOT make any connection to the terminal which is marked with the letter E or by the safety earth
symbol or coloured green or green-and-yellow.
The wires in the mains lead on this product are coloured in accordance with the following code:
Blue: Neutral
Brown: Live
As these colours may not correspond with the coloured markings identifying the terminals in your plug
proceed as follows:
The wire which is coloured blue must be connected to the terminal which is marked with the letter N or
coloured black.
The wire which is coloured brown must be connected to the terminal which is marked with the letter L or
coloured red.
IF IN DOUBT - CONSULT A COMPETENT ELECTRICIAN.
SAFETY INSTRUCTIONS
“SOME DOS AND DON'TS ON THE SAFE USE OF EQUIPMENT”
This equipment has been designed and manufactured to meet international safety standards but, like any
electrical equipment, care must be taken if you are to obtain the best results and safety is to be assured.
Do read the operating instructions before you attempt to use the equipment.
Do ensure that all electrical connections (including the mains plug, extension leads and interconnections
between pieces of equipment) are properly made and in accordance with the manufacturer's instructions.
Switch off and withdraw the mains plug when making or changing connections.
Do consult your dealer if you are ever in doubt about the installation, operation or safety of your equipment.
Do be careful with glass panels or doors on equipment.
DON'T continue to operate the equipment if you are in any doubt about it working normally, or if it is
damaged in any way
— switch off, withdraw the mains plug and consult your dealer.
DON'T remove any fixed cover as this may expose dangerous voltages.
DON'T leave equipment switched on when it is unattended unless it is specifically stated that it is designed
for unattended operation or has a standby mode.
Switch off using the switch on the equipment and make sure that your family know how to do this.
Special arrangements may need to be made for infirm or handicapped people.
DON'T use equipment such as personal stereos or radios so that you are distracted from the requirements
of traffic safety. It is illegal to watch television whilst driving.
DON'T listen to headphones at high volume as such use can permanently damage your hearing.
DON'T obstruct the ventilation of the equipment, for example with curtains or soft furnishings.
Overheating will cause damage and shorten the life of the equipment.
DON'T use makeshift stands and NEVER fix legs with wood screws — to ensure complete safety always
fit the manufacturer's approved stand or legs with the fixings provided according to the instructions.
DON'T allow electrical equipment to be exposed to rain or moisture.
ABOVE ALL
—
NEVER let anyone, especially children, push anything into holes, slots or any other opening in the case.
— this could result in a fatal electrical shock.
— NEVER guess or take chances with electrical equipment of any kind — it is better to be safe than sorry!
✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮
✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮
NX-F40_NX-F30[B].book Page 4 Wednesday, December 24, 2008 10:04 AM

1
Introduction
Thank you for purchasing a JVC product.
Please read all instructions carefully before operation, to ensure your complete understanding and to obtain
the best possible performance from the unit.
Part description .............................3
Using the remote control ..............4
Inserting the batteries into the remote control
...................................................................... 4
Operating the system from the remote control
...................................................................... 4
Preparation.....................................5
Connecting the FM antenna............................5
Connecting the speakers and subwoofer........ 6
When installing the speakers on the floor (For
SP-THFT3F) .................................................7
Installing on the wall (For SP-THFT3F) ..........7
Connecting a TV ............................................. 8
Connecting external digital audio devices..... 10
Connecting external analog audio devices ...10
Connecting the power cable ......................... 10
Selecting the video signal type .....................11
Basic operations..........................12
Using the number buttons............................. 12
Turning on/off the main unit .......................... 12
Selecting the source ..................................... 12
Adjusting the volume..................................... 12
Turning off the sound temporarily ................. 13
Adjusting the treble/bass............................... 13
Adjusting the volume level for surround/
subwoofer sound ........................................ 13
Selecting the surround mode........................ 13
Selecting the headphone surround mode ..... 14
Sharpening the voice sound .........................14
Selecting the surround volume level.............14
Using the sleep timer .................................... 15
Changing the brightness of the display window
.................................................................... 15
Locking disc ejection.....................................15
Listening to FM radio ..................16
Selecting an FM radio station ....................... 16
Tuning in to a preset FM radio station .......... 17
Radio Data System ....................................... 17
Playing back sources from external
devices..........................................21
Playing back sources from external devices...21
Selecting the signal gain ...............................21
Basic operations of disc/file
playback .......................................22
Playing back a disc .......................................22
Playing back a file .........................................23
Display window on the main unit for disc/file
types ...........................................................24
Stopping playback.........................................29
Resuming playback.......................................29
Pausing playback..........................................29
Advancing the picture frame by frame ..........29
Fast reverse/fast forward search ..................29
Playing back from a position 10 seconds before
....................................................................30
Slow motion playback ...................................30
Skipping to the beginning of a chapter/track/file
....................................................................30
Selecting a chapter/track using the number
buttons ........................................................ 30
Skipping at approximately 5 minute intervals
....................................................................30
Selecting a chapter/track from the menu screen
....................................................................31
Convenient functions of disc/file
playback .......................................32
Playing back a disc/file in the desired order
(Program playback) ....................................32
Playing back a disc/file in a random order
(Random playback).....................................34
Playing back a disc/file repeatedly (Repeat
playback) ....................................................34
Selecting the audio language and subtitle
language .....................................................35
Magnifying the picture...................................35
Adjusting the picture quality (VFP)................36
Introduction
Preparation
Basic operations
Listening to FM radio
Playing back sources from
external devices
Basic operations of disc/file
playback
Convenient functions of
disc/file playback
Table of contents
NX-F40_NX-F30[B].book Page 1 Thursday, December 24, 2009 2:00 PM

Introduction
2
Using the status bar and the menu
bar .................................................37
Playing back a specified part repeatedly (A-
B repeat playback)...................................... 39
Designating the time (Time search) .............. 39
Changing the initial settings with
the preference screen .................40
Basic operations ........................................... 40
LANGUAGE .................................................. 40
PICTURE ...................................................... 41
AUDIO........................................................... 42
OTHERS ....................................................... 42
Language codes ..........................43
Recording from a CD to a USB
device............................................44
Recording all tracks from a CD to a USB device
.................................................................... 44
Deleting a track/group from a USB device.... 46
Adding (Editing) a title to a track/group on a USB
device ......................................................... 47
Operating other equipment.........49
Operating a TV using the remote control ...... 49
Operating an STB using the remote control
.................................................................... 50
Operating a VCR using the remote control ... 51
Basic operations of HDMI CEC...53
Notes on operations ....................54
Suitable locations for the main unit ...............54
Condensation................................................54
Cleaning the main unit ..................................54
Notes on handling .........................................54
License and trademark .................................55
Notes on discs/files .....................56
Playable disc/file types..................................56
Data hierarchy...............................................59
Handling discs...............................................59
Troubleshooting...........................60
Specifications ..............................64
Main unit (CA-NXF55/ CA-NXF40/CA-NXF30)
....................................................................64
Speakers (SP-THFT3F) (For NX-F55) ..........64
Speakers (SP-NXF40F/ SP-NXF30F) (For NX-
F40/NX-F30) ...............................................64
Subwoofer (SP-NXF30W) (For NX-F55/NX-F40/
NX-F30) ......................................................64
Supplied accessories ....................................64
Recording from a CD to a
USB device
Operating other equipment
Basic operations of HDMI
CEC
Reference
How to read this manual
• This manual explains the operations
assuming that you will use the remote
control. Some buttons on the main unit are
the same as those on the remote control.
You can use either button in this case.
• Some diagrams in this manual are simplified
or exaggerated for the purpose of
explanation.
• You can operate some functions differently
from the explanation given in this manual.
• Depending on the disc/file, you may not
obtain the explained result even after
following the operation in this manual.
• The following marks refer to the usable
discs/files for the explained function.
NX-F40_NX-F30[B].book Page 2 Thursday, December 24, 2009 2:00 PM

3
Introduction
The numbers refer to the pages in which the parts are explained.
Front view
PHONES
Refer to “Display
window” below.
*Touch sensor panels
Remote control sensor
16, 24, 25,
29–31, 45
29, 30
22, 23
15, 22 11, 15, 23,
29, 44
12, 16,
21–23
11, 12 15, 22, 23
STANDBY
lamp 12
23 14, 28
Rear view
HDMI
Cooling fan
10
9, 11, 36, 41, 42, 53
10, 21
5
9, 11
8, 11
56
10, 42
10, 21
6
Display window
45
28 14, 28
34, 39
342011 163439
16
11
11 23 24–26, 33 30 32, 33
Part description
NX-F40_NX-F30[B].book Page 3 Thursday, December 24, 2009 2:00 PM

Introduction
4
Insert the batteries into the remote control by
matching the polarity (+ and –) correctly.
• If the range or effectiveness of the remote
control decreases, replace both batteries.
Point the remote control directly at the
front of the main unit.
• Do not block the remote control sensor on the
main unit.
12, 22
11, 12, 22–25, 29, 30, 33, 34, 44
12, 16
12, 21
12, 17, 22, 24, 25, 30
31, 33, 38, 39, 48–52
44, 52
46, 47, 49, 50
25, 31
11, 16, 17, 21, 22, 24, 30
31, 33, 35–40, 44–51
37, 39
24, 30
18, 20, 24–27, 33, 35
11, 25, 31
11, 23, 29, 33, 39, 44–48, 52
24, 25, 29–31, 45
13, 14, 35
34, 35
15
20
18
32–34
12, 29
11, 12, 23, 24, 29, 46, 47
50–52
49, 50
50
50–52
11, 12, 16, 21, 22, 24, 30, 32, 35,
36, 40, 44, 49–52
18, 33, 46–48, 51, 52
50, 51
25, 31
12, 50
13
16, 29, 30, 52
12, 22, 24, 25, 29, 30, 33, 34, 52
29, 30, 52
15, 36
14, 40
13
13, 14
13
18
12, 21
Inserting the batteries into
the remote control
R03 (UM-4)/AAA
(24F) type dry-cell
batteries (supplied)
Operating the system from
the remote control
Remote control sensor
Using the remote control
NX-F40_NX-F30[B].book Page 4 Thursday, December 24, 2009 2:00 PM

5
Preparation
When radio reception with the supplied FM antenna is poor, or when using a communal antenna
• When using an antenna other than those supplied for this system, refer to the operation manuals for the
antenna and converter for details of connection.
• When positioning the antennas, find the best position for reception while listening to an actual radio
program (refer to “Listening to FM radio” on page 16).
• You cannot receive an FM radio broadcast without the antenna connection.
Connecting the FM antenna
Main unit (rear view) FM antenna (supplied)
Stretch out the FM antenna to
the best position for radio
reception.
Main unit (rear view)
Antenna cable
(not supplied)
Outdoor FM
antenna
(not supplied)
Converter (not
supplied:
compatible with
300 C/75 C)
Coaxial cable
(not supplied)
Depending on the radio reception conditions, an
FM feeder antenna (not supplied: compatible with
300 C) can be used. In this case, a converter (not
supplied) is required.
or
Communal
antenna terminal
Preparation Do not connect the power cable until all other connections have been made.
NX-F40_NX-F30[B].book Page 5 Thursday, December 24, 2009 2:00 PM

Preparation
6
Connect the speakers to the main unit by connecting the colored connectors to the same color terminals on
the rear of the main unit.
(Continued on the next page)
Connecting the speakers and subwoofer
Speaker cableSpeaker cable
Red White
Gray
Purple
Blue
Right speaker
(rear view)
Left speaker
(rear view)
Speaker cable
Subwoofer
(rear view)
Main unit (rear view)
Black
Black
Gray
Red Black
Black
Blue
White
Right speaker
(rear view)
Left speaker
(rear view)
Speaker cableSpeaker cable
Speaker cable
Subwoofer
(rear view)
Main unit (rear view)
Red
Gray
Purple
Blue
White
For NX-F55
SP-THFT3F/SP-NXF30W
For NX-F40/NX-F30
SP-NXF40F/SP-NXF30F/SP-NXF30W
NX-F40_NX-F30[B].book Page 6 Thursday, December 24, 2009 2:00 PM

7
Preparation
■IMPORTANT
• Improper speaker cable connection reduces the
stereo effect and sound quality.
• The supplied left/right speakers are magnetically
shielded, but color irregularity may occur on the
TV. To prevent color irregularity, set up the
speakers following the instructions below.
(The subwoofer is not magnetically shielded.)
1. Turn off the main power of the TV before
setting up the speakers.
2. Place the speakers enough distance from the
TV so that they do not cause color irregularity
on the TV.
3. Wait for approximately 30 minutes before
turning on the main power of the TV again.
CAUTION
• Do not connect external speakers together with
the supplied speakers. The change in
impedance may damage the main unit and the
speakers.
• If you connect any speakers other than those
supplied for the system, be sure to use speakers
of the same speaker impedance (SPEAKER
IMPEDANCE) as that indicated on the rear of
the main unit.
• DO NOT connect more than one speaker cable
to one speaker terminal.
For NX-F55 only:
Attach the supplied speaker stands.
• If you install the speakers on the wall, do not
attach the speaker stands.
CAUTION
• Do not install the speakers in a place where they
may interfere with daily activities. Injury to
personnel or damage to equipment may result if
the speakers are installed in such a place.
You can install the speakers on the wall.
CAUTION
• The each speaker weighs approximately 0.85
kg. Sufficient care must be taken when installing
them on the wall to prevent any accidents
caused by their falling off.
• Use screws which are compatible with the
strength and material of the pillar or wall to
prevent the units from falling off.
• Do not install the speakers onto a plywood or
plasterboard wall; otherwise, they will fall and
sustain damage.
• When installing the speakers on the wall;
- Be sure to have them installed on the wall by
qualified personnel.
- Care must be taken when selecting a location
for installation on the wall. Injury to personnel
or damage to equipment may result if the
installed unit interfere with daily activities.
When installing the speakers
on the floor (For SP-THFT3F)
• The speaker has a groove on
the back where you can fit the
cords to hold them in place out
of sight.
Stand
Supplied screws
for stand
(M5 × 10 mm)
Installing on the wall
(For SP-THFT3F)
Use the upper
two holes.
Slot the screws
into the holes as
shown.
Wall
Screw
(not supplied)
A: Minimum 3.5 mm
B: Maximum 10 mm
C: Maximum 4 mm
D: φ 4 mm
(screw diameter)
Preparation (continued) Do not connect the power cable until all other connections have been made.
NX-F40_NX-F30[B].book Page 7 Thursday, December 24, 2009 2:00 PM

Preparation
8
For NX-F40/NX-F30:
CAUTION
• The left and right speakers can be installed on a
wall.
• When installing the speakers on the wall;
- Be sure to have them installed on the wall by
qualified personnel.
DO NOT install the speakers on the wall by
yourself to avoid unexpected damage from
falling off the wall due to incorrect installation
or weakness in wall structure.
- Care must be taken in selecting a location for
speaker installation on a wall. Injury to
personnel or damage to devices may result if
the installed speakers interfere with daily
activities.
This system is designed to provide virtual surround
sound by positioning the 3 speakers in front. (The
set of the left and right speakers and the
subwoofer refers to 2.1 channel.) The front
surround function processes input signals to
create a realistic sound field.
After connecting a TV, follow the instructions on
page 11.
Dimensions of
the wall-mount
attachment for
the speakers
(SP-THFT3F)
124 mm
Speaker layout
Install the speakers on a flat and level surface to
ensure the best sound quality.
• The sound may be affected depending on the
location in which you install them. To improve
the sound, adjust the location and orientation of
the speakers.
• Install the speakers leaving an appropriate
distance between them.
• To obtain the best possible sound from the
System, install all speakers at the same
distance from the listening position.
Speaker layout
Install the speakers on a flat and level surface to
ensure the best sound quality.
• The sound may be affected depending on the
location in which you install them. To improve th
e
sound, adjust the location and orientation of the
speakers.
• Install the speakers leaving an appropriate
distance between them.
Connecting a TV
•
T
o o
bt
a
i
n
th
e
b
es
t
poss
ibl
e soun
d
f
rom
th
e
System, install all speakers at the same
distance from the listening position.
Main unit
Left speaker
Subwoofer
Right speaker
Connecting a TV with the [VIDEO]
terminal
Main unit
(rear view)
TV
To a video input terminal
Composite video cable (supplied)
NX-F40_NX-F30[B].book Page 8 Thursday, December 24, 2009 2:00 PM

9
Preparation
■IMPORTANT
• Connect the main unit directly to a TV (or a
monitor) without routing through a video
cassette recorder (VCR). Otherwise picture
distortion may occur during playback. (Routing
the connection through a VCR, however, does
not affect the audio quality.)
• Connecting the main unit to a VCR-built-in-TV
may also cause picture distortion during
playback.
This system can output uncompressed digital
video signals to a TV compatible with HDMI (High
Definition Multimedia Interface).
NOTE
• The HDMI video signal type can be checked with
the “HDMI” indicator in the display window.
(Refer to “Selecting the video signal type” on
page 11.)
• If the picture is distorted while an HDMI TV is
connected, turn off the main unit and turn it on
again.
• A TV compatible with HDCP (High-Bandwidth
Digital Content Protection) can also be
connected to the [HDMI MONITOR OUT]
terminal, so that the uncompressed HD video
signal type can be output as well.
• This system is compatible with some basic
functions of HDMI CEC. (Refer to page 53.)
Connecting a TV with the
[COMPONENT] terminals
Main unit
(rear view)
TV
To component
input terminals
Component video cable (not supplied)
Main unit
Direct connection
TV (or monitor)VCR
Connecting a TV with the [HDMI
MONITOR OUT] terminal
Main unit
(rear view)
To an HDMI input terminal
HDMI cable (not supplied)
TV
Preparation (continued) Do not connect the power cable until all other connections have been made.
NX-F40_NX-F30[B].book Page 9 Wednesday, December 24, 2008 10:04 AM

Preparation
10
NOTE
• You can output the audio signal from the
[DIGITAL OUT] terminal when “DVD”, “USB” or
“DGTL IN” is selected as the source in the
display window.
• When “DGTL IN” is selected as the source in the
display window, digital audio from the
[DIGITAL OUT] terminal is decoded to a linear
PCM signal.
• Connect the power cable after you complete the
other connections.
• The [STANDBY] lamp on the main unit lights up.
Connecting external digital
audio devices
Output MD player or
satellite receiver
To an optical digital
output terminal
Optical digital cable
(not supplied)
Main unit
(rear view)
Input Output
Optical digital cable
(not supplied)
To an optical digital
input terminal
Input AV amplifier with
a built-in decoder
Connecting external analog
audio devices
Connecting the power cable
Output
Input
Analog audio
device
Main unit
(rear view)
Audio cable
(not supplied)
AC outlet
Main unit
(rear view)
NX-F40_NX-F30[B].book Page 10 Wednesday, December 24, 2008 10:04 AM

11
Preparation
To view an image on the TV screen, select the
video signal type correctly according to the TV
after connecting the main unit to the TV.
■IMPORTANT
• Slide the remote control mode
selector to [SHIFT].
1Turn on the main unit.
• Refer to “Turning on/off the main unit” on
page 12.
2Press [DVD 3] or [USB 3].
• When a disc is loaded or a USB device is
connected, press 7 to stop playback.
3Press [SCAN MODE].
• The current video signal type appears.
Example: When “576I (Interlace)” is
selected as the video signal
4Press 2or 3(cursor) to select the
video signal type suitable for the
TV.
• When the TV is connected to the [VIDEO]
terminal, select “576I”.
• When the TV is connected to the
[COMPONENT] terminals, select “576P”.
• When the TV is connected to the [HDMI
MONITOR OUT] terminal, the video signal
type can be selected as instructed below.
- Select “AUTO” for normal usage. (initial
setting)
- Select “576P”, “720P”, “1080I” or “1080P”
as needed. (The selectable settings differ
according to the resolution of the
connected TV.)
• You can also select the video signal type by
repeatedly pressing [SCAN MODE].
NOTE
• “576”, “720” and “1080” refer to the number of
the scanning lines. Generally, the larger the
number, the better picture that can be obtained.
• “I” refers to the interlaced scanning. “P” refers to
the progressive scanning. A better picture can
be obtained in the progressive scanning than in
the interlaced scanning.
• When an HDMI video signal is output, the
“HDMI” indicator lights up in the display window.
• When an HD video signal is output, the “HD”
indicator lights up.
• When “576P”, “720P” or “1080P” is selected, the
“PROGRESSIVE” indicator lights up in the
display window.
5Press [ENTER].
NOTE
• It is recommended that you slide the remote
control mode selector to [AUDIO] after selecting
the video signal type. Most of the other functions
can be used when the remote control mode
selector is at [AUDIO].
• Even if the main unit is turned off, the video
signal type setting is stored.
Selecting the video signal
type
Remote control
mode selector
2 / 3 (cursor)/
ENTER
Preparation (continued)
NX-F40_NX-F30[B].book Page 11 Wednesday, December 24, 2008 10:04 AM

Basic operations
12
■IMPORTANT
• Slide the remote control mode
selector to [AUDIO].
Examples:
5: [5]
15: [ 10] →
[1] → [5]
150: [ 10] →[ 10] →[1] →[5] → [0]
Press [AUDIO F] (or [STANDBY F]
on the main unit).
• The power of the main unit turns on and the
[STANDBY] lamp (button) on the main unit turns
off.
• Press [AUDIO F] (or [STANDBY F] on the
main unit) again to turn off the power of the main
unit. (The main unit enters the standby mode.)
• With the power off, pressing any of the following
buttons also turns on the main unit.
- [DVD
3 ], [USB 3 ], [TUNER], [AUDIO IN] and
[DIGITAL IN],
3 (playback) or 0 on the
remote control
The function assigned to the pressed button
starts working at the same time. (When
3
(playback) is pressed, “DVD” is selected as the
source in the display window.)
• An internal cooling fan turns on when the main
unit turns on. This is to prevent overheating of
the main unit. The cooling fan produces noise
during operation. This is not a malfunction.
Press [DVD3], [USB3], [TUNER],
[AUDIO IN] or [DIGITAL IN] on the
remote control.
• You can also select the source by turning
[SOURCE] on the main unit.
Press [VOL +] or [VOL –] repeatedly.
• You can also adjust the volume by turning the
[VOLUME] control on the main unit.
Using the number buttons
Remote control
mode selector
Number
buttons
3 (playback)
Turning on/off the main unit
Selecting the source
Adjusting the volume
USB FM
AUDIO INDGTL IN
DVD
Basic operations
NX-F40_NX-F30[B].book Page 12 Wednesday, December 24, 2008 10:04 AM

13
Basic operations
Press [MUTING].
• Press [MUTING] again or [VOL +] or [VOL –], or
turn the [VOLUME] control on the main unit to
restore the sound. The sound is also restored
when the main unit is turned off once and turned
on.
1Press [TREBLE/BASS] repeatedly
to select “TRE” or “BASS” in the
display window.
2Press [LEVEL +] or [LEVEL –]
repeatedly to adjust the sound
quality.
• Adjustable sound quality is from –10 to +10.
You can adjust the volume level for the left and
right surround sound and the subwoofer sound
respectively.
1Press [SPK LEVEL] repeatedly to
select “SURR” or “SUBWFR” in
the display window.
• “SURR” refers to the left and right surround
sound.
• “SUBWFR” refers to the subwoofer sound.
2Press [LEVEL +] or [LEVEL –]
repeatedly to adjust the volume
level.
• The adjustable volume range is from –6 to
+6.
Press [SURROUND].
• Each time you press [SURROUND], the display
changes in the display window as follows.
-“AUTOSUR”
When a multi-channel signal is input, surround
sound is automatically produced.
- “MOVIE”
Surround sound suitable for a movie or multi-
channel signal is produced.
- “WIDE/2CH”
When a 2ch signal is input, surround sound is
produced. The sound is broader than the one
with “MOVIE”.
-“SUPERW”
Surround sound broader than the one with the
“WIDE/2CH” is produced.
NOTE
• Depending on the signal type, surround sound
may not be produced as the surround mode
setting.
• During playback, when you change the surround
mode setting, sound from the [DIGITAL OUT]
terminal may be intermittent. Before recording
sound to an external device, select the desired
surround mode setting.
• This function does not work for a JPEG/ASF/
DivX/MPEG1/MPEG2 file.
Turning off the sound
temporarily
Adjusting the treble/bass
Adjusting the volume level
for surround/subwoofer
sound
Selecting the surround mode
Basic operations (continued)
NX-F40_NX-F30[B].book Page 13 Wednesday, December 24, 2008 10:04 AM

Basic operations
14
You can listen to surround sound via headphones
connected to the [PHONES] terminal.
■When headphones are connected to the
[PHONES] terminal
Press [SURROUND].
• Each time you press [SURROUND], the setting
toggles between “H.P. SURR” and “H.PHONE”
in the display window.
NOTE
• The [PHONES] terminal is for connecting a pair
of headphones equipped with a stereo mini plug
(not supplied). When headphones are
connected, no sound is output from the
speakers.
• This function does not work for a JPEG/ASF/
DivX/MPEG1/MPEG2 file.
This function allows you to easily understand
dialog recorded on the disc/file even with the
volume down low. This function is useful when you
are watching a movie.
1Press [SETTING] repeatedly to
select “CLR VOIC” in the display
window.
• “CLR VOIC” refers to a clear voice.
2Press [LEVEL +] or [LEVEL –]
repeatedly to select “CLR: ON” in
the display window.
• Each time you press [LEVEL +] or [LEVEL –]
the clear voice function turns on and off.
• When you want to deactivate the clear voice
function, select “CLR: OFF”.
You can increase the surround volume level.
This function is effective for the following
conditions:
(1) When the surround mode is set to an item
other than “AUTO SUR” (Refer to page 13.)
(2) When the surround mode is set to “AUTO
SUR” and a DVD VIDEO of multi-channel
signal is played back.
(3) When the surround mode is set to “AUTO
SUR” and the source is set to “DGTL IN”.
1Press [SETTING] repeatedly to
select “SURR VOL” in the display
window.
2Press [LEVEL +] or [LEVEL –]
repeatedly to select the desired
setting in the display window.
• Each time you press [LEVEL +] or [LEVEL –],
the surround volume level display changes to
one of three levels. The surround volume
level increases in the order of “SURR:
NRML”, “SURR: MID” and “SURR: HIGH”.
• Select the surround volume level while
listening to the actual sound to confirm the
difference.
NOTE
• This function does not affect the sound with the
headphone surround mode.
Selecting the headphone
surround mode
Sharpening the voice sound
This indicator lights up when the
clear voice function is activated.
Selecting the surround
volume level
For the locations of the remote
control buttons, refer to page 12.
NX-F40_NX-F30[B].book Page 14 Wednesday, December 24, 2008 10:04 AM

15
Basic operations
When the time you specify elapses, the main unit
automatically turns off.
Press [SLEEP].
• Each time you press [SLEEP], the time indicated in
the display window changes. You can set the time
to 10, 20, 30, 60, 90, 120, 150 or 180 minutes.
Example: Display when the sleep timer is
set to 60 minutes
Press [SLEEP] repeatedly to select the
time again.
Press [SLEEP] once.
Press [SLEEP] repeatedly until
“SLEEP --” appears.
Turning off the main unit also cancels the sleep
timer.
■When the main unit is turned on
Press [DIMMER] repeatedly.
• Each time you press [DIMMER], the brightness
changes in 3 levels.
You can lock the disc tray to prevent the disc from
being ejected.
■When the main unit is turned off
Touch 0while holding 7on the main
unit for more than 2 seconds.
If you attempt to open the disc tray by pressing 0
while the main unit is turned on, the disc tray does
not open and “LOCKED” appears in the display
window.
To cancel the lock, do the same operation above
again while the main unit is turned off.
“UNLOCKED” is displayed in the display window.
Using the sleep timer
Changing the remaining time
Confirming the remaining time
Canceling the sleep timer
Changing the brightness of
the display window
Locking disc ejection
Setting the disc ejection lock
Basic operations (continued)
For the locations of the remote
control buttons, refer to page 12.
