Kallista P72000 User manual

Installation Guide
Pedestal Bathroom Sinks
P72000, P72016, P72021,
P72030, P72034
1008428-2-C

Thank You For Choosing Kallista
We appreciate your commitment to KALLISTA quality products. Please
take a moment to review this manual before you install your
KALLISTA product. If you encounter any installation or performance
problems, please do not hesitate to contact us at the phone number
listed on the back cover.
Tools and Materials
Before You Begin
NOTICE: Risk of product damage. Do not overtighten connections.
Overtightening may damage the product.
Observe all local plumbing codes.
Prior to installation, unpack the new sink and pedestal and
inspect them for damage.
Return the sink and pedestal to the protective cartons until you
are ready to install.
These instructions are for installing the sink to wood frame
construction. For other installations, provide suitable bracing and
fastening devices of sufficient size and strength.
The walls and floor must be square, plumb, and level.
Sink dimensions are nominal and conform to tolerances in ASME
A112.19.9 standards for non-vitreous ceramic plumbing fixtures.
The appearance of your pedestal sink may differ from what is
shown in these instructions, however, the installation procedure is
the same.
KALLISTA reserves the right to make revisions in the design of
products without notice, as specified in the Price Book.
Square
Level
Tape
Measure Safety
Glasses
Adjustable
Wrench
Drill Pipe
Wrench
Socket Wrench
With Sockets
Pencil
Pliers
1008428-2-C 2 Kallista

Roughing-In
24"
(610 mm)
27"
(686 mm)
32-1/2"
(826 mm)
35"
(889 mm)
33-3/16"
(843 mm)
34-3/16"
(868 mm)
H
26"
(660 mm)
26"
(660 mm)
27"
(686 mm)
27"
(686 mm)
G
10"
(254 mm)
8-3/4"
(222 mm)
8-3/4"
(222 mm)
F
25-3/4"
(654 mm)
30"
(762 mm)
32"
(813 mm)
E
2-3/4"
(70 mm)
2-1/2"
(64 mm)
3-1/16"
(78 mm)
2"
(51 mm)
2-5/8"
(67 mm)
D
3-3/8"
(86 mm)
2-5/8"
(67 mm)
3-1/2"
(89 mm)
C
7"
(178 mm)
8-3/4"
(222 mm)
8-1/2"
(216 mm)
8"
(203 mm)
8"
(203 mm)
B
19-3/4"
(502 mm)
P72000
21-1/2"
(546 mm)
P72030
22"
(559 mm)
P72034
17"
(432 mm)
P72021
18-5/16"
(465 mm)
P72016
A
B
H
G
F
E
DC
A
Finished
Wall
Finished
Floor
Finished
Wall
4" (102 mm)
35-1/4"
(895 mm)
Kallista 3 1008428-2-C

1. Preparation
Install the water supplies and drain piping. Install the supply
stops so the handles will not touch the pedestal when fully open.
Install sufficient backing behind the finished wall to provide
secure material for the anchoring devices.
Place the pedestal in the approximate location.
NOTE: The sink must be supported by the pedestal.
Carefully lift the sink into place on the pedestal, and slowly move
the pedestal as required to ensure proper fit.
NOTE: Self-adhesive gaskets are not supplied with all pedestal
sinks.
To level the sink, apply self-adhesive gaskets as needed where the
pedestal contacts the sink.
Locate the two sink anchoring holes, and mark the hole locations
on the finished wall.
Carefully remove the sink from the pedestal and set aside. Move
the pedestal from the area.
Backing
Mark the anchor
hole locations.
Self-Adhesive
Gasket
1008428-2-C 4 Kallista

2. Install the Sink
For wood frame installations, drill 1/4″(6 mm) mounting holes
at the marked locations on the finished wall.
For tile or mansonry wall installations, anchors (provided) are
required. Drill 1/2″(13 mm) mounting holes at the marked
locations on the finished wall and insert the anchors.
Install hanger bolts (provided) in the wall so they extend
1″(25 mm) beyond the finished wall.
Install the faucet and drain to the sink according to the
manufacturer’s instructions.
Position the pedestal on the floor.
Carefully set the sink on the pedestal so the hanger bolts extend
through the sink anchoring holes.
Position the sink as desired.
Install the nuts (provided) to the hanger bolts. Level the sink, and
carefully tighten the nuts until secure. Do not overtighten.
1"
(25 mm)
Hanger Bolt
Nut
Kallista 5 1008428-2-C

Install the Sink (cont.)
Connect and tighten the trap to the drain. Complete the water
supply connections to the faucet according to the faucet
manufacturer’s instructions.
Run water into the sink and check all connections for leaks.
Optional: Apply silicone sealant around the pedestal foot to
stabilize.
1008428-2-C 6 Kallista

1008428-2-C

USA/Canada: 1-888-4-KALLISTA
Fax: [phone]
kallista.com
©2012 KALLISTA
