KAM Star Cluster Micro V2 User manual

Due to continuous product development, please ensure that you have downloaded
the latest instruction manual for this product from the Kam website at www.kam.co.uk
MANUAL VERSION 4.0
09-09-13
For the latest updates and information on the entire Kam range visit:
www.kam.co.uk
Kam products are manufactured by: Lamba plc, Unit 1, Southfields Road, Dunstable, Bedfordshire, United Kingdom LU6 3EJ
Telephone: (+44) (0)1582 690600 • Fax: (+44) (0)1582 690400 • Email: [email protected] • Web: www.lambaplc.com
If this product is ever no longer functional please take it to a recycling plant for environmentally friendly disposal.
Due to continuous product development, specifications and appearance are subject to change. © Copyright Lamba plc 2013. E&OE.
Star Cluster Micro V2
Compact star cluster laser with multi FX

Thank you for purchasing this Kam product, we are sure that it will serve you for many years to come.
To optimise the performance of this product, please read these operating instructions carefully to familiarise yourself
with the basic operations of this unit. Please retain them for future reference.This unit has been tested at the factory
before being shipped to you. To prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or
moisture. To prevent a fire hazard, do not expose the unit to any naked flame sources. Unplug this apparatus during
lightning storms or if it is unlikely to be used for long periods of time.
When installing the unit, please ensure you leave enough space around the unit for ventilation. Slots and openings in
the unit are provided for ventilation to ensure reliable operation of the product and to protect it from overheating. To
prevent fire hazard, the openings should never be blocked or covered.
If the unit is powered by the mains, always handle the power cable by the plug. Never pull out the plug by pulling on
the cable. Never touch the power cable when your hands are wet as this could cause an electric shock. Do not tie a
knot in the cable. The power cable should be placed such that it is not likely to be stepped on. A damaged power
cable can cause a fire or give you an electrical shock. Check the power cord periodicaly, if you ever find that it is
damaged, replace it before using the unit again. Contact your retailer for a replacement.
The voltage of the available power supply differs according to country or region. Be sure that the power supply
voltage of the area where this unit is to be used meets the required voltage written on the unit.
The lightning flash symbol inside a triangle is to alert the user to the presence high voltage within the unit’s
enclosure that may be of sufficient power to constitute a risk of electrical shock to persons.
Caution: to prevent the risk of electric shock, do not attempt to open the unit. No user-serviceable parts
inside. Refer all servicing to qualified service personnel.
The exclamation mark inside a triangle is intended to alert the user to the presence of important operating
and maintenance instructions in the literature accompanying the appliance.
Select the installation location of your unit carefully. Avoid placing it in direct sunlight or locations subject to vibration
and excessive dust. Do not use the unit where there are extremes in temperature (below 41ºF / 5ºC or exceeding
95ºF / 35ºC).
Unpacking and safety Please unpack your new product carefully. Your new product should reach you in perfect
condition. Please check that no damage has occurred during transit. If any damage is found, do not operate your
unit. Please contact the retailer you purchased it from immediately. If there is any damage to the mains cable do not
use the device. Always disconnect the unit from the mains supply when carrying out any cleaning of the unit.
Manufacturer declarations
In compliance with the following requirements: RoHS Directive (2002/95/EU) and WEEE Directive (2002/96/EU),
and Battery Directive (2006/66/EU). If this product is ever no longer functional please take it to a recycling plant for
environmentally friendly disposal. Any supplied batteries can also be recycled.
CE declaration of conformity
Low Voltage Directive (2006/95/EU). The declarations are available on application from cert[email protected]
Before putting the devices into operation, please observe the respective country-specific regulations.
Warning
This unit contains high power laser devices. Do not open the laser housing due to potential exposure to
unsafe levels of laser radiation. Never look directly into the laser aperture on the front of unit. Always
position the laser unit at least 0.25m / 10" away from anyone’s eyeline.
The manufacturer will not accept liability for any resulting damages caused by the non-observance of this manual or
any unauthorized modification to the device.

Operation
The Kam Star Cluster Micro is an easy to operate star cluster laser. There are two modes of operation; Sound-to-
Light and Automatic. The unit can be controlled from the chassis or via the remote control. The unit is powered by
the supplied adapter. To start the unit, plug in the power supply to the back of the unit, it will begin to operate
immediately but to reach its full power, please allow between five and ten minutes to warm up. The unit will only
begin emmiting its laser effect when the key on the rear of the unit has been inserted and turned to the On position.
The unit will stop emmiting laser light if the key is removed. When you power up the unit, ensure that the laser is not
pointing towards anyone’s eyes. Pressing the mode button on the front of the unit for 2.5 seconds will turn the unit
Off/On.
Auto mode
When the unit is working in Auto mode, it runs through a series of pre-programmed patterns. To activate Auto mode,
click the Mode Select button on the front of the unit or choose ‘Auto’ on the remote control. When the unit is
operating in Auto mode, the indicator LED light on the front of the unit will glow red.
Sound-to-Light mode
The unit has a built-in microphone that monitors any loud ambient sounds, including music. The laser then reacts to
this sound and displays a lightshow that matches the rhythm. To activate Sound-to-Light mode, click the Mode
Select button on the front of the unit or choose ‘Music’ on the remote control. When the unit is operating in Sound-to-
Light mode, the indicator LED light on the front of the unit will glow blue. You can adjust the sensitivity of the
microphone on the remote by choosing ‘Music’ mode and then pressing any number between 1-9 (1 is the least
sensitive and 9 is the most sensitive).
Manual mode
The unit can be controlled in Manual mode via the remote control by clicking on the third row buttons A, B or C (G).
The A button controls the units red strobing, this is adjusted using the buttons 1-9. The B button controls the unit’s
second colour strobing, this is adjusted using the buttons 1-9. The C button controls the units effect speed, this is
adjusted using the buttons 1-9. The bottom right button (H) controls the effect rotation.
Remote control
The unit can be operated by the supplied remote control. Make sure the unit is powered up and working, if no lasers
are showing, press the red power button on the remote (A). Use this button to place the unit in standby mode when it
is not needed. To completely turn the unit off, remove the power supply. The remote control’s Auto button (C) sets
the unit to Auto mode (see above). The Music button (B) sets the unit to Sound-to-Light mode (see above). The two
outer buttons in the second row of the remote (D and E) control the colour that the unit displays. The middle button
of the second row (F) pauses the effect.

Adjustable green laser (not applicable to red & blue laser)
The brightness of the green laser is adjustable. To increase or decrease the brightness, turn the Green Laser Power
knob on the back of the unit clockwise or anticlockwise.
Tripod mount
The unit can be mounted on the supplied tripod mount. Ensure that the unit is not plugged in, then screw the tripod to
the underside of the chassis. Spread the tripod’s legs and set in position.
Universal mounting bracket
If you wish to permanently position the unit, screw the universal mounting bracket to a surface using rawlplugs where
necessary. Attach the unit to the bracket with the screw mount. You can adjust the position of the laser by loosening
the ball and socket joints and tightening them when you are happy with the direction the unit is pointing in. Make sure
that the laser is never pointing in anyone’s eyes.
The unit is a class 3R laser. Please adhere to the following precautions:
Do not stare into the laser especially of a distance of less than 0.25m / 10".
Please mount the laser so that audiences cannot stare into the beams at these distances.
Caution – use of controls or adjustments or performance of procedures other than those specified herein may result
in hazardous radiation exposure.
Safety warning stickers
The yellow and black safety stickers that are attached to the laser unit are warnings that need to be adhered to.
The above sticker is placed next the laser aperture on the front of the unit. Never look directly into the unit’s aperture.
The above triangular sticker is placed on the front of the unit to indicate the presence of a laser.
The above sticker is placed on the top/front of the unit and indicates that the unit is a Class 3R laser product.

The above sticker is placed on the top/rear of the unit to indicate that if the chassis is opened, exposure to Class 3B
laser light can occur.
This sticker is placed on the bottom of the unit and gives further technical information including the laser power.
Specifications
Laser power:
Green - 50mW@532nm (adjustable)
Red - 100mW@650nm
Beam diameter: <5mm at aperture
Pulse rate: All pulses >4Hz (<0.25 sec)
Divergence (each beam): <2 mrad
Divergence (total light): 160 degrees
External power supply: AC 100V-240V / 50Hz-60Hz
Adapter: DC12V / 0.6A
Working environment: 10-40°c indoor
Full warm-up time: 5-10 minutes
Laser safety class: Class 3R
Dimensions: 117 x 92 x 46mm / 4.6 x 3.62 x 1.81 inches
Net weight: 0.35Kg
Features
Complete portable and compact laser kit
Full multi-function remote control
High quality temperature controlled diodes
Selectable multi star cluster effects
Built-in animated patterns
Sound-to-Light and Auto modes
Tough all-metal chassis
Mini tripod
Universal mounting bracket
Full instruction manual
Laser safety guide
