Kane 258 User manual

www.kane.co.uk
Welcome
KANE258
Flue Gas Analyser with
direct CO, O2& CO
sensor protection
Quick reference guide

On / Off
Function keys
(see below)
Water trap &
particle filter
Rotary switch
Hello KANE258 getting started
1 Know your KANE258
2 Connections
3 Before use
4 KANE ASSET MANAGEMENT (KAM)
Please register your analyser at www.kane.co.uk & download
the full instruction manual from our product selector
PLEASE READ ALL SAFETY WARNINGS IN THE MANUAL
Know your
KANE258
1
Function keys
Icon Description
Data hold - Short press to hold current data on screen (see Status bar section)
Pump toggle - Long press to toggle pump on & o
Navigate Up - Short press to scroll up
Enter key - Used to select current option
Navigate Down - Short press to scroll down
Save log - Long press to store data
Print report - Short press to print a report
(will enter a print destination menu if both Wireless & IRDA tted)

Before use
3
Check
Particle lter is not dirty; Water trap & ue probe empty of water;
Water trap & red plug tted to analyser; Flue probe hose connected to ue gas inlet; Flue
probe temperature plug connected to T1 temperature connection
Fresh air purge
Position ue probe in fresh air & press “On/O”
Analyser auto-calibrates within 30 seconds
Select “Ratio” on dial - in fresh air CO reading = 0ppm
Select “O2/E” on dial - in fresh air O2 reading = 20.9%
Select “Status” on dial to view
To charge NiMH rechargeable batteries
Switch o
Connect charger - charging indicator illuminates
Connections
2
Battery charger
Watertrap drain
with red plug
Flue probe
temperature T1
Inlet temperature T2
Flue gas inlet
Red connector
- plugs into flue
gas inlet
Flue probe temperature plug
- plugs into T1
Narrower (+ve) pin must be on
right hand side Flue probe hose

Northern Customer Service
Kane International Ltd
Gibfield Park Avenue, Atherton,
Manchester, M46 0SY, UK
Email: [email protected]
Southern & International Customer Service
Kane International Ltd
Kane House, 11 Bessemer Road,
Welwyn Garden City, Hertfordshire, AL7 1GF, UK
Email: [email protected]
0800 059 0800
Customer Service
Email: [email protected]
Stock No. QRG00092
Outside UK Call [phone]
KANE and the KANE logo (registered in the UK and elsewhere) are trademarks of Kane Group Limited, used under licence.
All other marks are trademarks of their respective holders. © 2020 Kane International Limited
Follow us on...
4
Please register your analyser at www.kane.co.uk & download
the full instruction manual from our product selector
PLEASE READ ALL SAFETY WARNINGS IN THE MANUAL
Register your KANE analyser to
create your KAM dashboard:
★ Simple online booking on www.kane.co.uk
★ Relevant product specific promotions, special offers & discounts
★ Automatic reminder when due for recertification
★ FREE POSTAGE returning your KANE analyser
★ SAME DAY annual FGA recertification OR YOUR MONEY BACK*
KAM
*Excludes KANE '9 series' analysers & UKAS certificates
KANE ASSET MANAGER (KAM)
