Powerfix Profi 291710 User manual

IAN 291710
DIGITAL CALLIPER
DIGITAL CALLIPER
Operation and safety notes
DIGITAL SKYDELÆRE
Brugs- og sikkerhedsanvisninger
PIED À COULISSE NUMÉRIQUE
Instructions d‘utilisation et consignes de sécurité
DIGITALE SCHUIFMAAT
Bedienings- en veiligheidsinstructies
DIGITALER MESSSCHIEBER
Bedienungs- und Sicherheitshinweise

GB/IE/NI Operation and safety notes Page 5
DK Brugs- og sikkerhedsanvisninger Side 14
FR/BE Instructions d‘utilisation et consignes de sécurité Page 23
NL/BE Bedienings- en veiligheidsinstructies Pagina 32
DE/AT/CH Bedienungs- und Sicherheitshinweise Seite 41

B
A
2
6
5
41
11 10 9 8
3
7

C
D
E
F

GB/IE/NI 5
Introduction..........................................................Page 6
Intended use................................................................Page 6
Scope of delivery .......................................................Page 6
Description of parts....................................................Page 6
Technical data.............................................................Page 6
Safety instructions..........................................Page 7
Safety instructions for batteries /
rechargeable batteries...............................................Page 8
Before start of operation..........................Page 9
Insert/replace battery...............................................Page 9
Preparing the calliper.................................................Page 9
Starting up the device..................................Page 9
Using the calliper........................................................Page 9
Examples of use..........................................................Page 10
Troubleshooting ..........................................................Pa g e 11
Cleaning and maintenance.....................Page 12
Disposal....................................................................Page 12
Warranty ................................................................Page 13

GB/IE/NI6
DIGITAL CALLIPER
Introduction
We congratulate you on the purchase of your new
product. You have chosen a high quality product. The
instructions for use are part of the product. They
contain important information concerning safety, use and
disposal. Before using the product, please familiarise yourself
with all of the safety information and instructions for use. Only
use the product as described and for the specified applications.
If you pass the product on to anyone else, please ensure that
you also pass on all the documentation with it.
Intended use
Only for private use.
Not for commercial use.
Scope of delivery
1x digital calliper
1x battery
1x storage box
1x instruction for use
Description of parts
1Measuring surfaces
2Internal measuring jaws
3Inch/mm key
4Locking screw
5LCD display
6Depth-measuring blade
7Handwheel for measuring jaws
8Battery compartment lid
9Key for zero setting (ZERO)
10
ON/OFF key (ON/OFF)
11
External measuring jaws
Technical data
Measurement unit: mm / inch
Measuring range: 0-150 mm / 0-6”
Resolution: 0.01 mm / 0.0005”
Accuracy
(Length measurement): 0-100 mm ± 0.02 mm / 0.001”
100-150 mm ± 0.03 mm / 0.001”
(Depth measurement): 0-100 mm ± 0.04 mm / 0.002”
100-150 mm ± 0.05 mm / 0.002”
Maximum measuring speed: 1.5 m/s, 60”/s
Measuring system: Liner capacitive measuring system
Display: LCD display
Operating temperature: +5°C to +40°C
Influence of humidity: within a range from 0% to 80%
relative humidity irrelevant
Battery: 3V (Direct current)
CR2032 (included)
Auto off: 5 minutes +/–30 seconds

GB/IE/NI 7
Safety instructions
BEFORE USING THIS DEVICE, PLEASE
READ THE DIRECTIONS FOR USE!
PLEASE KEEP THE DIRECTIONS FOR USE
IN A SAFE PLACE!
mCAUTION! RISK OF INJURY!
 KEEP THE PRODUCT OUT
OF THE REACH OF
CHILDREN. THIS PRODUCT
IS NOT A TOY! This product should
never be used by children unsupervised.
mDANGER TO LIFE AND RISK OF
ACCIDENT FOR TODDLERS AND
CHILDREN! Never leave children alone
and unsupervised with the packaging
material.
 There is a risk of suffocation from the
packaging material. Children often
underestimate risks. Always keep children
away from the product.
mDANGER TO LIFE! Batteries could be
swallowed and pose a lethal hazard.
Consult a doctor immediately if anyone
swallows a battery.
 This appliance can be used by children
aged from 8 years and above and
persons with reduced physical, sensory
or mental capabilities or lack of
experience and knowledge if they have
been given supervision or instruction
concerning use of the appliance in a
safe way and understand the hazards
involved. Children shall not play with
the appliance. Cleaning and user
maintenance shall not be made by
children without supervision.
 Never expose the product to high
temperatures, water or moisture as this
may damage the product.
 Do not put the calliper under any strain.
This may damage the chip in the calliper.
 Keep the calliper clean and dry. Fluids
could damage the calliper.

GB/IE/NI8
Safety instructions for batter-
ies / rechargeable batteries
 DANGER TO LIFE! Keep batteries /
rechargeable batteries out of reach of
children. If accidentally swallowed seek
immediate medical attention.
 DANGER OF EXPLOSION!
Never recharge non-
rechargeable batteries. Do not
short-circuit batteries / rechargeable
batteries and / or open them.
Overheating, fire or bursting can be the
result.
 Never throw batteries / rechargeable
batteries into fire or water.
 Do not exert mechanical loads to
batteries / rechargeable batteries.
Risk of battery leakage
 Avoid extreme environmental conditions
and temperatures, which could affect
batteries / rechargeable batteries, e.g.
radiators / direct sunlight.
 Avoid contact with the skin, eyes and
mucous membranes. In the event of
contact with battery acid, thoroughly
flush the affected area with plenty of
clean water and seek immediate medical
attention.
 WEAR PROTECTIVE GLOVES!
Leaked or damaged batteries /
rechargeable batteries can cause
burns on contact with the skin. Wear
suitable protective gloves at all times if
such an event occurs.
 In the event of a battery leak,
immediately remove it from the product
to prevent damage.
 Only use the same type of batteries /
rechargeable batteries. Do not mix used
and new batteries / rechargeable
batteries.
 Remove the batteries/rechargeable
batteries if the product will not be used
for a longer period.

GB/IE/NI 9
Risk of damage of the product
 Only use the specified type of battery /
rechargeable battery!
 When inserting ensure the correct
polarity! This is shown inside the battery
compartment!
 Clean the contacts on the battery and
in the battery compartment before
inserting!
 Remove exhausted batteries /
rechargeable batteries from the product
immediately.
Before start of operation
Insert/replace battery
Tip: Flashing numbers indicate a discharged/ flat battery.
Tip: When changing the battery, the LCD display 5may
experience faults. Remove the battery and insert it again after
waiting more then 30 seconds.
 Push open the lid to the battery compartment 8(see Fig. B).
 Remove the old battery.
 Insert the new battery into the battery compartment and
ensure correct polarity (+ and –). Make sure that the plus
terminal points outwards.
 Push the lid to the battery compartment 8shut again (see
Fig. B).
Preparing the calliper
 Loosen the locking screw 4so that you can move the
calliper.
 Clean all measuring surfaces 1and the calliper rod with a
dry cloth. Otherwise, faulty measuring results may occur due
to, for example, humidity.
 Check that all keys, switches and the LCD display 5work
correctly.
Starting up the device
Using the calliper
 Loosen the locking screw 4by turning it anti-clockwise.
 Push the external measuring jaws
11
and the internal
measuring jaws 2together.
 Switch the LCD display
5
on by pressing the ON/OFF key
10
.
 Press the inch/ mm key 3to set the unit of measurement
(inch or mm) you wish to use. Either “mm” or “in” will
appear to the right of the figures in the LCD display 5.
 Press the key to obtain the zero setting (ZERO) 9in order
to reset the LCD display 5to zero.
Measuring an object from the outside:
 Move the external measuring jaws
11
apart by turning the
handwheel 7outwards anti-clockwise. Place the external
measuring jaws
11
against the object to be measured.

GB/IE/NI10
 Turn the handwheel 7inwards clockwise. Move the
external measuring jaws
11
together until they touch both
sides of the object you want to measure. Please ensure that
you do not damage the object you want to measure by
subjecting it to too much pressure.
 The LCD display 5now displays the dimensions.
Measuring an object from the inside:
 Place the internal measuring jaws 2against the object you
want to measure.
 Turn the handwheel 7outwards anti-clockwise. Move
the internal measuring jaws 2apart until they touch the
object on both its inner sides. Please ensure that you do not
damage the object you want to measure by subjecting it to
too much pressure.
 The LCD display 5now displays the dimensions.
Measuring the depth of an object:
 Move the depth-measuring blade 6out of the calliper.
 Put the depth-measuring blade 6in position until it touches
the surface (e.g. inside a hole).
 Slide the body of the calliper downward until you feel
resistance.
 Ensure that you do not damage the depth-measuring blade
6or the object you want to measure by exerting too much
pressure on them.
 The LCD display 5now displays the dimensions.
After measurement:
 After carrying out the measurement, move the external
measuring jaws
11
/ internal measuring jaws 2together
again by turning the handwheel 7inwards clockwise.
 Switch the LCD display 5off again by pressing the
ON/OFF key
10
.
Tip: The LCD display 5automatically switches itself off
after approx. 5 minutes.
 Tighten the locking screw 4again by turning it clockwise
until you feel some resistance.
Examples of use
Tip: When measuring, always proceed as described in the
chapter on using the calliper.
Comparison of plug and socket (see fig. C):
 First measure the dimensions of the plug.
 You may wish to make a note of the measurement.
 Then measure the socket.
Deviation from a reference value (see fig. D):
 Measure a reference object (in this case A).
 Leave the measuring jaws 2/
11
in this position and press
the key to obtain the zero setting (ZERO) 9.

GB/IE/NI 11
 Then measure the second object. The LCD display 5now
shows the deviation of the measurement of the second object
to that of the reference object (A).
Measuring the thickness of the floor of an object
(see fig. E):
 First measure the depth of the object.
 Leave the depth blade 6in this position and press the key
to obtain the zero position (ZERO) 9.
 Now measure the entire object. The LCD display 5now
shows the thickness of the floor of the object.
Measuring the distance between two identical
holes (see fig. F):
 First measure one of the two, equally sized holes.
 Leave the measuring jaws 2/
11
in this position and press
the key to obtain the zero position (ZERO) 9.
 Now measure the total dimension. The LCD display 5now
shows the average distance.
Characteristics of metric ISO screw threads:
Nominal diameter:
[mm]
Increase:
[mm -1]
Core diameter:
[mm]
Drill diameter:
[mm]
3 0.5 2.46 2.5
4 0.7 3.24 3.3
5 0.8 4.13 4.2
6 1 4.92 5
8 1.25 6.65 6.8
10 1.5 8.38 8.5
12 1.75 10.11 10.2
16 2 13.84 14
20 2.5 17.29 17.5
Troubleshooting
The device contains sensitive electronic components. That is
why it experiences interference when in close proximity to radio
transmission devices. If any indication errors appear in the
display, remove such devices out of the proximity of the calliper.
Electrostatic discharge could result in malfunctions.
 When such malfunctions occur, remove the battery for a
short while and re-insert.

GB/IE/NI12
Failure Cause Solution
Five digits flash
simultaneously
every second.
The battery
voltage is lower
than 2.7 V.
Replace the battery in
line with the chapter on
“Inserting /replacing
battery”.
The LCD
display 5
does not
continue to
count.
Faulty wiring or
circuit.
Remove battery
and re-insert after
30 seconds.
Nothing is
displayed
on the LCD
display 5.
1. LCD
display 5is
switched off.
1. Switch the LCD
display 5on by
pressing the ON/
OFF key
10
.
2. Battery is the
wrong way
round or
the battery
contact is
poor.
2. Remove the battery
and insert /replace
it in line with
the terminals
and the chapter
“Inserting/replacing
the battery” so
that it touches all
contacts.
3. The battery
voltage is
lower than
2.1V.
3. Replace the
battery in line
with the chapter
“Inserting/replacing
the battery”.
Cleaning and maintenance
 Clean the calliper before and after using it with a dry cloth;
never use petrol, solvents or cleaning agents.
 Do not immerse the calliper into water. Liquids can damage
the calliper.
 Always switch the LCD display 5off when not using the
calliper. This will extend the life of the battery.
 Keep away from electrical current and electrically charged
pens to prevent damage to the chip.
Disposal
The packaging is made entirely of recyclable
materials, which you may dispose of at local recycling
facilities. The Green Dot is not valid for Germany.
Observe the marking of the packaging materials
for waste separation, which are marked with
abbreviations (a) and numbers (b) with following
meaning: 1–7: plastics / 20–22: paper and
fibreboard / 80–98: composite materials.
The product and packaging materials are recyclable,
dispose of it separately for better waste treatment. The
Triman logo is valid in France only.

GB/IE/NI 13
Contact your local refuse disposal authority for more
details of how to dispose of your worn-out product.
To help protect the environment, please dispose of the
product properly when it has reached the end of its
useful life and not in the household waste. Information
on collection points and their opening hours can be
obtained from your local authority.
Faulty or used batteries / rechargeable batteries must be
recycled in accordance with Directive 2006/66/EC and
its amendments. Please return the batteries / rechargeable
batteries and / or the product to the available collection points.
Environmental damage through incorrect
disposal of the batteries / rechargeable
batteries!
Batteries / rechargeable batteries may not be disposed of
with the usual domestic waste. They may contain toxic heavy
metals and are subject to hazardous waste treatment rules and
regulations. The chemical symbols for heavy metals are as
follows: Cd = cadmium, Hg = mercury, Pb = lead. Batteries /
rechargeable batteries may not be disposed of with the usual
domestic waste. That is why you should dispose of used
batteries / rechargeable batteries at a local collection point.
Warranty
The product has been manufactured to strict quality guidelines
and meticulously examined before delivery. In the event of
product defects you have legal rights against the retailer of
this product. Your legal rights are not limited in any way by our
warranty detailed below.
The warranty for this product is 3 years from the date of
purchase. Should this product show any fault in materials or
manufacture within 3 years from the date of purchase, we will
repair or replace it – at our choice – free of charge to you.
The warranty period begins on the date of purchase. Please
keep the original sales receipt in a safe location. This document
is required as your proof of purchase. This warranty becomes
void if the product has been damaged, or used or maintained
improperly.
The warranty applies to defects in material or manufacture. This
warranty does not cover product parts subject to normal wear,
thus possibly considered consumables (e.g. batteries) or for
damage to fragile parts, e.g. switches, rechargeable batteries
or glass parts.

DK14
Indledning..............................................................Side 15
Formålsbestemt anvendelse.......................................Side 15
Leveringsomfang.........................................................Side 15
Beskrivelse af delene..................................................Side 15
Tekniske data ..............................................................Side 15
Sikkerhedsregler.............................................Side 16
Sikkerhedsvejledning for batterier /
genopladelige batterier.............................................Side 17
Før anvendelsen...............................................Side 18
Indsæt /skift batteri....................................................Side 18
Forbered skydelære ...................................................Side 18
Idriftsættelse........................................................Side 18
Anvend skydelære......................................................Side 18
Anvendelseseksempler...............................................Side 19
Afhjælp fejl..................................................................Side 20
Service og rengøring....................................Side 21
Bortskaffelse.......................................................Side 21
Garanti......................................................................Side 22

DK 15
DIGITAL SKYDELÆRE
Indledning
Hjerteligt tillykke med købet af deres nye produkt. Du
har besluttet dig for et produkt af høj kvalitet.
Brugervejledningen er en del af dette produkt. Den
indeholder vigtige informationer om sikkerhed, brug og
bortskaffelse. Gør dig inden ibrugtagning af produktet fortrolig
med alle betjenings- og sikkerhedsanvisninger. Benyt kun
produktet som beskrevet og til de oplyste formål. Videregiv alle
papirer, hvis du giver produktet videre til tredjemand.
Formålsbestemt anvendelse
Kun til privat brug.
Ikke til erhvervsmæssig anvendelse.
Leveringsomfang
1 x digital skydelære
1 x batteri
1 x opbevaringsboks
1 x brugsvejledning
Beskrivelse af delene
1Måleflader med skala
2Målekæber til indvendig måling
3Inch/mm-tast
4Sikringsskrue
5LCD-display
6Dybdemåler
7Indstillingshjul til målekæberne
8Låg til batterirummet
9Knap til nulstilling (ZERO)
10
TÆND/SLUK- knap (ON / OFF)
11
Målekæber til udvendig måling
Tekniske data
Måleenhed: mm / inch
Måleområde: 0-150 mm / 0-6”
Opløsning: 0,01 mm / 0,0005”
Nøjagtighed
Dimensioner (længde): 0-100 mm ±0,02 mm / 0,001”
100-150 mm ±0,03 mm /
0,001”
Dimensioner (dybde): 0-100 mm ±0,04 mm / 0,002”
100-150 mm ± 0,05 mm /
0,002”
100-150 mm ±0,05 mm /
0,002”
Maksimal Målehastighed: 1,5 m/s, 60”/s
Målesystem: lineært, uden kontakt
CAP-målesystem
Display: LCD-display
Driftstemperatur: +5 °C - +40 °C
Indflydelse fra luftfugtighed: mellem 0 % og 80 % relativ
luftfugtighed ubetydelig
Batteri: 3 V (Jævnspænding)
CR2032 (er inklusiv i
leveringsomfanget)
Automatisk slukning: 5 min. +/–30 sek.

DK16
Sikkerhedsregler
LÆS VENLIGST BRUGSANVISNINGEN
IGENNEM FØR ANVENDELSE! OPBEVAR
BRUGSANVISNINGEN OMHYGGELIG!
mFORSIGTIG! FARE FOR
PERSONSKADER!
 DETTE PRODUKTET MÅ
IKKE KOMME I HÆNDERNE
PÅ BØRN. DETTE PRODUKT
ER IKKE ET LEGETØJ! Dette produkt
bør ikke benyttes af børn uden opsyn.
mLIVSFARE OG FARE FOR ULYKKER
FOR SMÅ BØRN OG BØRN! Lad
aldrig børn være uden opsyn i nærheden
af indpakningsmaterialet.
 Der er fare for kvælning ved
indpakningen. Børn undervurderer ofte
farerne. Hold derfor altid børn borte fra
dette produkt.
mLIVSFARE! Batterier kan sluges, hvilket
kan være livsfarligt. Kontakt straks en
læge, hvis en person har slugt et batteri.
 Dette apparat kan bruges af børn fra
8 år og opad, samt af personer med
forringede fysiske, følelsesmæssige
eller mentale evner eller med mangel
på erfaring og viden, når de er
under opsyn eller iht. sikker brug af
apparatet blev vejledt og forstod de
derudaf resulterende farer. Børn må
ikke lege med apparatet. Rengøring og
vedligeholdelse må ikke gennemføres af
børn uden opsyn.
 Udsæt aldrig produktet for høje
temperaturer eller fugtighed, da
produktet ellers kan tage skade.
 Skydelæren må aldrig udsættes for
spænding. I modsat fald kan chippen i
skydelæren tage skade.
 Hold skydelæren ren og tør. Væske kan
beskadige skydelæren.

DK 17
Sikkerhedsvejledning for bat-
terier / genopladelige batte-
rier
 LIVSFARE! Opbevar batterier /
genopladelige batterier utilgængeligt for
børn. Opsøg omgående læge hvis de
sluges ved et uheld.
 EKSPLOSIONSFARE!Ikke-
genopladelige batterier må
aldrig genoplades. Batterier /
genopladelige batterier må ikke
kortsluttes og / eller åbnes. Det kan
medføre overophedning, ild eller
eksplosion.
 Batterier / genopladelige batterier må
ikke kastes i ild eller vand.
 Udsæt ikke batterier / genopladelige
batterier for mekanisk belastning.
Risiko for batterilækage
 Undgå ekstreme miljøer og temperaturer,
som kan påvirke batterier/genopladelige
batterier fx radiatorer, direkte sollys.
 Undgå kontakt med hud, øjne og
slimhinder. Ved kontakt med batterisyre,
skylles det berørte område med masser
af rent vand og der skal omgående
opsøges lægehjælp.
 ANVEND
BESKYTTELSESHANDSKER!
Batterier / genopladelige
batterier der lækker eller er skadet kan
give brandsår ved hudkontakt. Anvend
altid passende beskyttelseshandsker, hvis
en sådan situation opstår.
 Hvis et batteri lækker skal det omgående
fjernes fra produktet for at forebygge
skader.
 Anvend kun den samme type
batterier / genopladelige batterier.
Bland ikke brugte og nye batterier /
genopladelige batterier.
 Fjern batterierne / de genopladelige
batterier fra produktet, hvis det ikke skal
anvendes i længere tid.

DK18
Fare for beskadigelse af produktet
 Anvend kun den specificerede type
batterier / genopladelige batterier.
 Ved isætning skal korrekt polaritet sikres!
Dette er vist inde i batterirummet!
 Batteriets og batterirummets kontakter
skal renses før isætning!
 Fjern straks udtjente batterier /
genopladelige batterier fra produktet
Før anvendelsen
Indsæt / skift batteri
Henvisning: Blinkende cifre betyder at batteriet er afladet /
tomt.
Henvisning: Ved udskiftning af batteriet kan der opstå
forstyrrelser på LCD-displayet 5. Tag batteriet ud og vent
ca. 30 sekunder inden du sætter det i igen.
 Skub batterirummets låg 8op (se billede B).
 Fjern det gamle batteri.
 Indsæt det nye batteri i batterirummet under hensyntagen til
polariteten (+ og –). Kontroller, at pluspolen viser udad.
 Skub batterirummets låg 8på igen (se billede B).
Forbered skydelære
 Skru sikringsskruen løs 4så du kan bevæge skydelæren.
 Rengør alle måleflader og skydelærestangen med en tør
klud. I modsat fald kan der opstå fejlmålinger, fx som følge
af fugt.
 Kontroller om alle knapper, kontakter og LCD-displayet 5
reagerer upåklageligt.
Idriftsættelse
Anvend skydelære
 Løsn sikringsskruen 4idet du drejer denne mod urets
retning.
 Skub målekæberne til udvendig måling
11
/ målekæberne
til indvendig måling 2sammen.
 Tænd for LCD-displayet 5idet du trykker på TÆND / SLUK
-knappen
10
.
 Tryk inch / mm-tasten 3, for at fastlægge den måleenhed,
(inch eller mm), som du ønsker at benytte. Der dukker enten
”mm” eller ”inch” op i LCD-displayet 5.
 Tryk på knappen til nulstilling (ZERO) 9for at resette LCD-
displayet 5.
Måling af en genstand udefra:
 Skub de ydre målekæber
11
fra hinanden idet du drejer
indstillingshjulet 7mod urets retning og udad. Anbring de
ydre målekæber
11
på den genstand, som du ønsker at
måle.

DK 19
 Drej indstillingshjulet 7i retning med uret indad. Skub
derved de ydre målekæber
11
sammen, indtil de rører den
genstand, der skal måles på begge sider. Vær opmærksom
på, at den genstand der skal måles ikke beskadiges af for
stort tryk.
 LCD-displayet 5viser dig nu målene.
Måling af en genstand indefra:
 Anbring de indre målekæber 2indefra på den genstand
som du ønsker at måle.
 Drej indstillingshjulet 7mod urets retning udad. Skub
derved de indre målekæber 2så langt fra hinanden,
at de rører ved genstanden på begge indre sider. Vær
opmærksom på, at den genstand der skal måles ikke
beskadiges af for stort tryk.
 LCD-displayet 5viser dig nu målene.
Måling af en genstands dybde:
 Skub dybdemåleren 6ud af skydelæren.
 Anbring dybdemåleren 6på den genstand der skal måles,
indtil den rører ved overfladen (f.eks. indeni et hul).
 Skub skydelærens krop nedad, indtil du mærker modstand.
 Kontroller, at du ikke beskadiger dybdemåleren 6eller den
genstand der skal måles ved for stort tryk.
 LCD-displayet 5viser dig nu målene.
Efter måling:
 Efter gennemført måling skubbes de udvendige
målekæber
11
/ de indvendige målekæber 2sammen
igen ved at dreje indstillingshjulet 7indad med uret.
 Sluk for LCD-displayet 5igen ved at trykke på TÆND /
SLUK-knappen
10
.
Henvisning:Efter ca. 5 minutter slukkes LCD-displayet 5
automatisk.
 Drej sikringsskruen 4fast igen, idet du drejer den i retning
med uret, indtil du mærker en modstand.
Anvendelseseksempler
Henvisning: Målinger skal altid udføres som beskrevet i
kapitlet „Anvend skydelære“.
Sammenligning mellem stik og hul (se billede C):
 Tag først stikkets mål.
 Noter i givet fald måleværdien.
 Tag derefter mål af hullet.
Afvigelse af en referencestørrelse (se billede D):
 Tag en referencegenstands mål (her A).
 Lad målekæberne 2/
11
forblive i denne position og tryk
knappen til nulstilling (ZERO) 9.

DK20
 Tag derefter den anden genstands mål. LCD-
displayet 5viser nu afvigelsen af den anden genstands mål
til referencegenstandens mål (A).
Måling af tykkelsen af en genstands bund
(se billede E):
 Mål først genstandens dybde.
 Bibehold dybdemåleren i denne position 6og tryk på
knappen til nulstilling (ZERO) 9.
 Tag nu mål på den samlede genstand. LCD-displayet 5
viser nu tykkelsen på genstandens bund.
Afstandsmåling mellem to identiske huller
(se illust. F):
 Tag først mål af et af de lige store huller.
 Hold målekæberne 2/
11
forblive i denne position og
tryk på knappen til nulstilling (ZERO) 9.
 Tag derefter de samlede mål. LCD-displayet 5viser dig nu
målet på den mellemste afstand.
Tekniske data på metriske ISO-gevind:
Pålydende
diameter: [mm]
Stigning:
[mm -1]
Kernediameter:
[mm]
Boringsdiameter:
[mm]
30,5 2,46 2,5
40,7 3,24 3,3
50,8 4,13 4,2
6 1 4,92 5
8 1,25 6,65 6,8
10 1,5 8,38 8,5
12 1,75 10,11 10,2
16 2 13,84 14
20 2,5 17,29 17,5
Afhjælp fejl
Apparatet indeholder følsomme elektroniske dele. Derfor kan
det forekomme, at man oplever forstyrrelser fra apparater med
overførsel pr. radiosignal i nærheden. Hvis der vises forkerte
målinger i displayet, skal du fjerne sådanne apparater fra
skydelærens omgivelser.
Elektrostatiske afladninger kan forårsage funktionsforstyrrelser.
 Hvis du oplever en sådan forstyrrelse, bør du fjerne batteriet
kort og derefter sætte det i igen.
