Karma KS-8 Series User manual

Powered Scooter Owner’s Manual
KS-8 Series

i
GENERAL WARNNING
IMPORTANT
Do not attempt to use the scooter before a qualified person has explained to your satisfaction how
to operate it without risk to yourself or others.
WARNNING：
DO NOT OPERATE THIS EQUIPMENT WITHOUT FIRST READING AND
UNDERSTANDING THIS MANUAL. IF YOU ARE UNABLE TO UNDERSTAND THE
WARNINGS, CAUTIONS AND INSTRUCTIONS, CONTACT A DEALER, HEALTHCARE
PROFESSIONAL OR TECHNICAL PERSONNEL IF APPLICABLE BEFORE ATTEMPTING
TO USE THIS EQUIPMENT --OTHERWISE, INJURY OR DAMAGE MAY RESULT.
PROCEDURES OTHER THAN THOSE DESCRIBED IN THIS MANUAL MUST BE
PERFORMED BY A QUALIFIED TECHNICIAN.
THE INFORMATION CONTAINED IN THIS DOCUMENT IS SUBJECT TO CHANGE
WITHOUT NOTICE.
WARNNING：
As a manufacturer of power scooters, KARMA endeavors to supply a wide variety of power
scooters to meet the many needs of the user. However, the responsibility of final selection of the
type of power scooter to be used by an individual rests solely with the user and his/her healthcare
professional capable of making such a selection.
KARMA recommends that power scooter users NOT be transported in vehicles of any kind while
in a power scooter.
As of this date, the Department of Transportation has not approved any tie-down systems for
transportation of a user while on a power scooter in a moving vehicle of any type. It is the
position of Karma that users of power scooters should be transferred into appropriate seating in
vehicles for transportation and make use of the restraints made available by the auto industry.
Karma cannot and does not recommend any power scooter transportation systems.
It is the responsibility of the Durable Medical Equipment (DME) Dealer, therapists and other
healthcare professionals to determine if a seat-positioning strap is required to ensure the safe
operation of this equipment by the user. Serious injury can occur in the event of a fall from a
power scooter.
Operating Information
◎ Performance adjustments should ONLY be made by professionals of the healthcare
field or persons fully conversant with this process and the driver's capabilities.
Incorrect settings could cause injury to the driver or bystanders and damage to the
power scooter and surrounding property.

ii
◎ To determine and establish your particular safety limits, practice bending, reaching,
mounting and dismounting activities in several combinations in the presence of a
qualified healthcare professional BEFORE attempting active use of the power scooter.
◎ For individuals with balance problems, practice mounting and dismounting activities
WITH AN ASSISTANT in the presence of a qualified healthcare professional. If so
equipped,
◎ DO NOT operate the wheelchair without anti-tippers being installed. Anti-tippers MUST
BE attached at all times.
◎ DO NOT attempt to reach objects if you have to move forward in the seat or pick them
up from the floor by reaching down between your knees as this may cause loss of
balance.
◎ DO NOT lean over the back of the chair to reach objects behind you as this may cause
the scooter to tip over.
◎ DO NOT shift your weight or sitting position toward the direction you are reaching as
the scooter may tip over.
◎ DO NOT use an escalator to move a scooter between floors. Serious bodily injury may
occur.
◎ DO NOT operate in car lanes on roads, streets, highways, etc.
◎ DO NOT attempt to move up or down an incline with a water, ice or oil film.
◎ DO NOT attempt to ride over curbs or obstacles. Doing so may cause your scooter to
turn over and cause bodily harm and/or damage to the scooter.
◎ DO NOT make sharp turns, in forward or reverse, at excessive speeds.
◎ DO NOT attempt to lift the scooter by its casings and seat.
◎ DO NOT attempt to lift the scooter by any detachable parts. Lifting by means of any
detachable parts of a scooter may result in injury to the user or damage to the scooter.
Please hold onto the frame when lifting your wheelchair.
◎ DO NOT operate the scooter until you have checked that the surroundings are clear
and that the area is safe for travel.
◎ Please pay attention to the environment, and to keep away from the hazard of external
flame. When the user is smoking, pay attention to safety and make sure to extinguish
the fire when finished. Be alert to the environment when someone nearby is smoking
or using a cigarette lighter, keep away from the hazard and use fire-proof cloth.
◎ DO NOT use parts, accessories or adapters other than those authorized by Karma.
Before attempting to sit in or exit the power scooter, REMOVE the key from the ignition.
This will ensure that the POWER is OFF and the power scooter will not drive. Remove
the key from the ignition while the scooter is not in use. Otherwise, injury and/or
damage to the scooter and surrounding property may occur.
◎ DO NOT connect any medical device (i.e., a ventilator, life support machine, et cetera)
to the battery. This could cause unexpected failure of the device and the power
scooter.

iii
◎ KARMA specifically disclaims responsibility to all personal injury and property damage
that may occur during use which does not comply with applicable federal, state and
local laws and ordinances.
◎ DO NOT stand on the front or rear casing of the power scooter.
◎ Only use freewheel mode on flat surfaces since your electromagnetic brakes are not
engaged in this mode, without these brakes it will roll down a hill causing injury or
damage.
◎ Never drive under the influence of alcohol or medication.
◎ DO NOT sit in the powered scooter within a moving vehicle unless it has been affixed
with the labels of hook mark. The labels of hook mark means that the powered scooter
fulfils the performance requirements for a “Crash Test ” of ISO 7176-19 and is suitable
to use as a seat in vehicles that have been adapted for this purpose.
RAMPS
◎ DO NOT climb, go up or down ramps or traverse slopes greater than the safe climbing
angle for your model specified in section 10.
◎ When negotiating ramps, if the variable speed lever is released while moving forward,
the power scooter will roll backwards approximately one foot before the brake
engages. If the variable speed lever is released while in reverse, the power scooter
will roll backwards approximately two and a half feet before the brake engages.
◎ Be sure to reduce your speed when driving on curved roads or making a turn; do not
drive at full speed. Please drive at a slower speed so you have complete control of the
scooter.
ELECTRICAL
◎ Check to ensure that all electrical connections are secure at all times.
◎ Grounding Instructions: DO NOT, under any circumstances, cut or remove the round
grounding prong from any plug. Some devices are equipped with three-prong
(grounding) plugs for protection against possible shock hazards. Where a two-prong
wall receptacle is encountered, it is the personal responsibility and obligation of the
customer to contact a qualified electrician and have the two-prong receptacle replaced
with a properly grounded three-prong wall receptacle/outlet in accordance with the
WARNNING：
◎ As of this date, the KS-8 series have NOT been tested for safety in collisions
according to ISO 7176-19. Therefore, the KS-8 series cannot be used as seats in any
vehicles. This is KARMA recommends that users are NOT transported in any vehicle
while seated in the scooter. In the case of accident or a sudden stop, the user could
be thrown from the scooter and get injured. The suggested solution is to transfer the
user from the scooter into a normal seat of the vehicle and to securely stow the
scooter in a separate compartment.

iv
National Electrical Code and local laws. Do not use a n extension cord when charging
your batteries. A risk of fire and /or electric shock could be encountered.
BATTERIES
◎ The warranty and performance specifications contained in this manual are based on
the use of deep cycle sealed lead acid batteries. KARMA strongly recommends their
use as the power source for this unit. (Refer to chapter 6)
◎ Carefully read the battery and charger information prior to installing, servicing or
operating your scooter.
RAIN TEST
◎ KARMA has tested its power scooter in accordance with ISO 7176 Part 9 Rain Test.
This test provides the end user or his/her attendant sufficient time to remove his/her
power scooter from a rainstorm and retain operation.
◎ DO NOT leave your power scooter in a rain storm of any kind.
◎ DO NOT use your power scooter in a shower or leave it in a damp bathroom while
taking a shower.
◎ DO NOT leave your power scooter in a damp area for any length of time. Direct
exposure to rain or dampness could cause the power scooter to malfunction
electrically and mechanically and may cause the power scooter to prematurely rust.
WEIGHT LIMITATION
◎ The maximum weight that can be carried, including goods, is stated beside "Max.
Capacity" in section 10.SPECIFICATIONS.
STAIRWAYS
◎ DO NOT attempt to move an occupiedpower scooter
between floors using a stairway. (See Figure 1)
◎ Use an elevator to move an occupied power scooter
between floors.
(Figure 1)
◎ If moving a power scooter between floors by means of a stairway, the occupant MUST
be removed and transported independently of the power scooter. Extreme caution is
advised when it is necessary to move an UNOCCUPIED power scooter up or down
stairs. Karma recommends disassembling the scooter and transporting the
components independently up or down stairs. Make sure to use ONLY secure,
non-detachable parts on each component for handhold supports.
◎ DO NOT attempt to lift a power scooter by any removable (detachable) parts. Lifting by
means of removable (detachable) parts may result in injury to the user or assistants or
damage to the scooter.

v
ESCALATORS? SORRY!
◎ DO NOT use an escalator to move a power scooter between floors. Serious bodily
injury and damage to the scooter may occur.
YOU AND YOUR KARMA SERVICE PROVIDER
◎ No tools are required for assembly. Your vehicle should be assembled by your
authorized Karma dealer. Your authorized Karma dealer is also your service provider.
Unauthorized repairs, upgrades and add-ons will negate your warranty. Anything
scooter related that requires tools should be done by your authorized Karma service
provider. Your Karma service provider has the necessary service manual for your
scooter.
◎ If you have any defective parts or lose any parts, please contact your dealer for repair
and/or replacement. Please only use parts authorized by karma. Use of parts that are
not authorized by Karma will negate your warranty.
◎ Part numbers are listed on our bill of materials (explosion drawings), which we give to
our authorized dealers and service providers. Customers should order parts through
their dealer as well as all repairs and scheduled maintenance.
◎ Customers should go to their dealership for all service needs to guarantee their
warranty is not nullified. Always go to an authorized service provider. Unauthorized
repairs will nullify your warranty. Procedures other than those described in this
manual must be performed by a qualified technician. They also have the service
manual with a complete list of maintenance required to keep your Karma scooter in
top performance. Check the warranty section of this manual to find out what Karma
guarantees and what maintenance and parts you will have to pay for.
◎ Karma does not have an official list of service providers at this time. Please contact
your dealer for service. If you cannot contact your dealer, please contact another
authorized Karma dealer for service. If all else fails, contact Karma directly via our
website or give us a call and we can refer you to your new service provider.
CLASSIFICATION
◎ Karma's KS-838 and KS-848 are classified as class C for outdoor use. They have been
tested, passed and meet German, British, American and other international standards.
Check with your local government as to legislation pertaining to mobility vehicles to
assure your legal requirements to drive on public roads have been met, i.e. a safety
belt, lighting or registration/licensing.
CE MARKING
◎ This scooter complies with the requirements of the Medical Devices Directive
93/42/EEC.

vi
CAUTION:
Before purchasing and using Karma scooter, please consult qualified professionals so as to
ensure that you choose suitable products and use them correctly as well. For safety reasons, if
there is any risk due to the user’s movement in the scooter or other environmental factors that
might cause the scooter to tip or the person on the scooter to fall off, Karma recommends that
you install anti-tippers, safety belt, or other additional safety accessories.

Table of contents
1. PREFACE ......................................................................................................................1
2. SAFETY .........................................................................................................................1
2.1 Before Driving .......................................................................................................1
2.2 While Driving.........................................................................................................2
2.3 Labeling ................................................................................................................5
3. EMI/RFI..........................................................................................................................6
4. PARTS ...........................................................................................................................8
5. OPERATION................................................................................................................10
5.1 Control Panel ......................................................................................................10
5.2 How to Operate Your Scooter.............................................................................10
6. BATTERIES AND CHARGER......................................................................................17
6.1 Charging the Batteries ........................................................................................17
6.2 Charger...............................................................................................................19
6.3 Batteries..............................................................................................................20
7. INSPECTION AND MAINTENANCE............................................................................25
7.1 Daily Check.........................................................................................................25
7.2 Regular Maintenance Record .............................................................................25
7.3 Batteries, Fuses and Tires..................................................................................27
7.4 General Maintenance..........................................................................................27
7.5 Transporting and Storing.....................................................................................28
8. OPTIONAL ACCESSORIES........................................................................................32
9. TROUBLESHOOTING.................................................................................................32
10. SPECIFICATIONS .....................................................................................................35
11. CLEANING & RECYCLING........................................................................................38
12. WARRANTY...............................................................................................................39
12.1 Serial Number...................................................................................................39
12.2 Warranty Policy.................................................................................................39
12.2.3 The Responsibilities of the User ....................................................................40
12.2.4 Warranty Effectiveness..................................................................................40
12.2.5 Transfer of Warranty Rights...........................................................................40

1
1. PREFACE
Please carefully read this owner's manual before using the vehicle. Improper use of the vehicle
could result in harm, injury or traffic accidents. Therefore, for safe and enjoyable use of the
vehicle, please read this owner's manual.
◎ This owner's manual includes operation instructions for the aspects of the vehicle,
assembly instructions, and instructions on how to deal with possible accidents.
◎ This owner's manual is written for Karma Scooters: KS-838 and KS-848.
◎ The symbols used in this manual are explained below. Pay special attention to the
parts marked with these symbols.
WARNING: Improper use could lead to serious injury or death.
CAUTION: Improper use could lead to serious injury and/or damage to your
scooter.
SUGGESTION: Follow these instructions to keep the scooter in good condition.
◎ This manual includes the repair and maintenance chart as well as the warranty. Please
keep it in a safe place or with the scooter.
◎ If someone else uses the scooter, make sure that you give him or her this owner's
manual for his or her reference.
◎ As designs change, some illustrations, pictures and specifications in this manual may
not correspond to the vehicle that you purchased. We reserve the right to make
design modifications without further notice.
2. SAFETY
2.1 Before Driving
The user must be familiar with the use and operation of this vehicle before driving. Therefore,
please always keep these safety guidelines in mind.
Traffic Rules
◎ Pedestrian traffic rules apply to this vehicle. Please be safe.
◎ Drive only on pedestrian areas such as the sidewalk. Never drive the scooter on the
highway. (See Figure 2.1)
◎ Be aware of other vehicles when crossing all roads.
◎ Be extremely cautious when driving your scooter in heavy traffic or the shopping mall.
◎ Do NOT drive your scooter when you feel tired or consume alcohol.
◎ Please do not drive your scooter at night.
◎ Please follow pedestrian traffic lights.

2
Practice Driving
◎ Before you are familiar with the operation of your scooter please practice in a wide and
open area, like a park.
◎ To avoid falling off your scooter please practice all kinds of driving motions, such as
accelerating, stopping, turning, reversing and going up and down ramps.
◎ Please set the speed dial on "3"when you first start practising.
◎ Be safe. Make sure someone accompanies you incase you need assistance.
◎ Be sure you are able to control and operate your scooter easily and confidently before
you move the speed dial higher.
No Passengers
◎ KARMA Scooters are limited to one driver.
◎ Do not carry passengers (including children) on your scooter.
No Hauling Heavy Goods
◎ Do not use this vehicle to carry or haul heavy goods.
◎ The maximum weight that can be carried, including goods,
◎ is stated beside "Max. Capacity" in section 10. SPECIFICATIONS.
◎ Maximum loading weight for the basket is 7kg (15.4lbs).
RAIN
This product is not guaranteed to be water resistant. Please do not drive in the rain,
through puddles or spray water to clean this product. (See Figure 2.2)
Figure 2.1 Figure 2.2 Figure 2.3
2.2 While Driving
Please carry out daily inspections. Refer to section 7.1 DAILY CHECK.
General Warning
◎ Do not lean over the side of the vehicle as such an action may cause you to lose
balance and fall.
◎ Use caution to assure your clothing doesn't get tangled with the wheels.
◎ DO NOT be towed by other vehicles (cars, motorcycles or bicycles, etc.)

3
Railroad Crossing (See Figure 2.3)
◎ Before crossing the tracks, please stop completely and look both ways.
◎ Cross the tracks perpendicular to avoid your wheels getting stuck.
◎ Do not drive at full speed over the railroad tracks.
Circumstances to Avoid
◎ Avoid roads with heavy traffic, mud, excessive gravel or bumps, snow and ice. These
conditions may damage your scooter.
◎ Avoid roads that are too narrow or by a canal/waterway without any fence/hedge.
◎ Also avoid places where your wheels might get stuck, slip or not have traction.
◎ Do not drive in a gale, at night or in rainy/snowy/foggy/misty weather. These conditions
may cause you scooter to rust. (See Figure 2.4)
◎ Do not drive in a figure 8, S curve, do doughnuts or make sudden turns.
◎ Do not take an escalator.
Mobile Phones and Other Electric Equipment
◎ Do not use a mobile phone or other wireless communication devices while driving.
◎ Do not charge the mobile phone or other electric devices from your scooter's batteries.
Ramps, Inclines and Drops
◎ Do not drive onto a steep ramp. Refer to "Climbing Angle" in section 10.
SPECIFICATIONS for your scooter's safe climbing angle.
◎ When climbing up to an inclined road, please set the speed dial higher than "5"and
drive carefully. (See Figure 2.5)
◎ When going down an inclined road, set the speed dial to "1" and never use reverse.
◎ Do not drive on a road with many bumps and holes close to each other, such as
potholes or washboard roads. (See Figure 2.6) Refer to "Ground Clearance" in
section 10. SPECIFICATIONS.
◎ Do not cross a ditch wider than 5 inches as the wheels might get stuck. (See Figure
2.7)
◎ Please lower your speed when driving down a hill.
◎ Do not make sudden turns when driving on gravel roads or ramps.
◎ The maximum surmountable obstacle height is 10cm for KS-838 and KS-848 scooters.
◎ Exceeding this obstacle height will damage your scooter and negate your warranty.
(See Figure 2.8)
◎ When negotiating an obstacle slow down, put your seat into the full upright position
and approach it head on (perpendicular).
◎ Just before the obstacle, speed up until the entire scooter has conquered the obstacle.
Negotiating an obstacle at an angle may cause your scooter to tip over. Don't do it!
(See Figure 2.8)

4
◎ When climbing down a curb, slow down just before you get to it and only speed up after
the entire scooter has lowered to the road.
◎ Again, descending obstacles should be done perpendicularly. (See Figure 2.9)
◎ Karma does not design scooters to take jumps over or off obstacles. Doing so will
negate your warranty. (Invest in an ATV, wear a helmet and pads, at your own risk if
you desire being reckless with a motorized vehicle ;)
Maximum User Weight Limit
Refer to "Max. Capacity" in section 10. SPECIFICATIONS.
Loads exceeding maximum capacity can damage your scooter and cause malfunctions yielding a
safety hazard. The warranty does not cover damage caused by improper operation of the scooter.
Figure 2.4 Figure 2.5 Figure 2.6
Figure 2.7 Figure 2.8 Figure 2.9
Maximum User Weight Limit
Refer to "Max. Capacity" in section 10. SPECIFICATIONS.
Loads exceeding maximum capacity can damage your scooter and cause malfunctions yielding a
safety hazard. The warranty does not cover damage caused by improper operation of the scooter.
WARNNING：
◎ Do not set the scooter in freewheel mode when on an incline or decline.
◎ If you breakdown on railroad tracks, first, check for an oncoming train. If a train is
coming, get out of its way immediately! If no train is coming, set to freewheel mode
and push the vehicle off the tracks.

5
2.3 Labeling
Please carefully read all the labeling on the scooter before driving it. Do not remove them. Protect
them for future reference.
WARNNING
Do not operate the scooter unless the steering column is locked into position. Do not lean against
or pull forward on the handlebars while mounting or dismounting the scooter. Serious harm or
injury may occur.
WARNNING
Radio waves can influence the operation of motor driven vehicles.
Radio wave sources: broadcasting/TV stations and personal wireless telecommunication
equipment that transmits waves can affect the normal operation of the vehicle. Therefore, follow
the items below to lower the chance of abnormal vehicle operating conditions or brake system
failure, which may lead to injury.
Do not use personal telecommunication devices (for example, mobile phones or
walkie-talkies) when the power source of the electric powered vehicle has been
turned on.
Try to avoid locations that broadcast radio waves, such as TV stations or radio
stations.
If the electric vehicle acts abnormally or the brake system fails, turn off the power
source as soon as safely possible.
Remember that the installation of non-genuine KARMA parts makes it difficult to
predict what effects radio waves will have on the vehicle. (Note: it is not possible

6
to make a direct calculation how radio waves will influence the vehicle).
If the vehicle moves abnormally or the brake system fails after turning on the
power source under normal operating conditions, notify the manufacturer
immediately.
3. EMI/RFI
This section provides the user with basic information about the problems with EMI, known
sources of EMI and protective measures either to reduce the possibility of exposure or to
minimize the degree of exposure. This section also shows some conditions in which unexpected
or erratic scooter movements may occur.
CAUTION
It is very important that you read this information regarding the possible effects of
electromagnetic interference on your electric KARMA Scooter.
Electromagnetic Interference From Radio Wave Sources
Powered vehicles may be susceptible to electromagnetic interference (EMI), which is interfering
electromagnetic energy (EM) emitted from sources such as radio stations, TV stations, amateur
radio (HAM) transmitters, two-way radios, and cellular phones. The interference (from radio
wave sources) can cause the powered vehicle to release its brakes, move by itself, or move in
unintended directions. It can also permanently damage the powered vehicle's control system. The
intensity of the interfering EM energy can be measured in volts per meter (V/m). Each powered
vehicle can resist EMI up to a certain intensity. This amount of resistance is called its immunity
level. The higher the immunity level, the greater the protection. At this time, current technology
is capable of achieving at least a 20 V/m immunity level, which would provide useful protection
from the more common sources of radiated EMI. This powered vehicle model, with no further
modification, has an immunity level of 20 V/m without any accessories.
There are a number of sources of relatively intense electromagnetic fields in our everyday
environment. Some of these sources are obvious and easy to avoid. Others are not apparent and
exposure could be unavoidable. However, we believe that by following the warnings listed below,
your risk to EMI can be greatly minimized.
The sources of radiated EMI can be broadly classified into three types:
1. Hand-held portable transceivers (transmitter-receivers) with the antenna
mounted directly on the transmitting unit, such as citizens band (CB) radios,
walkie-talkies, security and fire or police transceivers, cellular telephones and
other personal communication devices;
NOTE:
Some cellular telephones or similar devices transmit signals while they are ON, even
though they are not in use.

7
2. Medium-range mobile transceivers used in police cars, fire trucks, ambulances
and taxis usually having the antenna mounted on the outside of the vehicle; and
3. Long-range transmitters and transceivers, such as commercial broadcast
transmitters (radio and TV broadcast antenna towers) and amateur (HAM) radios.
Powered Vehicle Electromagnetic Interference (EMI)
Because EM energy rapidly becomes more intense as one moves closer to the transmitting
antenna (source), the EM fields from hand-held radio wave sources (transceivers) are of special
concern. It is possible to unintentionally bring high levels of EM energy too close to the powered
vehicle's control system while using these devices. This can affect your powered vehicle's
movement and braking. Therefore, the warnings listed below are recommended to prevent
possible interference with the control system of the powered vehicle.
Warnings
Electromagnetic interference (EMI) from sources such as radio and TV stations, amateur radio
(HAM) transmitters, two-way radios and cellular phones can affect powered vehicles and
motorized scooters. Following the warnings listed below should reduce the chance of unintended
brake release or powered vehicle movement which could result in serious injury.
Do not operate hand-held transceivers-receivers such as citizens band (CB) radios
or turn ON personal communication devices such as cellular phones, while the
powered vehicle is turned ON.
Be aware of nearby transmitters, such as radio or TV stations, and try to stay away
from them.
If unintended movement or brake release occurs, turn the powered vehicle OFF as
soon as it is safe.
Be aware that adding accessories/components or modifying the powered vehicle
may make it more susceptible to EMI. There is no easy way to evaluate their
effect on the overall immunity of the powered vehicle.
Report all incidents of unintended movement or brake release to your powered
vehicle dealer or KARMA, and note whether there was a source of EMI nearby.
Important Information
20 Volts per meter (V/m) is a generally achievable and useful immunity level against
EMI (the higher the level, the greater the protection).
This product has an immunity level of 20 V/m without any accessories connected to
it.
NOTE:
Other types of hand-held devices (cordless phones, laptop computers, AM/FM radios, TV sets,
CD players, cassette players, and small appliances such as electric shavers and hair dryers, et
cetera) so far as we know, are not likely to cause EMI problems.

8
4. PARTS
Parts Description
1. Headrest
2. Backrest
3. Armrests
4. Driver's Seat
5. Slide & Swivel Levers
6. Rear Casing
7. Steering Column
Adjustment Lever
8. Recline Lever
9. Decorative Rear Casing
10. Floorboard
11. Rear View Mirrors
12. Emergency Brake
13. Handlebars
14. Upper Front Casing
15. Headlight
16. Front Casing
17. Turn Signals
18. Front Wheel(s)
(Figure 4.1)

9
19. Speed Dial
20.Variable Speed Levers
21. Circuit Breaker
22. Taillight
23. Decorative Taillight Casing
24. Anti-tippers
25. Freewheel Lever
26. Turn Signals
27. Bumper
28. Rear Wheels
29. Speed Switch
Figure 4.2
Figure 4.3

10
5. OPERATION
5.1 Control Panel
Battery & Diagnostics Indicator
Turn Signal Indicator
Headlight/Taillight Indicator
Turn Signal Buttons
Headlight/Taillight Button
Horn Button
Speed Dial
Variable Speed Levers
Speed Switch
Figure 5.1
5.2 How to Operate Your Scooter
Ignition
◎ Turn the key forward (clockwise) to turn your scooter ON.
◎ Turn the key toward yourself (counter-clockwise) to turn the scooter OFF. Make sure
you come to a complete stop before you turn the scooter OFF. (See Figures 5.2)
Figure 5.2 Figure 5.3

11
Speed Dial
Allows you to set various forward and reverse speeds. The settings are not traditional gears, but
are a percentage of maximum power. This is gross power, while the variable speed levers help
you to fine tune your speed and act similar to an accelerator.
Forward, Reverse and Braking
◎ Pull the right variable speed lever backward with your right hand to make the scooter
move forward.
◎ Pull the left variable speed lever backward with your left hand for the scooter to move
backward.
◎ A small speaker will "beep" when the vehicle is in reverse.
◎ If you release the variable speed lever while in forward or reverse, the electromagnetic
brake will be activated to stop the vehicle.
Turn Signal Buttons
◎ The signal light will flash and a small speaker will make a "beep-beep" sound if you
press either the right or left button.
◎ Press the button again to turn off the turn signal.
Horn Button
The horn will sound for the duration of time the button is pressed.
Headlight/Taillight Button
The headlight and taillight will be turned on when this button is pressed. Push the button again
and the lights will turn off.
Electromagnetic Brake
Release the variable speed lever completely and the electromagnetic brake will automatically
activate.
WARNING：
NEVER use the freewheel mode when going down an incline.
The electromagnetic brake won't function in freewheel mode.
Driver's Seat
◎ Lift up the swivel lever completely to rotate the
seat up to 90 degrees to either side.
◎ Lift up the slide lever completely to move the
seat forward or backward.
◎ Lift up the recline lever completely to recline or
raise the seat to the full upright position. The
recline lever also allows you to fold the seat
down.
Figure 5.4
