KEBCO COMBIVERT F5 User manual

COMBIVERT F5
ELEVATOR DRIVE
Version 1.72
00.F5.LUB-K172 REV 1D -09/2015

This instruction manual describes the COMBIVERT F5 ELEVATOR DRIVE. Before
working with the unit the user must become familiar with it. This especially applies to
the knowledge and observance of the following safety and warning indications. The
icons used in this instruction manual have the following meaning:
Danger Pay Attention Information
Discharge Time Important
Warning
Help
Caution Tip
i
The QR codes used in this instruction manual are
linked to the KEB America Youtube Channel. Video ex-
amples of general start-up procedures will be linked
to QR codes in this instruction manual.
Scan the QR code with the QR code reader on your
smart phone to access videos. For your phone to be
able to read QR codes you will need to download a
QR code scanning app from your mobile app store.
KEB America Youtube Channel URL: http://qrs.ly/vq4hd9q

Table of Contents
1. General .................................................... 9
1.1 Product description ........................................ .....9
1.2 Summary of Changes ................................... .....10
1.2.1 Functions................................................................. .....10
1.2.2 Parameters............................................................... .....10
1.3 Model number information.......................... .....11
1.4 Mounting instructions .................................. .....12
1.4.1 Classication ........................................................... .....12
1.4.2 Physical Mounting .................................................. .....12
1.4.3 Harsh Environments ....................................................12
1.5 Electrical connections.................................. .....13
1.4.4 Ambient Conditions................................................. .....13
1.5.1 Safety First ............................................................... .....13
1.5.2 Voltage Supply...............................................................13
1.5.3 Disconnect switch .................................................. .....14
1.5.4 Fusing ............................................................................14
1.5.5 Line Chokes.............................................................. .....15
1.5.6 Motor Thermal Protection........................................ .....16
1.5.7 Motor Cable Length ................................................. .....16
1.5.8 High Voltage Connections............................................17
1.5.9 Ground Connections ............................................... .....17
2. Technical Data....................................... 18
1.5.10 High Frequency Shielding ..........................................18
1.5.11 Storage of the Unit ................................................. .....19
2.1 Technical data 230V (size 13 to 21) ............. .....20
2.2 Technical Data 460V (Size 13 to 19)..................22
2.2 Technical Data 460V (Size 20 to 26) ............ .....24
2.3 Dimensions and weight ............................... .....25
2.4 Summary of the power circuit terminals .... .....26
2.5 Connection of the power circuit.................. .....27
2.6 Time dependent overload curve.................. .....29
2.7 Low Speed Overload ........................................30
3.0 Installation and Connection .............. 31
3.1 Control Circuit .................................................31
3.1.1 Terminal Strip Connections..........................................31
3.1.2 Connection of the control signals..............................32
3.1.3 Digital Inputs ................................................................32
3.1.4 Analog Inputs ...............................................................32
3.1.5 Voltage Input / External Power Supply ......................33
3.1.6 Digital Outputs .............................................................33
3.1.7 Relay Outputs...............................................................33
3.1.8 Analog Outputs ............................................................33
3.1.9 Voltage Output..............................................................33
3.2 Encoder Connections ................................. .....34
3.2.1 X3A RS422/TTL Incremental Encoder Input..............34
3.2.2 X3A TTL Inc. Enc. In Screw Terminals........................36
3.2.3 X3A Hiperface Encoder ..............................................38
3.2.4 X3A EnDat Encoder ....................................................42
3.2.5 X3A SIN/COS-SSI Encoder ........................................46
3.2.6 X3B Incremental Encoder Output ..............................50
4. Operation of the unit ........................... 52
4.1 Digital Operator ................................................52
4.2 Parameter Identication....................................53
4.3 Parameter Selection ..................................... .....53
4.4 Changing Parameter Values ........................ .....54
4.5 Parameter Structure ..................................... .....54
4.6 Saving Parameter Values ............................. .....55
4.7 Error Messages..................................................55
5. Initial Start-up ...................................... 56
5.1 Selecting The Conguration.............................56
5.2 Loading The Conguration...............................56
5.3 Setting The Control Type .............................. .....57
5.4 Entering The Operating Data ............................57
5.5 Induction Motors ...............................................57
5.5.1 Motor Overload .............................................................57
5.5.2 Induction Motor Data....................................................58
5.5.3 Auto-Tuning Induction Motors.....................................58
5.6 PM Synchronous Motors ............................. .....60
5.6.1 Motor Overload .............................................................60
5.6.2 Motor Data.....................................................................60
5.6.3 Auto-Tuning PM motors ...............................................61
5.7 Machine Data ................................................ .....62
5.8 Encoder Feedback.............................................63
5.8.1 Encoder card verication ............................................63
5.8.2 Encoder serial com. verication .................................63
5.8.3 Other encoder adjustments.........................................64
5.9 Controller Settings ............................................64
5.10 Speed and Prole Settings..............................65
5.11 Running the Motor ...................................... .....65
5.11.1 Stationary Pole Identication (SPI)............................65
5.11.2 Absolute Encoder Setup (no ropes) .........................67
5.11.3 Absolute Encoder Setup (with ropes) ......................69
5.11.4 Absolute Encoder Position Verication.....................71
5.11.5 Encoder Synchronization ...........................................72
5.12 High Speed Tuning ..................................... .....73
5.12.1 System Inertia Learn ..................................................73
5.12.2 Feed Forward Torque Control, FFTC .................... .....74
5.12.3 Speed Gain Adjustment .............................................75
5.12.4 Synthetic Pre-Torque..................................................79
6. Parameter Description......................... 81
6.1 US-Parameters...................................................81
Password................................................................................81
Load defaults .........................................................................81
Load conguration................................................................81
Select conguration..............................................................81
Other US parameters ............................................................82
6.2 LF-Elevator Parameters ....................................83
Signal / operating mode........................................................83
Drive conguration................................................................88
Selected motor.......................................................................89
Drive fault auto reset.............................................................89
Electronic motor overload protection..................................90
Electronic motor overload current .....................................91
Rated motor power................................................................92
Rated motor speed ................................................................92
Rated motor speed ................................................................93
Rated motor current ..............................................................93
Rated motor frequency .........................................................93
Rated motor voltage..............................................................94
Power factor ..........................................................................94
Field weakening speed..........................................................95
Rated motor torque ...............................................................96
PM motor resistance .............................................................97
PM motor inductance ...........................................................97
Contract speed ......................................................................98

Table of Contents
Traction sheave diameter......................................................98
Gear reduction ratio ..............................................................98
Roping ratio ...........................................................................99
Load weight............................................................................99
Estimated gear reduction .....................................................99
Encoder interface ................................................................100
Encoder pulse number........................................................104
Encoder channel swap / direction......................................104
Encoder sample time ..........................................................105
Control Mode .................................................................. .....106
Kp speed accel. .............................................................. .....107
Kp speed decel. .............................................................. .....107
Kp speed synthetic pretorque...................................... .....107
Ki speed accel......................................................................107
Ki speed decel. ............................................................... .....107
Ki speed synthetic pretorque ........................................ .....107
Ki speed ......................................................................... .....108
offset accel...................................................................... .....108
Ki speed ......................................................................... .....108
offset decel...................................................................... .....108
Maximum torque ............................................................. .....108
Max. torque emergency oper. ........................................ .....109
Open loop torque boost................................................. .....110
Switching frequency ...................................................... .....110
Leveling speed, S..................................................................111
High speed, S........................................................................111
Inspection speed, S..............................................................111
High leveling Speed ...................................................... .....111
Intermediate Speed 1 ..................................................... .....112
Intermediate Speed 2 ..................................................... .....112
Intermediate Speed 3 ..................................................... .....112
Starting jerk .................................................................... .....113
Acceleration .................................................................... .....113
Acceleration jerk............................................................. .....114
Deceleration jerk............................................................. .....114
Deceleration ................................................................... .....114
Approach jerk ................................................................. .....114
Stop jerk .......................................................................... .....114
Recommended Prole Settings..................................... .....117
Speed following error..................................................... .....118
Speed difference............................................................. .....118
Following error timer...................................................... .....118
Emergency operation mode .......................................... .....119
Emergency Terminal Slowdown Speed ........................ .....119
External Load Weigher ........................................................120
Pre-torque gain ............................................................... .....120
External Load Weigher Pre-torque offset ..........................120
External Load Weigher Pre-torque direction ....................120
Speed Start Delay................................................................121
Brake Release Delay............................................................121
Encoder resolution multiplier........................................ .....122
Absolute encoder position ............................................ .....122
Brake engage time.......................................................... .....123
Current hold time............................................................ .....123
Software version............................................................. .....124
Software date .......................................................................124
X2A Input state ....................................................................125
X2A Output state ................................................................127
Operation phase ..................................................................127
Inverter load ................................................................... .....128
Motor command speed .................................................. .....128
Actual motor speed .............................................................128
Actual elevator speed..................................................... .....128
Phase current.................................................................. .....129
Peak phase current ........................................................ .....129
Actual DC voltage ................................................................129
Peak DC voltage ..................................................................129
Actual output frequency ................................................ .....129
Last fault ..............................................................................129
Inverter status ................................................................. .....131
7.0 Run Parameters ........................................... .....132
Inverter state ........................................................................132
Set speed ........................................................................ .....132
Command speed ............................................................ .....132
Actual output frequency ................................................ .....132
Actual speed value ..............................................................132
Encoder 1 speed..................................................................132
Encoder 2 speed..................................................................132
Commanded torque........................................................ .....133
Actual torque................................................................... .....133
Actual load ...................................................................... .....133
Peak load......................................................................... .....133
Phase current.................................................................. .....133
Peak current.................................................................... .....133
Torque current .....................................................................133
DC bus voltage ....................................................................133
Peak DC bus voltage ..................................................... .....133
Output voltage .....................................................................134
Input terminal state .............................................................134
Input terminal state .............................................................134
Output terminal state ..........................................................134
Output ag state..................................................................135
Output status .......................................................................135
Active parameter set .................................................. .....135
Analog pattern raw ..............................................................135
Analog pattern processed ............................................. .....135
Analog pre-torque raw ................................................... .....136
Analog pre-torque processed........................................ .....136
Analog option raw .......................................................... .....136
Analog option processed ...................................................136
Analog Out 1 preamp ..................................................... .....136
Analog Out 1 post-amp.......................................................136
Analog Out 2 preamp ..................................................... .....136
Analog Out 2 post-amp.......................................................136
Motor pot..............................................................................137
value ....................................................................................137
Power module temperature.................................................137
Overload counter.................................................................137
Power on counter ........................................................... .....137
Run counter .........................................................................137
Modulation grade.................................................................137
Timer 1............................................................................. .....137
Timer 1............................................................................. .....137
Actual switching frequency ................................................137
Motor temperature .......................................................... .....138
Position counter ..................................................................138
Active Motor Power .............................................................138
Peak Motor Speed ...............................................................138
Magnetizing Current............................................................138
8.0 Advanced Adjustments ............................. .....139
E.OL2 function.....................................................................139
Synthetic Pre-torque Brake Release Timer....................140
Synthetic Pre-torque Hold Timer ................................. .....140
Max. speed for max. KI........................................................141
Speed for min KI..................................................................141
Speed dependent KP gain ............................................. .....142
Min KP gain at high speed..................................................142
KD speed gain ....................................................................142
Phase current check ...........................................................143
Analog input noise clamp...................................................143
HSP5 Watchdog time...................................................... .....143
E.dOH function ............................................................... .....143
Analog pattern gain.............................................................144
Reference splitting ..............................................................144
Serial Com. Baud Rate ................................................... .....144
Function Test........................................................................144
Encoder 2 ....................................................................... .....144
Output PPR ..................................................................... .....144
Analog Output 2 Conguration..........................................145

9.0 Input/Output Conguration ............. 146
9.1 Digital Input Parameters ............................ .....146
Input Type........................................................................ .....146
Noise Filter ...........................................................................146
9.2 Digital Output Parameters ......................... .....147
Output Inversion..................................................................147
Output X2A.18......................................................................147
Output X2A.19......................................................................147
Output X2A.24..26................................................................147
Output X2A.27..29 ........................................................... .....147
9.3 Timing Graph - Analog Control.................. .....149
9.4 Timing Graph - Digital Control................... .....151
10.1 Elevator Drive Data ................................... .....154
Field weakening...................................................................154
corner ...................................................................................154
Field weakening...................................................................154
curve.....................................................................................154
Stator resistance .................................................................155
Sigma inductance................................................................155
Rotor resistance ..................................................................155
Magnetizing inductance......................................................155
Motor control .......................................................................155
Vmax regulation...................................................................156
KP current ............................................................................156
KI current......................................................................... .....156
Acceleration torque .............................................................156
System inertia ................................................................. .....156
FFTC lter........................................................................ .....156
FFTC gain.............................................................................156
Torque command lter ................................................... .....156
11.0 Position Control............................... 157
11.1 One Floor Position Control....................... .....157
One oor positioning ..........................................................157
Learning the slow down distance ......................................159
Min. slowdown dist..............................................................160
Slowdown distance ........................................................ .....160
Correction distance.............................................................160
Current position.............................................................. .....162
Scaling increments high.....................................................162
Scaling increments low.................................................. .....162
Scaling distance ............................................................. .....162
12.1 Operation Problems.................................. .....163
12.2 Diagnostic Solutions................................ .....170
12.3 Drive Faults .............................................. .....174
A.1 Parameter List Reference.......................... .....190
A.2 Customer Parameter Values...................... .....194
Table of Contents

Protect Against
Accidental
Contact

AC motor controls and servo drives contain dangerous voltages which
can cause death or serious injury. During operation they can have live
"energized" un-insulated parts, moving parts, as well as hot surfaces.
Care should be taken to ensure correct and safe operation in order to
minimize risk to personnel and equipment.
All work involving this product, installation, start up as well as mainte-
nance may only be performed by qualied electrical technical person-
nel. According to this manual "qualied" means: those who are able to
recognize and acknowledge the possible dangerous conditions based
on their training and experience and those who are familiar with the
relevant standards and installation codes as well as the eld of power
transmission.
AC motor controls and servo drives must be protected against physical
damage during transport, installation, and use. Components or covers
must not be bent or deformed as this may decrease insulation distanc-
es inside the unit resulting in an unsafe condition. On receipt of the unit
visual damage should be reported immediately to the supplier. DO NOT
ATTEMPT TO POWER UP A UNIT WITH VISIBLE PHYSICAL DAMAGE.
This unit contains electrostatically sensitive components which can be
destroyed by in correct handling. For that reason, disassembly of the
unit or contact with the components should be avoided.
Before any installation and connection work can be done, the supply
voltage must be turned off and locked out. After turning off the supply
voltage, dangerous voltages may still be present within the unit as the
bus capacitors discharge. Therefore it is necessary to wait 5 minutes
before working on the unit after turning off the supply voltage.
The low voltage control terminal strip and communication ports are se-
curely isolated in accordance with EN50178. When connecting to other
systems, it is necessary to verify the insulation ratings of these sys-
tems in order to ensure the EN requirements are still met. When con-
necting the unit to a grounded delta power system, the control circuit
can no longer be classied as a "securely isolated circuit".
Before putting the motor control into operation be sure the connection
terminals are tight and all covers removed for installation have been
replaced.
The AC motor control or servo system can be adjusted to self initiate an
automatic restart in the event of a fault or error condition. The design
of the system must take this into account, such that personnel are safe
guarded against potentially dangerous circumstances.
Software functions in the AC motor control or servo system can be
used to control or regulate external systems. However, in the event of
failure of the motor control or servo system there is no guarantee these
software function(s) will continue to provide the desired level of con-
trol. As a result, when operator or machine safety is at stake, external
elements must be used to supplement or override the software function
within the AC motor control or servo system.
Danger to Life

Only Qualied
Personnel

Secure
Isolation

Note Capacitor
Discharge Time

Damage to
Property and In-
jury to Persons

Redundant Safety
Mechanisms

READ FIRST - SAFETY PRECAUTIONS

9
General
1. General
1.1 Product description
In selecting the COMBIVERT F5 series inverter, you have chosen a frequency
inverter with the highest quality and dynamic performance.
The F5 inverter has the following features:
- small mounting footprint
- large die IGBTs
- power circuit gives low switching losses
- low motor noise with high carrier frequency
- extensive protection for over- current, voltage and temperature
- voltage and current monitoring in static and dynamic operation
- short circuit proof and ground-fault proof
- noise immunity in accordance with IEC1000
- hardware current regulation
- integrated temperature controlled cooling fan
- PM motor control capable
- Synthesized-pre torque for roll back compensation
- CE compliant and cULus listed
- extensive functional capabilities
- DPC - Direct Position Control
- Stationary Pole Identication
This manual describes the frequency inverter COMBIVERT F5.
- 10 hp...60 hp 270A peak / 230V class
- 10 hp...175 hp 450A peak / 480V class
CPU Software version 4.2 or greater
Application Software Version 1.72
It is exclusively designed for smooth speed regulation of a
three-phase motor.
The operation of other electrical loads is forbidden and can lead to destruction of the unit.
R

10
The following parameters are new to software version 1.72. Each will
be described in more detail on the following pages.
US.37 Test Function
Ld.29 Acceleration Torque
P.LF.31 Proportional Pre-torque Gain
P.LF.32 Integral Pre-torque Gain
New Parameters
1.2.2 Parameters
1.2 Summary of Changes
Deleted Parameters The following parameters have been deleted from the parameter list.
Their function is either no longer required or has been moved to an-
other parameter.
US.19 Field Weakening Corner Speed - use Ld.18 same function
US.31 Proportional Pre-torque Gain - use P.LF.31 same function
US.32 Integral Pre-torque Gain - use P.LF.32 same function
LF.34 Proportional Current Gain - use Ld.27 same function
LF.35 Integral Current Gain - use Ld.28 same function
3.LF.26 Write Data from or to encoder
1.2.1 Functions The following functions are new. Each will be described in more detail
on the following pages.
RUN / STOP - LF.3 = RUN or STOP with serial communication
Static Pole Identication - LF.3 = SPI
Inertia Learn - LF.3 = I Lrn
External Load Weighing Pretorque - LF.30=3 congured without US.17,
US.18, P.LF.31, P.LF.32
General

11
1.3 Model number information
Part Number
General
15.F5.A1G-RL02
2 = software/function V1.72 / CPU v4.3
Unit identification 3 = peak power unit
0 = none installed at the factory
Feedback Card J = HTL input, TTL output
M = SINCOS, TTL output
F = HIPERFACE, TTL output
P = ENDAT, TTL output
V = Sin/Cos-SSI, TTL input
Z = UVW, TTL input
9 = UVW encoder, TTL output
Voltage ident. R = 460V 3 Phase
P = 230V 3 Phase
Housing type E, G, H, R, U,
Accessories 1 = Braking transistor (standard)
3 = Braking transistor and EMI filter
Control stage A = Appl- supports all motors in closed
loop speed, torque or position control.
Additionally can operate open-loop
induction motors
Unit Type F5
Unit size 14 = 10 hp 19 = 40 hp 24 = 125 hp
15 = 15 hp 20 = 50 hp 26 = 175 hp
16 = 20 hp 21 = 60 hp
17 = 25 hp 22 = 75 hp
18 = 30 hp 23 = 100 hp

12
General
1.4 Mounting instructions
1.4.1 Classication
The elevator drive is classied as an "Open Type" inverter with an IP20
rating and is intended for "use in a pollution degree 2 environment."
The unit must be mounted inside of a control cabinet offering proper
environmental protection.
1.4.2 Physical Mounting
Install the inverter in a stationary location offering a rm mounting point
with low vibration.
Installation of the inverter on a moving system may require special
earth ground connections to the inverter.
For best high frequency grounding, install the inverter on a bare metal
sub-panel, i.e. zinc plated steel or galvanized steel.
Take into consideration the minimum clearance distances when
positioning the inverter (see drawing below). The F5 series inverters
are designed for vertical installation and can be aligned next to each
other. Maintain a distance of at least 2 inches in front of the unit. Make
sure cooling is sufficient.
F5 F5 F5
F5
Cool air
Inlet
Warm air
outlet
F5
6.0" 6.0"
1.2"
4.0" 4.0"
Minimum distances
F5
1.4.3 Harsh Environments
For extended life, prevent dust from getting into the inverter.
When installing the unit inside a sealed enclosure, make sure the
enclosure is sized correctly for proper heat dissipation or that a cooling
system has been installed in the panel.
Protect the inverter against conductive and corrosive gases and
liquids. Water or mist should not be allowed into the inverter.
The F5 elevator drive inverter must be installed in an explosion-proof
enclosure when operating in an explosion-proof environment.


Direction of cooling fins

13
1.5.1 Safety First
CAUTION - RISK OF ELECTRIC SHOCK! Always disconnect supply volt-
age before servicing the F5 Elevator Drive.
After disconnecting the supply voltage, always wait 5 minutes before at-
tempting to change the wiring. The internal DC BUS capacitors must dis-
charge.
1.5.2 Voltage Supply
Pay attention to the supply voltage and be sure the supply voltage matches
that of the inverter. A 230V unit can be supplied with voltage in the range
180 to 260VAC +/-0%, for a 460V unit the range is 305 to 500VAC +/- 0%,
48Hz to 62 Hz.
All 240V models are suitable for use on a circuit capable of delivering not
more than ___ kA rms symmetrical amperes, 240 volts maximum when
protected by class ___ fuses rated ___ Amperes as specied in table 1.5.4.1
or when protected by a circuit breaker having an interrupt rating not less than
___ kA rms symmetrical amperes, 240V maximum, rated ___ amperes as
specied in table 1.5.4.1.
All 480V models are suitable for use on a circuit capable of delivering not
more than ___ kA rms symmetrical amperes, 480 volts maximum when
protected by class ___ fuses rated ___ Amperes as specied in table 1.5.4.2
or when protected by a circuit breaker having an interrupt rating not less than
___ kA rms symmetrical amperes, 480V maximum, rated ___ amperes as
specied in table 1.5.4.2.
1.4.4 Ambient Conditions
Maximum Surrounding Air Temperature 45°C! The operating temperature
range of the unit is -10°C to + 45°C (14°F to +113°F). Operation outside of
this temperature range can lead to shut down of the inverter.
The unit can be stored (power off) in the temperature range -25°C to 70°C
(-13°F to +158°F).
The power rating of the inverter must be derated for operation above 3,300
ft (1000 m). Reduce the rated power 1% for each additional 330 ft (100 m).
The maximum elevation for operation is 6,560 ft (2000 m).
The relative humidity shall be limited to 95% without condensation.
1.5 Electrical connections


General

14
General
Connection of the F5 series inverters to voltage systems congured as a
corner grounded delta, center tap grounded delta, open delta, or ungrounded
delta, may defeat the internal noise suppression of the inverter. Increased high
frequency disturbance in the controller and on the line may be experienced.
A balanced, neutral grounded wye connection is always recommended. The
three phase voltage imbalance must be less than 2% phase to phase. Greater
imbalance can lead to damage of the inverter's power circuit.
1.5.3 Disconnect switch
A disconnect switch or contactor should be provided as a means of turning off the
supply voltage when the unit is not in use or when it must be serviced.
Repetitive cycling on and off of the input supply voltage more than once every
two minutes can lead to damage of the inverter.
1.5.4 Fusing
Integral solid state short circuit protection does not provide branch circuit
protection. Branch circuit protection must be provided in accordance with the
Manufacturer Instructions, National Electrical Code (NFPA70 or CSA22.1) and
any additional local codes.
Branch circuit protection for the F5 must be provided using the fuses as listed in
the tables 1.5.4.1 and 1.5.4.2 below. Fast acting class J fuses are recommended.
As an example, use BUSSMANN type JKS. For installations supplied by an
isolation transformer and that have harmonic lters installed, a high speed
class J fuse must be used (only Ferraz type HSJ is approved).
The minimum voltage rating for protection devices used with 230V inverters shall
be 250VAC. The minimum voltage rating for protection devices used with 460V
inverters shall be 600VAC.

i
Table 1.5.4.1 - 230V Units
* Semiconductor fuses are manufactured by Siba Fuse Inc. When using this type of fuse,
this is the model number of the fuse is the fuse that must be used.
SCCR UL 248 Semiconductor UL 489
Unit Size /
Housing
[kA]
rms
Class J
Rating [A]
Fuse Number* /
Rating [A]
MCCB [A] /
Siemens Cat. No.
13 / E 10 40 50 140 06 80 / 80
14 / G 10 50 50 140 06 100 / 100
15 / G, H 10, 18 70 50 140 06 80 / 80
16 / H 18 90 - -
17 / H 18 110 - -
18 / R 100 125 - - 150A / DG-frame 3VL 150 UL
19 / R 100 150 - - 150A / DG-frame 3VL 150 UL
20 / R 100 175 - - 250A / FG-frame 3VL 250 UL
21 / R 100 200 - - 250A / FG-frame 3VL 250 UL


15
Fuses shall not be installed between the drive and the motor.
In PM motor applications where the drive input current can be lower than the
output current, it is allowed to use a protection device with a lower current rating
thus being able to optimize line side wiring and ancillary components.
If the controller / elevator drive is supplied through an individual isolation
transformer, the maximum fuse amp rating shall not be greater than 125% of the
secondary current rating of the transformer per NFPA70 and CSA 22.1. This
value may be signicantly lower than the values in the preceding tables.
1.5.5 Line Chokes
A line choke with minimum 3% impedance is required for all 230 V inverters 50hp
(size 20) and greater. A line choke with minimum 3% impedance is required for
all 480V inverters 100hp (size 23) and greater.
Table 1.5.4.2 - 480V Units

* Semiconductor fuses are manufactured by Siba Fuse Inc. When using this type
of fuse, this is the model number of the fuse is the fuse that must be used.
SCCR UL 248 Semiconductor UL 489
Unit Size /
Housing
[kA]
rms
Class J
Rating [A]
Fuse Number* /
Rating [A]
MCCB [A] /
Siemens Cat. No.
13 / E 10 25 50 140 06 40 / 40
14 / E 10 30 50 140 06 50 / 50
14 / G 10 30 50 140 06 80 / 80
15 / E 10 40 50 140 06 80 / 80
15 / G, H 10, 18 40 50 140 06 40 / 40
16 / G, H 10, 18 50 50 140 06 63 / 63
17 / G, H 10, 18 60 50 140 06 80 / 80
18 / H 18 70 50 140 06 80 / 80
19 / H 18 90 50 140 06 100 / 100
19 / R 100 90 - - 150A / DG-frame 3VL 150 UL
20 / H 18 100 - -
20 / R 100 100 - - 150A / DG-frame 3VL 150 UL
21 / R 100 150 - - 150A / DG-frame 3VL 150 UL
22 / R 100 175 - - 150A / DG-frame 3VL 150 UL
23 / R,U 100 200 - - 250A / FG-frame 3VL 250 UL
24 / R,U 100 225 - - 250A / FG-frame 3VL 250 UL
25 / U 100 275 - - 400A / JG-frame 3VL 400 UL
26 / U 100 300 - - 400A / JG-frame 3VL 400 UL
27 / U 100 350 - - 400A / JG-frame 3VL 400 UL
28 / U 100 400 - - 400A / JG-frame 3VL 400 UL
General


16
General
Installation of a line choke is recommended and can be used prevent nuisance
errors and protection caused by voltage spikes. Additionally, the use of a line
choke will double the operational lifetime of the DC bus capacitors in the unit.
1.5.6 Motor Thermal Protection
The F5 series inverters are UL approved as a solid state motor overload
protection device. It is necessary to adjust the current trip level in parameter LF.9
or LF.12. The function assumes the use of a non-ventilated motor. The function
meets the requirements set forth in VDE 0660 Part 104, UL508C section 42,
NFPA 70 Article 430 part C. See the description for parameter LF.9 for the trip
characteristics.
A motor winding sensor can also be used for additional safety and the highest
level of protection. Either a normally closed contact (rating: 15V / 6mA) or a
PTC (positive temperature coefficient) resistor can be connected to the T1, T2
terminals on the inverter. The thermal device should be connected as indicated
in Section 2.5.
1.5.7 Motor Cable Length
In some conventional installations and many MRL applications, the motor can
be a considerable distance (greater then 40 feet) from the elevator drive. Under
these circumstances the long cable length can cause high voltage peaks or high
dv/dt (rate of voltage rise) on the motor windings. Depending on the design of
the motor, these can lead to damage of the motor winding. Therefore, in these
installations use of a special dv/dt lter is highly recommended.
The standard approved solution is a special output choke. The choke is designed
to be used with a maximum of 16kHz switching frequency and low inductance so
it does not drastically inuence the motor's equivalent circuit model.
There are three sizes available for motors rated up to 100A. The part numbers
and current ratings are listed below.
Part Number Rated Current
15Z1F04-1005 22A
17Z1F04-1005 42A
21Z1F04-1005 100A
The use of a conventional line or motor choke on the output of the drive is not
recommend since the inductance value is high enough that it would distort the
values in the motor model and result in poor control of the motor.

17
