Kennedy DCS150 User manual

ABS DIGITAL CALIPERS
INSTRUCTION MANUAL
www.kennedy-tools.co.uk
MODEL ORDER CODE
DCS150 KEN-331-2260K
DCS200 KEN-331-2280K
DCS300 KEN-331-2320K
Features:
Comfortable to use
Knurled thumbwheel for precise movement
Large display for clarity
Fast response speed
Multi-use, Inside, Outside, Depth and Step measuring
Absolute and relative reading
Kennedy Tools continually strives to improve its products.
Specifications may change without prior notice.
KENNEDY TOOLS
Wigston, Leicester, England.
www.kennedy-tools.co.uk
Kennedy is a registered trade mark of The Kennedy Group Ltd.
QUALITY GUARANTEE & WARRANTY
KENNEDY TOOLS carry a one year manufacturers warranty.
KENNEDY TOOLS are designed & manufactured
to the highest standards & specifications.
Assuring the quality and performance required by all sectors of industry.
KENNEDY TOOLS are fully guaranteed against
faulty materials & workmanship.
Should they be found to be defective, they will either be repaired or replaced
free of charge (fair wear and tear and/or misuse excepted).
Please retain supplier invoice as proof of purchase.
© The Kennedy Group Ltd. 01/09
Always dispose of unwanted tools, accessories and packaging
materials in an environmentally friendly manner.
For EU and EEA countries only.
In observance of European Directive 2002/96/EC on Waste Electrical
and Electronic Equipment (WEEE) and its implementation in accordance
with national law, electrical goods that have reached the end of their life
must be collected separately and returned to an environmentally
compatible recycling facility.
Do not dispose of electrical goods with domestic waste materials as
inappropriate disposal may cause potential hazards to the environment
and human health.
For further information, please contact your local authority or the retailer
from whom you purchased the product.
This product does not contain any restricted substances in
concentrations and applications which are banned by the European
RoHS Directive.
TECHNICAL SPECIFICATIONS
Resolution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.0005”/0.01mm
Instrumental Error . . . . . . . . . . . . . . . . . . . . . . . . . . ±0.001”/±0.03mm
Repeatability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.0005”/0.01mm
Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . 1 x SR44 (EDI-904-4000K)
Battery Life . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.5 years
Operational Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . 0°C to 40°C
Storage Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . –10°C to 60°C
KEN-331-2260_2320K_Instructions.qxd 26/05/2009 08:58 Page 1

ABSOLUTE MEASUREMENT(ABS)
1. With ‘power-on’ the caliper is in ABS mode and displays a measurement
from zero.
RELATIVE MEASUREMENT
1. For taking repeated measurements relative to a proposed zero point.
2. Move the slider to the proposed zero point.
3. Press the REL button to set a false zero (REL will be displayed).
4. Measurements will now read ± from the chosen relative zero point.
5. During this operation, if you decide you want a reading from the absolute
zero simply press the REL button again to take reading.
6. You will then need to reset the chosen relative zero point.
FUNCTIONS/IDENTIFICATION
KENNEDY thoroughly recommends reading these instructions before
using the Digital Caliper, even if you have used one before. Reading these
instructions carefully and understanding them fully will enable you
to perform tasks correctly.
FITTING/REPLACING BATTERY
1. Insert the battery + side facing up. Inserting the battery upside down may
result in caliper failure.
2. If the display on the digital caliper does not show “0.00” after the battery
change, remove battery and insert again.
3. Your Kennedy caliper is supplied with one 1.5V silver oxide button cell
battery. Replace with either SR44 type, 357,SG13, 10L14 or 1154.
Dimensions: 11.6 x 5.4mm. ORDER CODE EDI-904-4000K
PREPARATION
1. When using the caliper for the first time after purchase, wipe away the
rust-preventive oil on the caliper with a soft cloth soaked in oil.
2. Install the supplied battery, by pressing and pushing the battery lid away
from the main body.
3. Before measuring, wipe the sliding surfaces and measuring faces to
remove dust and dirt.
4. Close the jaws and make sure that there is no light observed between
the jaws, if the caliper is not already reading “0.00mm” press the “ABS”
button once.
5. Please note that the digital caliper must be switched off after use and
should be kept in its original box.
1Outside measuring faces
2Step measuring faces
3Inside measuring faces
4Slider
5Clamping screw
6LCD display
7Main scale
8Depth bar
9Main beam
10 Battery lid
11 ON/OFF button
(for turning power on or off)
12 REL button
(for setting a false zero)
13 ABS button
(for setting absolute zero)
14 mm/inch conversion button
15 Slider thumb wheel
(for precise movement)
983
2
1
11 12 13 10 15
7
Battery, SR44 type, 357,
SG13, 10L14 OR L1154
4 6 5 14
TAKING
MEASUREMENTS
External Dimensions
Put the workpiece as close
to the reference surface as
possible, and have the
measuring faces firmly in
contact with the workpiece
without excessive force.
Depth Measurement
For depth measurement, set
the depth bar perpendicular
to the measured surfaces.
Internal Dimensions
For inside measurement,
put the inside jaws as deep
as possible and have the
measuring faces firmly in
contact with the workpiece
without excessive force.
Step Measurement
For step measurement,
have the step-measuring-
faces firmly in contact with
the workpiece.
