Kentec Electronics Sigma ZXT User manual

Man-1452EN Rev.02
Sigma ZXT Operation Manual
Extinguishant Release Panel
Sigma ZXT
Operation Manual
*MAN-1452EN*

Man-1452EN Rev.02
Sigma ZXT Operation Manual
Safety
Suppliers of articles for use at work are required under section 6 of the Health and Safety at Work Act 1974 to ensure
as reasonably as is practical that the article will be safe and without risk to health when properly used.
An article is not regarded as properly used if it is used ‘without regard to any relevant information or advice’ relating
to its use made available by the supplier.
This product should be installed, commissioned and maintained by trained service personnel in accordance with the
following:
(i) Regulations for electrical equipment in buildings specific to the country of use.
(ii) Codes of practice
(iii) Statutory requirements
(iv) Any instructions advised by the manufacturer.
According to the provisions of the Act you are therefore requested to take such steps as are necessary to ensure
that you make any appropriate information about this product available to anyone concerned with its use.
Suppliers of articles for use at work are required under section 6 of the Health and Safety at Work Act 1974 to ensure
as reasonably as is practical that the article will be safe and without risk to health when properly used.
An article is not regarded as properly used if it is used ‘without regard to any relevant information or advice’ relating
to its use made available by the supplier.
This product should be installed, commissioned and maintained by trained service personnel in accordance with the
following:
(i) IEE regulations for electrical equipment in buildings
(ii) Codes of practice
(iii) Statutory requirements
(iv) Any instructions specifically advised by the manufacturer
According to the provisions of the Act you are therefore requested to take such steps as are necessary to ensure
that you make any appropriate information about this product available to anyone concerned with its use.
This equipment is designed to operate at 230V AC 50/60Hz mains supplies, class 1 construction. As such it must
be connected to a protective earthing conductor in the fixed wiring of the installation and a readily accessible double
pole disconnect device meeting the requirements of EN60950/IEC950 which disconnects live and neutral simulta-
neously shall be incorporated in the fixed wiring.
Switch disconnect devices such as MK Sentry 63A or similar are suitable for this. Failure to ensure that all conduc-
tive accessible parts of this equipment are adequately bonded to the protective earth will render the equipment un-
safe.
This Control Panel is environmental class A and is designed for indoor use only at temperatures between -10°C and
+45°C with a maximum relative humidity of 95%. The IP rating for the enclosure is IP30.
Operation outside of these limits may render the equipment unsafe.

Man-1452EN Rev.02
Sigma ZXT Operation Manual
Compliance
Sigma ZXT is compliant with the following standards:
EN54-2 and EN54-4 Fire Detection and Fire Alarm Systems - Control and Indicating Equipment
In addition to the standard EN54-2 requirements the following options with requirements have been includ-
ed in the Control Panel:
Output to alarm devices to enable an audible warning to be sounded throughout the premises upon the detection of
a fire condition or the operation of a manual call point. EN54-2 Section 7.8.
Test condition to allow the automatic resetting of zones in alarm for testing purposes. EN54-2 Section 10.
Delay of the actioning of fire alarm devices (sounders) so that an alarm may be verified before a premise is evacu-
ated. EN54-2 Section 7.11
In addition to the requirements of EN54-2, Sigma ZXT Control Panels have a voltage free relay contact for fire which
operates upon a fire condition. This is to be used for local control and signalling.
EN12094-1 Fixed fire-fighting systems - Components for gas extinguishing systems - Part 1: Requirements and test
methods for electrical automatic control and delay devices.
In addition to the standard EN12094-1 requirements the following options with requirements have been in-
cluded in the Control Panel:
Delay of extinguishing signal of up to 60 seconds. EN12094-1 Section 4.17.
Signal representing the flow of extinguishing agent to indicate the released condition. EN12094-1 Section 4.18.
Monitoring of the status of components by way of a low pressure switch input. EN12094-1 Section 4.19.
Emergency hold device to enable the extinguishant delay time to be extended. EN12094-1 Section 4.20.
Control of flooding time to deactivate the releasing output after a set period of time. EN12094-1 Section 4.21.
Manual only mode to disable the release of extinguishant via automatic detection devices.EN12094-1
Section 4.23.
Extinguishing signals to spare cylinders enables the switching to a spare set of cylinders following a discharge to
return the system to a functional state. EN12094-1 Section 4.25.
Emergency Abort device to inhibit the extinguishing signal until the emergency abort device has been de-activated
and the Panel has been reset. EN12094-1 Section 4.27.
Activation of alarm devices with different signals to indicate pre-discharge and released warnings using different
sounds. EN12094-1 Section 4.30.
Default panel settings provide EN54-2 compliance:
BUZZER O/P: Enabled/Disabled This must be set to ENABLED.
MAINS FLT RLY DLY: OFF/30m This must be set to OFF.
FAULT RELAY: ENABLED/DISABLED This must be set to ENABLED.
FIRE RELAY: ENABLED/DISABLED. This must be set to ENABLED.
EARTH FAULT: ENABLED/DISABLED This must be set to ENABLED.
Important! Any deviation from these settings and compliance EN54-2 is void.

Man-1452EN Rev.02
Sigma ZXT Operation Manual
Disclaimer
In no event shall The Manufacturer be liable for any damages or injury of any nature or kind, no matter how caused,
that arise from the use of the equipment referred to in this manual. Strict compliance with the safety procedures set
out and referred to in this manual, and extreme care in the handling or use of the equipment, are essential to avoid
or minimise the chance of personal injury or damage to the equipment.
The information, figures, illustrations, tables, specifications, and schematics contained in this manual are believed
to be correct and accurate as at the date of publication or revision. However, no representation or warranty with re-
spect to such correctness or accuracy is given or implied and The Manufacturer will not, under any circumstances,
be liable to any person or corporation for any loss or damages incurred in connection with the use of this manual.
The information, figures, illustrations, tables, specifications, and schematics contained in this manual are subject to
change without notice.
Unauthorised modifications to the fire detection system or its installation are not permitted, as these may give rise
to unacceptable health and safety hazards.
Any software forming part of this equipment should be used only for the purposes for which The Company supplied
it. The user shall undertake no changes, modifications, conversions, translations into another computer language,
or copies (except for a necessary backup copy).In no event shall The Manufacturer be liable for any equipment mal-
function or damages whatsoever, including (without limitation) incidental, direct, indirect, special, and consequential
damages, damages for loss of business profits, business interruption, loss of business information, or other pecu-
niary loss, resulting from any violation of the above prohibitions.

Contents i
Man-1452EN Rev.02
Sigma ZXT Operation Manual
Section 1
Introduction ...................................................................................................................... 1
Section 2
Control Panel Operation .................................................................................................. 2
Manual Only Mode ..........................................................................................................................................2
Auto Mode .......................................................................................................................................................2
Zone Fire – Automatic Detection .....................................................................................................................3
Zone Fire – Manual mode ...............................................................................................................................3
1st Stage Extinguishant Release – Automatic Activation ................................................................................4
2nd Stage Extinguishant release – Automatic Activation ................................................................................4
Extinguishant Gas Released - Automatic ........................................................................................................5
2nd Stage Extinguishing Release – Manual Activation ...................................................................................5
Extinguishant Gas Released - Manual ............................................................................................................6
Fault Condition ................................................................................................................................................7
Disablements ..................................................................................................................................................8
Test Mode .......................................................................................................................................................9
Section 3
How to... ............................................................................................................................ 10
View Active Events ..........................................................................................................................................10
View Event Log ...............................................................................................................................................10
Put a Detection Zone Into Test Mode .............................................................................................................10
Disable a Detection Zone ................................................................................................................................11
Disable Extinguishant Release Output ............................................................................................................11
Disable Manual Release Function ..................................................................................................................11
Disable Relay Outputs ....................................................................................................................................12
Disable Sounder Outputs ................................................................................................................................12
Disable Monitored Inputs ................................................................................................................................12
Disable Panel Inputs .......................................................................................................................................12
Enable Sounder Delay ....................................................................................................................................13
Section 4
User Controls Overview ................................................................................................... 14
User Controls - Access Level 1 .......................................................................................................................14
User Controls - Access Level 2 .......................................................................................................................15
Notes ...............................................................................................................................................................16

Introduction 1
Man-1452EN Rev.02
Sigma ZXT Operation Manual
1
Section 1
Introduction
In accordance with BS5839 part 1; training on the operation of the Sigma ZXT Extinguishant Control Panel should
be provided to the end user as part of the commissioning and handover. In addition to training, the following docu-
ment provides a convenient reference point for Control Panel status indications, controls and actions.

Control Panel Operation 2
Man-1452EN Rev.02
Sigma ZXTOperation Manual
2
Section 2
Control Panel Operation
Manual Only Mode
Manual Only mode will prevent the release of extinguishant being activated by automatic detection devices. Panel
will indicate as follows:
• Mode key-switch will be in the Manual position
• Manual LED will be illuminated
• LCD will display panel status as Manual mode.
EXTINGUISHANT RELEASE CAN ONLY BE INSTIGATED BY MANUAL INTERVENTION
Auto Mode
In Auto mode extinguishant release can be instigated by either automatic detection devices or manual intervention:
• Mode key-switch will be in the Auto position
• Auto LED will be illuminated
• LCD will display panel status as Auto & Manual mode.
EXTINGUISHANT RELEASE CAN BE INSTIGATED BY AUTOMATIC DETECTION OR
MANUAL INTERVENTION
Reserve Selected
Released
Abort Operated
Hold Operated
Pre-activated/
Activated
Low Pressure
Flooding Zone
Fault / Disabled
Extinguishant
Disablement
Power On
Zone 1 Fire
Zone 2 Fire
Zone 3 Fire
Test
Buzzer Silenced
General
Disablement
Delay Active
General Fault
Power Fault
System Fault
Zone 1 Fault /
Disabled / Test
Zone 2 Fault /
Disabled/ Test
Zone 3 Fault /
Disabled / Test
Sounder Fault
Sounder Disabled
Auto Manual
Enable
Extract Fan On Manual Release
Alarm General Extinguishant Controls
Extinguishant Release
Manual
Pull Down - Push Button
