Kenwood KQL61 User manual

TYPE KQC51 (Chef)
TYPE KQL61 (Chef XL)
instructions
istruzioni
instrucciones
Bedienungsanleitungen
gebruiksaanwijzing
Instrukcja obsługi
instruções

English 2 - 11
Nederlands 12 - 21
Français 22 - 32
Deutsch 33 - 43
Italiano 44 - 54
Português 55 - 65
Español 66 - 76
Dansk 77 - 86
Svenska 87 - 96
Norsk 97 - 106
Suomi 107 - 117
Türkçe 118 - 127
Ïesky 128 - 138
Magyar 139 - 149
Polski 150 - 162
Ekkgmij 163 - 176
Slovenčina 177 - 187
Українська 188 - 200
´¸∂w
102 - 902

(2
(1
(7


(5
(4
(6b
(6a





(3


(8 (9





1




(1
(2




Know your Kenwood Kitchen Machine
Congratulations on buying a Kenwood. With such a wide range of attachments
available, it’s more than just a mixer. It’s a state-of-the-art Kitchen Machine. We
hope you’ll enjoy it.
Robust. Reliable. Versatile. Kenwood.
2
Safety
ORead these instructions carefully and retain for future
reference.
ORemove all packaging and any labels.
OIf the cord is damaged it must, for safety reasons, be replaced
by KENWOOD or an authorised KENWOOD repairer.
OTurn the speed control to ‘O’ OFF position and unplug before
fitting or removing tools/attachments, after use and before
cleaning.
OKeep your fingers away from moving parts and fitted
attachments.
ONever leave the Kitchen Machine unattended when it is
operating.
ONever use a damaged appliance. Get it checked or repaired:
see ‘service and customer care’ section.
ONever operate the Kitchen Machine with the head in the raised
position.
ONever let the cord hang down where a child could grab it.
ONever let the power unit, cord or plug get wet.
ONever use an unauthorised attachment or more than one
attachment at once.
ONever exceed the quantities stated in the maximum capacity
chart.
OWhen using an attachment, read and follow the safety
instructions that are supplied with it.
OTake care when lifting this appliance as it is heavy. Ensure the
head is correctly latched in the down position and that the
bowl, tools, outlet covers and cord are secure before lifting.
English

3
Before plugging in
• Make sure your electricity supply is
the same as the one shown on the
underside of your machine.
• This appliance conforms to EC
Regulation 1935/2004 on materials and
articles intended to come into contact
with food.
Before using for the first time
• Wash the parts: see ‘care and cleaning’
section.
OTake care when removing bowl tools after extended use as
they may get hot.
OEnsure the cord is fully unfolded from the cord storage
compartment (3 before using the Kitchen Machine.
OChildren should be supervised to ensure that they do not play
with the appliance.
ODo not move or raise the mixer head with an attachment fitted
as the Kitchen Machine could become unstable.
ODo not operate your appliance near the edge of a work
surface.
OAppliances can be used by persons with reduced physical,
sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and if they
understand the hazards involved.
OMisuse of your appliance can result in injury.
OThis appliance shall not be used by children. Keep the
appliance and its cord out of reach of children.
OThe maximum rating is based on the attachment that draws
the greatest load. Other attachments may draw less power.
OOnly use the appliance for its intended domestic use.
Kenwood will not accept any liability if the appliance is subject
to improper use, or failure to comply with these instructions.
English

4
Key
Attachment outlets
high-speed outlet
slow-speed outlet
bowl tool socket
Mixer
high speed outlet cover
mixer head
head release lever
mixer ready indicator light
on/off and speed control
power unit
(1 bowl
(2 slow speed outlet cover
(3 cord storage compartment
(4 K-beater
(5 whisk
(6adough hook (if supplied)
(6bspiral dough hook (if supplied)
(7 spatula
(8 head shield
(9 splashguard
Note: Spanner (2 shown is for illustration
purposes only and is not supplied in pack.
Optional attachments
There are a range of optional attachments
available to use with your Kitchen Machine.
See the attachment leaflet included in your
pack or visit www.kenwoodworld.com
to see the full range and how to buy an
attachment not included in your pack.
Note: Slow Speed outlet attachments
The slow speed outlet on your Kitchen
Machine model features the Twist
Connection System. It is designed
to accept Twist Connection System
attachments.
When purchasing new attachments
for the slow speed outlet you should
check compatibility with your Kitchen
Machine. All Twist Connection System
attachments can be identified by the
product code which starts with KAX and
also by the Twist logo which is visible
on packaging. For more information visit
www.kenwoodworld.com/twist.
If you own attachments featuring the Bar
Connection System you will need to
use the KAT002ME
adaptor to connect these to the Twist
Connection System on your Kitchen
Machine.
For more information visit
www.kenwoodworld.com/twist.
Know your Kitchen Machine
K-beater
For making cakes, biscuits, pastry, icing,
fillings, éclairs and mashed potato.
Whisk
For eggs, cream, batters, fatless sponges,
meringues, cheesecakes, mousses,
soufflés. Do not use the whisk for heavy
mixtures (e.g. creaming fat and sugar) -
you could damage it.
Dough Hook
For yeast mixtures only.
The bowl tools and some of their uses

5
To use your bowl tools
Ensure the cord is fully unfolded from the
cord storage compartment (3 before
using the Kitchen Machine.
1 Push the head-lift lever down and
raise the mixer head until it locks .
2 Fit the bowl on the base and turn
clockwise to secure in position .
3 Place the required tool into the socket.
Then push up and turn the tool to
lock into position.
Note: If the K-beater or Whisk are
not picking up ingredients from the
bottom of the bowl refer to the “Tool
Adjustment” section.
4 Lower the mixer head by pushing the
head release lever down and lower
the mixer head until it locks .
5 Plug into the power supply and the
‘mixer ready indicator light’ will illuminate.
6 Start the machine by turning the speed
control to the desired speed setting. Use
the pulse (P) position for short bursts of
maximum speed.
7 After use, return the speed control to ‘O’
OFF position and unplug your Kitchen
Machine.
8 Release the tool by turning clockwise
to unlock from the tool socket and then
remove.
Hints
• The fold function can be used for
folding light ingredients into heavier
mixtures for example meringues,
mousses, fruit fools, Genoese sponges
and soufflés, and to slowly incorporate
flour and fruit into cake mixtures. The
mixer will operate at a constant slow
speed.
Important
Ensure that no bowl tools are fitted or
stored in the bowl when using other
outlets.

6
Recommended Usage Chart
Tool Recipe/ Process Maximum Capacities
* (Minutes)
Hints and Tips
Chef Chef XL
K-beater Creaming butter/margarine and
sugar
2.72kg
(9 Egg mix)
4.55kg
(15 Egg
mix)
Min Max 4 • To avoid splashing of ingredients
gradually increase the speed.
• When creaming fat and sugar for
cake mixes, always use the fat at room temperature or soften it first.
• To fully incorporate the ingredients
stop mixing and scrape down the bowl with the spatula frequently.
• Use cold ingredients for pastry unless
your recipe says otherwise.
Beating eggs into cake mixes Min Max 1 – 4 Folding in flour, fruit etc Fold 130 – 60 secs Pastry & Biscuits – rubbing fat into flour
Flour Weight 680g 910g Min 12
All In one cake mixes
Total Weight 2kg 5kg Min Max 45 – 60 secs
Whisk Egg whites 12 (455g) 16 (605g) Min Max 1½ – 2 Important
• To avoid splashing of ingredients
gradually increase the speed.
• The whisk is not suitable for
making all in one cake mixes as these mixes are too heavy and will damage it.
• Best results achieved when eggs are
at room temperature.
• Before whisking egg whites, make
sure there is no grease or egg yolk on the whisk or the bowl.
Fatless sponges 620g
(6 Egg Mix)
930g
(9 Egg Mix)
4 – 6
Cream (Fresh whipping cream used, 38% fat content. Processing times may vary, depending on fat content of cream)
1L 2L Min 4-6 1½ – 3
Mayonnaise Egg yolk 2 Max 1 – 1½ • For best results scrape down the
bowl after the addition of the oil and run for a further 10 secs at max speed.
Mustard 10g Vegetable Oil 200ml
Pancake Batter Flour 250g
‘Min’ speed for
10 secs. Then
increase to
max speed for
45 – 60 secs
1 • Add flour to the bowl first, followed
by the wet ingredients.
• Mix on minimum speed to
incorporate ingredients.
Milk 500g Eggs 200g
Eggs sizes used = medium sized (Weight 53 – 63g) * This is for guidance only and will vary depending on the exact recipe and ingredients being processed
