INSTRUCTION MANUAL
FAW
KEPCO
KEPCO, INC. !"! 131-38 SANFORD AVENUE !" FLUSHING, NY. 11352 U.S.A.!!" TEL [phone]!!"!FAX [phone]!!
http://www.kepcopower.com "!email: [e-mail]
An ISO 9001 Company.
KEPCO SINGLE OUTPUT 15 WATT
HIGH FREQUENCY SWITCHING POWER SUPPLIES
I — INTRODUCTION
The Kepco FAW 15 Watt Series low profile high frequency switching power supplies employ flyback conversion and operate with a 70% efficiency with
either a-c or d-c input. A thermistor soft-start circuit limits start-up surge. Surface mount technology permits efficient component layout for minimum
mounting space. Four models may be selected for outputs of 5, 12, 15 or 24V. “POWER OK” logic and a green “POWER OK” light are provided. A steel
cover (Model CA 24) is available as an option. Output voltage may be adjusted with a trimmer accessible near the input-output terminal strip. When the
input is cut off, the output is maintained for 15 milliseconds minimum. EMI filtering meets FCC Class B rating and VDE 0871 Class B rating. This page
contains specifications for each model of the FAW 15 Watt Series. Environmental specifications for each model are the same.
II — SPECIFICATIONS
The following specifications apply to FAW 15 Watt Series models. Other models are also available; consult your Kepco representative for their specifi-
cations.
INPUT:
Voltage: 120V a-c/240V a-c nominal; Range 85-264V a-c; 110-370V d-c.
Frequency: Nominal 50-60 Hz; Range 47-440Hz (at 440Hz leakage current exceeds UL/VDE safety spec.limit).
Current (nominal output at rated load): @120V a-c rms: 0.3A typ., 0.4A max; @240V a-c rms: 0.2A typ., 0.3A max.
Initial Turn-on Surge: (one-half of first input cycle): @120V a-c rms, 22A max., @240V a-c rms, 34A max.
STABILIZATION:
Source Effect: Range 85-132V a-c or 170-264V a-c, 1.0% typ.; 2.0% max.
Load Effect: Range 10%-100% load, 1.0% typ.; 2.0% max.
Temperature Effect: Range 0oto 50oC, 1.0% typ.; 2.0% max.
Combined Effect: 2.6% typ.; 4.0% max. (includes source, load, and temperature effects).
Drift: 0.1% typ.; 0.5% max. (1/2 hr-8 hr at 25oC).
RECOVERY CHARACTERISTICS: A step load change from 50% to 100% produces less than +4% output excursion. Recovery occurs to within
+1% of the original setting in <2 ms (tr or tfequal to or greater than 50µsec at load change).
START-UP TIME: 500 ms. maximum.
HOLD-UP TIME: 15 ms. min (100V a-c), 20 ms. typ. (120V a-c).
DIELECTRIC STRENGTH:
Between input and output: 2KV a-c for one minute.
Between input and output with Y-capacitor removed: 3.75KV a-c for one minute.
Between input and case (ground): 2KV a-c for one minute.
INSULATION RESISTANCE: Between input and ground, output and ground, input and output;
100 Megohms min. (500V d-c).
TABLE 1. OUTPUT RATINGS AND SPECIFICATIONS, FAW 15W SERIES
MODEL FAW 5-3K FAW 12-1.3K FAW 15-1K FAW 24-0.7K
OUTPUT VOLTS, d-c (NOMINAL) 5V 12V 15V 24V
ADJUSTMENT RANGE 4.2-5.5V 10.8-13.2V 13.5-16.5V 21.6-26.4V
OUTPUT CURRENT (NOMINAL) 3.0A 1.3A 1.0A 0.7A
OUTPUT POWER (MAXIMUM) 15.0W 15.6W 15.0W 16.8W
RIPPLE
AND
NOISE
(mV p-p)
0-50°C
10-100% LOAD
source (typ) 10 20 20 30
source (max) 30 50 50 50
switching (typ) 15 10 10 20
switching (max) 30 30 30 50
spike noise (d-c—50MHz) 120 190 220 310
OVERVOLTAGE SETTING 25°C, NOM. INPUT 6.0-6.9V 13.7-15.7V 17.0-19.0V 27.0-30.5V
OVERCURRENT SETTING 25°C, NOM. INPUT 3.3-5.5A 1.4-2.5A 1.1-2.0A 0.8-1.4A

2228-1156 062599
KEPCO, INC. !"! 131-38 SANFORD AVENUE !" FLUSHING, NY. 11352 U.S.A.!!" TEL [phone]!!"!FAX [phone]!!
http://www.kepcopower.com "!email: [e-mail]
LEAKAGE CURRENT
(UL method, 120V a-c, 50-60Hz): 0.5 mA maximum.
(VDE method, 240V a-c): 0.75 mA maximum.
SAFETY: UL 478 recognized; CSA 1402B certified, VDE 0806, IEC 380 approved by TÜV Rheinland
“POWER OK” SIGNAL OUTPUT: The unit supplies a “POWER OK” logic 1 signal at CP51 (see Figure 2).
CONNECTOR TYPES: Refer to the Mechanical Outline Drawing. The mating connector for CP51 is a Panduit, P/N CT10F22-2: Cover, P/N
TC100F-2.
CONNECTOR KIT: Kepco furnishes an optional connector kit with the specified connector listed above. The kit may be ordered under Kepco
Model Kit P/N 518-0029. The connector is provided with 1 meter length leads for trimming to desired lengths.
EMI: Designed to meet FCC Class B (100-120V a-c) and VDE 0871 Class B (220-240V a-c).
VIBRATION: (non-operating, one hour on each one of the three axes):
5-10 Hz, 10 mm amplitude.
10-55 Hz, 2g acceleration.
SHOCK: (non-operating, one-half sinusoidal pulse, three shocks to each axis):
Acceleration: 20g
Duration: 11ms +5ms
OPERATING TEMPERATURE: See Figure 1.
STORAGE TEMPERATURE: -40oC to +75oC.
OPERATING AND STORAGE RELATIVE HUMIDITY: up to 95% (wet bulb temp. <35oC non-condensing).
FUSE: Quick acting 2A, 250V; (5.2 x 20mm), San-O P/N MT4 2A; Kepco P/N 541-0109.
WARRANTY: 1 year.
FIGURE 1. OUTPUT POWER RATING VS. AMBIENT TEMPERATURE FIGURE 2. “POWER OK” SIGNAL RELATED TO OUTPUT
3040229/1161

062599 228-1156 3
KEPCO, INC. !"! 131-38 SANFORD AVENUE !" FLUSHING, NY. 11352 U.S.A.!!" TEL [phone]!!"!FAX [phone]!
http://www.kepcopower.com "!email: [email protected]
POSSIBLE MOUNTING CHOICES
30400550

4228-1156 062599
KEPCO, INC. !"! 131-38 SANFORD AVENUE !" FLUSHING, NY. 11352 U.S.A.!!" TEL [phone]!!"!FAX [phone]!
http://www.kepcopower.com "!email: [email protected]
MECHANICAL OUTLINE DRAWING
CM17960
