INSTRUCTION MANUAL
Product images may vary slightly from actual product.
54" Bead LED

KICHLER.COM

TABLE OF CONTENTS
SAFETY RULES …………………………………………………………………………....4
TOOLS REQUIRED …………………………..………………………………..………...5
PACKAGE CONTENTS ……………….....................……………………………....5
MOUNTING OPTIONS ………….................................................................6
HANGING THE FAN ……………………………………………………………………...7
INSTALLATION OF SAFETY SUPPORT …………................................8
ELECTRICAL CONNECTIONS…………..................................................9
FINISHING THE MOTOR INSTALLATION….....................................10
ATTACHING THE FAN BLADES…......................................................…11
INSTALLING THE SWITCH HOUSING…........................................….11
INSTALLING THE LIGHT KIT AND GLASS..............................……..12
OPERATING INSTRUCTIONS …………………………...........……………... 15
TROUBLESHOOTING …………………………..................………………………16
FCC INFORMATION ......………………………………………………………..........17
54" Bead LED | 3

4 | KICHLER.COM
SAFETY RULES
READ AND SAVE THESE INSTRUCTIONS
CAUTION – RISK OF SHOCK – Disconnect Power at
the main circuit breaker panel or main fuse box before
starting and during the installation.
WARNING:WARNING: This fixture is intended for installation in
accordance with the National Electrical Code (NEC) and
all local code specifications. If you are not familiar with
code requirements, installation by a certified electrician is
recommended.
WARING:WARING: To reduce the risk of fire or electric shock, use
only the control provided with the fan.
WARNING:WARNING: To reduce the risk of fire, electric shock, or
Personal Injury, mount directly to a structural framing
member or to an outlet box marked “Acceptable For
Fan Support of 15.9kg(35 lbs) or less”. For outlet box
mounting, use mounting screws provided with the outlet
box.
WARNING:WARNING: Chemical Burn Hazard. Keep batteries away
from children. This remote contains a lithium button cell
battery. If a new or used lithium button/coin cell battery is
swallowed or enters the body, it can cause severe internal
burns and can lead to death in as little as 2 hours. Always
completely secure the battery compartment. If the
battery compartment does not close securely, stop using
the product, remove the batteries, and keep it away from
children. If you think batteries might have been swallowed
or placed inside any part of the body, seek immediate
medical attention. Dispose of cells properly and keep
away from children. Even used cells may cause injury.
WARNING:WARNING: Do not operate reversing switch while fan
blades are in motion. Fan must be turned off and blades
stopped before reversing blade direction.
1.
2.
3.
4.
5.
6.
Avoid placing objects in the path of the blades.
To avoid personal injury or damage to the fan and other
items, be cautions when working around or cleaning the
fan.
Make sure the installation site you choose allows a
minimum clearance of 7 feet from the blades to the floor
and at least 30 inches from the ends of the blades to any
obstruction.
Do not use water or detergents when cleaning the fan or
fan blades. A dry dust cloth or lightly dampened cloth will
be suitable for most cleaning.
After making the electrical connections, spliced
conductors should be turned upward and pushed carefully
up into outlet box. The wires should spread apart with the
ground wire and white(common) wire to one side with the
black (load) wire to the other side of the outlet box.
Electrical diagrams are for reference only. Light kits that
are not packed with fan must be ETL Listed and marked
suitable for use with the model fan you are installing.
Switches must be ETL General Use Switches. Refer to the
instructions packaged with the light kits and switches for
proper assembly.
7.
8.
9.
10.
11.
12.
WARNING
TO REDUCE THE RISK OF PERSONAL INJURY. DO NOT BEND
THE BLADE BRACKETS (ALSO REFERRED TO AS FLANGES)
DURING ASSEMBLY OR AFTER INSTALLATION. DO NOT
INSERT OBJECTS IN THE PATH OF THE BLADES.

TOOLS REQUIRED
PACKAGE CONTENTS
Phillips screwdriver
Blade screwdriver
11 mm wrench
Step ladder
Wire cutters
Unpack your fan and check the contents . You should have the following items:
A. Motor Assembly
B. Fan Blade (3)
C. Switch Housing
D. Light Kit
E. Glass
F. Remote Control Kit
G. Package hardware
1) Mounting hardware :
Wire Connector (3)
2)Blade attachment hardware :
Screws (9) , Washers (9)
3) Safety cable hardware :
Wood screw (1) ,Spring washer (1),
Flat washer (1)
A
C
D
E
B
G
54" Bead LED | 5
F
X6
X2 X2
X2 X2
X2 X2

6 | KICHLER.COM
MOUNTING OPTIONS
If there isn’t an existing UL (cUL for Canadian Installation ) listed
mounting box, then read the following instructions. Disconnect the
power by removing fuses or turning o circuit breakers.
Secure the outlet box directly to the building structure. Use
appropriate fasteners and building materials. The outlet box and its
support must be able to fully support the full weight of the fan (up to
50 lbs). Do not use plastic outlet boxes.
Figure 1 and 2 are examples of dierent ways to mount the outlet box.
NOTE:NOTE: Depending on the location you have selected for installation,
you may need to purchase and install a “Joist Hanger” for the support
of the outlet box. Make sure the joist hanger you purchase has been
designed for use with ceiling fans. (Fig.3)
Outlet box
Fig. 2
Fig. 3
Fig. 1
Outlet box
Outlet box

HANGING THE FAN
REMEMBERREMEMBER to turn off the power before you begin installation. This is
necessary for your safety and also the proper programming of the control
system. To properly install your ceiling fan, follow the steps below.
Step 1.Step 1. Loosen two (one of each across) of the four screws from the ceiling
mounting bracket, and remove the other two and keep for later use, then
release the ceiling mounting bracket from the motor assembly. (Fig. 4)
Step 2.Step 2. Before attaching fan to outlet box (not included), ensure the outlet
box is securely fastened to at least two points to a structural ceiling member
(a loose box will cause the fan to wobble). Pass the 120 volt supply wires from
the ceiling outlet box through the center of the ceiling mounting bracket.
Install mounting bracket to outlet box in ceiling using the screws and washers
included with the outlet box. (Fig. 5)
Step 3.Step 3. Hook the motor body onto the ceiling mounting bracket as shown.
You can now proceed with the electrical wiring of your fan. (Fig. 6)
Fig. 4
Fig.6
Fig. 5
54" Bead LED | 7
Ceiling Mounting
Bracket
Listed Outlet Box
Ceiling Mounting Bracket
Flat Washer
Screw
Hook
Motor Assembly
Motor Assembly
Motor
Assembly

8 | KICHLER.COM
INSTALLATION OF SAFETY SUPPORT
(required for Canadian installation ONLY)
A safety support cable is provided to help prevent the ceiling fan from failing,A safety support cable is provided to help prevent the ceiling fan from failing,
please install it as follows.please install it as follows.
Step 1.Step 1. Drive a wood screw and washers into the side of the brace that holdsDrive a wood screw and washers into the side of the brace that holds
the outlet box. Leave 3mm (1/8") of space between the support brace andthe outlet box. Leave 3mm (1/8") of space between the support brace and
the washer. (Fig. 7)the washer. (Fig. 7)
Step 2.Step 2. Insert the safety cable through the mounting bracket and one of theInsert the safety cable through the mounting bracket and one of the
holes in the outlet box into the ceiling. Adjust the length of the safety cableholes in the outlet box into the ceiling. Adjust the length of the safety cable
to reach the screw and washers by pulling the extra cable through the cableto reach the screw and washers by pulling the extra cable through the cable
clamp until the overall length is correct, put the end of the cable back throughclamp until the overall length is correct, put the end of the cable back through
the cable clamp, forming a loop at the end of the cable. Tighten the cablethe cable clamp, forming a loop at the end of the cable. Tighten the cable
clamp securely. Now, put the loop in the end of the safety cable over theclamp securely. Now, put the loop in the end of the safety cable over the
wood screw and under the washer. Tighten the wood screw securely.wood screw and under the washer. Tighten the wood screw securely.
(Fig. 8)(Fig. 8)
NOTE:NOTE: Although the safety support cable is required for CanadianAlthough the safety support cable is required for Canadian
installations only. It’s a good idea to make the attachment with anyinstallations only. It’s a good idea to make the attachment with any
installation.installation.
Flat Washer
Support Brace
Wood screw
Spring Washer
Safety Cable
Bolt Wood Screw
Outlet Box
Ceiling
Fig. 7
Fig. 8

54" Bead LED | 9
MAKE THE ELECTRICAL CONNECTIONS
WARNING:WARNING: To avoid possible electrical shock, be sure you have turned offTo avoid possible electrical shock, be sure you have turned off
the power at the main circuit panel before wiring. Follow the steps belowthe power at the main circuit panel before wiring. Follow the steps below
to connect the fan to your household wiring. Use the wire connecting nutsto connect the fan to your household wiring. Use the wire connecting nuts
supplied with your fan. Secure the connector with electrical tape. Make suresupplied with your fan. Secure the connector with electrical tape. Make sure
there are no loose wire stands or connections.there are no loose wire stands or connections.
WARNING:WARNING: If your house wires are different colors than referenced in thisIf your house wires are different colors than referenced in this
manual, stop immediately. A professional electrician is recommended tomanual, stop immediately. A professional electrician is recommended to
determine proper wiring.determine proper wiring.
Step 1.Step 1. Insert the receiver into the motor assembly, and keep flat in oppositionInsert the receiver into the motor assembly, and keep flat in opposition
of ceiling. (Fig. 9)of ceiling. (Fig. 9)
Step 2.Step 2. Motor to Receiver Electrical Connections: Connect the BLACKMotor to Receiver Electrical Connections: Connect the BLACK
wire from the fan to BLACK wire marked "TO MOTOR L" from the receiver.wire from the fan to BLACK wire marked "TO MOTOR L" from the receiver.
Connect the WHITE wire from the fan to the WHITE wire marked "TO MOTORConnect the WHITE wire from the fan to the WHITE wire marked "TO MOTOR
N" from the receiver. Connect the BLUE wire from the fan to the BLUE wireN" from the receiver. Connect the BLUE wire from the fan to the BLUE wire
marked "FOR LIGHT" from the receiver. Secure all the wire connections withmarked "FOR LIGHT" from the receiver. Secure all the wire connections with
the plastic wire connectors provided. (Fig. 10)the plastic wire connectors provided. (Fig. 10)
Step 3.Step 3. Remote Receiver to Outlet Box Electrical Connections: Connect theRemote Receiver to Outlet Box Electrical Connections: Connect the
BLACK (hot) wire from the ceiling to the BLACK wire marked "AC IN L" fromBLACK (hot) wire from the ceiling to the BLACK wire marked "AC IN L" from
the receiver. Connect the WHITE (Neutral) wire from the ceiling to the WHITEthe receiver. Connect the WHITE (Neutral) wire from the ceiling to the WHITE
wire marked "AC IN N" from the receiver. Secure all the wire connections withwire marked "AC IN N" from the receiver. Secure all the wire connections with
the plastic wire connectors provided. (Fig. 10)the plastic wire connectors provided. (Fig. 10)
Receiver
Motor Assembly
Outlex box
White
Green or bare copper (ground)
White("AC IN N")
White("TO MOTOR N")
Ground wire
White(Neutral)
Black
Black("AC IN L")
Black ("TO MOTOR L"
Black (motor)
Blue(FOR LIGHT)
Blue(for light)
Fig. 9
Fig. 10

10 | KICHLER.COM
MAKE THE ELECTRICAL CONNECTIONS
FINISHING THE MOTOR INSTALLATION
Step 4.Step 4. If your outlet box has a ground wire (green or bare copper) connectIf your outlet box has a ground wire (green or bare copper) connect
it to the fan ground wires : otherwise connect the fan ground wire to theit to the fan ground wires : otherwise connect the fan ground wire to the
mounting bracket. Secure the wire connection with a plastic nut provided.mounting bracket. Secure the wire connection with a plastic nut provided.
After connecting the wires, spread them apart so that the green and whiteAfter connecting the wires, spread them apart so that the green and white
wires are on one side of the outlet box and black and blue wires are on thewires are on one side of the outlet box and black and blue wires are on the
other side.other side.
NOTE:NOTE: Carefully tuck the wire connections up into the outlet box.Carefully tuck the wire connections up into the outlet box.
NOTE:NOTE: Fan must be installed at a maximum distance of 30 feet from theFan must be installed at a maximum distance of 30 feet from the
transmitting unit for proper signal transmission between the transmittingtransmitting unit for proper signal transmission between the transmitting
unit and the fan’s receiving unit.unit and the fan’s receiving unit.
Step 1.Step 1. Remove the motor assembly from the hook of the ceiling mountingRemove the motor assembly from the hook of the ceiling mounting
bracket and push up the motor assembly until the two screws on the ceilingbracket and push up the motor assembly until the two screws on the ceiling
mounting bracket are engaged with the slot holes on the canopy of themounting bracket are engaged with the slot holes on the canopy of the
motor assembly. Rotate the motor assembly slightly until the two screwmotor assembly. Rotate the motor assembly slightly until the two screw
heads are in the slot holes. Install the two screws previously removed andheads are in the slot holes. Install the two screws previously removed and
tighten all four screws. (Fig. 11)tighten all four screws. (Fig. 11)
Step 2.Step 2. Push the canopy trim ring up until it locks into place at the top of thePush the canopy trim ring up until it locks into place at the top of the
canopy. (Fig. 12)canopy. (Fig. 12)
Fig. 11
Fig. 12
Canopy Trim Ring

Step 1.Step 1. Insert the blade through the slot on the motor housing, align theInsert the blade through the slot on the motor housing, align the
holes on the blade and blade bracket, secure with the screws and washersholes on the blade and blade bracket, secure with the screws and washers
provided. Repeat process with the other blades. (Fig. 13)provided. Repeat process with the other blades. (Fig. 13)
Step 1.Step 1. Remove the screw marked with a dot label on the mounting plate andRemove the screw marked with a dot label on the mounting plate and
save for later use, and slightly loosen the other two screws. Attach the switchsave for later use, and slightly loosen the other two screws. Attach the switch
housing to mounting plate using the two key slots in the switch housing.housing to mounting plate using the two key slots in the switch housing.
Replace the previously removed screw and securely tighten all 3 screws. (Fig.Replace the previously removed screw and securely tighten all 3 screws. (Fig.
14)14)
54" Bead LED | 11
ATTACHING THE FAN BLADES
INSTALLING THE SWITCH HOUSING
Fig. 13
Fig. 14
Blade
Washer
Screw
Mounting Plate
Switch Housing

12 | KICHLER.COM
INSTALLING THE LIGHT KIT AND GLASS
NOTE:NOTE: Before continuing installation, confirm that the power is still turned oBefore continuing installation, confirm that the power is still turned o
at the main circuit breaker or by removing the circuit fuse. Turning the powerat the main circuit breaker or by removing the circuit fuse. Turning the power
o using a wall switch is not sucient to prevent electrical stock.o using a wall switch is not sucient to prevent electrical stock.
Step 1.Step 1. Hold the light kit close to the switch housing and connect the WHITEHold the light kit close to the switch housing and connect the WHITE
wires from the light kit and fan by pushing the connectors together. Followwires from the light kit and fan by pushing the connectors together. Follow
the same procedure with the BLACK wires. (Fig. 15)the same procedure with the BLACK wires. (Fig. 15)
Step 2.Step 2. Tuck the connections neatly into the light kit. Remove one of threeTuck the connections neatly into the light kit. Remove one of three
screws pre-installed on the switch housing and keep for later use. Loosen thescrews pre-installed on the switch housing and keep for later use. Loosen the
other two (do not remove). Place the two slot holes on the light kit over the 2other two (do not remove). Place the two slot holes on the light kit over the 2
screws previously loosened from the switch housing. Rotate the light kit untilscrews previously loosened from the switch housing. Rotate the light kit until
it locks in place at the narrow end of the key holes. Secure by tightening the 2it locks in place at the narrow end of the key holes. Secure by tightening the 2
screws previously loosened and the one previously removed. (Fig. 15)screws previously loosened and the one previously removed. (Fig. 15)
Step 3.Step 3. Secure the glass to light kit assembly and twist clockwise. Do notSecure the glass to light kit assembly and twist clockwise. Do not
over-tighten.(Fig. 16)over-tighten.(Fig. 16)
Fig. 15
Fig. 16
Light Kit
Glass

54" Bead LED | 13
OPERATING INSTRUCTIONS
Step 1.Step 1. Select a location to install your handset control holder, you couldSelect a location to install your handset control holder, you could
install the holder as shown. (Fig. 17)install the holder as shown. (Fig. 17)
Step 2.Step 2. Remove the battery cover from the handset control by screwdriver.Remove the battery cover from the handset control by screwdriver.
(Fig.26)(Fig.26)
Step 3.Step 3. To make fan operational, install two 3V CR2032 batteries (included).To make fan operational, install two 3V CR2032 batteries (included).
(Fig. 19)(Fig. 19)
WARNING:WARNING: Chemical Burn Hazard. Keep batteries away from children.Chemical Burn Hazard. Keep batteries away from children.
NOTE:NOTE: If not used for long periods of time, remove batteries to preventIf not used for long periods of time, remove batteries to prevent
damage to the handset control. Store the control away from excessive heatdamage to the handset control. Store the control away from excessive heat
or humidity.or humidity.
Fig. 17
Fig. 18
Fig. 19
D
O
L
E
A
R
N
CR2032 3V
CR2032 3V
D
O
L
E
A
R
N
Battery Cover
Batteries

14 | KICHLER.COM
NOTE:NOTE: Each handset control carries a unique ID code to facilitate communication betweenEach handset control carries a unique ID code to facilitate communication between
paired devices. The ID code is set by factory and is not user changeable. However, you will bepaired devices. The ID code is set by factory and is not user changeable. However, you will be
required to perform an "ID code learning" process manually under these circumstances:required to perform an "ID code learning" process manually under these circumstances:
∙If you have multiple fans install within a close proximity and want to control all fans using a∙If you have multiple fans install within a close proximity and want to control all fans using a
same handset control.same handset control.
NOTE:NOTE: Each fan requires its own receiver.Each fan requires its own receiver.
∙When your remote control is not responding(make sure battery is not flat)∙When your remote control is not responding(make sure battery is not flat)
∙After you have replaces a faulty transmitter or receiver with a new one.∙After you have replaces a faulty transmitter or receiver with a new one.
Otherwise the remote control will not work. To perform this process manually, follow stepsOtherwise the remote control will not work. To perform this process manually, follow steps
below:below:
After installing and wiring the unit, restore power to your fan, press and hold the LEARN keyAfter installing and wiring the unit, restore power to your fan, press and hold the LEARN key
for 1~3 seconds, the fan will turn on at medium speed and light (if installed) will turn on. Thisfor 1~3 seconds, the fan will turn on at medium speed and light (if installed) will turn on. This
confirms that the learning process have been completed. This operation must be completedconfirms that the learning process have been completed. This operation must be completed
within 30 seconds after restore power to the fan. (Fig. 20)within 30 seconds after restore power to the fan. (Fig. 20)
NOTE:NOTE: If the fan has fluorescent lighting, slide to "O" position. If the fan is with incandescent orIf the fan has fluorescent lighting, slide to "O" position. If the fan is with incandescent or
halogen lighting or LED, slide to "D" position. Factory set is on "D" position. (Fig. 20)halogen lighting or LED, slide to "D" position. Factory set is on "D" position. (Fig. 20)
Step 4.Step 4. Replace the battery cover and tighten with screwdriver. (Fig. 20)Replace the battery cover and tighten with screwdriver. (Fig. 20)
Step 5.Step 5. The buttons control the fan speed and light as follows: (Fig. 21)The buttons control the fan speed and light as follows: (Fig. 21)
D
O
D
O
L
E
A
R
N
CR20323V CR20323V
L
E
A
R
N
Fig. 20
Fig. 21
Battery Cover
Screw
OPERATING INSTRUCTIONS
Low speedLow speed
Medium speedMedium speed
High speedHigh speed
Fan OFFFan OFF
a.) Light ON/ OFF.a.) Light ON/ OFF.
b.) Press and hold to dim or brighten light to desired levelb.) Press and hold to dim or brighten light to desired level

54" Bead LED | 15
Fig. 22
REV switch: Controls direction, forward or reverse. (Fig. 22)REV switch: Controls direction, forward or reverse. (Fig. 22)
WARNING:WARNING: do not operate reversing switch while fan blades are in motion.do not operate reversing switch while fan blades are in motion.
Fan must be turned o and blades stopped before reversing blade direction.Fan must be turned o and blades stopped before reversing blade direction.
OPERATING INSTRUCTIONS
Fig. 23 Fig. 24
Warm Weather Operation:Warm Weather Operation: Forward (counter clockwise). A downward airflowForward (counter clockwise). A downward airflow
creates a cooling eect (Fig.23). This allows you to set your air conditioner oncreates a cooling eect (Fig.23). This allows you to set your air conditioner on
a warmer setting without aecting your general comfort.a warmer setting without aecting your general comfort.
Cool Weather Operation:Cool Weather Operation: Reverse (clockwise). An upward airflow movesReverse (clockwise). An upward airflow moves
warm air o the ceiling areas (Fig.24). This allows you to set your heating unitwarm air o the ceiling areas (Fig.24). This allows you to set your heating unit
on a cooler setting without aecting your general comort.on a cooler setting without aecting your general comort.

16 | KICHLER.COM
TROUBLESHOOTING
ProblemProblem
Fan will not start.Fan will not start.
Fan sounds noisy.Fan sounds noisy.
Fan wobble.Fan wobble.
Remote controlRemote control
malfunction.malfunction.
SolutionSolution
1. Check circuit fuses or breakers.1. Check circuit fuses or breakers.
2. Check all electrical connections to ensure proper contact.2. Check all electrical connections to ensure proper contact. CAUTION:CAUTION: Make sure the main power is OFF when checkingMake sure the main power is OFF when checking
any electrical connection.any electrical connection.
3. Make sure the transmitter batteries are installed properly. Positive (+) side facing out.3. Make sure the transmitter batteries are installed properly. Positive (+) side facing out.
4. Ensure the batteries have a good charge.4. Ensure the batteries have a good charge.
1. Make sure all motor housing screws are snug.1. Make sure all motor housing screws are snug.
2. Make sure the screws that attach the fan blade brackets to the motor are tight.2. Make sure the screws that attach the fan blade brackets to the motor are tight.
3. Make sure wire nut connections are not rubbing against each other or the interior wall of the switch housing.3. Make sure wire nut connections are not rubbing against each other or the interior wall of the switch housing.
CAUTION:CAUTION: Make sure main power is o.Make sure main power is o.
4. Allow a 24-hour "breaking-in" period. Most noise associated with a new fan disappears during this time.4. Allow a 24-hour "breaking-in" period. Most noise associated with a new fan disappears during this time.
5. If using an optional light kit, make sure the screws securing the glassware are tight. Make sure the light bulbs are not5. If using an optional light kit, make sure the screws securing the glassware are tight. Make sure the light bulbs are not
touching any other component.touching any other component.
6. Do not connect this fan to a wall mounted variable speed control(s). They are not compatible with ceiling fan motors or6. Do not connect this fan to a wall mounted variable speed control(s). They are not compatible with ceiling fan motors or
remote controls.remote controls.
7. Make sure the upper canopy has a short distance from the ceiling. It should not touch the ceiling.7. Make sure the upper canopy has a short distance from the ceiling. It should not touch the ceiling.
1. Check that all blade and blade arm screws are secure.1. Check that all blade and blade arm screws are secure.
2. Most fan wobbling problems are caused when blade levels are unequal. Check this level by selecting a point on the ceiling2. Most fan wobbling problems are caused when blade levels are unequal. Check this level by selecting a point on the ceiling
above the tip of one of the blades. Measure this distance. Rotate the fan until the next blade is positioned for measurement.above the tip of one of the blades. Measure this distance. Rotate the fan until the next blade is positioned for measurement.
Repeat for each blade. The distance deviation should be equal within 1/8".Repeat for each blade. The distance deviation should be equal within 1/8".
3. If the blade wobble is still noticeable, interchanging two adjacent (side by side) blades can redistribute the weight and3. If the blade wobble is still noticeable, interchanging two adjacent (side by side) blades can redistribute the weight and
possibly result in smoother operation.possibly result in smoother operation.
1.Ceiling Fans with remote control systems CAN NOT be operated in conjunction with any other control system EXCEPT a1.Ceiling Fans with remote control systems CAN NOT be operated in conjunction with any other control system EXCEPT a
basic On/o wall switch, if desired.basic On/o wall switch, if desired.

54" Bead LED | 17
FCC Information
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
1.)This device may not cause harmful interference, and
2.)This device must accept any interference received, including interference that may cause undesired operation.
Note:Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician or help.

www.kichler.com
KICHLER LIGHTING
7711 EAST PLEASANT VALLEY ROAD
CLEVELAND, OHIO 44131-8010
CUSTOMER SERVICE 866.558.5706
8:00 AM TO 5:00 PM EST, MONDAY - FRIDAY
© Kichler Lighting LLC. All Rights Reserved.

MANUEL D’INSTRUCTION
Les images du produit pourraient légèrement varier par rapport au produit réel.
54" Bead LED

KICHLER.COM
