INSTRUCTION MANUAL
Model#: 300322
Product images may vary slightly from actual product.
52" Compass LED

2 | KICHLER.COM
TABLE OF CONTENTS
SAFETY RULES …………………………………………………………………………....3
TOOLS REQUIRED …………………………..………………………………..………...4
PACKAGE CONTENTS ……………….....................……………………………...4
MOUNTING OPTIONS ………….................................................................5
HANGING THE MOTOR ASSEMBLY…………………………………………..6
ELECTRICAL CONNECTIONS…………..................................................9
FINISHING THE MOTOR INSTALLATION ………..….........................10
ATTACHING THE FAN BLADES ………………………….......................... 11
INSTALLING THE LIGHT PLATE ASSEMBLY……………..................12
INSTALLING THE LIGHT KIT AND ACRYLIC SHADE…….............13
OPERATING INSTRUCTIONS …………………………...........…………........14
TROUBLESHOOTING …………………………..................………………...……16
FCC INFORMATION......………………………………………………………...........17

52" Compass LED | 3
SAFETY RULES
READ AND SAVE THESE INSTRUCTIONS
CAUTIONCAUTION – RISK OF SHOCK –
Disconnect Power at the main circuit breaker panel or
main fuse box before starting and during the installation.
WARNING:WARNING: This fixture is intended for installation in
accordance with the National Electrical Code (NEC) and
all local code specifications. If you are not familiar with
code requirements, installation by a certified electrician is
recommended.
WARING:WARING: To reduce the risk of fire or electric shock, use
only the control provided with the fan.
WARNING:WARNING: To reduce the risk of fire, electric shock, or
Personal Injury, mount directly to a structural framing
member or to an outlet box marked “Acceptable For Fan
Support of up to 22.6kg(50 lbs)”. For outlet box mounting,
use mounting screws provided with the outlet box.
WARNING:WARNING: Do not operate reversing switch while fan
blades are in motion. Fan must be turned off and blades
stopped before reversing blade direction.
Avoid placing objects in the path of the blades.
To avoid personal injury or damage to the fan and other
items, be cautions when working around or cleaning the
fan.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
Make sure the installation site you choose allows a
minimum clearance of 7 feet from the blades to the floor
and at least 30 inches from the ends of the blades to any
obstruction.
Do not use water or detergents when cleaning the fan or
fan blades. A dry dust cloth or lightly dampened cloth will
be suitable for most cleaning.
After making the electrical connections, spliced
conductors should be turned upward and pushed carefully
up into outlet box. The wires should spread apart with the
ground wire and white(common) wire to one side with the
black (load) wire to the other side of the outlet box.
Electrical diagrams are for reference only. Light kits that
are not packed with fan must be ETL Listed and marked
suitable for use with the model fan you are installing.
Switches must be ETL General Use Switches. Refer to the
instructions packaged with the light kits and switches for
proper assembly.
WARNING
TO REDUCE THE RISK OF PERSONAL INJURY. DO NOT
BEND THE BLADES DURING ASSEMBLY OR AFTER
INSTALLATION. DO NOT INSERT OBJECTS IN THE PATH
OF THE BLADES.

4 | KICHLER.COM
TOOLS REQUIRED
PACKAGE CONTENTS
Phillips screwdriver
Blade screwdriver
11 mm wrench
Step ladder
Wire cutters
Unpack your fan and check the contents . You should have the following items:
A. Mounting bracket
B. Ball / downrod assembly
C. Canopy
D. Canopy Hole Cover
E. Coupling Cover
F. Motor Body
G. Fan Blade (5)
H. Light Plate Assembly
I. Light Kit
J. Acrylic Shade
K .Remote Control Kit:
Remote Control (1)
Receiver (1)
Battery (1)
Wire Connectors (6)
Handset Control Holder (1)
L. Package hardware
1) Mounting hardware :
Wire Connector (3)
2)Blade attachment hardware :
Screws(15), Flat washer (15)
A
G
I
L
K
J
B
C
D
E
F
H

52" Compass LED | 5
MOUNTING OPTIONS
If there is not an existing UL (cUL for Canadian Installation ) listed
mounting box, then read the following instructions. Disconnect the
power by removing fuses or turning o circuit breakers.
Secure the outlet box directly to the building structure. Use
appropriate fasteners and building materials. The outlet box and its
support must be able to fully support the full weight of the fan (up to
50 lbs). Do not use plastic outlet boxes.
Figure 1, 2 and 3 are examples of dierent ways to mount the outlet
box.
NOTE:NOTE: If you are installing the ceiling fan on a sloped (vaulted) ceiling,
you may need a longer downrod to maintain proper clearance
between the tip of the blade and the ceiling. A minimum clearance of
12” is suggested for optimal operation.
NOTE:NOTE: Depending on the location you have selected for installation,
you may need to purchase and install a “Joist Hanger” for the support
of the outlet box. Make sure the joist hanger you purchase has been
designed for use with ceiling fans. (Fig.4)
Outlet box
ANGLED CEILING
MAXIMUM 18° ANGLE Provide strong
support
Ceiling
mounting
plate
Recessed
Outlet box
Fig. 2
Fig. 4
Fig. 3
Fig. 1
Outlet box
Outlet box

6 | KICHLER.COM
HANGING THE MOTOR ASSEMBLY
REMEMBERREMEMBER to turn off the power before you begin installation. This is
necessary for your safety and also the proper programming of the control
system. To properly install your ceiling fan, follow the steps below.
Step 1.Step 1. Before attaching fan to outlet box (not included), ensure the outlet box
is securely fastened to at least two points to a structural ceiling member
(a loose box will cause the fan to wobble). Install the screws and washers
included with the outlet box. NOTE:NOTE: Do not lock the screws completely, just
lock half.
Pass the 120 volt supply wires form the ceiling outlet box through the center
of the ceiling mounting bracket.(Fig. 5)
Step 2.Step 2. Align the slot holes on the mounting bracket with the screws, and
push the mounting bracket to the screws, then tighten the screws. (Fig. 6
and 7)
Fig. 5
Fig. 6
Fig. 7
Outlet Box
Washer
Screw
Mounting Bracket

52" Compass LED | 7
HANGING THE MOTOR ASSEMBLY
Step 3.Step 3. Remove the hairpin and clevis pin from the downrod assembly, retain
for later use.(Fig.8)
Step 4.Step 4. Loosen the two set screws on the motor coupling.(Fig. 9)
Step 5.Step 5. Place the coupling cover, canopy hole cover and canopy over the
coupling found on the top of the motor assembly. Carefully feed fan wires
from the motor assembly through the downrod, then insert the downrod into
the coupling.(Fig.10)
Fig. 10
Set Screw
Downrod
Canopy
Canopy Hole Cover
Coupling Cover
Coupling
Clevis Pin
Hair pin
Fig. 9
Fig. 8

8 | KICHLER.COM
HANGING THE MOTOR ASSEMBLY
Step 6.Step 6. Insert the clevis pin through the downrod and coupling found on the
motor assembly, and secure with the hair pin. Tighten set screws found on
the coupling. (Fig. 11 )
Step 7.Step 7. Now lift the motor body into position and place the hanger ball into
the mounting bracket. Rotate until the "Check Tab" has dropped into the
"Registration Slot" and seats firmly. (Fig. 12) The entire motor body should
not rotate if this is done correctly.
WARNING:WARNING: Failure to properly seat the "Check Tab" can damage the ceiling
fan during operation.
Fig. 12
Fig. 11
Hairpin
Clevis Pin
Set Screw
Coupling
OK NO
Registration Slot
Mounting Bracket
Hanger Ball Check Tab

52" Compass LED | 9
ELECTRICAL CONNECTIONS
WARNING:WARNING: To avoid possible electrical shock, be sure you have turned offTo avoid possible electrical shock, be sure you have turned off
the power at the main circuit panel before wiring. Follow the steps belowthe power at the main circuit panel before wiring. Follow the steps below
to connect the fan to your household wiring. Use the wire connecting nutsto connect the fan to your household wiring. Use the wire connecting nuts
supplied with your fan. Secure the connector with electrical tape. Make suresupplied with your fan. Secure the connector with electrical tape. Make sure
there are no loose wire stands or connections.there are no loose wire stands or connections.
WARNING:WARNING: If your house wires are different colors than referenced in thisIf your house wires are different colors than referenced in this
manual, stop immediately. A professional electrician is recommended tomanual, stop immediately. A professional electrician is recommended to
determine proper wiring.determine proper wiring.
Step 1.Step 1. Insert the receiver into the mounting bracket, and keep flat inInsert the receiver into the mounting bracket, and keep flat in
opposition of ceiling.Cut o excess fixture wires approximately 6 to 9 inchesopposition of ceiling.Cut o excess fixture wires approximately 6 to 9 inches
above top of the downrod assembly. Strip insulation o 1/2 in. from the end ofabove top of the downrod assembly. Strip insulation o 1/2 in. from the end of
each fixture wire. (Fig. 13)each fixture wire. (Fig. 13)
Step 2.Step 2. Motor to Receiver Electrical Connections: Connect the BLACKMotor to Receiver Electrical Connections: Connect the BLACK
wire from the fan to BLACK wire marked "TO MOTOR L" from the receiver.wire from the fan to BLACK wire marked "TO MOTOR L" from the receiver.
Connect the WHITE wire from the fan to the WHITE wire marked "TO MOTORConnect the WHITE wire from the fan to the WHITE wire marked "TO MOTOR
N" from the receiver. Connect the BLUE wire from the fan to the BLUE wireN" from the receiver. Connect the BLUE wire from the fan to the BLUE wire
marked "FOR LIGHT" from the receiver. Secure all the wire connections withmarked "FOR LIGHT" from the receiver. Secure all the wire connections with
the plastic wire connectors provided. (Fig. 14)the plastic wire connectors provided. (Fig. 14)
Step 3.Step 3. Remote Receiver to Outlet Box Electrical Connections: Connect theRemote Receiver to Outlet Box Electrical Connections: Connect the
BLACK (hot) wire from the ceiling to the BLACK wire marked "AC IN L" fromBLACK (hot) wire from the ceiling to the BLACK wire marked "AC IN L" from
the receiver. Connect the WHITE (Neutral) wire from the ceiling to the WHITEthe receiver. Connect the WHITE (Neutral) wire from the ceiling to the WHITE
wire marked "AC IN N" from the receiver. Secure all the wire connections withwire marked "AC IN N" from the receiver. Secure all the wire connections with
the plastic wire connectors provided. (Fig. 14)the plastic wire connectors provided. (Fig. 14)
Fig. 13a Fig. 13b
Fig. 14
Receiver Mounting Bracket
Green or bare copper (ground)
AC IN N(White)
AC IN L(Black)
Black ("AC IN L") White("AC IN N")
White("TO MOTOR N")
Ground wire
Ground wire
White (Neutral)
Receiver
Black ("TO MOTOR L")
Black (motor)
Blue(FOR LIGHT)
Blue(for light)
6 to 9 in.

10 | KICHLER.COM
ELECTRICAL CONNECTIONS
FINISHING THE MOTOR INSTALLATION
Step 4.Step 4. If your outlet box has a ground wire ( green or bare copper ) connectIf your outlet box has a ground wire ( green or bare copper ) connect
it to the fan ground wires : otherwise connect the fan ground wire to theit to the fan ground wires : otherwise connect the fan ground wire to the
mounting bracket. Secure the wire connection with a plastic nut provided.mounting bracket. Secure the wire connection with a plastic nut provided.
After connecting the wires, spread them apart so that the green and whiteAfter connecting the wires, spread them apart so that the green and white
wires are on one side of the outlet box and black and blue wires are on thewires are on one side of the outlet box and black and blue wires are on the
other side. (Fig. 14)other side. (Fig. 14)
NOTE:NOTE: Carefully tuck the wire connections up into the outlet box.Carefully tuck the wire connections up into the outlet box.
NOTE:NOTE: Fan must be installed at a maximum distance of 30 feet from theFan must be installed at a maximum distance of 30 feet from the
transmitting unit for proper signal transmission between the transmittingtransmitting unit for proper signal transmission between the transmitting
unit and the fan’s receiving unit.unit and the fan’s receiving unit.
Step 1.Step 1. Remove one of the two shoulder screws in the mounting bracket.Remove one of the two shoulder screws in the mounting bracket.
Loosen the second shoulder screw without fully removing it. (Fig. 15)Loosen the second shoulder screw without fully removing it. (Fig. 15)
Step 2.Step 2. Assemble canopy by rotating key slot in canopy over shoulderAssemble canopy by rotating key slot in canopy over shoulder
screw in mounting bracket. Reinstall the shoulder screw that was previouslyscrew in mounting bracket. Reinstall the shoulder screw that was previously
removed, then retighten two shoulder screws securely. (Fig.16)removed, then retighten two shoulder screws securely. (Fig.16)
Fig. 15
Fig. 16
Canopy
Shoulder Screw
Shoulder Screw
Mounting Bracket

52" Compass LED | 11
FINISHING THE MOTOR INSTALLATION
ATTACHING THE FAN BLADES
Step 3.Step 3. Securely attach and tighten the canopy hole cover over the shoulderSecurely attach and tighten the canopy hole cover over the shoulder
screws in the mounting bracket utilizing the keyslot twist-lock feature. (Fig.17)screws in the mounting bracket utilizing the keyslot twist-lock feature. (Fig.17)
NOTE:NOTE: Before continuing, make sure the power is disconnected by turningBefore continuing, make sure the power is disconnected by turning
o the circuit breaker or removing the fuse at the circuit box.o the circuit breaker or removing the fuse at the circuit box.
Step 1.Step 1. Insert the blade through the slot on the motor housing, as shown,Insert the blade through the slot on the motor housing, as shown,
secure with the screws and washers provided. Repeat process with the othersecure with the screws and washers provided. Repeat process with the other
blades. (Fig. 18)blades. (Fig. 18)
Fig. 17a Fig. 17b
Fig. 18
Canopy
Hole
Cover
Blade

12 | KICHLER.COM
Fig. 19
Fig. 20
Screw
Screw
Mounting Plate
Light Plate Assembly
INSTALLING THE LIGHT PLATE ASSEMBLY
Step 1.Step 1. Remove one of three screws which preinstalled on mounting plate andRemove one of three screws which preinstalled on mounting plate and
keep for later use, loosen the other two (do not remove). (Fig. 19)keep for later use, loosen the other two (do not remove). (Fig. 19)
Step 2.Step 2. Place the two slot holes on the light plate assembly over the 2 screwsPlace the two slot holes on the light plate assembly over the 2 screws
previously loosened from the mounting plate. Rotate the light plate assemblypreviously loosened from the mounting plate. Rotate the light plate assembly
until it locks in place at the narrow end of the key holes, secure by tighteninguntil it locks in place at the narrow end of the key holes, secure by tightening
the 2 screws previously loosened and the one previously removed. (Fig. 20)the 2 screws previously loosened and the one previously removed. (Fig. 20)

52" Compass LED | 13
Fig. 21
Fig. 23
Fig. 22
INSTALLING THE LIGHT KIT AND ACRYLIC SHADE
NOTE:NOTE: Before continuing installation, confirm that the power is still turned oBefore continuing installation, confirm that the power is still turned o
at the main circuit breaker or by removing the circuit fuse. Turning the powerat the main circuit breaker or by removing the circuit fuse. Turning the power
o using a wall switch is not sucient to prevent electrical stock.o using a wall switch is not sucient to prevent electrical stock.
Step 1.Step 1. Remove three screws on the light plate assembly and keep for laterRemove three screws on the light plate assembly and keep for later
use. (Fig. 21)use. (Fig. 21)
Step 2.Step 2. Hold the light kit close to the light plate assembly and connect theHold the light kit close to the light plate assembly and connect the
9-pin connector together. Note: The two connectors have keyholes that9-pin connector together. Note: The two connectors have keyholes that
must be mated correctly before they can be engaged. (Fig. 22)must be mated correctly before they can be engaged. (Fig. 22)
Step 3.Step 3. Tuck the connections neatly into light kit, then attach the light kit toTuck the connections neatly into light kit, then attach the light kit to
light plate assembly and securely tighten with three screws removed on steplight plate assembly and securely tighten with three screws removed on step
1.(Fig. 23)1.(Fig. 23)
Step 4Step 4. Secure the acrylic shade to light plate assembly by twisting in a. Secure the acrylic shade to light plate assembly by twisting in a
clockwise direction, twist the acrylic shade gradually until it snaps on to theclockwise direction, twist the acrylic shade gradually until it snaps on to the
light plate assembly. Do not over - tighten. (Fig. 23)light plate assembly. Do not over - tighten. (Fig. 23)
Light Plate Assembly
9-Pin Connector
Light Plate Assembly
Screw
Light Kit
Acrylic Shade

14 | KICHLER.COM
Remote Control
Fig. 26
Fig. 25
Fig. 24
Fig. 27
OPERATING INSTRUCTIONS
Restore electrical power to the outlet box by turning the electricity on theRestore electrical power to the outlet box by turning the electricity on the
main fuse box.main fuse box.
Step 1.Step 1. Select a location to install your handset control holder, install theSelect a location to install your handset control holder, install the
holder as shown. (Fig. 24)holder as shown. (Fig. 24)
Step 2.Step 2. Remove remote battery door, connect 9V battery (included) with plugRemove remote battery door, connect 9V battery (included) with plug
pressing the battery inside and replace the battery door. (Fig. 25)pressing the battery inside and replace the battery door. (Fig. 25)
NOTE:NOTE: If not used for long periods of time, remove battery to preventIf not used for long periods of time, remove battery to prevent
damage to remote control. Store remote control away from excessive heatdamage to remote control. Store remote control away from excessive heat
and humidity.and humidity.
NOTE:NOTE: There are 16 combinations of code for setting up the remote control.There are 16 combinations of code for setting up the remote control.
If you do not use the dip switch set up by manufacturer, then you will need toIf you do not use the dip switch set up by manufacturer, then you will need to
use the set up procedures listed below.(Fig. 26)use the set up procedures listed below.(Fig. 26)
a.)Set up the code combination you would like to use.a.)Set up the code combination you would like to use.
b.)After installing the unit and restoring power to the fan, press and hold theb.)After installing the unit and restoring power to the fan, press and hold the
“Light” button until the light flashes (on/off) 3 times, then the control and“Light” button until the light flashes (on/off) 3 times, then the control and
speed setting process is completed. You must pres the “Light” button withinspeed setting process is completed. You must pres the “Light” button within
30 seconds of restoring power to the fan.30 seconds of restoring power to the fan.
c.)If programming is unsuccessful, retry the above instructions.c.)If programming is unsuccessful, retry the above instructions.
Step 3.Step 3. The buttons control the fan speed and light as follows:(Fig. 27)The buttons control the fan speed and light as follows:(Fig. 27)
3 Low speed3 Low speed
2 Medium speed2 Medium speed
1 High speed1 High speed
0 To turn o the fan0 To turn o the fan
Press light key quickly to turn light on or oPress light key quickly to turn light on or o
Receiver

52" Compass LED | 15
OPERATING INSTRUCTIONS
For DIMMER function: press and hold button to dim the light. The light willFor DIMMER function: press and hold button to dim the light. The light will
cycle from bright to dim to bright until button is released. Light will maintaincycle from bright to dim to bright until button is released. Light will maintain
last setting if turned off. This remote has a memory function. The remotelast setting if turned off. This remote has a memory function. The remote
stores the fan speed and light setting when the fan is turned o. When thestores the fan speed and light setting when the fan is turned o. When the
fan is turned on again, it starts with the most recent setting.fan is turned on again, it starts with the most recent setting.
Step 4.Step 4.Use the fan reversing switch to optimize your fan for seasonalUse the fan reversing switch to optimize your fan for seasonal
performance.performance.
WARNING:WARNING: do not operate reversing switch while fan blades are in motion.do not operate reversing switch while fan blades are in motion.
Fan must be turned o and blades stopped before reversing blade direction.Fan must be turned o and blades stopped before reversing blade direction.
NOTE:NOTE: The reverse switch is located on the LED light kit, remove the shade toThe reverse switch is located on the LED light kit, remove the shade to
access the switch. Slide reverse switch to change fan rotation.access the switch. Slide reverse switch to change fan rotation.
NOTE:NOTE: Wait for fan to stop and shade to be cool before reversing the directionWait for fan to stop and shade to be cool before reversing the direction
of the bladeof the blade
rotation.rotation.
Warm Weather Operation:Warm Weather Operation: Forward (counter clockwise). A downward airflowForward (counter clockwise). A downward airflow
creates a cooling eect (Fig. 29). This allows you to set your air conditionercreates a cooling eect (Fig. 29). This allows you to set your air conditioner
on a warmer setting without aecting your general comfort.on a warmer setting without aecting your general comfort.
Cool Weather Operation:Cool Weather Operation: Reverse (clockwise). An upward airflow movesReverse (clockwise). An upward airflow moves
warm air o the ceiling areas (Fig. 30). This allows you to set your heating unitwarm air o the ceiling areas (Fig. 30). This allows you to set your heating unit
on a cooler setting without aecting your general comfort.on a cooler setting without aecting your general comfort.
Reverse switch
Fig. 28
Fig. 29 Fig. 30

16 | KICHLER.COM
TROUBLESHOOTING
ProblemProblem
Fan will not start.Fan will not start.
Fan sounds noisy.Fan sounds noisy.
Fan wobble.Fan wobble.
Remote controlRemote control
malfunction.malfunction.
SolutionSolution
1. Check circuit fuses or breakers.1. Check circuit fuses or breakers.
2. Check all electrical connections to ensure proper contact. CAUTION: Make sure the main power is OFF when checking2. Check all electrical connections to ensure proper contact. CAUTION: Make sure the main power is OFF when checking
any electrical connection.any electrical connection.
3. Make sure the transmitter batteries are installed properly. Positive (+) side facing out.3. Make sure the transmitter batteries are installed properly. Positive (+) side facing out.
4. Ensure the batteries have a good charge.4. Ensure the batteries have a good charge.
1. Make sure all motor housing screws are snug.1. Make sure all motor housing screws are snug.
2. Make sure the screws that attach the fan blade brackets to the motor are tight.2. Make sure the screws that attach the fan blade brackets to the motor are tight.
3. Make sure wire nut connections are not rubbing against each other or the interior wall of the switch housing.3. Make sure wire nut connections are not rubbing against each other or the interior wall of the switch housing.
CAUTION: Make sure main power is o.CAUTION: Make sure main power is o.
4. Allow a 24-hour "breaking-in" period. Most noise associated with a new fan disappears during this time.4. Allow a 24-hour "breaking-in" period. Most noise associated with a new fan disappears during this time.
5. If using an optional light kit, make sure the screws securing the glassware are tight. Make sure the light bulbs are not5. If using an optional light kit, make sure the screws securing the glassware are tight. Make sure the light bulbs are not
touching any other component.touching any other component.
6. Do not connect this fan to a wall mounted variable speed control(s). They are not compatible with ceiling fan motors or6. Do not connect this fan to a wall mounted variable speed control(s). They are not compatible with ceiling fan motors or
remote controls.remote controls.
7. Make sure the upper canopy has a short distance from the ceiling. It should not touch the ceiling.7. Make sure the upper canopy has a short distance from the ceiling. It should not touch the ceiling.
1. Check that all blade and blade arm screws are secure.1. Check that all blade and blade arm screws are secure.
2. Most fan wobbling problems are caused when blade levels are unequal. Check this level by selecting a point on the ceiling2. Most fan wobbling problems are caused when blade levels are unequal. Check this level by selecting a point on the ceiling
above the tip of one of the blades. Measure this distance. Rotate the fan until the next blade is positioned for measurement.above the tip of one of the blades. Measure this distance. Rotate the fan until the next blade is positioned for measurement.
Repeat for each blade. The distance deviation should be equal within 1/8".Repeat for each blade. The distance deviation should be equal within 1/8".
3. If the blade wobble is still noticeable, interchanging two adjacent (side by side) blades can redistribute the weight and3. If the blade wobble is still noticeable, interchanging two adjacent (side by side) blades can redistribute the weight and
possibly result in smoother operation.possibly result in smoother operation.
1.Ceiling Fans with remote control systems CAN NOT be operated in conjunction with any other control system EXCEPT a1.Ceiling Fans with remote control systems CAN NOT be operated in conjunction with any other control system EXCEPT a
basic On/o wall switch, if desired.basic On/o wall switch, if desired.

52" Compass LED | 17
FCC Information
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
1.)This device may not cause harmful interference, and
2.)This device must accept any interference received, including interference that may cause undesired operation.
Note:Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician or help.

www.kichler.com
KICHLER LIGHTING LLC
7711 EAST PLEASANT VALLEY ROAD
CLEVELAND, OHIO 44131-8010
CUSTOMER SERVICE 866.558.5706
8:00 AM TO 5:00 PM EST, MONDAY - FRIDAY
© Kichler Lighting LLC. All Rights Reserved.

MANUEL D’INSTRUCTION
Modèle #: 300322
Les images des produits peuvent diérer légèrement du produit réel.
52" Compass LED

2 | KICHLER.COM
TABLE DES MATIÈRES
RÈGLES DE SÉCURITÉ .......................................................................... 3
OUTILS NÉCESSAIRES .......................................................................... 4
CONTENU DE L’EMBALLAGE ............................................................ 4
OPTIONS DE MONTAGE ........................................................................ 5
SUSPENSION DE L’ASSEMBLAGE DU MOTEUR ........................6
BRANCHEMENTS ÉLECTRIQUES .................................................... 9
TERMINER DE L’INSTALLATION DU MOTEUR .......................... 10
FIXATION DES PALES DU VENTILATEUR ..................................... 11
INSTALLATION DE L’ASSEMBLAGE DE LA PLAQUE
D'ÉCLAIRAGE .......................................................................................... 12
INSTALLATION DU KIT D’ÉCLAIRAGE ET DE L’OMBRE
ACRYLIQUE ............................................................................................... 13
INSTRUCTIONS DE FONCTIONNEMENT .................................... 14
DÉPANNAGE ............................................................................................ 16
INFORMATION FCC ............................................................................... 17
