KIESELMANN 5629 Series User manual

Operating Instructions
Translation of the original
Double seat tank outlet valve
Type 5629
Seal material: EPDM, HNBR, FKM
EN
ENGLISHPDF • ak • 21/06/2023

KIESELMANN GmbH
Paul-Kieselmann-Str. 4-10
D - 75438 Knittlingen
( [phone] • 7 [phone]
www.kieselmann.de • [email protected]
Copyright: © KIESELMANN FLUID PROCESS GROUP

KIESELMANN GmbH Table of Contents
5629_Doppelsitz-Tankauslaufventile_EN 3
Table of Contents
1 General informations ................................................................................................................................................... 4
1.1 Informations for your safety...............................................................................................................................................4
1.2 Marking of security instructions......................................................................................................................................... 4
1.3 General designated use ......................................................................................................................................................4
1.4 Personnel............................................................................................................................................................................. 4
1.5 Modifications, spare parts, accessories............................................................................................................................5
1.6 General instructions ............................................................................................................................................................5
2 Safety instructions....................................................................................................................................................... 6
2.1 General notes....................................................................................................................................................................... 6
2.2 General safety instructions.................................................................................................................................................6
3 Delivery, transport and storage .................................................................................................................................... 8
3.1 Delivery.................................................................................................................................................................................8
3.2 Transport .............................................................................................................................................................................8
3.3 Storage................................................................................................................................................................................. 8
4 Specification................................................................................................................................................................ 9
4.1 Modular system...................................................................................................................................................................9
5 Function and operation .............................................................................................................................................. 10
5.1 Description of function .....................................................................................................................................................10
5.2 Control system and position indicator.............................................................................................................................10
5.3 Pneumatic valve activation...............................................................................................................................................11
6 Commissioning, service and maintenance.................................................................................................................. 12
6.1 Commissioning .................................................................................................................................................................12
6.1.1 Installation instructions .......................................................................................................................................12
6.1.2 General welding guidelines..................................................................................................................................12
6.1.3 ATEX - Guidelines.................................................................................................................................................12
6.2 Service................................................................................................................................................................................13
6.2.1 Maintenance table................................................................................................................................................13
6.3 Cleaning .............................................................................................................................................................................13
7 Technical data ........................................................................................................................................................... 14
7.1 Double seat valve Type 5629............................................................................................................................................14
7.2 Operating pressure............................................................................................................................................................14
7.3 KV - value ...........................................................................................................................................................................15
7.4 Cleaning flow rate .............................................................................................................................................................15
7.5 Torques ..............................................................................................................................................................................15
8 Disassembly and assembly ........................................................................................................................................ 16
8.1 Disassembly ......................................................................................................................................................................16
8.1.1 Dismount the valve insert (VE)............................................................................................................................17
8.1.2 Replacement wear parts......................................................................................................................................18
8.2 Assembly ...........................................................................................................................................................................20
9 Drawings and dimensions .......................................................................................................................................... 22
9.1 Drawings ............................................................................................................................................................................22
9.2 Dimensions........................................................................................................................................................................24
9.3 Control units ......................................................................................................................................................................25
10 Wearing parts ............................................................................................................................................................ 26
10.1 Spare parts list...................................................................................................................................................................26
11 Classification............................................................................................................................................................. 31
11.1 Structure of Order Number ...............................................................................................................................................31
12 Appendix ................................................................................................................................................................... 33
12.1 Declaration of incorporation.............................................................................................................................................33

Operating Instructions | KIESELMANN GmbH1 | General informations
4 / 33 5629_Doppelsitz-Tankauslaufventile_EN
1 General informations
1.1 Informations for your safety
We are pleased that you have decided for a high-classKIESELMANN product. With correct applica-
tion and adequate maintenance, our products provide long time and reliable operation.
Before installation and initiation, please carefully read this instruction manual and the security ad-
vices contained in it. This guarantees reliable and safe operation of this product and your plant re-
spectively. Please note that an incorrect application of the process components may lead to great
material damages and personal injury.
In case of damages caused by non observance of this instruction manual, incorrect initiation, hand-
ling or external interference, guarantee and warranty will lapse!
Our products are produced, mounted and tested with high diligence. However, if there is still a
reason for complaint, we will naturally try to give you entire satisfaction within the scope of our war-
ranty. We will be at your disposal also after expiration of the warranty. In addition, you will also find
all necessary instructions and spare part data for maintenance in this instruction manual. If you
don't want to carry out the maintenance by yourself, ourKIESELMANN - service team will naturally
be at your disposal.
1.2 Marking of security instructions
Hints are available in the chapter "safety instructions" or directly before the respective operation in-
struction. The hints are highlighted with a danger symbol and a signal word. Texts beside these
symbols have to be read and adhered to by all means. Please continue with the text and with the
handling at the valve only afterwards.
Symbol Signal word Meaning
DANGER Imminent danger which will result severe personal injury or
death.
WARNING Imminent danger which may result severe personal injury or
death.
CAUTION Dangerous situation which may cause slight personal injury or
material damages.
NOTICE An harmful situation which may result in damages of the product
itself or of adjacent vicinity.
INFORMATION Marks application hints and other information which is particu-
larly useful.
1.3 General designated use
The fitting is designed exclusively for the purposes described below. Using the fitting for purposes
other than those mentioned is considered contrary to its designated use. KIESELMANNcannot be
held liable for any damage resulting from such use. The risk of such misuse lies entirely with the
user. The prerequisite for the reliable and safe operation of the fitting is proper transportation and
storage as well as competent installation and assembly. Operating the fitting within the limits of its
designated use also involves observing the operating, inspection and maintenance instructions.
1.4 Personnel
Personnel entrusted with the operation and maintenance of the tank safety system must have the
suitable qualification to carry out their tasks. They must be informed about possible dangers and
must understand and observe the safety instructions given in the relevant manual. Only allow quali-
fied personnel to make electrical connections.

KIESELMANN GmbH | Operating Instructions General informations | 1
5629_Doppelsitz-Tankauslaufventile_EN 5 / 33
1.5 Modifications, spare parts, accessories
Unauthorized modifications, additions or conversions which affect the safety of the fitting are not
permitted. Safety devices must not be bypassed, removed or made inactive. Only use original spare
parts and accessories recommended by the manufacturer.
1.6 General instructions
The user is obliged to operate the fitting only when it is in good working order. In addition to the in-
structions given in the operating manual, please observe the relevant accident prevention regula-
tions, generally accepted safety regulations, regulations effective in the country of installation,
working and safety instructions effective in the user's plant.

Operating Instructions | KIESELMANN GmbH2 | Safety instructions
6 / 33 5629_Doppelsitz-Tankauslaufventile_EN
2 Safety instructions
2.1 General notes
NOTICE - observe the operating instructions
To avoid danger and damage, the fitting must be used in accordance with the safety instructions
and technical data contained in the operating instructions.
NOTICE
All data are in line with the current state of development. Subject to change as a result of tech-
nical progress.
2.2 General safety instructions
WARNING
Risk of injury by moving parts
Do not grab into the valve when the actuator is pressurized. Limbs can be crushing or amputating.
– Remove the control air line before dismantling.
– Ensure that the actuator is unpressurized.
WARNING
Risk of injury by outflowing medium
Dismantling the valve or valve assemblies from the plant can cause injuries.
– Medias flowing through the leakage drain outlet are to be drained off without splashing
into a discharge arrangement.
– Carry the disassembling only if when the plant has been rendered pressure-less and free
of liquid and gas.
WARNING
Risk of injury by pre-stressed pressure spring.
The actuator is spring-loaded. When disassembling the actuator, components that jump out may
cause injuries.
– For dismantling please observe the separate assembly instructions.
– We recommend having the manufacturer do the maintenance work required for the actu-
ation.
WARNING
ATEX - Guidelines
If the valve or the plant is operated in a potentially explosive atmosphere, the valid ATEX directive of
the EC and the installation instructions in this operating manual must be observed.
CAUTION
When mounting the clamps, the max. torque must not be exceeded.
(see technical data)
CAUTION
To avoid air leaking, only use pneumatic connection parts that have an O-ring seal facing the even
surface.

KIESELMANN GmbH | Operating Instructions Safety instructions | 2
5629_Doppelsitz-Tankauslaufventile_EN 7 / 33
CAUTION
Before starting the system, the entire pipeline system must be thoroughly cleaned.
CAUTION
Steps should be taken to ensure that no external forces are exerted on the fitting.

Operating Instructions | KIESELMANN GmbH3 | Delivery, transport and storage
8 / 33 5629_Doppelsitz-Tankauslaufventile_EN
3 Delivery, transport and storage
3.1 Delivery
• Immediately after receipt check the delivery for completeness and transport damages.
• Remove the packaging from the product.
• Retain packaging material, or expose of according to local regulations.
3.2 Transport
CAUTION
Risk of injury and damage to the product
During the transport the generally acknowledged rules of technology, the national accident preven-
tion regulations and company internal work and safety regulations must be observed.
3.3 Storage
NOTICE
Damage to the product due to improper storage!
Observe storage instructions
avoid a prolonged storage
INFORMATION
Recommendation for longer storage
We recommend regularly checking the product and the prevailing storage conditions during long
storage times.
• To avoid damage to seals and bearings,
– products up to DN 125 / OD 5 inch should be stored horizontally for maximum 6 months.
– products larger than DN 125 / 5 inch, should be stored in the upright position with the actu-
ator on top.
• Don't store any objects on the products.
• Protect the products for wetness, dust and dirt.
• The product should be stored in a dry and well ventilated room at a constant temperature (op-
timal indoor temperature: 25 C ±5; indoor humidity data 70% ±5%).
• Protect seals, bearings and plastic parts for UV light and ozone.

KIESELMANN GmbH | Operating Instructions Specification | 4
5629_Doppelsitz-Tankauslaufventile_EN 9 / 33
4 Specification
4.1 Modular system
KI-Top control head feedback unit
Stainless steel hood Transparent hood Feedback unit with finger guard
(E)
Valve insert
Sealing material
HNBR EPDM FKM
Valve housing
Type 5629 (S) Type 5629 (SS)

Operating Instructions | KIESELMANN GmbH5 | Function and operation
10 / 33 5629_Doppelsitz-Tankauslaufventile_EN
5 Function and operation
5.1 Description of function
L
The valve is opened in direction ’X’ by means of control air, and is closed from top to bottom by
means of spring power without any leakage. Different media fed from the tank or the piping system
ar separated in a leakage–free fashion by means of two, independently acting valve discs with
double seal function. Any leaks occurring due to damaged valve plate seals are drained to the exter-
ior without pressure via the leakage discharge (L).
5.2 Control system and position indicator
Feedback unit -optional-
Optionally, modular valve control head systems can be installed to the actuator for reading and ac-
tuating valve positions. The standard version is a closed system with SPS or ASI-bus switch-on
electronics, and integrated 3/2-way solenoid valves. For tough operating conditions we recommend
employing a high-grade steel cover.
Feedback unit with finger guard -optional-
For the acquisition of the valve positions over inductive initiators (Sensors), a feedback unit is
mounted on the actuation. The enquiry takes place over the position of the piston rod.

KIESELMANN GmbH | Operating Instructions Function and operation | 5
5629_Doppelsitz-Tankauslaufventile_EN 11 / 33
5.3 Pneumatic valve activation
Valve functions Pneum. activation
via control head
with solenoid valves (MV)
Pneum. activation
via external
Solenoid valves (MV external)
main lift
valve “OPEN“
Control supply air
P - MV1 - P1/LA1
Control supply air
ext.MV1 - LA1
main lift
valve “CLOSE“
Ventilation
P1/LA1 - MV1 - R
valve is closing by spring
Ventilation
LA1 - ext.MV1
valve is closing by spring
lifting lower seat OPEN = control air feed
P - MV2 - P2/LA2
OPEN = control air feed
ext.MV2 - P - LA2
CLOSE = de-aeration
P2/LA2 - MV2 - R
valve is closing by spring
CLOSE = de-aeration
LA2 - P - ext.MV2
valve is closing by spring
Lifting upper seat OPEN = control air feed
P - MV3 - P3/LA3
OPEN = control air feed
ext.MV3 - LA3
CLOSE = de-aeration
P3/LA3 - MV3 - R
valve is closing by spring
CLOSE = de-aeration
LA3 - ext.MV3
valve is closing by spring
control unit and solenoid valves external pneum. activation
MV = Solenoid valve
MV1 = main stroke valve open
MV2 = lifting lower seat
MV3 = lifting upper seat
R = Ventilation silencer
P = Supply air connection
LA = Air connection
S = Slide switch for manual op-
eration of the solenoid valves
Si = Sensors M12x1
E = mounting kit for feedback
unit
MV1MV2MV3
R
P3 P1
P
LA2
LA1
LA3
S
P2
Si
LA2
LA1
LA3
MV2
MV1
MV3
ext.
E

Operating Instructions | KIESELMANN GmbH6 | Commissioning, service and maintenance
12 / 33 5629_Doppelsitz-Tankauslaufventile_EN
6 Commissioning, service and maintenance
6.1 Commissioning
NOTICE
Checking the solenoid valves in the control head
Before using the valve for the first time, the function of the solenoid valves in the control head must
be checked.
– Remove the hood on control head.
– Connect the supply air to the control head
– Check the valve functions using the slide switches on the solenoid valve
ðPlease also read the documentation for control heads!
6.1.1 Installation instructions
Fitting position
The valve must be installed vertically with the actuator at the bottom. Liquid must be able to flow
freely from the valve housing and the leakage outlet (L).
6.1.2 General welding guidelines
Sealing elements integrated in weld components must generally be removed prior to welding. To
prevent damage, welding should be undertaken by certified personnel (EN ISO 9606-1). Use the TIG
(Tungsten Inert Gas) welding process.
CAUTION
Damage and injuries due to high temperature supply
To avoid a distortion of the components, all welding parts must be welded to stress-relieved.
Allow all components to cool before assembling.
NOTICE
Damage due to impurities
Impurities can cause damage to the seals and seals area.
Clean inside areas prior to assembly.
6.1.3 ATEX - Guidelines
For valves or plants/installations that are operated in the ATEX area, sufficient bonding (grounding)
must be ensured (see valid ATEX Guidelines EG).

KIESELMANN GmbH | Operating Instructions Commissioning, service and maintenance | 6
5629_Doppelsitz-Tankauslaufventile_EN 13 / 33
6.2 Service
RECOMMENDATION
Replacement of seals
To achieve optimal maintenance cycles, the following points must be observed!
– When replacement of seals, all product-contacting seals should be replaced.
– Only original spare parts may be installed.
Maintenance interval
The maintenance intervals depend on the operating conditions "temperature, temperature-intervals,
medium, cleaning medium, pressure and opening frequency". We recommend replacing the seals1-
year cycle. The user, however should establish appropriate maintenance intervals according to the
condition of the seals.
Lubricant recommendation
EPDM; HNBR; NBR; FKM; k-flex - Klüber Paraliq GTE703*
Silicone - Klüber Sintheso pro AA2*
Thread - Interflon Food*
*) It is only permitted to use approved lubricants, if the respective fitting is used for the produc-
tion of food or drink. Please observe the relevant safety data sheets of the manufacturers of lub-
ricants.
Maintenance - Lift actuator
The actuator is maintenance-free and non-removable.
6.2.1 Maintenance table
Annually
Additional information
6.2 Service 1
1 - Maintenance personnel
6.3 Cleaning
Cleaning
The valve housing is cleaned with the pipe cleaning system when the valve is closed. At the same
time, the leakage chamber with the valve shaft is cleaned by cycling the valve disk V2. When clean-
ing the tank, it is possible to clean the leakage chamber when the valve is closed and the valve disk
V1 is cycled. When the valve is open, the valve housing is cleaned via the CIP return line.

Operating Instructions | KIESELMANN GmbH7 | Technical data
14 / 33 5629_Doppelsitz-Tankauslaufventile_EN
7 Technical data
7.1 Double seat valve Type 5629
Model Double seat valve
Size DIN: DN25 - DN150
Inch: OD1 - OD4
Connection type Weld-on end DIN EN 10357
Temperature range Ambient temperature: +4°C to +45°C
-5°C to +100°C
Product temperature:
(depends on medium)
-5°C to +100°C
Sterilisation temperat-
ure:
(SIP 30 min)
HNBR +100°C
EPDM +140°C
FKM +100°C
Pressure resistance 40 bar
Leakage rate A (DIN EN 12266-1)
Control air Control air pressure:
5,5 - 8,0 bar
Control air quality:
ISO 8573-1 : 2001 quality class 3
Material
(in product contact)
Stainless steel: 1.4404 / AISI 316L
Surface: Ra ≤ 0,8µm e-polished
Sealing material: EPDM (FDA)
HNBR (FDA)
FKM
7.2 Operating pressure
P1 / P4
P2
P3
ND
Inch
25
1
40
1½
50
2
65
2½
80
3
100
4
125
5
150
6
Tank pressure P1 [bar]: 6 6 6 6 6 6 5 5
Line pressure P2 [bar]: 6 6 6 6 6 6 6 6
Lifting to pipe system P3 [bar]: 4 4 4 4 4 4 4 4
Lifting to tank P4 [bar]: 4 4 4 4 2 2 4 4

KIESELMANN GmbH | Operating Instructions Technical data | 7
5629_Doppelsitz-Tankauslaufventile_EN 15 / 33
7.3 KV - value
ND
Inch
25
1
40
1½
50
2
65
2½
80
3
100
4
125
5
150
6
flow direction: [m³/h]
transition-flow at top ↔26 50 95 150 240 380 580 940
from tank to pipe system 16 26 45 72 98 155 245 370
7.4 Cleaning flow rate
Cleaning parameters for the leakage chamber
Cleaning step valve disc
lifting
DIN
Inch
25
1
40
1½
50
2
65
2½
80
3
100
4
125
5
150
6
Pre-Rinse - lifting
upper
seat
0,97 1,10 1,1 1,38 1,66 2,08 2,50 4,02
Lye 80°C 3 x 5 sec.
Intermediate rinse 2 x 5 sec. (l/s bei 3bar)
Acid 3 x 5 sec. lifting
lower
seat
0,54 0,69 0,69 0,83 0,83 1,25 1,66 2,50
Final rinse 2 x 5 sec.
7.5 Torques
Torque: clamp coupling
ND
Inch
25
1
40
1½
50
2
65
2½
80
3
100
4
125
5
150
6
Torque [Nm] 15 15 15 25 25 55 65 65
Torque: clamp coupling
ND
Inch
40
1½
50
2
65
2½
80
3
Torque [Nm] 15 15 25 25
Torque: clamp coupling
DN
Inch
25
1
40
1½
50
2
65
2½
80
3
100
4
Torque [Nm] 15 15 15 25 25 55

Operating Instructions | KIESELMANN GmbH8 | Disassembly and assembly
16 / 33 5629_Doppelsitz-Tankauslaufventile_EN
8 Disassembly and assembly
8.1 Disassembly
NOTICE
All threaded joint have right-hand thread.
Unscrew and remove control air, steam resp. cleaning lines and electrical lines, complete feedback
unit or control head.
Assembly Tools
Mounting toos sets: DN40 - DN65
DN80 - DN100
DN125 - DN150
5670 065 100-000
5670 100 100-000
5670 150 100-000
ST1 Socket DN40 - DN65
DN80 - DN150
5620 065 131-130
5620 100 131-130
ST2 Socket
+ guide bush (POM)
+ O-rings
DN40 - DN65
DN80 - DN100
DN125 - DN150
5670 080 105-000
5670 100 105-000
5670 150 105-000
ST3 Eccentric socket DN40 - DN65
DN80 - DN150
5620 065 134-130
5620 100 134-130
ST4 Centring ring DN40/50
DN65
DN80
DN100
DN125
DN150
5620 050 025-020
5620 065 025-020
5620 080 025-020
5620 100 025-020
5620 125 025-020
5620 150 025-020
T10 Joint -pin wrench DN40 - DN65
DN80 - DN150
5620 065 015-000
5620 150 015-000
ST1
5
Mounting plate DN40 - DN65
DN80 - DN100
DN125 - DN150
5620 065 121-020
5620 100 121-020
5620 150 121-020
Pos. Figure Designation Article number
T1 Combination wrench-Set SW 8 - SW 24 -
T4 Soft-head hammer - -
T40 Socket box SW8 - SW36 -
ST16 Mounting wrench DN 40 - 150 5670150126-020

KIESELMANN GmbH | Operating Instructions Disassembly and assembly | 8
5629_Doppelsitz-Tankauslaufventile_EN 17 / 33
8.1.1 Dismount the valve insert (VE).
CAUTION
Risk of injury by falling parts
First secure the valve insert (VE) against falling down. For example, with lugs (L) and a safety chain.
– Then open the clamp coupling (VK).
• Unscrew the clamp coupling (VK).
• Remove the complete valve insert
with the shaft seal (D1) from the
housing (VG).
VK
VG
VE
L
1
D1
• Unscrew the screws (1).
• Remove the housing (VG) and re-
move the sealing ring (D7).
D7
VG
1
12
1a
D1

Operating Instructions | KIESELMANN GmbH8 | Disassembly and assembly
18 / 33 5629_Doppelsitz-Tankauslaufventile_EN
8.1.2 Replacement wear parts
• Unscrew the lower piston (6)
from the upper piston (7) with
the assembly tool ST16. Hold
against the spanner flat SW17.
• Remove piston plate (9), O-ring
(D3), (D5) and seal (D4).
ST16
6
SW17
• Unscrew the hexagon screws
(14).
• Push the lantern (13) with shaft
seal (D1) in direction ‘X‘, until the
hole (B) is freely visible.
14
6
D5
D4
9
7
D6
B
13
X

KIESELMANN GmbH | Operating Instructions Disassembly and assembly | 8
5629_Doppelsitz-Tankauslaufventile_EN 19 / 33
• Unscrew the upper piston (7)
with the mounting plate ST15
from piston rod (3).
Hold against the hole (B) with a
pin spanner T10.
NOTICE!
Valve ≥ DN 40 / 1½“
(Valves with divided pistons):
• If the piston plate (8) loosens be-
fore the piston (7), then unscrew
the piston (7) with the eccentric
ST3 and a ratchet.
T10
ST15
7
8
B
T10 7 ST3 8
B ST15
Remove the rinsing connection (Sp)
from lantern (13) and dismount the
O-ring (D11).
2
16
D10
D9
D8
D11
D1
7
8
D4
15
Sp
D8

Operating Instructions | KIESELMANN GmbH8 | Disassembly and assembly
20 / 33 5629_Doppelsitz-Tankauslaufventile_EN
8.2 Assembly
Mounting seal (D4), pair of piston (7)/(8)
Pair of piston upper = Piston (7) and piston plate (8)
• Screw together the piston plate
(7) / (8) without the seal (D4) to
the metal limit stop by hand.
• Make a colored mark at the pis-
ton surfaces.
• After then, unscrew the pairs of
piston again.
7
D4
ST4
8
Mark
• Slide the seal (D4) onto the pis-
ton (7).
• Screw together the pair of piston
by hand again.
• Clamp the mounting plate M6
into the vice.
• Position the eccentric ring (ST4)
on seal (D4).
• Screw up the piston (7) with the
socket ST1 and a ratchet to the
final limit mark.
ST1
ST15
ST4
Mark
7
8D4
