Kinze 3605 User manual

OPERATOR’S MANUAL
M0312-01
MODEL 3605 PIVOT FOLD EXPORT PLANTER

MODEL 3605
PIVOT FOLD EXPORT PLANTER
OPERATOR’S MANUAL
M0312-01 Rev. 11/20
This manual is for: Model 3605 Pivot Fold Planters
- 12 Row 70 CM “Y”Hitch; 2021 Production Year and on
- 16 Row 70 CM “Y”Hitch; 2021 Production Year and on
Record model number and serial number of your planter along with date purchased:
Model Number __________________________________
Serial Number ___________________________________
Date Purchased__________________________________
Monitor Serial Number _______________________________________________
Measured Pulses Per Mile/Km (Radar Distance Sensor) ____________________
Measured Pulses Per Mile/ Km (Magnetic Distance Sensor) _________________
Kinze®, the Kinze®logo, Twin-Line®, and Interplant®are registered trademarks of Kinze Manufacturing, Inc.
SERIAL NUMBER
Record your serial number and purchase date above for quick reference.
The serial number provides important information about your planter and is required to obtain correct replacement
parts. Always provide planter model and serial number to your Kinze Dealer when ordering parts or anytime
correspondence is made with Kinze Manufacturing, Inc.
3605
Serial number plate location - Outer R.H. Wing
(2021 Production And On)

Model 3605M0312-01
07/20 1
Predelivery/Delivery Checklist
TO THE DEALER
Predelivery service includes assembly, lubrication, adjustment and test. This service helps ensure planter is delivered
to retail customer/end user ready for field use.
PREDELIVERY CHECKLIST
Use the following checklist after planter is completely assembled. Check off each item as it is found satisfactory or after
proper adjustment is made.
Center pivot base mounting hex head cap screws torqued as specified in the manual.
Row units properly spaced and optional attachments correctly assembled.
Row marker assemblies installed and adjusted at each end of the planter.
Vacuum is properly installed (as applicable).
All grease fittings in place and lubricated.
All working parts move freely, bolts are tight, and cotter pins are spread.
Check all drive chains for proper tension and alignment.
Check for oil leaks and proper hydraulic operation.
Hydraulic hoses correctly routed to prevent damage.
Inflate tires to specified air pressure and torque wheel lug bolts and lug nuts as specified in the manual.
All safety decals correctly located and legible. Replace if damaged.
All reflective decals and SMV sign correctly located and visible when the planter is in transport position.
Safety/warning lights correctly installed and working properly.
Paint all parts scratched during shipment or assembly.
All safety lockup devices on the planter and correctly located.
Auxiliary safety chain properly installed and hardware torqued to specification.
Control box properly installed in tractor. All cables correctly routed and secure.
Planter has been thoroughly checked and to the best of my knowledge is ready for delivery to the customer.
(Signature Of Set-Up Person/Dealer Name/Date)
OWNER REGISTER
Name Delivery Date
Street Address Model No. 3605 Serial No.
City, State/Province Dealer Name
ZIP/Postal Code Dealer No.

M0312-01Model 3605
2 07/20
Predelivery/Delivery Checklist
DELIVERY CHECKLIST
Use the following checklist at time planter is delivered as a reminder of very important information which should be
conveyed to retail customer/end user. Check off each item as it is fully explained.
Life expectancy of this or any other machine is dependent on regular lubrication as directed in the Operator Manual.
All applicable safety precautions.
Along with retail customer/end user, check reflective decals and SMV sign are clearly visible with planter in transport
position and attached to tractor. Check safety/warning lights are in working condition. Tell retail customer/end user
to check federal, state/provincial, and local regulations before towing or transporting on a road or highway.
Give Operator Manual, Parts Manual, and all Instruction Sheets to retail customer/end user and explain all operating
adjustments.
Read warranty to retail customer/end user.
Complete Warranty and Delivery Report form.
To the best of my knowledge this machine has been delivered ready for field use and customer has been fully
informed as to proper care and operation.
(Signature Of Delivery Person/Dealer Name/Date)
AFTER DELIVERY CHECKLIST
The following is a list of items we suggest to check during the first season of use of the equipment.
Check planter performance with retail customer/end user.
Check performance of vacuum or mechanical seed metering system with retail customer/end user.
Review importance of proper maintenance and adherence to all safety precautions with retail customer/end user.
Check for parts that may need to be adjusted or replaced.
Check all safety decals, reflective decals, and SMV sign are correctly located as shown in the Parts Manual and that
decals are legible. Replace if damaged or missing.
Check safety/warning lights are working properly.
(Signature Of Follow-Up Person/Dealer Name/Date)
All registrations must be submitted online at “business.kinze.com”within 5 business days of delivery.
Retain a copy of this form for auditing purposes.
Tear Along Perforation

Model 3605M0312-01
07/20 i
Table of Contents
OVERVIEW
To The Owner ..................................1-1
Warranty ......................................1-3
General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
General Safety Rules. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
Safety Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
MACHINE OPERATION
Manual Safety Lockup ............................2-1
Row Marker Safety Lockup ........................2-1
Tongue Safety Pin ...............................2-2
Transport Latch Locking Pin .......................2-2
Initial Preparation................................2-3
Tractor Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
Tractor Mounted PTO Pump And Oil Cooler Option .....2-5
Tractor Preparation and Hookup ....................2-6
Oil Specification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
Cylinder Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
Hydraulic Hose Information .......................2-12
Level Planter ..................................2-17
Ridge Planting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-18
True Depth Hydraulic System Overview .............2-19
True Depth Filter ...............................2-20
Contact Wheel Drive Sprockets . . . . . . . . . . . . . . . . . . . . 2-21
Contact Wheel Spring Adjustment . . . . . . . . . . . . . . . . . . 2-22
Seed Rate Transmission Adjustment . . . . . . . . . . . . . . . . 2-22
Wrap Spring Wrench Operation ...................2-22
Shear Protection ...............................2-23
Hydraulic/Electric Operation ......................2-24
Transport to Field Sequence ......................2-26
Field Operation ................................2-29
Planting Speed ................................2-29
Field to Transport Sequence ......................2-30
Transport to Field Sequence Using Blue Vantage . . . . . . 2-33
Vacuum System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-34
Digital Vacuum Readout. . . . . . . . . . . . . . . . . . . . . . . . . . 2-34
Vacuum Fan Motor Valve Block Assembly . . . . . . . . . . . . 2-34
Bulk Fill System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-35
Analog Vacuum or Pressure Gauge. . . . . . . . . . . . . . . . . 2-36
Bulk Fill Entrainer Access ........................2-36
Bulk Fill Tanks - Clean Out. . . . . . . . . . . . . . . . . . . . . . . . 2-36
Bulk Fill Scale Package Option ....................2-37
Ag Leader Integra Display . . . . . . . . . . . . . . . . . . . . . . . . 2-40
Ag Leader Monitoring Control (PMM) ...............2-40
Kinze Blue Vantage .............................2-40
Ag Leader InCommand 1200 Display ...............2-40
Kinze ISOBUS Option ...........................2-41
Auxiliary Work Lights Package. . . . . . . . . . . . . . . . . . . . . 2-41
Row Marker Operation...........................2-42
Row Marker Speed Adjustment . . . . . . . . . . . . . . . . . . . . 2-43
Even-Row Push Row Unit ........................2-43
Row Marker Adjustments. . . . . . . . . . . . . . . . . . . . . . . . . 2-44
Row Marker Even-Row Length Adjustment ...........2-45
Offset Hitch Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . 2-45
Point Row Clutches .............................2-46
Auxiliary Hydraulic Option ........................2-47
Rear Trailer Hitch ...............................2-48
Field Test .....................................2-49
Field Check Seed Population. . . . . . . . . . . . . . . . . . . . . . 2-49
Determining Kilograms Per Hectare (Brush-Type Meter) 2-50
Field Check Granular Chemical Application ..........2-51
Water Tank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-52
ROW UNIT OPERATION
Planting Depth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
“V” Closing Wheel Adjustment (Rubber or Cast Iron) ....3-1
Closing Wheel Shield
(Rubber or Cast Iron “V” Closing Wheels) .............3-1
Drag Closing Attachment. . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
Row Unit Extension Brackets. . . . . . . . . . . . . . . . . . . . . . . 3-2
Seed Hoppers ..................................3-3
Seed Meter Drive Release. . . . . . . . . . . . . . . . . . . . . . . . . 3-3
Row Unit Chain Routing. . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
Quick Adjustable Down Force Springs Option .........3-5
Pneumatic Down Pressure Package Option ...........3-6
Split Row Push Row Unit Clutch Sprocket. . . . . . . . . . . . 3-10
Split Row Push Row Unit Vacuum Hose Shutoff .......3-10
Split Row Lockups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-11
Brush-Type Seed Meter . . . . . . . . . . . . . . . . . . . . . . . . . . 3-14
Finger Pickup Seed Meter . . . . . . . . . . . . . . . . . . . . . . . . 3-15
Vacuum Settings ...............................3-16
Rapeseed Planting Section .......................3-20
Seed Meter Cleanout. . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-22
Additives .....................................3-22
Row Unit Mounted Residue Wheel .................3-24
Row Unit Mounted No Till Coulter ..................3-25
Coulter Mounted Residue Wheels . . . . . . . . . . . . . . . . . . 3-25
Spiked Closing Wheel ...........................3-26
Granular Chemical Hopper and Drive ...............3-27
Granular Chemical Banding Options . . . . . . . . . . . . . . . . 3-28
Granular Chemical Bander Shield . . . . . . . . . . . . . . . . . . 3-28

M0312-01Model 3605
ii 07/20
Table of Contents
FERTILIZER
Double Disc Fertilizer Opener ......................4-1
Notched Single Disc Opener . . . . . . . . . . . . . . . . . . . . . . . 4-2
Residue Wheel Attachment for Notched
Single Disc Fertilizer Opener . . . . . . . . . . . . . . . . . . . . . . . 4-4
Depth/Gauge Wheel Attachment for Notched
Single Disc Fertilizer Opener ......................4-4
HD Single Disc Fertilizer Opener....................4-5
Dry Fertilizer Attachment . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7
Liquid Fertilizer Attachment ........................4-9
RATE CHARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
LUBRICATION AND MAINTENANCE
Lubrication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
Lubrication Symbols .............................6-1
Sealed Bearings ................................6-1
Wrap Spring Wrench Assembly . . . . . . . . . . . . . . . . . . . . . 6-1
Drive Chains ...................................6-2
Bushings ......................................6-3
Center Post ....................................6-5
U-Joint Slides. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5
PTO Pump Shaft Coupling (Tractor Mounted PTO Pump
and Oil Cooler) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5
Wheel Bearings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-6
Liquid Fertilizer Piston Pump ......................6-6
Crankcase Oil Level. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-6
Grease Fittings .................................6-6
Mounting Bolts and Hardware .....................6-10
Tire Servicing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-12
Finger Pickup Seed Meter Inspection/Adjustment. . . . . . 6-13
Cleaning Finger Pickup Seed Meter For Storage ......6-14
Brush-Type Seed Meter Maintenance ...............6-15
Cleaning Brush-Type Seed Meter For Storage ........6-16
Vacuum Seed Meter Maintenance. . . . . . . . . . . . . . . . . . 6-17
Seed Meter Cleanout. . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-17
Chain Tension Adjustment . . . . . . . . . . . . . . . . . . . . . . . . 6-18
Drag Closing Attachment ........................6-18
Gauge Wheel Adjustment ........................6-18
Gauge Wheel Arm Bushing/Seal Replacement. . . . . . . . 6-19
Gauge Wheel Arm Pivot Spindle Replacement . . . . . . . . 6-20
15" Seed Opener Disc Blade/Bearing Assembly .......6-21
Seed Tube Guard/Inner Scraper ...................6-23
Row Unit Mounted Disc Furrower ..................6-24
Row Unit Mounted No Till Coulter ..................6-24
Coulter Mounted Residue Wheels . . . . . . . . . . . . . . . . . . 6-25
Row Unit Mounted Residue Wheel .................6-25
Granular Chemical Attachment ....................6-25
Point Row Clutch Maintenance ....................6-26
Check Valve (Lift System) ........................6-28
Check Valve (Vacuum Fan) .......................6-28
Flow Control Valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-28
Pressure Relief Valve. . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-28
Pressure Reducing Relief Valve. . . . . . . . . . . . . . . . . . . . 6-28
Relief Valve Cartridge ...........................6-28
Solenoid Valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-29
Row Marker Bearing Lubrication or Replacement . . . . . . 6-30
Row Marker Transport Stand Adjustment ............6-31
Wheel Bearing Repack or Replacement .............6-31
Wear Pad Field Replacement/Adjustment . . . . . . . . . . . . 6-32
Tractor Mounted PTO Pump and Oil Cooler Option. . . . . 6-36
Pneumatic Down Pressure Air Compressor Tank ......6-36
Fertilizer Check Valve Cleaning and Repair...........6-38
Piston Pump Storage. . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-38
Electrical Control Console Schematic ...............6-39
Valve Block - Located on Hitch ....................6-40
Valve Block - Located on Rear Center Frame .........6-41
Hydraulic Hose Life .............................6-42
Hydraulic System Schematic . . . . . . . . . . . . . . . . . . . . . . 6-43
Hydraulic Schematic - Vacuum Fan Motor System .....6-46
Hydraulic Schematic - Optional Tractor Driven
PTO Pump and Oil Cooler System .................6-46
Wing Down Pressure Schematic
(Weight Transfer Mechanism) .....................6-47
Electrical Control Console Connections - isobus.......6-48
Power Pack Wiring Diagram (Blue Drive). . . . . . . . . . . . . 6-50
Cables and Harnesses ..........................6-51
TROUBLESHOOTING ......................7-1
Bulk Fill .......................................7-1
Closing Wheel ..................................7-1
Lift Circuit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-2
PTO Pump Drive and Oil Cooler Option ..............7-3
Point Row Clutch ................................7-3
Rotation Circuit .................................7-4
Row Marker Operation............................7-4
Seed Meter (Brush-Type). . . . . . . . . . . . . . . . . . . . . . . . . . 7-5
Seed Meter (Vacuum) ............................7-6
Seed Meter (Finger Pickup) .......................7-8
Solenoid Valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-8
Tongue Cylinder Circuit ...........................7-9
Wing Lock Cylinder Circuit. . . . . . . . . . . . . . . . . . . . . . . . . 7-9

Model 3605M0312-01
07/20 1-1
To The Owner
Kinze Manufacturing, Inc. thanks you for your patronage. We appreciate your confidence in Kinze farm machinery. Your
Kinze planter has been carefully designed to provide dependable operation in return for your investment.
This manual has been prepared to aid you in the operation and maintenance of the planter. It should be
considered a permanent part of the machine and remain with the machine when you sell it.
It is the responsibility of the user to read and understand the Operator Manual in regards to safety, operation,
lubrication and maintenance before operation of this equipment. It is the user’s responsibility to inspect and service
the machine routinely as directed in the Operator Manual. We have attempted to cover all areas of safety, operation,
lubrication and maintenance; however, there may be times when special care must be taken to fit your conditions.
Throughout this manual the symbol and the words DANGER, WARNING, and CAUTION are used to call
attention to safety information that if not followed, will or could result in death or injury. NOTICE and NOTE are used to
call your attention to important information. The definition of each of these terms follows:
NOTE: Special point of information or machine adjustment instructions.
Indicates an imminently hazardous
situation that, if not avoided, will
result in death or serious injury. This
signal word is to be limited to the most
extreme situations, typically for machine
components which, for functional
purposes, cannot be guarded.
DANGER
Indicates a potentially hazardous
situation that, if not avoided, could result
in death or serious injury, and includes
hazards that are exposed when guards
are removed. It may also be used to alert
against unsafe practices.
WARNING
Indicates a potentially hazardous
situation that, if not avoided, may result
in minor or moderate injury. It may also
be used to alert against unsafe practices.
CAUTION
Used to address safety practices not
related to personal injury.
NOTICE

M0312-01Model 3605
1-2 07/20
To The Owner
Improperly operating or working on
this equipment could result in death
or serious injury. Read and follow all
instructions in Operator Manual before
operating or working on this equipment.
WARNING
Some photos in this manual may show
safety covers, shields, or lockup devices
removed for visual clarity. NEVER
OPERATOR OR WORK ON machine
without all safety covers, shields, and
lockup device in place as required.
WARNING
NOTE: Some photos in this manual may have been taken of prototype machines. Production
machines may vary in appearance.
NOTE: Some photos and illustrations in this manual show optional attachments installed. Contact
your Kinze Dealer for purchase of optional attachments.

Model 3605M0312-01
07/20 1-3
Warranty
Model 3605 16 Row Planter with Vacuum, Split Rows, and Bulk Fill System
The Kinze Limited Warranty for your new machine is stated on the retail purchaser’s copy of the Warranty And Delivery
Receipt form. Additional copies of the Limited Warranty can be obtained through your Kinze Dealer.
Warranty, within the warranty period, is provided as part of Kinze’s support program for registered Kinze products
which have been operated and maintained as described in this manual. Evidence of equipment abuse or modification
beyond original factory specifications will void the warranty. Normal maintenance, service and repair is not covered by
Kinze warranty.
To register your Kinze product for warranty, a Warranty And Delivery Receipt form must be completed by the Kinze
Dealer and signed by the retail purchaser, with copies to the Dealer, and to the retail purchaser. Registration must be
completed and submitted to Kinze Manufacturing, Inc. within 5 business days of delivery of the Kinze product to the
retail purchaser. Kinze Manufacturing, Inc. reserves the right to refuse warranty on serial numbered products which
have not been properly registered.
If service or replacement of failed parts which are covered by the Limited Warranty are required, it is the user’s
responsibility to deliver the machine along with the retail purchaser’s copy of the Warranty And Delivery Receipt to
the Kinze Dealer for service. Kinze warranty does not include cost of travel time, mileage, hauling or labor. Any prior
arrangement made between the Dealer and the retail purchaser in which the Dealer agrees to absorb all or part of this
expense should be considered a courtesy to the retail purchaser.
Kinze warranty does not include cost of travel time, mileage, hauling, or labor.

M0312-01Model 3605
1-4 07/20
General Information
The Model 3605 Twin-Line Planter is available with vacuum or mechanical meters, conventional hoppers or bulk fill,
Split Rows, and various other options. Liquid or dry fertilizer application equipment and various row unit attachments
are also available.
Information used in these instructions was current at time of printing. However, due to Kinze’s ongoing product
improvement, production changes may cause your machine to appear slightly different in detail. Kinze Manufacturing,
Inc. reserves the right to change specifications or design without notice and without incurring obligation to install the
same on machines previously manufactured.
Right hand (R.H.) and left hand (L.H.), as used throughout this manual, are determined by facing direction machine
travels in use unless otherwise stated.
TOOLS REQUIRED
Hardware Size / Tool Required
/" = /"/" = /"
(nut for /" hardware uses /" tool)
/" = 1/" 1/" = 1/"
/" = /"/" = /"/" = 1/" 1/" = 2/"
/" = /"/" = /" 1" = 1/"

Model 3605M0312-01
07/20 1-5
Specifications
Specification Conventional Hoppers
Number of Rows 12R 70 CM Y 16R 70 CM Y
Base Machine (Empty)* 12,780-13,185 lb (5795-5980 kg) 15,730-16,210 lb (7135-7350 kg)
Axle Weight Empty 10,376 lb (4707 kg) 19,903 lb (9028 kg)
Tongue Weight Empty 2,034 lb (923 kg) 3,497 lb (1586 kg)
Transport Height 11' 4" (3.50 m) 11' 4" (3.50 m)
Planting Length 21' 0" (6.40 m) 23' 11" (7.30 m)
Transport Length 34' 5" (10.50 m) 43' 8" (13.30 m)
Planting Width 29' 6" (9.00 m) 38' 5" (11.70 m)
Transport Width 10' 6" (3.20 m) 10' 6" (3.20 m)
Seed Capacity 1.75 bu (62 L)/Hopper (Vacuum);
1.90 bu (67 L)/Hopper (Mechanical)
1.75 bu (62 L)/Hopper (Vacuum);
1.90 bu (67 L)/Hopper (Mechanical)
Transport Tire Size
Four 255 - 70R 22.5 radial load range ‘H’ tubeless rib implement w/o center groove.
Field Tire Size
7.50" x 20" 8 ply rib implement tires w/o center groove.
Field Lift
Two master/two slave rephasing cylinders.
Row Markers
Independently controlled, three stage, low profile, w/disk blade depth bands.
Specification Bulk Fill
Number of Rows 12R 70 CM Y 16R 70 CM Y
Base Machine (Empty)* 14,590-15,242 lb (6615-6915 kg) 15,600-17,048 lb (7075-7730 kg)
Axle Weight Empty 16,021 lb (7267 kg) 21,980 lb (9970 kg)
Tongue Weight Empty 3,139 lb (1424 kg) 3860 lb (1751 kg)
Transport Height 12' 5" (3.80 m) 12' 5" (3.80 m)
Planting Length 21' 0" (6.40 m) 23' 11" (7.30 m)
Transport Length 34' 5" (10.50 m) 43' 8" (13.30 m)
Planting Width 29' 6" (9.00 m) 38' 5" (11.70 m)
Transport Width 10' 6" (3.20 m) 10' 6" (3.20 m)
Seed Capacity 80 bu (2819 L)
Transport Tire Size
Four 255 - 70R 22.5 radial load range ‘H’ tubeless rib implement w/o center groove.
Field Tire Size
7.50" x 20" 8 ply rib implement tires w/o center groove.
Field Lift
Two master/two slave rephasing cylinders.
Row Markers
Independently controlled, three stage, low profile, w/disk blade depth bands.
*Base machine weight depending on how machine is equipped (meters, drives, and hoppers).
TRACTOR HYDRAULIC REQUIREMENTS
Configuration No Optional Pumps Tractor Mounted PTO Pump
Mechanical Meter1,2 2 SCV 15 gpm (57 L/min)
Vacuum Meter1,2 3 SCV 30 gpm (113 L/min) 2 SCV 15 gpm (57 L/min)
Bulk Fill (with Mechanical Meter)33 SCV 25 gpm (95 L/min) 2 SCV 15 gpm (57 L/min)
Bulk Fill (with Vacuum)24 SCV 40 gmp (151 L/min) 3 SCV 25 gpm (95 L/min)
1Blue drive adds 1 SCV + 10 gpm (38 L/min) (vacuum) min. to requirements.
2Wing down pressure option adds 1 SCV to conventional only.
3Blue Drive not available for mechanical planters.

M0312-01Model 3605
1-6 07/20
General Safety Rules
1. Read and understand instructions provided in this manual
and warning labels. Review these instructions frequently!
2. This machine is designed and built with your safety
in mind. Do not make any alterations or changes to this
machine. Any alteration to design or construction may
create safety hazards.
3. A large portion of farm accidents happen from fatigue
or carelessness. Safe and careful operation of tractor and
planter will help prevent accidents.
4. Never allow planter to be operated by anyone unfamiliar
with operation of all functions of the unit. Operators must
read and thoroughly understand all instructions given in this
manual before operating or working on equipment.
5. Be aware of bystanders, particularly children! Always
look around to make sure it is safe to start tow vehicle
engine or move planter. This is particularly important with
higher noise levels and quiet cabs, as you may not hear
people shouting.
6. Make sure planter weight does not exceed towing
capacity of tractor, or bridge and road limits. This is critical
to maintain safe control and prevent death or injury, or
property and equipment damage.
7. Never ride or allow others to ride on planter.
8. Store planter in an area away from human activity. DO
NOT permit children to play on or around the stored unit.
9. Keep hands, feet, and clothing away from moving parts.
Do not wear loose-fitting clothing which may catch in
moving parts.
10. Always wear protective clothing, shoes, gloves, hearing,
and eye protection applicable for the situation.
11. Do not allow anyone to stand between tongue or hitch
and towing vehicle when backing up to planter.
13. Prevent electrocution, other injuries, or property and
equipment damage. Watch for obstructions such as wires,
tree limbs, etc. when operating machine. Be aware of
clearances during turns and when folding/unfolding planter.
14. Reinstall all guards removed for maintenance activities.
Never leave guards off during operation.
15. Use of aftermarket hydraulic, electric, or PTO drives
may create serious safety hazards to you and people
nearby. If you install such drives, follow all appropriate
safety standards and practices to protect you and others
near this planter from injury.
16. Follow all federal, state/provincial, and local regulations
when towing farm equipment on a public highway. Use
safety chain (not an elastic or nylon/plastic tow strap) to
retain connection between towing and towed machines in
the event of primary attaching system separation.
17. Make sure all safety/warning lights, SMV sign, and
reflective decals are in place and working properly before
transporting the machine on public roads.
18. Limit towing speed to 24 km/h. Tow only with farm tractor
of a minimum 90 HP. Allow for unit length when making turns.
19. Reduce speed prior to turns to avoid the risk of
overturning. Always drive at a safe speed relative to local
conditions and ensure your speed is slow enough for a safe
emergency stop.
20. Chemical application is often an integral part of planting.
Follow label instructions for proper chemical mixing,
handling and container disposal methods.
21. Be familiar with safety procedures for immediate first aid
should you accidentally contact chemical substances.
22. Use the proper protective clothing and safety equipment
when handling chemicals.
23. Chemicals are supplied with Material Safety Data
Sheets (MSDS) that provide full information about the
chemical, its effects on exposure, and first aid needs in the
event of an emergency. Keep your MSDS file up-to-date and
available for first responders in case of emergency.
24. When servicing ground engaging components such as
opening disks and firming points, use special care to avoid
points and edges worn sharp during use.
25. Use professional help if you are unfamiliar with working
on hydraulic systems. Pressurized hydraulic fluid can
penetrate body tissue and result in death, serious infection,
or other injuries.
26. Transporting planter with hoppers over half full or unevenly
loaded can cause loss of control and could result in death,
serious injury, or damage to property and equipment.
27. Disposing of waste improperly can threaten the
enviroment. To dispose of your equipment properly contact
your local environmental or recyling center.
Never pour waste onto the ground, down a drain, or into any
water source.
When disposing of waste such as oil, use leakproof
containers. Be sure to use containers that do not resemble
food or beverage which may mislead someone into
consuming them. Dispose of oil per your local, regional
requirements.
When disposing of any fertilizer chemicals used, contact the
supplier of the chemicals.
Model 3605 planter consists of 85% recyclable metals, 10%
recyclable plastic and rubber, and 5% waste.

Model 3605M0312-01
07/20 1-7
Safety Precautions
Following are some common hazard warnings associated with this equipment. Pay close attention to all safety,
operating, and maintenance information in this manual and decals applied to your equipment.
Contacting or coming close to power
lines or other high energy sources will
cause death or serious injury.
Keep away from power lines or high
energy sources at all times.
DANGER
Improperly operating or working on
this equipment could result in death
or serious injury. Read and follow all
instructions in Operator Manual before
operating or working on this equipment.
WARNING
Falling equipment can cause death or
serious injury. Install all lockup devices
or lower planter to ground before
working on equipment.
WARNING
Explosive separation of rim and tire
parts can cause death or serious injury.
Overinflation, rim and tire servicing,
improper use of rims and tires, or worn
or improperly maintained tires could
result in a tire explosion.
WARNING

M0312-01Model 3605
1-8 07/20
Safety signs and decals are placed on the machine to warn of hazards and provide important operating and maintenance
instructions. Information on these signs are for your personal safety and the safety of those around you. FOLLOW ALL
SAFETY INSTRUCTIONS!
• Keep signs clean so they can be easily seen. Wash with soap and water or cleaning solution as required.
• Replace safety signs if damaged, painted over, or missing.
• Check reflective decals and SMV sign periodically. Replace if they show any loss of of reflective properties.
• When replacing decals, clean machine surface thoroughly with soap and water or cleaning solution to
remove all dirt and grease.
NOTE: Safety sign and decal locations are shown in the Parts Manual for this machine.
NOTE: Style and locations of SMV sign, reflective decals, and safety/warning lights conform to
ANSI/ASABE S279.14 JUL 2008 and ANSI/ASABE S276.6 JAN 2005.
SAFETY SIGNS AND DECALS
All safety/warning lights, reflective
decals, and SMV sign must be in place
and visible before transporting machine
on public roads or death, serious injury,
and damage to property and equipment
may result. Check federal, state/
provincial, and local regulations before
transporting equipment on public roads.
WARNING
Safety Precautions

Model 3605M0312-01
07/20 2-1
Machine Operation
MANUAL SAFETY LOCKUP
Always install row marker lockups when working or
transporting planter.
Connect chain between marker stand and second
stage of marker assembly.
Remove manual safety lockup and store on L.H. side of hitch for field operation.
Manual safety lockup in transport positionManual safety lockup in storage position
ROW MARKER SAFETY LOCKUP
Row marker safety lockup installed
Uncontrolled machine movement can
crush or cause loss of control resulting
in death, serious injury, or damage to
property and equipment. Install all safety
lockup devices before working under or
transporting this equipment.
WARNING
Row marker can lower at any time and
could cause death or serious injury. Stay
away from row markers! Install safety
lockup device when not in use.
WARNING

M0312-01Model 3605
2-2 07/20
Machine Operation
TRANSPORT LATCH LOCKING PIN
TONGUE SAFETY PIN
Tongue safety pin installed for transport Tongue safety pin stored for field operation
Never transport planter without installing transport latch locking pin. Transport latch locking pin prevents latch bar from
disengaging and allowing planter frame to swing away.
Remove transport latch locking pin and store in location provided on latch post for field operation.
Never transport planter without installing tongue safety pin. Tongue safety pin prevents tongue cylinder from retracting
should hydraulic failure occur or a sudden stop be made when transporting planter.
Remove tongue safety pin and store in bracket on transport latch post at center of planter for field operation.
Transport latch locking pin stored for field operation Transport latch locking pin installed for transport
Uncontrolled movement of equipment
can cause loss of control and could
result in death, serious injury, or damage
to property and equipment. Install
all safety pins before transporting
equipment.
WARNING
