Kinze 4805 User manual

OPERATOR'S MANUAL
M0314-01
MODEL 4805 70CM EXPORT FRONT FOLD
PLANTER

This manual is applicable to: Model 4805 70CM 24R Front Folding Planters
Record the model number and serial number of your planter along with date purchased:
Model Number ________________________________
Serial Number ___________________________________
Date Purchased__________________________________
Monitor Serial Number _______________________________________________
Measured Pulses Per km (Radar Distance Sensor) ________________________
Measured Pulses Per km (Magnetic Distance Sensor) ______________________
SERIAL NUMBER
The serial number plate is located on the planter frame as shown below. The serial number provides important information
about your planter and is needed to obtain correct replacement parts. Always provide model number and serial number
to your Kinze Dealer when ordering parts or when contacting Kinze Manufacturing, Inc.
Kinze®and the Kinze®logo are registered trademarks of Kinze Manufacturing, Inc.
Vacuum Meter, Electric Drive, and Flip Axle have patents pending.
MODEL 4805 70CM EXPORT
FRONT FOLDING PLANTER
OPERATOR'S MANUAL
M0314-01 Rev. 10/20
Serial Number Plate Location
4805

This page intentionally left blank.

Model 4805M0314-01
10/20
Predelivery/Delivery Checklist
TO THE DEALER
Predelivery service includes assembly, lubrication, adjustment and test. This service helps ensure planter is delivered
to retail customer/end user ready for field use.
PREDELIVERY CHECKLIST
Use the following checklist after planter is completely assembled. Check off each item as it is found satisfactory or after
proper adjustment is made.
Row units properly spaced and optional attachments correctly assembled.
Row marker assemblies installed and adjusted at each end of the planter.
Vacuum meter and bulk fill components properly installed (as applicable).
All grease fittings in place and lubricated.
All working parts move freely, bolts are tight, and cotter pins are spread.
Check all drive chains for proper tension and alignment.
Check for oil leaks and proper hydraulic operation.
Hydraulic hoses correctly routed to prevent damage.
Inflate tires to specified air pressure and torque wheel lug bolts and lug nuts as specified in the Operator Manual.
All safety decals correctly located and legible. Replace if damaged.
All reflective decals and SMV sign correctly located and visible when the planter is in transport position.
Safety/warning lights correctly installed and working properly.
Paint all parts scratched during shipment or assembly.
All safety lockup devices on the planter and correctly located.
Auxiliary safety chain properly installed and hardware torqued to specification.
Vacuum fan PTO-driven pump correctly attached to tractor. Oil reservoir filled to capacity and system inspected for
leaks (If applicable).
Bulkfill/dry fertilizer hoses remain in place with no belt slipping or hose pinching between stub wing and vacuum
manifold.
Planter has been thoroughly checked and to the best of my knowledge is ready for delivery to the customer.
(Signature of Set-Up Person/Dealer Name/Date)
OWNER REGISTER
Name Delivery Date
Street Address Model No. 4805 Serial No.
City, State/Province Dealer Name
ZIP/Postal Code Dealer No.

M0314-01Model 4805
10/20
Predelivery/Delivery Checklist
DELIVERY CHECKLIST
Use the following checklist at time planter is delivered as a reminder of very important information which should be
conveyed to retail customer/end user. Check off each item as it is fully explained.
Check proper operation of vacuum fan, bulk fill fan, and PTO-driven pump (If applicable) with tractor used with planter.
Life expectancy of this or any other machine is dependent on regular lubrication as directed in the Operator Manual.
All applicable safety precautions.
Along with retail customer/end user, check reflective decals and SMV sign are clearly visible with planter in transport
position and attached to tractor. Check safety/warning lights are in working condition. Tell retail customer/end user
to check federal, state/provincial, and local regulations before towing or transporting on a road or highway.
Give Operator Manual, Parts Manual, and all Instruction Sheets to retail customer/end user and explain all operating
adjustments.
Read warranty to retail customer/end user.
Complete Warranty and Delivery Report form.
To the best of my knowledge this machine has been delivered ready for field use and customer has been fully
informed as to proper care and operation.
(Signature of Delivery Person/Dealer Name/Date)
AFTER DELIVERY CHECKLIST
The following is a list of items we suggest to check during the first season of use of the equipment.
Check planter performance with retail customer/end user.
Check performance of vacuum meter or mechanical seed metering system with retail customer/end user.
Review importance of proper maintenance and adherence to all safety precautions with retail customer/end user.
Check for parts that may need to be adjusted or replaced.
Check all safety decals, reflective decals, and SMV sign are correctly located as shown in the Parts Manual and that
decals are legible. Replace if damaged or missing.
Check safety/warning lights are working properly.
(Signature of Follow-Up Person/Dealer Name/Date)
All registrations must be submitted online at “business.kinze.com” within 5 business days of delivery.
Retain a copy of this form for auditing purposes.
Tear Along Perforation

Model 4805M0314-01
10/20 i
Table of Contents
OVERVIEW
To The Owner ..................................1-1
General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
General Safety Rules. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8
Safety Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-9
MACHINE OPERATION
Loading and Unloading ...........................2-1
Row Marker Safety Lockup ........................2-1
Transport Axle Cylinder Safety Lockup ...............2-2
Drawbar Hitch Lockup ............................2-3
Wing Latch Lockup ..............................2-4
Initial Planter Preparation. . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
Tractor Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
Bulk fill Tractor Mounted PTO Pump and Planter Mounted
Hydraulics ...................................2-7
Oil specification .................................2-7
Tractor Preparation and Hookup ....................2-8
Cylinder Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-11
Hydraulic Hose Information .......................2-13
Transporting Planter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-21
Level Planter ..................................2-22
Jump Start Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-22
Field Operation ................................2-23
Transport to Field Sequence Using Control Box .......2-24
Transport to Field Sequence Using Kinze Blue Vantage
System ....................................2-28
Field to Transport Sequence Using Control Box .......2-29
Field to Transport Sequence Using Kinze Blue Vantage
System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-32
Row Marker Operation using Control Box ............2-33
Row Marker Operation Using Kinze Blue Vantage System ..
2-34
Row Marker Speed Adjustment . . . . . . . . . . . . . . . . . . . . 2-35
Row Marker Cable Adjustment ....................2-36
Row Marker Length And Disc Blade Adjustment.......2-37
Vacuum Meter System...........................2-38
Analog Vacuum or Pressure Gauge. . . . . . . . . . . . . . . . . 2-38
Bulk Fill System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-39
Bulk fill Entrainer Access . . . . . . . . . . . . . . . . . . . . . . . . . 2-40
Bulk Fill Tanks - Clean Out. . . . . . . . . . . . . . . . . . . . . . . . 2-41
Bulk Fill Scale Package Option ....................2-41
Monitor Seed Levels ............................2-42
Ag Leader InCommand 1200 Display ...............2-42
Kinze Blue Vantage .............................2-42
Kinze ISOBUS Option ...........................2-42
Point Row Clutches .............................2-43
Field Test .....................................2-44
Field Test using Blue Vantage System ...............2-44
Field Check Seed Population. . . . . . . . . . . . . . . . . . . . . . 2-44
Determining Kilograms Per Hectare ................2-45
Determining Liters Per Hectare ....................2-45
Field Check Granular Chemical Application ..........2-46
Water Tank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-47
ROW UNIT OPERATION
Planting Depth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
“V” Closing Wheel Adjustment (Rubber or Cast Iron) ....3-1
Closing Wheel Shield (Rubber or Cast Iron “V” Closing
Wheels) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Quick Adjustable Down Force Springs Option .........3-2
Pneumatic Down Pressure ........................3-3
Field Operation .................................3-4
Vacuum Settings ................................3-5
Finger Pickup Seed Meter . . . . . . . . . . . . . . . . . . . . . . . . . 3-6
Brush-Type Seed Meter 2.0 ........................3-7
Seed Meter Clean out ...........................3-10
Additives .....................................3-11
Spiked Closing Wheel ...........................3-13
Row Unit Mounted No Till Coulter ..................3-13
Coulter Mounted Residue Wheels . . . . . . . . . . . . . . . . . . 3-14
Granular Chemical Banding Options . . . . . . . . . . . . . . . . 3-14
Granular Chemical Hopper and Drive ...............3-15
FERTILIZER
PTO Connection Procedure........................4-1
Preparing the System for Operation .................4-2
Piston Pump ...................................4-3
Startup Procedure ...............................4-4
PTO Pump Drive Startup Procedure .................4-6
Calibration Procedure ............................4-7
Notched Single Disc Openers ......................4-8
Depth/Gauge Wheel Attachment for Notched Single Disc
Fertilizer Opener ..............................4-9
Liquid Fertilizer Attachment .......................4-10
Check Valves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-11
Rear Trailer Hitch Option .........................4-11
RATE CHARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
LUBRICATION AND MAINTENANCE
Lubrication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
Wheel Bearings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1

M0314-01Model 4805
ii 10/20
Grease Fittings .................................6-2
Notched Single Disc Opener ......................6-6
PTO Shaft Coupling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-6
Liquid Fertilizer Piston Pump Crankcase Oil Level ......6-7
Mounting Bolts and Hardware ......................6-7
Fertilizer Maintenance ...........................6-10
Vacuum Seed Meter Maintenance. . . . . . . . . . . . . . . . . . 6-12
Seed Meter Cleanout. . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-12
Gauge Wheel Adjustment ........................6-13
Gauge Wheel Arm Bushing/Seal Replacement . . . . . . . . 6-14
15" Seed Opener Disc Blade/Bearing Assembly .......6-15
Seed Tube Guard/Inner Scraper ...................6-16
Row Unit Mounted No Till Coulter ..................6-17
Coulter or Row Unit Mounted Residue Wheels . . . . . . . . 6-17
Tractor Mounted Pump Drive and Oil Cooler . . . . . . . . . . 6-18
Check Valve ...................................6-19
Flow Control Valves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-19
Pressure Relief Valves ...........................6-19
Pressure Compensated Flow Control Valves. . . . . . . . . . 6-19
Solenoid Valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-20
Pneumatic Down Pressure Air Compressor Tank ......6-20
Row Marker Bearing Lubrication or Replacement . . . . . . 6-21
Transport and Lift/Ground Drive Wheel Bearing Repack or
Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-22
Fertilizer Check Valve Cleaning and Repair...........6-23
Piston Pump Storage. . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-23
Preparation for Storage ..........................6-24
Power Pack Wiring Diagram (Blue Drive). . . . . . . . . . . . . 6-26
Electrical Control Console Connections - ISOBUS .....6-28
Cables and Harnesses ..........................6-30
Ethernet Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-31
Hydraulic Hose Life .............................6-56
Tire Pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-57
Inflation Specifications ...........................6-57
Finger Pickup Seed Meter Inspection/Adjustment. . . . . . 6-58
Cleaning Finger Pickup Seed Meter For Storage ......6-59
Brush-Type Seed Meter Maintenance ...............6-60
Cleaning Brush-Type Seed Meter For Storage ........6-61
Vacuum Manifold Maintenance ....................6-61
Mechanical Planter with PTO and BulK Fill Hydraulic System
Schematic ..................................6-62
Vacuum Planter with PTO Hydraulic System Schematic 6-63
Vacuum Planter with Bulk Fill and Dry Fertilizer Hydraulic
System Schematic. . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-64
Vacuum Planter with Bulk Fill and Dual Section PTO
Hydraulic System Schematic. . . . . . . . . . . . . . . . . . . . 6-65
Mechanical Planter Hydraulic System Schematic ......6-66
TROUBLESHOOTING
Bulk Fill .......................................7-1
Closing Wheel ..................................7-1
Piston Pump ...................................7-2
Row Marker Operation............................7-3
Vacuum Seed Meter .............................7-4
Solenoid Valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-6
PTO Pump Drive and Oil Cooler Option ..............7-6

Model 4805M0314-01
10/20 1-1
To The Owner
Kinze Manufacturing, Inc. thanks you for your patronage. We appreciate your confidence in Kinze farm machinery. Your
Kinze planter has been carefully designed to provide dependable operation in return for your investment.
This manual has been prepared to aid you in the operation and maintenance of the planter. It should be
considered a permanent part of the machine and remain with the machine when you sell it.
It is the responsibility of the user to read and understand the Operator Manual in regards to safety, operation,
lubrication and maintenance before operation of this equipment. It is the user’s responsibility to inspect and service
the machine routinely as directed in the Operator Manual. We have attempted to cover all areas of safety, operation,
lubrication and maintenance; however, there may be times when special care must be taken to fit your conditions.
Throughout this manual the symbol and the words DANGER, WARNING, and CAUTION are used to call
attention to safety information that if not followed, will or could result in death or injury. NOTICE and NOTE are used to
call your attention to important information. The definition of each of these terms follows:
NOTE: Special point of information or machine adjustment instructions.
Indicates an imminently hazardous
situation that, if not avoided, will
result in death or serious injury. This
signal word is to be limited to the most
extreme situations, typically for machine
components which, for functional
purposes, cannot be guarded.
DANGER
Indicates a potentially hazardous
situation that, if not avoided, could result
in death or serious injury, and includes
hazards that are exposed when guards
are removed. It may also be used to alert
against unsafe practices.
WARNING
Indicates a potentially hazardous
situation that, if not avoided, may result
in minor or moderate injury. It may also
be used to alert against unsafe practices.
CAUTION
Used to address safety practices not
related to personal injury.
NOTICE

M0314-01Model 4805
1-2 10/20
To The Owner
Improperly operating or working on
this equipment could result in death
or serious injury. Read and follow all
instructions in Operator's Manual before
operating or working on this equipment.
WARNING
Some photos in this manual may show
safety covers, shields, or lockup devices
removed for visual clarity. NEVER
OPERATE OR WORK ON machine
without all safety covers, shields, and
lockup device in place as required.
WARNING
NOTE: Some photos in this manual may have been taken of prototype machines. Production machines may
vary in appearance.
NOTE: Some photos and illustrations in this manual show optional attachments installed. Contact your Kinze
Dealer for purchase of optional attachments.

Model 4805M0314-01
10/20 1-3
Warranty
The Model 4805 Front Folding Planter is available with vacuum or mechanical meters, conventional hoppers or bulk fill
tanks, liquid fertilizer, and various other options. Contact your Kinze Dealer for additional details.
The Kinze Limited Warranty for your new machine is stated on the retail purchaser’s copy of the Warranty And Delivery
Receipt form. Additional copies of the Limited Warranty can be obtained through your Kinze Dealer.
Warranty, within the warranty period, is provided as part of Kinze’s support program for registered Kinze products
which have been operated and maintained as described in this manual. Evidence of equipment abuse or modification
beyond original factory specifications will void the warranty. Normal maintenance, service and repair is not covered by
Kinze warranty.
To register your Kinze product for warranty, a Warranty And Delivery Receipt form must be completed by the Kinze
Dealer and signed by the retail purchaser, with copies to the Dealer, and to the retail purchaser. Registration must be
completed and submitted to Kinze Manufacturing, Inc. within 5 business days of delivery of the Kinze product to the
retail purchaser. Kinze Manufacturing, Inc. reserves the right to refuse warranty on serial numbered products which
have not been properly registered.
If service or replacement of failed parts which are covered by the Limited Warranty are required, it is the user’s
responsibility to deliver the machine along with the retail purchaser’s copy of the Warranty And Delivery Receipt
to the Kinze Dealer for service. Kinze warranty does not include cost of travel time, mileage or hauling. Any prior
arrangement made between the Dealer and the retail purchaser in which the Dealer agrees to absorb all or part of this
expense should be considered a courtesy to the retail purchaser.
Kinze warranty does not include cost of travel time, mileage, hauling, or labor.
GENERAL INFORMATION
Model 4805 24 Row Bulk Fill Planter

M0314-01Model 4805
1-4 10/20
General Information
TOOLS REQUIRED
Hardware Size / Tool Required
/" = /"/" = /"
(nut for /" hardware uses /" tool)
/" = 1/" 1/" = 1/"
/" = /"/" = /"/" = 1/" 1/" = 2/"
/" = /"/" = /" 1" = 1/"
Information used in these instructions was current at time of printing. However, due to Kinze’s ongoing product
improvement, production changes may cause your machine to appear slightly different in detail. Kinze Manufacturing,
Inc. reserves the right to change specifications or design without notice and without incurring obligation to install the
same on machines previously manufactured. To obtain the most recent version of your publication, please contact your
Kinze dealer.
Right hand (R.H.) and left hand (L.H.), as used throughout this manual, are determined by facing direction machine
travels in use unless otherwise stated.
NOTE: Metric unit values in parentheses are approximate values and are to be used for reference only.

Model 4805M0314-01
10/20 1-5
Specifications
SPECIFICATIONS - GROUND CONTACT DRIVE
Specification Bulk Fill Bulk Fill with Dry Fer-
tilizer
Bulk Fill with Liquid
Fertilizer
Conventional
Number of Rows 24 24 24 24
Row Spacing 70 cm 70 cm 70 cm 70 cm
Weight Empty
(Vacuum Meter) 14670 kg 16294 kg 17270 kg 13046 kg
Transport Height 3,81 m 3,93 m 3,81 m 2,98 m
Planting Height 3,01 m 3,13 m 3,01 m 2,20 m
Planting Length 9,32 m* 9,32 m* 10,32 m* 9,32 m*
* add 0,65 m to planting length for optional granular chemical hoppers
Transport Length 13,50 m* 13,50 m* 14,50 m* 13,40 m*
* add 0,65 m to transport length for optional granular chemical hoppers
Planting Width 17,53 m 17,53 m 17,53 m 17,53 m
Transport Width 4,75 m* 4,75 m* 4,75 m* 4,75 m*
* add 0,65 m to transport width for optional granular chemical hoppers
Seed Capacity 3875 l
(2 x 1938 l Tanks)
1608 l
(24 x 67 l Tanks)
Hydraulic Lift System Four Master, Four Slave
Row Markers Independently controlled, three stage, disk blade depth bands
SPECIFICATIONS - ELECTRIC DRIVE
Specification Bulk Fill Conventional
Number of Rows 24 24
Row Spacing 70 cm 70 cm
Weight Empty
(Vacuum Meter) 14570 kg 12946 kg
Transport Height 3,81 m 2,98 m
Planting Height 3,01 m 2,20 m
Planting Length 9,32 m* 9,32 m*
* add 0,65 m to planting length for optional granular chemical hoppers
Transport Length 13,50 m* 13,40 m*
* add 0,65 m to transport length for optional granular chemical hoppers
Planting Width 17,53 m 17,53 m
Transport Width 4,75 m* 4,75 m*
* add 0,65 m to transport width for optional granular chemical hoppers
Seed Capacity 3875 l
(2 x 1938 l Tanks)
1608 l
(24 x 67 l Tanks)
Hydraulic Lift System Four Master, Four Slave
Row Markers Independently controlled, three stage, disk blade depth bands

M0314-01Model 4805
1-6 10/20
Tire Specifications
Specification Conventional Hoppers Bulk Fill
Transport Tire Size 11- 22.5
14 PR
11- 22.5
14 PR
Transport Tire Pressure 90 PSI
(6,20 bar)
90 PSI
(6,20 bar)
Wing Tires 11- 22.5
(4)
11- 22.5
(4)
Field Tire Pressure 90 PSI
(6,20 bar)
60 PSI
(4,14 bar)
Piston Pump Drive Tires
(Optional)
7.60" x 15"
(2)
Field Lift Four Master/Four Slave Hydraulics
Row Markers Independently controlled, three stage fold, disk blade depth bands.
Specifications
Tractor Hydraulic Requirements and Use of Power Beyond
The Power Beyond hydraulic system is used as a pressure/flow source for additional functions equipped with indepen-
dent flow control valves; for example, bulk fill fan. Possible scenarios include:
• Tractor Selective Control Valve (SCV) control is not needed.
• No other SCV outlet is available.
The major difference between SCV and Power Beyond is than an SCV has built-in pressure/flow compensation
whereas Power Beyond requires an external load signal.
Kinze suggests that if Power Beyond must be used, only the bulk fill circuit be connected using all three connections
(Pressure, Return, Load Sense). Consult your tractor manufacturer to ensure proper connection, hydraulic flow,
pressure and heat dissipation are met.
For more information on Power Beyond for remote hydraulic connections, refer to the tractor Operator's Manual.

Model 4805M0314-01
10/20 1-7
Specifications
Selective Control Valve (SCV) Identification
#1 SCV: Planter Lift (Red Labels)
#2 SCV: Markers/Fold (Blue Labels)
#3 SCV: Weight Distribution /Bulk Fill/Fertillizer (Yellow Labels)
#4 SCV: Power Pack (Black Labels)
#5 ACV: Vacuum (PTO) (Green Labels)
Hydraulic Requirements @ 2350 PSI 24 Row with PTO pump* 24 Row without PTO pump****
Configuration l/min** SCV*** l/min** SCV***
Electric Drive/Bulk Fill/Vacuum Meters 167 4 231 5
Electric Drive/Hoppers/Vacuum Meters 136 4 201 5
Ground Contact Drive/Bulk Fill/ Vacuum
Meters 136 3 201 5
Ground Contact Drive/Hoppers/Vacuum
Meters 106 3 170 5
Ground Contact Drive/Bulk Fill/
Mechanical Meters N/A 3 136 3
Ground Contract Drive/Hoppers/
Mechanical Meters N/A 3 121 3
*Dual-section PTO pump supplies oil flow to the Vacuum circuit in Bulk Fill configurations
**Add 15 l/min when using centrifugal fertilizer pump option
***Power Beyond use will reduce the number of SCV by 1. Not recommended- Kinze suggests that if Power Beyond must
be used, only the bulk fill circuit be connected using all three connections (Pressure, Return, Load Sense). Consult your
tractor manufacture for recommendations.
**** Minimum PTO pump requirement- 1000 RPM.
ADDITIONAL NOTES:
• All 4805 planters require an external case drain hose.
• All SCVs should be set to max flow at all times with the exception of the bulk fill circuit on mechanical 4805.
• Tractor RPM not recommended below 1750 RPM.
• Consult your tractor manufacturer to ensure proper connection, hydraulic flow, pressure and heat dissipation.
• Lift circuit must be left active for hydraulic weight distribution to function.

M0314-01Model 4805
1-8 10/20
General Safety Rules
1. Read and understand instructions provided in this manual
and warning labels. Review these instructions frequently!
2. This machine is designed and built with your safety
in mind. Do not make any alterations or changes to this
machine. Any alteration to design or construction may
create safety hazards.
3. A large portion of farm accidents happen from fatigue
or carelessness. Safe and careful operation of tractor and
planter will help prevent accidents.
4. Never allow planter to be operated by anyone unfamiliar
with operation of all functions of the unit. Operators must
read and thoroughly understand all instructions given in this
manual before operating or working on equipment.
5. Be aware of bystanders, particularly children! Always
look around to make sure it is safe to start tow vehicle
engine or move planter. This is particularly important with
higher noise levels and quiet cabs, as you may not hear
people shouting.
6. Make sure planter weight does not exceed towing
capacity of tractor, or bridge and road limits. This is critical
to maintain safe control and prevent death or injury, or
property and equipment damage.
7. Never ride or allow others to ride on planter.
8. Store planter in an area away from human activity. DO
NOT permit children to play on or around the stored unit.
9. Keep hands, feet, and clothing away from moving parts.
Do not wear loose-fitting clothing which may catch in
moving parts.
10. Always wear protective clothing, shoes, gloves, hearing,
and eye protection applicable for the situation.
11. Do not allow anyone to stand between tongue or hitch
and towing vehicle when backing up to planter.
13. Prevent electrocution, other injuries, or property and
equipment damage. Watch for obstructions such as wires,
tree limbs, etc. when operating machine. Be aware of
clearances during turns and when folding/unfolding planter.
14. Reinstall all guards removed for maintenance activities.
Never leave guards off during operation.
15. Use of aftermarket hydraulic, electric, or PTO drives
may create serious safety hazards to you and people
nearby. If you install such drives, follow all appropriate
safety standards and practices to protect you and others
near this planter from injury.
16. Follow all federal, state/provincial, and local regulations
when towing farm equipment on a public highway. Use
safety chain (not an elastic or nylon/plastic tow strap) to
retain connection between towing and towed machines in
the event of primary attaching system separation.
17. Make sure all safety/warning lights, SMV sign, and
reflective decals are in place and working properly before
transporting the machine on public roads.
18. Limit towing speed to 20 km/h. Tow only with a farm
tractor equipped with a minimum of a Cat 4 hitch. Allow for
unit length when making turns.
19. Reduce speed prior to turns to avoid the risk of
overturning. Always drive at a safe speed relative to local
conditions and ensure your speed is slow enough for a safe
emergency stop.
20. Chemical application is often an integral part of planting.
Follow label instructions for proper chemical mixing,
handling and container disposal methods.
21. Be familiar with safety procedures for immediate first aid
should you accidentally contact chemical substances.
22. Use the proper protective clothing and safety equipment
when handling chemicals.
23. Chemicals are supplied with Material Safety Data
Sheets (MSDS) that provide full information about the
chemical, its effects on exposure, and first aid needs in the
event of an emergency. Keep your MSDS file up-to-date and
available for first responders in case of emergency.
24. When servicing ground engaging components such as
opening disks and firming points, use special care to avoid
points and edges worn sharp during use.
25. Use professional help if you are unfamiliar with working
on hydraulic systems. Pressurized hydraulic fluid can
penetrate body tissue and result in death, serious infection,
or other injuries.
26. Disposing of waste improperly can threaten the
environment. To dispose of your equipment properly contact
your local environmental or recycling center.
Never pour waste onto the ground, down a drain, or into any
water source.
When disposing of waste such as oil, use leakproof
containers. Be sure to use containers that do not resemble
food or beverage which may mislead someone into
consuming them. Dispose of oil per your local, regional
requirements.
When disposing of any fertilizer chemicals used, contact the
supplier of the chemicals.
Model 4805 planter consists of 85% recyclable metals, 10%
recyclable plastic and rubber, and 5% waste.

Model 4805M0314-01
10/20 1-9
Safety Precautions
Following are some common hazard warnings associated with this equipment. Pay close attention to all safety,
operating, and maintenance information in this manual and decals applied to your equipment.
Contacting or coming close to power
lines or other high energy sources will
cause death or serious injury.
Keep away from power lines or high
energy sources at all times.
DANGER
Improperly operating or working on
this equipment could result in death
or serious injury. Read and follow all
instructions in Operator Manual before
operating or working on this equipment.
WARNING
Falling equipment can cause death or
serious injury. Install all lockup devices
or lower planter to ground before
working on equipment.
WARNING
Explosive separation of rim and tire
parts can cause death or serious injury.
Overinflation, rim and tire servicing,
improper use of rims and tires, or worn
or improperly maintained tires could
result in a tire explosion.
WARNING

M0314-01Model 4805
1-10 10/20
Safety signs and decals are placed on the machine to warn of hazards and provide important operating and maintenance
instructions. Information on these signs are for your personal safety and the safety of those around you. FOLLOW ALL
SAFETY INSTRUCTIONS!
• Keep signs clean so they can be easily seen. Wash with soap and water or cleaning solution as required.
• Replace safety signs if damaged, painted over, or missing.
• Check reflective decals and SMV sign periodically. Replace if they show any loss of reflective properties.
• When replacing decals, clean machine surface thoroughly with soap and water or cleaning solution to
remove all dirt and grease.
NOTE: Safety sign and decal locations are shown in the Parts Manual for this machine.
NOTE: Style and locations of SMV sign, reflective decals, and safety/warning lights conform to ANSI/ASABE
S279.14 JUL 2008 and ANSI/ASABE S276.6 JAN 2005.
SAFETY SIGNS AND DECALS
All safety/warning lights, reflective
decals, and SMV sign must be in place
and visible before transporting machine
on public roads or death, serious injury,
and damage to property and equipment
may result. Check federal, state/
provincial, and local regulations before
transporting equipment on public roads.
WARNING
Safety Precautions
