Kinze 4900 User manual

4900
This manual is applicable to: Model 4900 Forward Folding Planters for Production 2019 and on
Record the model number and serial number of your planter along with date purchased:
Model Number ___________________________________
Serial Number ___________________________________
Date Purchased__________________________________
Monitor Serial Number _______________________________________________
Measured Pulses Per Mile/Km (Radar Distance Sensor) ____________________
Measured Pulses Per Mile/Km (Magnetic Distance Sensor) _________________
SERIAL NUMBER
The serial number plate is located on the planter frame as shown below. The serial number provides important information
about your planter and is needed to obtain correct replacement parts. Always provide model number and serial number
to your Kinze Dealer when ordering parts or when contacting Kinze Manufacturing, Inc.
Kinze®and the Kinze®logo are registered trademarks of Kinze Manufacturing, Inc.
Vacuum Meter, Electric Drive, and Flip Axle have patents pending.
MODEL 4900
FRONT FOLD PLANTER
OPERATOR MANUAL
M0290-01 Rev. 8/19
Serial Number Plate Location

This page intentionally left blank.

TM
Model 4900M0290-01
Rev. 7/19
Predelivery/Delivery Checklist
TO THE DEALER
Predelivery service includes assembly, lubrication, adjustment and test. This service helps ensure planter is delivered
to retail customer/end user ready for field use.
PREDELIVERY CHECKLIST
Use the following checklist after planter is completely assembled. Check off each item as it is found satisfactory or after
proper adjustment is made.
Row units properly spaced and optional attachments correctly assembled.
Row marker assemblies installed and adjusted at each end of the planter.
Vacuum meter and bulk fill components properly installed (as applicable).
All grease fittings in place and lubricated.
All working parts move freely, bolts are tight, and cotter pins are spread.
Check all drive chains for proper tension and alignment.
Check for oil leaks and proper hydraulic operation.
Hydraulic hoses correctly routed to prevent damage.
Inflate tires to specified air pressure and torque wheel lug bolts and lug nuts as specified in the Operator Manual.
All safety decals correctly located and legible. Replace if damaged.
All reflective decals and SMV sign correctly located and visible when the planter is in transport position.
Safety/warning lights correctly installed and working properly.
Paint all parts scratched during shipment or assembly.
All safety lockup devices on the planter and correctly located.
Auxiliary safety chain properly installed and hardware torqued to specification.
Vacuum fan PTO-driven pump correctly attached to tractor. Oil reservoir filled to capacity and system inspected for
leaks (If applicable).
Planter has been thoroughly checked and to the best of my knowledge is ready for delivery to the customer.
(Signature of Set-Up Person/Dealer Name/Date)
OWNER REGISTER
Name Delivery Date
Street Address Model No. 4900 Serial No.
City, State/Province Dealer Name
ZIP/Postal Code Dealer No.

M0290-01Model 4900
Rev. 7/19
TM
Predelivery/Delivery Checklist
DELIVERY CHECKLIST
Use the following checklist at time planter is delivered as a reminder of very important information which should be
conveyed to retail customer/end user. Check off each item as it is fully explained.
Check proper operation of vacuum fan, bulk fill fan, and PTO-driven pump (If applicable) with tractor used with planter.
Life expectancy of this or any other machine is dependent on regular lubrication as directed in the Operator Manual.
All applicable safety precautions.
Along with retail customer/end user, check reflective decals and SMV sign are clearly visible with planter in transport
position and attached to tractor. Check safety/warning lights are in working condition. Tell retail customer/end user
to check federal, state/provincial, and local regulations before towing or transporting on a road or highway.
Give Operator Manual, Parts Manual, and all Instruction Sheets to retail customer/end user and explain all operating
adjustments.
Read warranty to retail customer/end user.
Complete Warranty and Delivery Report form.
To the best of my knowledge this machine has been delivered ready for field use and customer has been fully
informed as to proper care and operation.
(Signature of Delivery Person/Dealer Name/Date)
AFTER DELIVERY CHECKLIST
The following is a list of items we suggest to check during the first season of use of the equipment.
Check planter performance with retail customer/end user.
Check performance of vacuum meter or mechanical seed metering system with retail customer/end user.
Review importance of proper maintenance and adherence to all safety precautions with retail customer/end user.
Check for parts that may need to be adjusted or replaced.
Check all safety decals, reflective decals, and SMV sign are correctly located as shown in the Parts Manual and that
decals are legible. Replace if damaged or missing.
Check safety/warning lights are working properly.
(Signature of Follow-Up Person/Dealer Name/Date)
All registrations must be submitted online at “business.kinze.com” within 5 business days of delivery.
Retain a copy of this form for auditing purposes.
Tear Along Perforation

TM
Model 4900M0290-01
Rev. 8/19 i
Table of Contents
OVERVIEW
To The Owner ..................................1-1
Warranty ......................................1-3
General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
Tractor Hydraulic Requirements @ 2350 psi . . . . . . . . . . . 1-7
General Safety Rules. . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-10
Safety Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11
MACHINE OPERATION
Row Marker Safety Lockup ........................2-1
Transport Axle Cylinder Safety Lockup ...............2-2
Drawbar Hitch Lockup (Option) .....................2-3
2-Point Hitch Option. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
Initial Planter Preparation. . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
Tractor Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
Vacuum Meter Tractor Mounted PTO Pump and
Planter Mounted Hydraulics .....................2-7
Tractor Preparation and Hookup ....................2-8
True Depth Hydraulic System Overview .............2-11
True Depth Filter ...............................2-12
Transporting Planter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-13
Level Planter ..................................2-14
Hydraulic Seed Rate Drive. . . . . . . . . . . . . . . . . . . . . . . . 2-14
Hall Effect Sensor ..............................2-14
Jump Start Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-15
Field Operation ................................2-15
Transport to Field Sequence Using Control Box .......2-16
Transport to Field Sequence Using Blue Vantage . . . . . . 2-21
Field to Transport Sequence Using Control Box .......2-23
Field to Transport Sequence Using Blue Vantage ......2-27
Row Marker Operation Using Control Box . . . . . . . . . . . . 2-29
Row Marker Speed Adjustment . . . . . . . . . . . . . . . . . . . . 2-30
Row Marker Cable Adjustment ....................2-31
Row Marker Length And Disc Blade Adjustment.......2-32
Vacuum Meter System...........................2-33
Analog Vacuum or Pressure Gauge. . . . . . . . . . . . . . . . . 2-33
Bulk Fill System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-34
Bulk fill Entrainer Access . . . . . . . . . . . . . . . . . . . . . . . . . 2-35
Bulk Fill Tanks - Clean Out. . . . . . . . . . . . . . . . . . . . . . . . 2-36
Bulk Fill Scale Package Option ....................2-36
Monitor Seed Levels ............................2-37
Ag Leader InCommand 1200 Display ...............2-37
Kinze True Depth Display. . . . . . . . . . . . . . . . . . . . . . . . . 2-37
Kinze Blue Vantage .............................2-37
Point Row Clutches .............................2-38
Field Test .....................................2-39
Field Check Seed Population. . . . . . . . . . . . . . . . . . . . . . 2-39
Determining Pounds Per Acre . . . . . . . . . . . . . . . . . . . . . 2-40
Determining Bushels Per Acre. . . . . . . . . . . . . . . . . . . . . 2-40
Field Check Granular Chemical Application ..........2-41
Water Tank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-42
ROW UNIT OPERATION
Planting Depth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
“V” Closing Wheel Adjustment (Rubber or Cast Iron) ....3-1
Closing Wheel Shield
(Rubber or Cast Iron “V” Closing Wheels) . . . . . . . . . . . 3-1
Covering Discs/Single Press Wheel Adjustment ........3-2
Seed Hoppers ..................................3-3
Manual Run Button (Blue Drive) ....................3-3
Quick Adjustable Down Force Springs Option. . . . . . . . . . 3-4
Pneumatic Down Pressure ........................3-5
Field Operation .................................3-6
Vacuum Settings ...............................3-10
Brush-Type Seed Meter . . . . . . . . . . . . . . . . . . . . . . . . . . 3-12
Brush-Type Seed Meter 2.0 .......................3-13
Finger Pickup Seed Meter . . . . . . . . . . . . . . . . . . . . . . . . 3-14
Seed Meter Cleanout. . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-17
Row Unit Mounted No Till Coulter ..................3-20
GFX Hydraulic Row Cleaners .....................3-21
Coulter Mounted Residue Wheels . . . . . . . . . . . . . . . . . . 3-22
Granular Chemical Banding Options . . . . . . . . . . . . . . . . 3-22
Granular Chemical Hopper and Drive ...............3-23
FERTILIZER
System Overview................................4-1
Centrifugal Pump ................................4-1
Piston Pump ...................................4-4
Notched Single Disc Openers ......................4-5
Gauge Wheel Depth Adjustment ....................4-6
Down Force Settings .............................4-7
Knife Adjustment ................................4-8
Liquid Fertilizer Attachment .......................4-10
Check Valves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-11
Rear Trailer Hitch Option .........................4-11
RATE CHARTS
General Planting Rate Information. . . . . . . . . . . . . . . . . . . 5-1
Fertilizer Rates - Centrifugal Pump and
Piston Pump with Manifolds ....................5-26

M0290-01Model 4900
ii Rev. 8/19
TM
LUBRICATION AND MAINTENANCE
Lubrication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
Lubrication Symbols .............................6-1
Wheel Bearings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
Grease Fittings .................................6-2
Notched Single Disc Opener ......................6-8
PTO Shaft Coupling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-9
Liquid Fertilizer Piston Pump Crankcase Oil Level ......6-9
Liquid Fertilizer Centrifugal Pump ...................6-9
Mounting Bolts and Hardware .....................6-10
Tire Pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-12
Transport Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-12
Inflation Specifications ...........................6-13
Finger Pickup Seed Meter Inspection/Adjustment. . . . . . 6-14
Cleaning Finger Pickup Seed Meter For Storage ......6-15
Brush-Type Seed Meter Maintenance ...............6-16
Cleaning Brush-Type Seed Meter For Storage ........6-17
Vacuum Manifold Maintenance ....................6-17
Vacuum Seed Meter Maintenance. . . . . . . . . . . . . . . . . . 6-18
Seed Meter Cleanout. . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-18
Fertilizer Flow Sensor Cleanout. . . . . . . . . . . . . . . . . . . . 6-19
Vacuum Manifold Maintenance ....................6-20
Gauge Wheel Adjustment ........................6-21
Gauge Wheel Arm Pivot Spindle Replacement . . . . . . . . 6-21
Gauge Wheel Arm Bushing/Seal Replacement. . . . . . . . 6-22
15" Seed Opener Disc Blade/Bearing Assembly .......6-23
Seed Tube Guard/Inner Scraper ...................6-24
Row Unit Mounted No Till Coulter ..................6-25
Coulter or Row Unit Mounted Residue Wheels . . . . . . . . 6-25
GFX Hydraulic Row Cleaners .....................6-26
Tractor Mounted Pump Drive and Oil Cooler . . . . . . . . . . 6-27
Check Valve ...................................6-28
Flow Control Valves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-28
Pressure Relief Valves ...........................6-28
Pressure Compensated Flow Control Valves. . . . . . . . . . 6-28
Solenoid Valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-29
Pneumatic Down Pressure Air Compressor Tank ......6-29
Row Marker Bearing Lubrication or Replacement . . . . . . 6-30
Transport and Lift/Ground Drive
Wheel Bearing Repack or Replacement ...........6-31
Fertilizer Check Valve Cleaning and Repair...........6-32
Piston Pump Storage. . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-32
Centrifugal Pump Storage . . . . . . . . . . . . . . . . . . . . . . . . 6-32
Preparation for Storage ..........................6-33
Electrical Wiring Diagram - ISOBUS ................6-34
Electrical Control Console Connections .............6-36
ISO Extension Cable - 12 Row, 16 Row, and 24 Row . . . . . 6-38
Drawbar Hitch Cable - 12 Row, 16 Row, and 24 Row ...6-38
12V ASABE Light Harness - 12 Row and 16 Row. . . . . . 6-39
12V ASABE Light Harness - 24 Row. . . . . . . . . . . . . . . . 6-40
ISOBUS Implement Cable -
12 Row, 16 Row, and 24 Row ...................6-41
CAN Jumper Cable - 12 Row, 16 Row, and 24 Row . . . . . 6-41
Product Control Module Cable -
12 Row, 16 Row, and 24 Row ...................6-42
ISOBUS Implement Switch Extension Cable. . . . . . . . . . 6-43
Section Adapter Cable - 12 Row ...................6-44
Section Adapter Cable - 16 Row ...................6-44
Section Adapter Cable - 24 Row ...................6-45
12V Clutch Cable - 12 Row .......................6-46
12V Clutch Cable - 16 Row .......................6-47
12V Clutch Cable - 24 Row .......................6-48
Center Work Light Cable -
12 Row, 16 Row, and 24 Row ...................6-49
Work Light Relay Harness -
12 Row, 16 Row, and 24 Row ...................6-49
Wing Worklight Harness -
12 Row, 16 Row, and 24 Row ...................6-50
Tractor Power Harness -
12 Row, 16 Row, and 24 Row ...................6-51
Tractor Console Harness -
12 Row, 16 Row, and 24 Row ...................6-52
Tractor Power 10' Extension Harness -
12 Row, 16 Row, and 24 Row ...................6-53
Tractor Power 16' Extension Harness -
12 Row, 16 Row, and 24 Row ...................6-53
12V Power Harness, Draft Link -
12 Row, 16 Row, and 24 Row ...................6-54
12V Power Harness, Toolbar - 12 Row ..............6-55
12V Power Harness, Toolbar - 16 Row . . . . . . . . . . . . . . 6-56
12V Power Harness, Toolbar - 24 Row ..............6-57
24V Power Harness (Rows 1-6), 12 Row ............6-58
24V Power Harness (Rows 7-12), 12 Row ...........6-59
24V Power Harness (Rows 1-8), 16 Row ............6-60
24V Power Harness (Rows 9-16), 16 Row ...........6-61
24V Power Harness (Rows 1-12), 24 Row ...........6-62
24V Power Harness (Rows 13-24), 24 Row ..........6-64
Row Unit Power Extension Harness -
12 Row, 16 Row, and 24 Row ...................6-66
4K Row Unit Seed Meter Harness -
12 Row, 16 Row, and 24 Row ...................6-67
Bulk Fill Scale Harness -
12 Row, 16 Row, and 24 Row ...................6-68
Fold Harness, Left Wing -
12 Row, 16 Row, and 24 Row ...................6-69
Fold Harness, Right Wing -
12 Row, 16 Row, and 24 Row ...................6-70
IPN Harness, Left Wing -
12 Row, 16 Row, and 24 Row ...................6-71
Table of Contents

TM
Model 4900M0290-01
Rev. 8/19 iii
IPN Harness, Right Wing - 12 Row and 16 Row .......6-72
IPN Harness, Right Wing - 24 Row .................6-73
IPN Fold Harness - 12 Row ......................6-74
IPN Fold Harness - 16 Row ......................6-76
IPN FOld Harness, 24 Row .......................6-78
Bulk Fill Harness - 12 Row, 16 Row, and 24 Row ......6-80
IPP Wing Harness - 12 Row, 16 Row, and 24 Row . . . . . 6-81
Taillight Harness - 12 Row, 16 Row, and 24 Row ......6-82
Taillight Extension Harness -
12 Row, 16 Row, and 24 Row ...................6-83
PDP Control/Sensor Harness -
12 Row, 16 Row, and 24 Row ...................6-84
PDP Air Pump Harness -
12 Row, 16 Row, and 24 Row ...................6-85
PDP Power Extension Harness, 18' -
12 Row, 16 Row, and 24 Row ...................6-86
PDP Power Extension Harness, 30' -
12 Row, 16 Row, and 24 Row ...................6-87
Alternator Sensor Harness -
12 Row, 16 Row, and 24 Row. . . . . . . . . . . . . . . . . . . . . .6-88
24V Power Harness - 12 Row, 16 Row, and 24 Row . . . . . . 6-89
Battery Voltage Harness -
12 Row, 16 Row, and 24 Row ...................6-90
Ethernet Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-91
Ethernet CA CAT 5E (RJ45-Female M12 STR). . . . . . . . 6-92
Hydraulic Hose Life .............................6-93
Hydraulic Schematic (Planter Raising) ..............6-94
Hydraulic Schematic (Options) ....................6-96
Hydraulic Schematic (Hydraulic Drive Option). . . . . . . . 6-113
Hydraulic Valve Block Functions ..................6-114
TROUBLESHOOTING
Bulk Fill .......................................7-1
Closing Wheel ..................................7-1
Piston Pump ...................................7-2
Centrifugal Pump ................................7-2
GFX Hydraulic Row Cleaners ......................7-3
Row Marker Operation............................7-3
Vacuum Seed Meter .............................7-4
Solenoid Valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-6
PTO Pump Drive and Oil Cooler Option ..............7-6
Blue Drive .....................................7-6
Table of Contents

This page intentionally left blank.

TM
Model 4900M0290-01
Rev. 8/19 1-1
To The Owner
Kinze Manufacturing, Inc. thanks you for your patronage. We appreciate your confidence in Kinze farm machinery. Your
Kinze planter has been carefully designed to provide dependable operation in return for your investment.
This manual has been prepared to aid you in the operation and maintenance of the planter. It should be
considered a permanent part of the machine and remain with the machine when you sell it.
It is the responsibility of the user to read and understand the Operator Manual in regards to safety, operation,
lubrication and maintenance before operation of this equipment. It is the user’s responsibility to inspect and service
the machine routinely as directed in the Operator Manual. We have attempted to cover all areas of safety, operation,
lubrication and maintenance; however, there may be times when special care must be taken to fit your conditions.
Throughout this manual the symbol and the words DANGER, WARNING, and CAUTION are used to call
attention to safety information that if not followed, will or could result in death or injury. NOTICE and NOTE are used to
call your attention to important information. The definition of each of these terms follows:
NOTE: Special point of information or machine adjustment instructions.
Indicates an imminently hazardous
situation that, if not avoided, will
result in death or serious injury. This
signal word is to be limited to the most
extreme situations, typically for machine
components which, for functional
purposes, cannot be guarded.
DANGER
Indicates a potentially hazardous
situation that, if not avoided, could result
in death or serious injury, and includes
hazards that are exposed when guards
are removed. It may also be used to alert
against unsafe practices.
WARNING
Indicates a potentially hazardous
situation that, if not avoided, may result
in minor or moderate injury. It may also
be used to alert against unsafe practices.
CAUTION
Used to address safety practices not
related to personal injury.
NOTICE

M0290-01Model 4900
1-2 Rev. 8/19
TM
To The Owner
Improperly operating or working on
this equipment could result in death
or serious injury. Read and follow all
instructions in Operator Manual before
operating or working on this equipment.
WARNING
Some photos in this manual may show
safety covers, shields, or lockup devices
removed for visual clarity. NEVER
OPERATOR OR WORK ON machine
without all safety covers, shields, and
lockup device in place as required.
WARNING
NOTE: Some photos in this manual may have been taken of prototype machines. Production machines may
vary in appearance.
NOTE: Some photos and illustrations in this manual show optional attachments installed. Contact your Kinze
Dealer for purchase of optional attachments.

TM
Model 4900M0290-01
Rev. 8/19 1-3
Overview
WARRANTY
The Model 4900 Front Folding Planter is available in multiple sizes and row configurations with vacuum meter or
mechanical meters, conventional hoppers or bulk fill, liquid fertilizer, and various other options. Contact your Kinze Dealer
for additional details.
The Kinze Limited Warranty for your new machine is stated on the retail purchaser’s copy of the Warranty And Delivery
Receipt form. Additional copies of the Limited Warranty can be obtained through your Kinze Dealer.
Warranty, within the warranty period, is provided as part of Kinze’s support program for registered Kinze products
which have been operated and maintained as described in this manual. Evidence of equipment abuse or modification
beyond original factory specifications will void the warranty. Normal maintenance, service and repair is not covered by
Kinze warranty.
To register your Kinze product for warranty, a Warranty And Delivery Receipt form must be completed by the Kinze
Dealer and signed by the retail purchaser, with copies to the Dealer, and to the retail purchaser. Registration must be
completed and submitted to Kinze Manufacturing, Inc. within 5 business days of delivery of the Kinze product to the
retail purchaser. Kinze Manufacturing, Inc. reserves the right to refuse warranty on serial numbered products which
have not been properly registered.
If service or replacement of failed parts which are covered by the Limited Warranty are required, it is the user’s
responsibility to deliver the machine along with the retail purchaser’s copy of the Warranty And Delivery Receipt
to the Kinze Dealer for service. Kinze warranty does not include cost of travel time, mileage or hauling. Any prior
arrangement made between the Dealer and the retail purchaser in which the Dealer agrees to absorb all or part of this
expense should be considered a courtesy to the retail purchaser.
Kinze warranty does not include cost of travel time, mileage, hauling, or labor.
GENERAL INFORMATION
Model 4900 24 Row Bulk Fill Planter

M0290-01Model 4900
1-4 Rev. 8/19
TM
Overview
TOOLS REQUIRED
Hardware Size / Tool Required
/" = /"/" = /"
(nut for /" hardware uses /" tool)
/" = 1/" 1/" = 1/"
/" = /"/" = /"/" = 1/" 1/" = 2/"
/" = /"/" = /" 1" = 1/"
Information used in these instructions was current at time of printing. However, due to Kinze’s ongoing product
improvement, production changes may cause your machine to appear slightly different in detail. Kinze Manufacturing,
Inc. reserves the right to change specifications or design without notice and without incurring obligation to install the
same on machines previously manufactured. To obtain the most recent version of your publication, please contact your
Kinze dealer.
Right hand (R.H.) and left hand (L.H.), as used throughout this manual, are determined by facing direction machine
travels in use unless otherwise stated.

TM
Model 4900M0290-01
Rev. 8/19 1-5
Specifications
Specifications - Ground, Hydraulic Drive, or Electric Drive
Specification Conventional Hoppers Bulk Fill
Number of Rows 12 16 24 12 16 24
Row Spacing 30" 30" 30" 30" 30" 30"
Weight Empty
(Vacuum Meter)
14,300 -
16,370 lb
18,930 -
20,180 lb
28,000 -
30,875 lb
17,070 -
18,000 lb
18,930 -
20,180 lb
31,525 -
33,770 lb
Weight Empty
(Mechanical Meter)
17,070 -
18,000 lb
21,490 -
22,930 lb
31,525 -
33,720 lb
17,070 -
18,000 lb
21,490 -
22,930 lb
31,525 -
33,720 lb
Transport Height* 11'-0" 11'-1" 11'-4" 11'-7" 11'-9" 12'-0"
*12R and 16R includes row markers and fertilizer
*24R includes row markers, flip axle and fertilizer
Planting Height 8'-8" 8'-8" 8'-8" 8'-9" 8'-11" 9'-3"
Planting Length* 17'-6" 20'-0" 27'-1" 19'-4" 21'-11" 28'-10"
*add 2'-9" to total length for drawbar hitch
*add 1'-2" to total length for 2 pt hitch
Transport Length* 27'-7" 31'-9" 42'-2" 29'-5" 33'-5" 43'-8"
*add 2'-9" to total length for drawbar hitch
*add 1'-2" to total length for 2 pt hitch
Planting Width 33'-4" 43'-4" 62'-5" 33'-4" 43'-4" 62'-5"
Field Lift 12 Row - Four Master/Two Slave Hydraulics
16/24 Row - Four Master/Four Slave Hydraulics
Row Markers Independently controlled, three stage fold, disk blade depth bands.

M0290-01Model 4900
1-6 Rev. 8/19
TM
Specifications
Tractor Hydraulic Requirements and Use of Power Beyond
The Power Beyond hydraulic system is used as a pressure/flow source for additional functions equipped with indepen-
dent flow control valves; for example, bulk fill fan. Possible scenarios include:
• Tractor Selective Control Valve (SCV) control is not needed.
• No other SCV outlet is available.
The major difference between SCV and Power Beyond is than an SCV has built-in pressure/flow compensation
whereas Power Beyond requires an external load signal.
Kinze suggests that if Power Beyond must be used, only the bulk fill circuit be connected using all three connections
(Pressure, Return, Load Sense). Consult your tractor manufacturer to ensure proper connection, hydraulic flow,
pressure and heat dissipation are met.
For more information on Power Beyond for remote hydraulic connections, refer to the tractor Operator's Manual.
Specification Conventional Hoppers Bulk Fill
Transport Tire Size (4) 255-70R 22.5 11- 22.5
14 PR
11- 22.5
14 PR
255-70R 22.5 11- 22.5
14 PR
11- 22.5
14 PR
Transport Tire Pressure 100 psi 90 psi 90 psi 100 psi 90 psi 90 psi
Wing Tires 7.5" x 20"
(2)
7.5" x 20"
(4)
11- 22.5
(4)
7.5" x 20"
(2)
7.5" x 20"
(4)
11- 22.5
(4)
Field Tire Pressure 40 psi 40 psi 90 psi 40 psi 40 psi 60 psi
Piston Pump Drive Tires
(Optional)
(2) 7.60" x 15"
Field Lift 12 Row - Four Master/Two Slave Hydraulics
16/24 Row - Four Master/Four Slave Hydraulics
Row Markers Independently controlled, three stage fold, disk blade depth bands.
Tire Specifications

TM
Model 4900M0290-01
Rev. 8/19 1-7
Tractor Hydraulic Requirements @ 2350 psi
Configuration Rows Requirements Description
Base Machine with Ground Contact Drive / RU Hoppers /
Mechanical Meters 12R 3 SCV 28 gpm
#1 SCV: Planter Lift (red label)
#2 SCV: Markers/Fold (blue label)
#3 SCV: Weight Distribution (yellow label)
16R 3 SCV 30 gpm
24R 3 SCV 32 gpm
Base Machine with Ground Contact Drive / Bulk Fill /
Mechanical Meters
12R 3 SCV 34 gpm #1 SCV: Planter Lift (red label)
#2 SCV: Markers/Fold (blue label)
#3
SCV: Weight Distribution (yellow label)
16R 3 SCV 35 gpm
24R 3 SCV 36 gpm
Base Machine with Ground Contact Drive / Hoppers /
Mechanical Meters / True Depth 16R 3 SCV 34 gpm
#1 SCV: Planter Lift (red label)
#2 SCV: Markers/Fold (blue label)
#3 SCV: Weight Distribution (yellow label)
24R 3 SCV 38 gpm
Base Machine with Ground Contact Drive / Bulk Fill /
Mechanical Meters / True Depth 16R 3 SCV 39 gpm
#1 SCV: Planter Lift (red label)
#2 SCV: Markers/Fold (blue label)
#3 SCV: Weight Distribution (yellow label)
24R 3 SCV 42 gpm
Continued on next page.

M0290-01Model 4900
1-8 Rev. 8/19
TM
Tractor Hydraulic Requirements @ 2350 psi
Configuration Rows Requirements Description
Base Machine with Ground Contact Drive / RU Hoppers /
Vacuum Meters with PTO pump
PTO Hydraulic pump supplies oil flow for vacuum
hydraulic circuit.
 Add 4 GPM when using centrifugal fertilizer pump
option.
External case drain required.
12R
3 SCV 28 gpm
#1 SCV: Planter Lift (red label)
#2 SCV: Markers/Fold (blue label)
#3 SCV: Weight Distribution (yellow label)
16R
24R
Base Machine with Ground Contact Drive / RU Hoppers /
Vacuum Meters without PTO pump

Add 4 GPM when using centrifugal fertilizer pump
option.
External case drain required.
12R
5 SCV
43 gpm #1 SCV: Planter Lift (red label)
#2 SCV: Markers/Fold (blue label)
#3 SCV: Weight Distribution (yellow label)
#4 and #5 SCV: Vaccum (PTO) (green
label)
16R 44 gpm
24R 5 SCV 45 gpm
Base Machine with Hydraulic Drive / RU Hoppers /
Vacuum Meters with PTO pump
PTO Hydraulic pump supplies oil flow for vacuum
hydraulic circuit.
Add 4 GPM when using centrifugal fertilizer pump
option.
External case drain required.
12R
4 SCV 36 gpm
#1 SCV: Planter Lift (red label)
#2 SCV: Markers/Fold (blue label)
#3 SCV: Weight Distribution (yellow label)
#4 SCV: Power Pack/Hydraulic Drive
(black label)
16R
24R
Base Machine with Hydraulic Drive / RU Hoppers /
Vacuum Meters without PTO pump

Add 4 GPM when using centrifugal fertilizer pump
option.
External case drain required.
12R
6 SCV
51 gpm
#1 SCV: Planter Lift (red label)
#2 SCV: Markers/Fold (blue label)
#3 SCV: Weight Distribution (yellow label)
#4 SCV: Power Pack/Hydraulic Drive
(black label)
#5 and #6 SCV: Vaccum (PTO) (green
label)
16R 52 gpm
24R 53 gpm
Base Machine with Hydraulic Drive / RU Hoppers /
Vacuum Meters / True Depth (hydraulic down force) with
PTO pump
PTO Hydraulic pump supplies oil flow for vacuum
hydraulic circuit.

Add 4 GPM when using centrifugal fertilizer pump
option.
External case drain required.
16R 4 SCV 40 gpm
#1 SCV: Planter Lift (red label)
#2 SCV: Markers/Fold (blue label)
#3 SCV: Weight Distribution/True Depth
(Hydraulic Down Force) (yellow
label)
#4 SCV: Power Pack/Hydraulic Drive
(black label)
24R 4 SCV 40 gpm
Continued on next page.

TM
Model 4900M0290-01
Rev. 8/19 1-9
Tractor Hydraulic Requirements @ 2350 psi
Configuration Rows Requirements Description
Base Machine with Hydraulic Drive / RU Hoppers /
Vacuum Meters / True Depth without PTO pump
 Add 4 GPM when using centrifugal fertilizer pump
option.
External case drain required.
16R
6 SCV 56 gpm
#1 SCV: Planter Lift (red label)
#2 SCV: Markers/Fold (blue label)
#3 SCV: Weight Distribution/True Depth
(Hydraulic Down Force) (yellow label)
#4 SCV: Power Pack/Hydraulic Drive
(black label)
#5 and #6 SCV: Vaccum (PTO) (green
label)
24R
Base Machine with Ground Contact Drive / Bulk Fill /
Vacuum Meters with PTO pump
PTO Hydraulic pump supplies oil flow for vacuum
hydraulic circuit.

Add 4 GPM when using centrifugal fertilizer pump
option.
External case drain required.
12R
3 SCV
34 gpm #1 SCV: Planter Lift (red label)
#2 SCV: Markers/Fold (blue label)
#3 SCV: Weight Distribution/Bulk Fill
(yellow label)
16R 35 gpm
24R 36 gpm
Base Machine with Ground Contact Drive / Bulk Fill /
Vacuum Meters without PTO pump

Add 4 GPM when using centrifugal fertilizer pump
option.
External case drain required.
12R
6 SCV
49 gpm #1 SCV: Planter Lift (red label)
#2 SCV: Markers/Fold (blue label)
#3 SCV: Weight Distribution/Bulk Fill
(yellow label)
#4 SCV: Power Pack/Hydraulic Drive
(black label)
#5 and #6 SCV: Vaccum (PTO) (green label)
16R 51 gpm
24R 53 gpm
Base Machine with Blue Drive or Hydraulic Drive / Bulk Fill
/ Vacuum Meters with PTO pump
PTO Hydraulic pump supplies oil flow for vacuum
hydraulic circuit.

Add 4 GPM when using centrifugal fertilizer pump
option.
External case drain required.
12R
4 SCV
42 gpm #1 SCV: Planter Lift (red label)
#2 SCV: Markers/Fold (blue label)
#3 SCV: Weight Distribution/Bulk Fil
(yellow label)
#4 SCV: Power Pack/Hydraulic Drive
(black label)
16R 43 gpm
24R 44 gpm
Base Machine with Blue Drive or Hydraulic Drive / Bulk Fill
/ Vacuum Meters without PTO pump

Add 4 GPM when using centrifugal fertilizer pump
option.
External case drain required.
12R
6 SCV
57 gpm #1 SCV: Planter Lift (red label)
#2 SCV: Markers/Fold (blue label)
#3 SCV: Weight Distribution/Bulk Fill
(yellow label)
#4 SCV: Power Pack/Hydraulic Drive
(black label)
#5 and #6 SCV: Vaccum (PTO) (green label)
16R 59 gpm
24R 61 gpm
Base Machine with Blue Drive or Hydraulic / Bulk Fill /
Vacuum Meters / True Depth with PTO pump
PTO Hydraulic pump supplies oil flow for vacuum
hydraulic circuit.

Add 4 GPM when using centrifugal fertilizer pump
option.
External case drain required.
16R
4 SCV
47 gpm
#1 SCV: Planter Lift (red label)
#2 SCV: Markers/Fold (blue label)
#3 SCV: Weight Distribution/Bulk Fill
(yellow label)
#4 SCV: Power Pack/Hydraulic Drive/
True Depth (Hydraulic Down Force)
(black label)
24R 52 gpm
Notes:
 All SCVs should be set to max flow at all times wih the exception of the bulk fill circuit on mechanical 4900
Tractor RPMs not recommended below 1750 RPMs
 Consult your tractor manufacturer to ensure proper connection, hydraulic flow, pressure and heat
dissipation
Power beyond will reduce the number of SCVs by 1. Not recommended - Kinze suggests that if power
beyond must be used, only the bulk fill circuit be connected using all three connections (Pressure, Return,
Load Sens). Consult your tractor manufacturer for recommendations.
PTO pump is required for all machines equipped with Bulk Fill, Vacuum & Blue Drive

M0290-01Model 4900
1-10 Rev. 8/19
TM
General Safety Rules
1. Read and understand instructions provided in this manual
and warning labels. Review these instructions frequently!
2. This machine is designed and built with your safety
in mind. Do not make any alterations or changes to this
machine. Any alteration to design or construction may
create safety hazards.
3. A large portion of farm accidents happen from fatigue
or carelessness. Safe and careful operation of tractor and
planter will help prevent accidents.
4. Never allow planter to be operated by anyone unfamiliar
with operation of all functions of the unit. Operators must
read and thoroughly understand all instructions given in this
manual before operating or working on equipment.
5. Be aware of bystanders, particularly children! Always
look around to make sure it is safe to start tow vehicle
engine or move planter. This is particularly important with
higher noise levels and quiet cabs, as you may not hear
people shouting.
6. Make sure planter weight does not exceed towing
capacity of tractor, or bridge and road limits. This is critical
to maintain safe control and prevent death or injury, or
property and equipment damage.
7. Never ride or allow others to ride on planter.
8. Store planter in an area away from human activity. DO
NOT permit children to play on or around the stored unit.
9. Keep hands, feet, and clothing away from moving parts.
Do not wear loose-fitting clothing which may catch in
moving parts.
10. Always wear protective clothing, shoes, gloves, hearing,
and eye protection applicable for the situation.
11. Do not allow anyone to stand between tongue or hitch
and towing vehicle when backing up to planter.
13. Prevent electrocution, other injuries, or property and
equipment damage. Watch for obstructions such as wires,
tree limbs, etc. when operating machine. Be aware of
clearances during turns and when folding/unfolding planter.
14. Reinstall all guards removed for maintenance activities.
Never leave guards off during operation.
15. Use of aftermarket hydraulic, electric, or PTO drives
may create serious safety hazards to you and people
nearby. If you install such drives, follow all appropriate
safety standards and practices to protect you and others
near this planter from injury.
16. Follow all federal, state/provincial, and local regulations
when towing farm equipment on a public highway. Use
safety chain (not an elastic or nylon/plastic tow strap) to
retain connection between towing and towed machines in
the event of primary attaching system separation.
17. Make sure all safety/warning lights, SMV sign, and
reflective decals are in place and working properly before
transporting the machine on public roads.
18. Limit towing speed to 24 km/h. Tow only with farm tractor
of a minimum 90 HP. Allow for unit length when making turns.
19. Reduce speed prior to turns to avoid the risk of
overturning. Always drive at a safe speed relative to local
conditions and ensure your speed is slow enough for a safe
emergency stop.
20. Chemical application is often an integral part of planting.
Follow label instructions for proper chemical mixing,
handling and container disposal methods.
21. Be familiar with safety procedures for immediate first aid
should you accidentally contact chemical substances.
22. Use the proper protective clothing and safety equipment
when handling chemicals.
23. Chemicals are supplied with Material Safety Data
Sheets (MSDS) that provide full information about the
chemical, its effects on exposure, and first aid needs in the
event of an emergency. Keep your MSDS file up-to-date and
available for first responders in case of emergency.
24. When servicing ground engaging components such as
opening disks and firming points, use special care to avoid
points and edges worn sharp during use.
25. Use professional help if you are unfamiliar with working
on hydraulic systems. Pressurized hydraulic fluid can
penetrate body tissue and result in death, serious infection,
or other injuries.
26. Disposing of waste improperly can threaten the
enviroment. To dispose of your equipment properly contact
your local environmental or recyling center.
Never pour waste onto the ground, down a drain, or into any
water source.
When disposing of waste such as oil, use leakproof
containers. Be sure to use containers that do not resemble
food or beverage which may mislead someone into
consuming them. Dispose of oil per your local, regional
requirements.
When disposing of any fertilizer chemicals used, contact the
supplier of the chemicals.
Model 4900 planter consists of 85% recyclable metals, 10%
recyclable plastic and rubber, and 5% waste.

TM
Model 4900M0290-01
Rev. 8/19 1-11
Safety Precautions
Following are some common hazard warnings associated with this equipment. Pay close attention to all safety,
operating, and maintenance information in this manual and decals applied to your equipment.
Contacting or coming close to power
lines or other high energy sources will
cause death or serious injury.
Keep away from power lines or high
energy sources at all times.
DANGER
Improperly operating or working on
this equipment could result in death
or serious injury. Read and follow all
instructions in Operator Manual before
operating or working on this equipment.
WARNING
Falling equipment can cause death or
serious injury. Install all lockup devices
or lower planter to ground before
working on equipment.
WARNING
Explosive separation of rim and tire
parts can cause death or serious injury.
Overinflation, rim and tire servicing,
improper use of rims and tires, or worn
or improperly maintained tires could
result in a tire explosion.
WARNING

M0290-01Model 4900
1-12 Rev. 8/19
TM
Safety Precautions
Safety signs and decals are placed on the machine to warn of hazards and provide important operating and maintenance
instructions. Information on these signs are for your personal safety and the safety of those around you. FOLLOW ALL
SAFETY INSTRUCTIONS!
• Keep signs clean so they can be easily seen. Wash with soap and water or cleaning solution as required.
• Replace safety signs if damaged, painted over, or missing.
• Check reflective decals and SMV sign periodically. Replace if they show any loss of of reflective properties.
• When replacing decals, clean machine surface thoroughly with soap and water or cleaning solution to
remove all dirt and grease.
NOTE: Safety sign and decal locations are shown in the Parts Manual for this machine.
NOTE: Style and locations of SMV sign, reflective decals, and safety/warning lights conform to ANSI/ASABE
S279.14 JUL 2008 and ANSI/ASABE S276.6 JAN 2005.
SAFETY SIGNS AND DECALS
All safety/warning lights, reflective
decals, and SMV sign must be in place
and visible before transporting machine
on public roads or death, serious injury,
and damage to property and equipment
may result. Check federal, state/
provincial, and local regulations before
transporting equipment on public roads.
WARNING
