Kioti DS4110 User manual

FORWARD
Make sure to read this manual carefully and keep it handy for future reference.
When leasing or transferring this tractor, deliver this manual together with the tractor.
The specications in this manual are subject to change without notice.
< NOTE >
Congratulations, and welcome to the fabulous world of DS4110(HS) / DS4510(HS) ownership, where seri-
ous work is made fun again!
This versatile tractor is a culmination of the entire tractor and diesel knowledge gained by the Daedong In-
dustrial Co.,LTD over the years since 1947 and has been designed with the finest materials and under rigid
quality control standards set forth by the KIOTI Engineering Department.
Knowledge of tractor operation is essential for many years of dependable service and reliability. To help new
owner's familiarize themselves with the KIOTI DS4110(HS) / DS4510(HS), it is the policy of KIOTI tractor
to provide an owner's manual which includes helpful information about tractor safety, operation and mainte-
nance. If the information you seek is not found in this manual, your KIOTI tractor dealer will be happy to help
you.
M50-EU-00.indd 1 2009-09-17 오후 1:15:06

M50-EU-00.indd 2 2009-09-14 오후 2:22:41

SAFETY PRECAUTIONS ................................
PRECAUTIONS BEFORE OPERATION .........
SPECIFICATIONS ............................................
DESCRIPTION OF OPERATING SYSTEM .....
OPERATION ....................................................
3-POINT HITCH IMPLEMENT AND LOADER OPERATION ..
MAINTENANCE ...............................................
STORAGE AND DISPOSAL ............................
TROUBLESHOOTING .....................................
INDEX ...............................................................
SECTION
1
2
3
4
5
6
7
8
9
10
TABLE OF CONTENTS
M50-EU-00.indd 3 2009-09-17 오후 1:15:06

TABLE OF CONTENTS
SAFETY PRECAUTIONS ............................. 1-1
PRECAUTIONS BEFORE OPERATION .......... 1-2
GENERAL PRECAUTIONS ................................... 1-2
PRECAUTIONS DURINg OPERATION ........... 1-5
WHEN STARTING THE ENGINE........................... 1-5
WHEN DRIVING THE TRACTOR .......................... 1-8
WHEN PARKING THE TRACTOR ......................... 1-9
WHEN OPERATING THE P.T.O............................. 1-9
WHEN USING THE 3-POINT HITCH................... 1-10
SAFETY PRECAUTIONS DURINg SERvICINg ... 1-10
SAFETYPRECAUTIONS WhEN USINg ThE LOADER .. 1-13
SAFETY DECAL mAINTENANCE.................. 1-16
DECAL MOUNTING LOCATION.......................... 1-16
DECALS ............................................................... 1-17
CAUTIONS FOR DECAL MAINTENANCE .......... 1-19
PRECAUTIONS BEFORE OPERATION ...... 2-1
vEhICLE IDENTIFICATION NUmBER............. 2-2
TRACTOR SERIAL NUMBER................................ 2-2
ENGINE SERIAL NUMBER ................................... 2-2
TRANSMISSION NUMBER ................................... 2-2
ESSENTIAL REPLACEmENT PART................ 2-4
OILS AND FLUIDS ................................................. 2-4
FILTERS................................................................. 2-4
BELTS AND RUBBER PARTS ............................... 2-5
OTHER COMPONENTS ........................................ 2-5
SPECIFICATIONS......................................... 3-1
gENERAL SPECIFICATIONS .......................... 3-2
EXTERNAL DIMENSIONS..................................... 3-2
GENERAL SPECIFICATIONS................................ 3-3
TRAvELINg SPEED ......................................... 3-6
AGRICULTURAL.................................................... 3-6
ImPLEmENT LImITATIONS .............................. 3-7
M50-EU-00.indd 4 2009-09-17 오후 1:15:07

TABLE OF CONTENTS
PTO INDICATOR.................................................. 4-13
OPERATINg ThE CONTROLS ..................... 4-14
MAIN SHIFT LEVER ............................................ 4-16
RANGE GEAR SHIFT LEVER ............................. 4-16
SHUTTLE SHIFT LEVER..................................... 4-16
HYDRAULIC SHUTTLE SHIFT LEVER ............... 4-17
CLUTCH PEDAL .................................................. 4-17
BRAKE PEDAL..................................................... 4-18
PARKING BRAKE LEVER ................................ 4-18
FRONT WHEEL DRIVE LEVER........................... 4-19
FOOT THROTTLE ............................................... 4-20
HAND THROTTLE LEVER ................................. 4-20
DIFFERENTIAL LOCK PEDAL ............................ 4-21
SEAT ADJUSTMENT ........................................... 4-22
POSITION CONTROL LEVER ............................. 4-23
JOYSTICK LEVER (INCLUED IN THE
FRONT END LOADER PACKAGE) ......................... 4-24
LIFTING ARM (LOWER LINK)
SPEED CONTROL KNOB.................................... 4-24
REMOTE HYDRAULIC LEVER ........................... 4-24
7-PIN POWER OUTPUT SOCKET ...................... 4-25
DESCRIPTION OF OPERATINg SYSTEm .. 4-1
ExTERIOR vIEW .............................................. 4-2
SWITCh............................................................. 4-3
MOUNTING LOCATION......................................... 4-3
KEY SWITCH ......................................................... 4-4
COMBINATION SWITCH ....................................... 4-5
HAZARD LAMP SWITCH....................................... 4-6
PTO SWITCH ........................................................ 4-7
INSTRUmENT PANEL ...................................... 4-8
TACHOMETER/HOURMETER ............................. 4-9
FUEL GAUGE ........................................................ 4-9
ENGINE COOLANT TEMPERATURE GAUGE ......... 4-10
ENGINE OIL PRESSURE WARNING LAMP ..........4-11
BATTERY CHARGING LAMP ...............................4-11
HEAD LIGHT HIGH BEAM LAMP........................ 4-12
TURN SIGNAL LAMP........................................... 4-12
GLOW PLUG INDICATOR ................................... 4-12
PARKING BRAKE WARNING LAMP ................... 4-13
M50-EU-00.indd 5 2009-09-17 오후 1:15:07

7-PIN SOCkET................................................ 4-25
TIRES, WhEELS AND BALLAST .................. 4-26
GENERAL TIRE INFORMATION ......................... 4-26
INFLATION PRESSURE ..................................... 4-27
TREAD ................................................................. 4-28
WHEEL TORQUE AND DIRECTION ................... 4-30
ADDITIONAL WEIGHT (OPTION) ....................... 4-32
OPERATION ................................................. 5-1
PRE-OPERATION ChECk ............................... 5-2
OPERATINg ThE ENgINE............................... 5-3
STARTING THE ENGINE....................................... 5-3
CHECKING WARNING LAMPS ............................. 5-6
STOPPING THE ENGINE ...................................... 5-7
WARMING UP........................................................ 5-8
JUMP STARTING................................................... 5-9
OPERATINg ThE TRACTOR......................... 5-10
HOW TO DRIVE................................................... 5-10
HOW TO FOLD THE ROPS................................. 5-13
HOW TO RAISE THE ROPS TO UPRIGHT POSI-
TION..................................................................... 5-14
PARKING ............................................................. 5-15
TURNING ............................................................. 5-17
DRIVING ON SLOPE ........................................... 5-17
THE CAUTIONS WHEN COMING IN AND OUT OF
WORK FIELD ........................................................ 5-18
PRECAUTIONS WHILE DRIVING ON THE ROAD .....
5-18
LOADING INTO AND UNLOADING OUT OF THE
TRUCK ................................................................. 5-19
PRECAUTIONS WHEN USING POWER STEERING .
5-20
3-POINT HITCH CONTROL ................................ 5-22
REMOTE HYDRAULICS...................................... 5-24
3-POINT hITCh ImPLEmENT AND
LOADER OPERATION ................................. 6-1
REmOvAL AND INSTALLATION OF 3-POINT
hITCh ImPLEmENT (WITh PTO ShAFT)........ 6-2
TABLE OF CONTENTS
M50-EU-00.indd 6 2009-09-17 오후 1:15:07

OPERATION TIP FOR 3-POINT
hITCh ELEmENTS ........................................... 6-4
ADJUSTMENT OF LIFT ROD ............................... 6-4
ADJUSTMENT OF TOP LINK ............................... 6-5
ADJUSTMENT OF STABILIZER ............................ 6-5
DISMOUNTING THE IMPLEMENT........................ 6-5
DRAW BAR AND TRAILER.................................... 6-6
INSTALLING PTO SHAFT...................................... 6-7
hANDLINg LOADER ....................................... 6-8
DRIVING ON SLOPE ............................................. 6-9
JOYSTICK LEVER (COME WITH LOADER PACKAGE) ... 6-10
HYDRAULIC BLOCK ........................................... 6-13
mAINTENANCE............................................ 7-1
mAINTENANCE ChECk LIST.......................... 7-3
DAILY CHECK ITEM .............................................. 7-3
MAINTENANCE SCHEDULE CHART ................... 7-4
LUBRICANTS ................................................... 7-7
mAINTENANCE CODE..................................... 7-8
HOW TO DISCONNECT THE HOOD (A) ............. 7-8
OPENING SIDE AND FRONT COVER (B) ........... 7-8
CHECKING AND ADDING FUEL(C) ...................... 7-9
CHECKING TRANSMISSION FLUID LEVEL (D) ....... 7-10
CHECKING ENGINE OIL LEVEL (E) ....................7-11
CHECKING COOLANT LEVEL (F) ...................... 7-12
CLEANING GRILL, RADIATOR SCREEN (G) ..... 7-13
CHECKING BRAKE AND CLUTCH PEDALS (H) ........ 7-13
CHECKING GAUGES, METER
AND EASY CHECKER (I) .................................... 7-14
CHECKING HEAD LIGHT, HAZARD LIGHT ETC. (J) ........ 7-14
CHECKING SEAT BELT AND ROPS (K) ............. 7-14
CHANGING ENGINE OIL AND
REPLACING FILTER (L) ...................................... 7-14
REPLACING TRANSMISSION FLUID
AND FILTER (M) .................................................. 7-16
CHANGING FRONT AXLE CASE OIL (N) ........... 7-18
ADJUSTING BRAKE PEDAL(O).......................... 7-18
GREASE FITTING LOCATIONS (P) .................... 7-20
CHECKING WHEEL BOLT/NUT TORQUE (Q) ....... 7-21
ADJUSTING CLUTCH PEDAL (R)....................... 7-21
TABLE OF CONTENTS
M50-EU-00.indd 7 2009-09-17 오후 1:15:07

TABLE OF CONTENTS
REPLACING FUEL FILTER (S)............................ 7-22
REPLACING AIR CLEANER PRIMARY
ELEMENT (T)....................................................... 7-22
CHECKING FUEL LINES (U)............................... 7-23
ADJUSTING FAN BELT TENSION (V)................. 7-24
BATTERY (W) ...................................................... 7-25
CHECKING INTAKE AIR LINE (X) ....................... 7-26
ADJUSTING TOE-IN (Y) ...................................... 7-27
CHECKING RADIATOR HOSE AND CLAMP (Z) ........ 7-27
POWER STEERING LINE (AA) ........................... 7-28
ADJUSTING FRONT AXLE PIVOT (AD).............. 7-28
ADJUSTING ENGINE VALVE CLEARANCE (AE) ......... 7-28
REPLACING AIR CLEANER FILTER (AF) .......... 7-29
FLUSH COOLING SYSTEM AND
CHANGING COOLANT (AJ) ................................ 7-29
ANTI-FREEZE...................................................... 7-31
BLEEDING FUEL SYSTEM (AK) ......................... 7-31
DRAINING WATER FROM CLUTCH
HOUSING (AL)..................................................... 7-33
REPLACING FUSE (AN)...................................... 7-33
SLOW BLOW FUSE (AP) .................................... 7-34
REPLACING BULB (AQ)...................................... 7-35
STORAgE AND DISPOSAL......................... 8-1
TRACTOR STORAgE ...................................... 8-2
DAILY STORAGE................................................... 8-2
LONG-TERM STORAGE ....................................... 8-2
USINg TRACTOR AFTER STORAgE ............. 8-4
USAgE AND DISPOSAL ................................ 8-4
TROUBLEShOOTINg.................................. 9-1
ENgINE TROUBLEShOOTINg ....................... 9-2
TRACTOR TROUBLEShOOTINg.................... 9-4
INDEx.......................................................... 10-2
M50-EU-00.indd 8 2009-09-17 오후 1:15:07

This manual includes information titled as WARNING, CAUTION, IMPORTANT
and NOTE. These titles indicate the following:
SAFETY AND VEHICLE DAMAGE WARNING
NOTE
This indicates that interesting or helpful information is being
provided.
CAUTION
This indicates that a condition may result in damage to your
vehicle or its equipment if the caution is not heeded. Follow
the advice provided with the caution.
WARNING
This indicates that a condition may result in harm, serious in-
jury or death to you or other persons if the warning is not
heeded. Follow the advice provided with the warning.
!
This mark indicates emphasis on notable characteristics or
working procedures, and information about technology for
easier operation.
IMPORTANT
M50-EU-00.indd 9 2009-09-17 오후 1:15:08

Various universal symbols have been used on the instruments and controls of your KIOTI tractor. Below is a
list of the universal symbols and their meanings.
UNIVERSAL SYMBOLS
Fuel-Level
Engine Coolant-Temperature
Parking Brake
Battery Charging Condition
Engine Oil-Pressure
Turn Signal
Power Take-Off Clutch Con-
trol-On Position
Power Take-Off Clutch Con-
trol-Off Position
Differential Lock
Position Control-Lowered Posi-
tion
Hazard Warning Lights
Headlight-Low Beam
Headlight-High Beam
Four-Wheel Drive-ON
Fast
Slow
Creep
High Range
Middle Range
h
L
Low Range
Coolant
Preheat
QT lamp
H:High speed travel light
M:Middle speed travel light
L:Low speed travel light
Neutral Position
Single brake light
m
N
m
L
N
M50-EU-00.indd 10 2009-09-17 오후 1:15:14

1
PRECAUTIONS BEFORE OPERATION ........................... 1-2
GENERAL PRECAUTIONS............................................................... 1-2
PRECAUTIONS DURING OPERATION ............................ 1-5
WHEN STARTING THE ENGINE ...................................................... 1-5
WHEN DRIVING THE TRACTOR ..................................................... 1-8
WHEN PARKING THE TRACTOR .................................................... 1-9
WHEN OPERATING THE P.T.O. ....................................................... 1-9
WHEN USING THE 3-POINT HITCH .............................................. 1-10
SAFETY PRECAUTIONS DURING SERVICING ............ 1-10
SAFETY PRECAUTIONS WHEN USING THE LOADER ........ 1-13
SAFETY DECAL MAINTENANCE .................................. 1-16
DECAL MOUNTING LOCATION ..................................................... 1-16
DECALS .......................................................................................... 1-17
CAUTIONS FOR DECAL MAINTENANCE ..................................... 1-19
SAFETY PRECAUTIONS
1
M50-EU-01.indd 1 2009-09-17 오후 1:16:24

1
-
3
SAFETY PRECAUTIONS
1
-
2DS4110(HS) / DS4510(HS)
1
-
3
SAFETY PRECAUTIONS
1
-
2DS4110(HS) / DS4510(HS)
PRECAUTIONS BEFORE OPERATION
GENERAL PRECAUTIONS
A careful operator is the best oper-
ator. Most accidents can be avoid-
ed by observing certain precautions.
To help prevent accidents, use these
safety precautions, and pay attention
to the job at hand. If you can prevent
an accident, your time will have been
well spent.
5. Keep safety decals clean of dirt
and debris.
6. Watch where you are going at all
times so that you are able to avoid
obstacles that can cause injury or
damage to your tractor.
7. When starting the tractor make
sure your path is clear of people to
avoid accidents caused by sudden
movements.
8. Before making reverse move-
ments with your tractor, you should
always check to see that the path
is clear.
1. It is recommended that you read
and understand this entire manual
before operation of your new trac-
tor. Failure to do so could result in
accidents or injury.
2. Only persons who are properly
trained should be allowed to oper-
ate the tractor.
3. Read and follow all warning labels
and decals afxed to the tractor.
4. Replace any missing or damaged
decals as soon as it is practical.
A list of decals is shown on page
1-16~18
T66O101a T66O102a
M50-EU-01.indd 2 2009-09-17 오후 1:16:25

1
-
3
SAFETY PRECAUTIONS
1
-
2DS4110(HS) / DS4510(HS)
1
-
3
SAFETY PRECAUTIONS
1
-
2DS4110(HS) / DS4510(HS)
1
16. All persons using the tractor
should have knowledge of its
proper operation and should read
this manual carefully.
17. Never get off the tractor without
setting the parking brake, lower-
ing the implement to the ground
and shutting of the tractor.
18. No alterations should be made to
your KIOTI tractor.
12. Never start the engine while
standing on the ground.
13. Only the operator should ride on
the tractor unless a passenger
seat is installed. Keep bystand-
ers away from the tractor while in
operation.
14. When getting on and off the trac-
tor, handholds and step plates
should always be used. This will
help to prevent accidental slips
trips and falls.
15. Be sure to scrape off mud or soil
from your shoes before mounting
the tractor.
T66O103a T66O104a T66O105a
9. Never operate this tractor or
any other agricultural equipment
while under the inuence of alco-
hol, drugs or while fatigued.
10. While working in cooperation with
other tractors always communi-
cate your intentions.
11. Do not start your tractor by short-
ing across the starter.
M50-EU-01.indd 3 2009-09-17 오후 1:16:27

1
-
5
SAFETY PRECAUTIONS
1
-
4DS4110(HS) / DS4510(HS)
1
-
5
SAFETY PRECAUTIONS
1
-
4DS4110(HS) / DS4510(HS)
A ROPS and CAB should never be
modied by welding, grinding or cut-
ting, as this can weaken the ROPS
structure. If any components of the
ROPS unit is damaged, it must be
replaced.
If the ROPS unit is removed or loos-
ened for any reason, the parts should
be fitted back to their original posi-
tions and all bolts should be properly
torqued.
21. Extra caution should be taken
when driving tractors with nar-
row tread widths. For added sta-
bility you should adjust your rear
wheel tread width, see page 4-29
19. Before starting your tractor you
should depress the clutch and
make sure that all shift levers are
in the neutral position and park-
ing brake is applied.
20. For your safety ROPS with a seat
belt is recommended for all appli-
cations.
(1) Tread
T66O106a T66O107a
Always use seat belt when the
tractor is equipped with a ROPS
and CAB. Never use the seat
belt when tractor is not equipped
with a ROPS.
(ROPS: Roll-Over Protective
Structures)
NOTE
M50-EU-01.indd 4 2009-09-17 오후 1:16:28

1
-
5
SAFETY PRECAUTIONS
1
-
4DS4110(HS) / DS4510(HS)
1
-
5
SAFETY PRECAUTIONS
1
-
4DS4110(HS) / DS4510(HS)
1
1. Avoid accidental contact with gear
shift levers while the engine is run-
ning. Unexpected tractor move-
ments can result in bodily injury.
2. Do not park your tractor on a
steep incline, and remember to
shut off the engine and P.T.O be-
fore dismounting the tractor.
PRECAUTIONS DURING OPERATION
WHEN STARTING THE ENGINE
3. Do not operate your tractor in
an enclosed building without the
proper ventilation. Tractor exhaust
containing carbon monoxide can
cause serious injury or death.
T66O109a
T66O108a T66O110a
M50-EU-01.indd 5 2009-09-17 오후 1:16:29

1
-
7
SAFETY PRECAUTIONS
1
-
6DS4110(HS) / DS4510(HS)
1
-
7
SAFETY PRECAUTIONS
1
-
6DS4110(HS) / DS4510(HS)
7. Always use the proper ballast
weight on your tractor when using
rear implements.
8. Watch front and rear to avoid ob-
stacles at row ends, near trees
and around other obstructions.
4. Make sure that all pressure lines
are tight before starting the tractor.
5. Pull only from the drawbar. Nev-
er hitch anything to the axle hous-
ing or any other point except the
drawbar. Pulling from any other lo-
cation only increase the risk of se-
rious personal injury or death.
6. If the front of the tractor tends to
rise up when heavy implements
are attached to the three point
hitch, weights should be installed
on the tractor. Do not operate the
tractor with a light front end.
(1) Drawbar
H61O101a T66O112a T66O113a
M50-EU-01.indd 6 2009-09-17 오후 1:16:30

1
-
7
SAFETY PRECAUTIONS
1
-
6DS4110(HS) / DS4510(HS)
1
-
7
SAFETY PRECAUTIONS
1
-
6DS4110(HS) / DS4510(HS)
1
9. Do not leave equipment in the
raised position when the vehicle
is stopped or unattended.
10. When using implements or at-
tachments with your tractor you
should rst read their respective
owner's manual. You should al-
ways keep their safe operation
procedures in mind.
11. You should be familiar with your
equipment and its limitations.
12. If abused or used incorrectly your
tractor can become dangerous to
you and bystanders. Overload-
ing your tractor or using unsafe
equipment can also be danger-
ous and should be avoided. Re-
fer to the "Specifications of Im-
plement Limitation", which out-
lines the maximum load for safe
tractor operation.
15. When working in groups, always
let the others know what you are
going to do before you do it.
16. Never "freewheel". Disengaging
the clutch or shifting into neutral
while descending a slope as this
could lead to a loss of control.
17. Do not operate near ditches,
holes, embankments, or other
terrain features which may col-
lapse under the tractor's weight.
The risk of tractor upset is even
higher when the ground is loose
or wet.
13. Driving forward out of a ditch
or steep inclines can cause the
tractor to tip over backwards. To
avoid this you should back out of
these positions. Four wheel drive
tractors can give you a false
sense of security in the tractors
ability to maneuver out of these
positions, so extra caution should
be taken.
14. Never try to get on or off a mov-
ing tractor.
T66O114a T66O115a
M50-EU-01.indd 7 2009-09-17 오후 1:16:31

1
-
9
SAFETY PRECAUTIONS
1
-
8DS4110(HS) / DS4510(HS)
1
-
9
SAFETY PRECAUTIONS
1
-
8DS4110(HS) / DS4510(HS)
2. Always slow the tractor before
turning. Turning at high speed may
tip the tractor over or cause a loss
of control.
3. Observe all local trafc and safety
regulations.
4. Turn the headlights on. Dim them
when meeting another vehicle.
5. Drive at speeds that allow you to
maintain control at all times.
6. Do not apply the differential lock
while traveling at road speeds. As
the tractor may run out of control.
7. Avoid sudden movements of the
steering wheel as this can cause
a loss of control of the tractor. This
risk is especially great when trav-
eling at road speeds.
8. Do not operate an implement while
the tractor is on the road. Lock the
three point hitch in the raised posi-
tion.
9. When towing other equipment,
use a safety chain and place an
SMV emblem on it as well.
1. Lock the brake pedals togeth-
er when traveling at road speeds.
Brake both wheels simultaneously
when making an emergency stop.
Uneven braking at road speeds
could cause the tractor to tip over.
WHEN DRIVING THE TRACTOR
(1) Brake Pedal Lock (2) Brake Pedal (L)
(3) Brake Pedal (R)
T66O118a
H61O102a
M50-EU-01.indd 8 2009-09-17 오후 1:16:31

1
-
9
SAFETY PRECAUTIONS
1
-
8DS4110(HS) / DS4510(HS)
1
-
9
SAFETY PRECAUTIONS
1
-
8DS4110(HS) / DS4510(HS)
1
1. Disengage the P.T.O, lower all
implements, place all control le-
vers in the neutral position, set
the parking brake, stop the engine
and remove the key.
WHEN PARKING THE TRACTOR
T66O120a
(1) P.T.O Shaft Cover
(2) P.T.O Shaft Cap
WHEN OPERATING THE P.T.O.
1. Make sure the tractor is complete-
ly stopped, gears are in neutral
and all moving components have
completely stopped before con-
necting, disconnecting, adjusting,
cleaning or servicing any P.T.O
driven equipment.
2. Keep the P.T.O shaft cover in
place at all times. Replace the
P.T.O shaft cap when the shaft is
not in use.
3. Before installing or using P.T.O
driven equipment, read the manu-
facturer's manual and review the
H61O103a T66O122a
safety labels attached to the
equipment.
4. When operating stationary P.T.O
driven equipment, always ap-
ply the tractor parking brake and
place chocks behind and in front
of the rear wheels. Stay clear of all
rotating parts.
5. Do not attach a PTO driven im-
plement if the implements safe-
ty shields are damaged or not in
place. Rotating shafts are an en-
tanglement hazard.
M50-EU-01.indd 9 2009-09-17 오후 1:16:33

1
-
11
SAFETY PRECAUTIONS
1
-
10 DS4110(HS) / DS4510(HS)
1
-
11
SAFETY PRECAUTIONS
1
-
10 DS4110(HS) / DS4510(HS)
(1) 3-point hitch lowering speed knob
(A) “FAST” (B) “SLOW”
WHEN USING THE 3-POINT
HITCH
1. Use the 3-point hitch only with
equipment designed for 3-point
hitch usage.
2. When using a 3-point hitch mount-
ed implement, be sure to install
the proper counterbalance weight
on the front of the tractor.
3. When transporting on the road,
set the implement lowering control
in the "LOCK" position to hold the
implement in the raised position.
2. Allow the tractor time to cool off
before servicing any part that may
have become hot while the tractor
was running.
3. You must always stop the engine
before refueling the tractor. Avoid
overlling the tractor or spilling the
fuel.
4. Before jump starting a dead bat-
tery, read and follow all of the in-
structions.
5. It is recommended to keep a rst
aid kit and re extinguisher handy
at all times.
In order to service your tractor you
must park it on a flat level surface,
set the parking brake, place the gear
shift lever in neutral and stop the en-
gine.
1. Do n o t sm o ke w hi l e wo rk i ng
around the battery or when refu-
eling your tractor. Keep all sparks
and ames away from the battery
and fuel tank. The battery pres-
ents an explosive hazard because
it gives off hydrogen and oxygen
… especially when recharging.
SAFETY PRECAUTIONS
DURING SERVICING
T66O124a T66O125a
H61O104a
M50-EU-01.indd 10 2009-09-17 오후 1:16:34
